Peugeot 607 Dag 2002 Owner's Manual

YOUR 607 IN DETAIL119
Sun visor with illuminated
courtesy mirror
With the ignition on, the mirror is
automatically illuminated when the
flap is opened.
COURTESY LIGHTS
1 Front courtesy light
2 Front map reading lights
With the key in the accesories position (1st notch) or with the ignition on,
operate the relevant switch.
3 Rear courtesy light
4 Rear map reading lights With the key in the accesories position (1st notch) or with the ignition on,
operate the relevant switch.
The front and rear courtesy lights come on when the ignition key is removed, on
unlocking the vehicle or on opening one of the doors.
They gradually go off after the ignition has been switched on or the vehicle is
locked. Pressing switch 1turns on the front and rear courtesy lights.
Note: The courtesy lights and sill lights can be neutralised by pressin g switch 1
for more than three seconds. The map reading lights are not af fected by this and
may be switched on. To reactivate the lights, press the switch. Sill illumination
The sill light is at the bottom of each
door trim.
The light comes on automatically
when the door is opened and goes
off automatically when the door is
closed.

YOUR 607 IN DETAIL
120
4 Control buttons
A Switching 'SPORT' suspension on / off
B Central locking / Unlocking
C Opening / Closing / Partial opening of sunroof
D Unrolling / storing of rear screen electric blind
5 Front armrest
6 Rear ashtray Press the cover to open the ashtray.
To empty the ashtray, open it then release it by pulling i t
towards you.
To refit the ashtray, clip it back into its housing.
7 Rear lighter Push in and wait for a few moments until it springs out auto
matically.
8 Heated rear seats control
CENTRE CONSOLE
1 Storage compartment
2 Front lighter Press and wait for a few moments until it springs out automat
ically.
Ventilated glove box
To open the glove box, lift the han
dle.
The glove box is lit up when the
cover is opened.
The glove box has a vent E
that
can be closed, which produces the
same conditioned air as the vents
in the passenger compartment.
It also has a pen holder F
and
three sockets Gfor connecting
video equipment.
3 Front ashtray
Press the cover to open the ashtray.
To release the ashtray for emptying, open it then push the co ver
downwards. To refit the ashtray, clip it back into its housin g.

Rear sunblind
The blind, fitted to the rear parcel
shelf, is intended to protect occu
pants from the glare of the sun and
the lights of cars behind.
Sunblind operation:
With the engine running:  Briefly press button Don the cen
tre console to open it out.
 Briefly press button Dagain to
store it away.
Warning: Do not place anything on
the blind, to avoid it being damaged. Rear armrest
This provides access to the ski flap
from the passenger compartment.
It has two cup holders. Storage compartments
There are two storage compartments
located behind the side trim of the
boot.
The left side storage compartment is
fitted with a CD storage bracket for
eight single CDs and one double CD.
To access a storage compartment:
Push the handle downwards and
fold down the panel.
YOUR 607 IN DETAIL 121
Rear shelf compartment
This is provided for the storage of a
first aid kit.
The catch on the lid is designed to
withstand a weight of 9 lbs (4kg) on
impact.Luggage net
Six stowing rings allow the net to be
placed in different positions.

YOUR 607 IN DETAIL
122
The
four speed automatic gearbox offers a choice between the comfort of inte
gral automatic operation , enhanced by a sportand a snow programme, or the
pleasure of manual gear changing .
Gear selection gate  Move the lever in the gate to select a function.
Once the function is selected, the corresponding indicator lig ht appears on the
instrument panel screen.
S: sport programme.
: snow programme.
P ark: to immobilise the vehicle and to start the
engine , with the handbrake on or off.
R everse: to reverse(select this function with the vehi
cle stationary, engine at idle).
N eutral: to start the engine and to park, with the hand
brake on.
Note: if position Nis inadvertently engaged while dri
ving, allow the engine to return to idle before engagin g
function Dto accelerate.
D rive: for driving in automatic mode.
M anual: for drivingin manual mode.
PORSCHE TIPTRONIC system' AUTOMATIC GEARBOX Moving Off
With the engine running, to move off
from position
P:
 it is essential to press the brake
pedal to exit position P,
 select function R, D or M, then
gradually release the pressure on
the brake pedal; the vehicle
moves off immediately.
You can also move off from position N:
 release the handbrake, with your
foot on the brake,
 select function R, D or M, then
gradually release the pressure on
the brake pedal; the vehicle
moves off immediately.
WARNING
When the engine is at idle, brakes not
applied, if function R, D or Mis select
ed, the vehicle moves even without
the accelerator being pressed. For
this reason, do not leave children
unsupervised inside the vehicle,
with the engine running.
When maintenance operations need
to be carried out with the engine run
ning, apply the handbrake and select
position P.

Notes
It is only possible to change from one gear
to another if the vehicle speed and engine
speed permit. If they do not, the vehicle will
operate temporarily in automatic mode.
When the vehicle is stationary or moving
very slowly, the gearbox automatically
selects gear M1.
Programmes S(sport) and
(snow) do not
operate in manual mode.
Operating abnormality
Any operating abnormality is
shown by illumination of this warn
ing light, accompanied by an audi
ble signal and the message 'Auto
matic gearbox faulty' on the
multifunction display.
In this situation the gearbox operates in
downgrade mode (locked in 3rd gear). You
may feel a substantial knock when selecting
reverse from Pto Rand from Nto R(this will
not cause any damage to the gearbox).
Do not exceed 60 mph (100 km/h).
Contact a PEUGEOT dealer as soon as
possible.
If the battery is flat and the
lever is in position P, it will
be impossible to change
to another position.
YOUR 607 IN DETAIL 123
Automatic operation
Automatic changing of the
four gears:
select function Din the gate.
The gearbox always selects the most
suitable gear according to the follow
ing parameters:
– the style of driving,
– the road profile,
– the vehicle load.
The gearbox is then operating in auto
adaptive mode, without any action on
your part.
WARNING
Never select function N when the vehi
cle is moving.
Never select functions Por Runless
the vehicle is stationary.
Never change betwen functions to
optimise braking on a slippery surface.
Notes
For immediate maximum acceleration
without touching the gear lever, press
the accelerator pedal down as far as it
will go (kickdown). The gearbox will
automatically change down or main
tain the gear selected until maximum
engine speed is reached.
When the brake is applied, the gear
box will automatically change down in
order to provide efficient engine brak
ing.
If you take your foot off the accelerator
suddenly, the gearbox will not change
to a higher gear for reasons of safety. Sport and snow programmes
In addition to the autoadaptive pro
gramme, there are two special pro
grammes.
The programme is displayed on the
instrument panel screen.
Sport programme
Press button
Sonce the vehicle has
been started and function Dselected.
The gearbox automatically favours
sporty driving and more dynamic
acceleration.
Snow programme
This programme improves starting
and drive when traction is poor.
Press button once the vehicle has
been started and function Dselected.
The gearbox adapts to driving on slip
pery roads.
Note: you can return to the autoadap
tive programme at any time.
Press button Sor again to switch
off the programme you are in.
Manual operation
Manual changing of the four gears:
select function Min the gate,
push the lever to the + sign to
change to a higher gear,
pull the lever to the sign to change
to a lower gear.
You can change from position D(dri
ving in automatic mode) to position M
(driving in manual mode) at any time.

EMERGENCY BRAKING
ASSISTANCE SYSTEM
In an emergency, this system
enables the optimum braking pres
sure to be reached more quickly,
thus reducing the stopping distance.
It is triggered according to the speed
of activation of the brake pedal. The
effect of this is a reduction in the
resistance of the pedal and an
increase in braking efficiency.
YOUR 607 IN DETAIL
124
ABS ANTILOCK BRAKING
SYSTEM
The ABS system with Electronic
Brake Force Distribution (EBFD)
increases the stability and manoevra
bility of your vehicle, particularly on
poor or slippery road surfaces.
Note:
when changing wheels (tyres
and rims), make sure that these are
approved.
The antilock braking system comes
into operation automatically when
there is a risk of wheel lock.
When this warning light
comes on, accompanied by
an audible signal and the
message 'Braking fault' , it
indicates that there is a mal
function of the electronic brake force
distribution, which can cause a loss
of control of the vehicle when
braking.
Stop immediately.
Contact a Peugeot dealer.
Normal operation of the ABS may
make itself felt by slight vibrations
of the brake pedal.
In emergency braking, press
very firmly without releasing
the pressure.
MANUAL GEARBOX
Reverse
To change to reverse gear, lift the
ring under the gear lever knob and
push the gear lever to the left then to
the front.
Reverse gear can only be
engaged when the vehicle is sta
tionary with the engine idling.

YOUR 607 IN DETAIL
126
ELECTRONICALLY
CONTROLLED SUSPENSION
T
he suspension adapts automatically
and instantly to different driving styles
and road characteristics, improving the
comfort of the occupants and the vehi
cle's road holding capabilities.
The suspension favours smooth shock
absorption, ensuring a comfortable ride,
but as soon as conditions demand a
change (sporty driving, tight bends,
avoidance action, etc.) it automatically
selects firmer shock absorption, guaran
teeing optimum road holding.
Selecting the SPORT position
 Press switch 1, the SPORT indi
cator light will come on,
accompanied by an audible
signal.
In this position, the suspen
sion is maintained in the
SPORT position.
To return to automatic
operation
 Press switch 1again. The indicator
light will go out and the
AUTO indicator light comes
on, accompanied by an audi
ble signal.
Operating check
This is confirmed by the switch light
and the indicator lights. The switch
light comes on for approximately three
seconds every time the ignition is
switched on.
If the switch light flashes or if the indi
cator light comes on, accompanied by
an audible signal and the message
' Hydraulic suspension pressure
insufficient' , contact your PEUGEOT
dealer.
Handbrake
Locking
When parking, pull the handbrake to
immobilise your vehicle.
Warning: when parking on a slope,
direct your wheels towards the pave
ment and pull on the handbrake.
Unlocking
Pull the handle and press the button
to release the handbrake.

Operating check
When a malfunction of the sys
tems occurs, the switch light
flashes and the warning light
comes on, accompanied by an
audible signal and the mes
sage 'ESP/ASR system faulty' on the
multifunction display.
Contact a PEUGEOTdealer to have the
system checked.
YOUR 607 IN DETAIL
125
The ESP system offers
exceptional safety in normal
driving, but this should not
encourage the driver to take
extra risks or drive at high
speed.
The correct functioning of this sys
tem depends on observation of the
manufacturer's recommendations
regarding wheels (tyres and rims),
the braking components and the
electronic components, as well as
the PEUGEOT assembly and opera
tion procedures.
After an impact, have the system
checked by a PEUGEOT dealer.
Disarming the ASR/ESP
systems
In exceptional conditions (starting a
vehicle which is bogged down, stuck
in snow, on soft ground...), it may be
advisable to disarm the ASR system,
so that the wheels can move freely
and regain grip.
Press the 'ESP OFF'
switch, located under the
steering wheel to the left.
The switch lights up and the
warning light comes on,
accompanied by an audible
signal and the message
'ASR/ESP system deacti
vated' on the multi–function
display : the ASR and ESP systems
no longer have any effect on the
engine operation.
These are triggered again :
 automatically if the ignition is
switched off,
 manually by pressing the switch
again.DYNAMIC STABILITY
CONTROL (ESP) AND
TRACTION CONTROL (ASR)
These systems are linked and com
plementary to the ABS system.
In the event of a significant variation
between the trajectory of the vehicle
and the path required by the driver,
the ESP system acts automatically
on the engine and on the brake of
one or more wheels, to put the vehi
cle back on course. The traction con
trol (ASR) system optimises drive, in
order to avoid the wheels slipping, by
acting on the brakes of the drive
wheels and on the engine. It also
enables the directional stability of the
vehicle to be improved during accel
eration.
Operation of the ESP
and ASR systems
When one of the two sys
tems is in operation, this
indicator light flashes.

YOUR 607 IN DETAIL
127
CRUISE CONTROL
Cruise control enables the vehicle to
maintain a steady speed programmed
by the driver, regardless of the road
characteristics and without the driver
having to touch the accelerator or
brake pedals.
In order for it to be memorised, the
vehicle speed must be greater than
25 mph (40 km/h) or 40 mph (60
km/h), (according to engine).Operation
 Place the ring of switch 1in the ON
position. The indicator light
will come on accompanied
by an audible signal.
A speed can be memorised.
 Place the ring of switch 1 in the
OFF position to cancel.
Memorising a speed
As soon as you reach the chosen
speed, push stalk 1upwards or
downwards. This memorises the
speed, which will be maintained
automatically.
Note : it is possible to accelerate
momentarily without disarming the
cruise control.
Cancelling the memorised
speed
If you wish to cancel the memorised
speed :
 Pull stalk 1towards you or press
the brake or clutch pedal.
Recalling the memorised
speed
After cancellation, flick stalk
1 upwards or downwards. Your vehicle
will return to the last memorised speed.
Changing a memorised speed
To memorise a speed higher than
the previous one:
 keep stalk 1pressed upwards;
 release it when you have reached
the required speed.
To memorise a speed lower than the
previous one :  keep stalk 1pressed downwards;
 release it when you have reached
the required speed.
Disarming the cruise control  place the ring in the OFFposition
or switch off the ignition.
Do not use cruise control
on slippery roads or in
heavy traffic.

If there is an operating
fault, the audible signal will
be a short bleep followed
by a long bleep when
changing to reverse gear.
YOUR 607 IN DETAIL
128
REAR PARKING ASSISTANCE
This system consists of four proximity
sensors, located in the rear bumper,
and a special speaker fitted under the
rear parcel shelf.
It detects any obstacle (person, vehicle,
tree, gate, pavement etc.) behind the
vehicle.
Note: this function will be disarmed
when the vehicle is towing a trailer
(vehicle fitted with towing attachment
recommended by PEUGEOT). In win
ter, ensure that the sensors are not
covered with frost or snow.
Activation
The system is activated as soon as
reverse gear is engaged; an audible
bleep shows that it is active.
An audible signal indicates the prox
imity of the obstacle. This signal
becomes more rapid as the vehicle
approaches the obstacle.
When the distance between the rear
of the vehicle and the obstacle is
less than approximately twentyfive
centimetres, the audible signal
becomes continuous. Deactivation
 Change to neutral, the system
becomes inactive.
Detection zone
