![RENAULT KANGOO 1997 KC / 1.G Body Sealing Workshop Manual Sealing and Soundproofing
BODY SEALING
77 11 194 289JULY 1997Edition Anglaise
The repair methods given by the manufacturer in this document are based on the
technical specifications current when it wa RENAULT KANGOO 1997 KC / 1.G Body Sealing Workshop Manual Sealing and Soundproofing
BODY SEALING
77 11 194 289JULY 1997Edition Anglaise
The repair methods given by the manufacturer in this document are based on the
technical specifications current when it wa](/img/7/1729/w960_1729-0.png)
Sealing and Soundproofing
BODY SEALING
77 11 194 289JULY 1997Edition Anglaise
The repair methods given by the manufacturer in this document are based on the
technical specifications current when it was prepared.
The methods may be modified as a result of changes by the manufacturer in the
production of the various component units and accessories from which his vehicles
are constructed".All copyrights reserved by Renault.
Copying or translating, in part or in full, of this document or use of the service part
reference numbering system is forbidden without the prior written authority of
RENAULT.
CRenault 1997
Page 2 of 6
![RENAULT KANGOO 1997 KC / 1.G Body Sealing Workshop Manual EXPLODED VIEW
PRB6000 RENAULT KANGOO 1997 KC / 1.G Body Sealing Workshop Manual EXPLODED VIEW
PRB6000](/img/7/1729/w960_1729-1.png)
EXPLODED VIEW
PRB6000
Page 3 of 6
![RENAULT KANGOO 1997 KC / 1.G Body Sealing Workshop Manual Pages
Contents
BODY SEALING
Seals for side opening elements
Luggage compartment seal
Interior finishing seal for sliding
door and side opening64
Sealing and
Soundproofing
64-1
64-2
64-3 RENAULT KANGOO 1997 KC / 1.G Body Sealing Workshop Manual Pages
Contents
BODY SEALING
Seals for side opening elements
Luggage compartment seal
Interior finishing seal for sliding
door and side opening64
Sealing and
Soundproofing
64-1
64-2
64-3](/img/7/1729/w960_1729-2.png)
Pages
Contents
BODY SEALING
Seals for side opening elements
Luggage compartment seal
Interior finishing seal for sliding
door and side opening64
Sealing and
Soundproofing
64-1
64-2
64-3
Page 4 of 6
![RENAULT KANGOO 1997 KC / 1.G Body Sealing Workshop Manual BODY SEALING
Seals for side opening elements
64
PRB6402
For reasons of standardisation, the Parts
Department only supplies front door seals.
Cut a length of 189 mm ± 15 from the seal to
adapt it to t RENAULT KANGOO 1997 KC / 1.G Body Sealing Workshop Manual BODY SEALING
Seals for side opening elements
64
PRB6402
For reasons of standardisation, the Parts
Department only supplies front door seals.
Cut a length of 189 mm ± 15 from the seal to
adapt it to t](/img/7/1729/w960_1729-3.png)
BODY SEALING
Seals for side opening elements
64
PRB6402
For reasons of standardisation, the Parts
Department only supplies front door seals.
Cut a length of 189 mm ± 15 from the seal to
adapt it to the length required for a sliding door.
64-1
Page 5 of 6
![RENAULT KANGOO 1997 KC / 1.G Body Sealing Workshop Manual BODY SEALING
Luggage compartment seal
64
PRB6403
to adapt the seal to suit the body version with
swing-out doors or a tailgate.940 mm+20
- 0 For reasons of standardisation, the Parts
Department only RENAULT KANGOO 1997 KC / 1.G Body Sealing Workshop Manual BODY SEALING
Luggage compartment seal
64
PRB6403
to adapt the seal to suit the body version with
swing-out doors or a tailgate.940 mm+20
- 0 For reasons of standardisation, the Parts
Department only](/img/7/1729/w960_1729-4.png)
BODY SEALING
Luggage compartment seal
64
PRB6403
to adapt the seal to suit the body version with
swing-out doors or a tailgate.940 mm+20
- 0 For reasons of standardisation, the Parts
Department only supplies luggage compartment
seals for hinged rear roof flaps.
Cut off the following length:
64-2
Page 6 of 6
![RENAULT KANGOO 1997 KC / 1.G Body Sealing Workshop Manual BODY SEALING
Interior finishing seal for sliding door and side opening64
For reasons of standardisation, the Parts Department only
supplies seals for the left-hand side opening.
The following lengths RENAULT KANGOO 1997 KC / 1.G Body Sealing Workshop Manual BODY SEALING
Interior finishing seal for sliding door and side opening64
For reasons of standardisation, the Parts Department only
supplies seals for the left-hand side opening.
The following lengths](/img/7/1729/w960_1729-5.png)
BODY SEALING
Interior finishing seal for sliding door and side opening64
For reasons of standardisation, the Parts Department only
supplies seals for the left-hand side opening.
The following lengths will need to be cut from the seals:
-1401 mm ± 2.5 to adapt the seal for a sliding door,
-1590 mm ± 2.5 to adapt the seal for a right-hand side
opening.
PRB6401
64-3
