RENAULT KANGOO 1997 KC / 1.G Electrical Equipment Workshop Manual 81-1
81-2
Contents
BATTERIE PROJECTEURS
Battery
Special   notes
Headlights
Lens units and indicators
Remote adjustment
80-1
80-3
80-4
ECLAIRAGE ARRIERE
Courtesy  light
Fuses
PagePage
Electrical
Equi

Page 9 of 83

RENAULT KANGOO 1997 KC / 1.G Electrical Equipment Workshop Manual REAR AND INTERIOR LIGHTS
Fuses
81
FUSE BOX (passenger compartment)
This unit is located in the passenger compartment on the driver’s side.
Allocation of fuses (depending on equipment level).
Symbol

Page 12 of 83

RENAULT KANGOO 1997 KC / 1.G Electrical Equipment Workshop Manual IMMOBILISER
Coded key immobiliser system
GENERAL
The immobiliser is controlled by a key recognition
system  (known as coded key immobiliser system).
An independently operating coded chip without a
bat

Page 13 of 83

RENAULT KANGOO 1997 KC / 1.G Electrical Equipment Workshop Manual IMMOBILISER
Coded key immobiliser system
DESCRIPTION
With this system the engine immobiliser is activa-
ted 10 seconds after switching off the ignition
(shown by the flashing of the red engine immobi-

Page 14 of 83

RENAULT KANGOO 1997 KC / 1.G Electrical Equipment Workshop Manual IMMOBILISER
Coded key immobiliser system
82
• An antenna ring  (C) around the ignition
switch, with an electronic unit which transmits
the key code to the decoder unit (D).
NOTE : This antenna ring

Page 15 of 83

RENAULT KANGOO 1997 KC / 1.G Electrical Equipment Workshop Manual IMMOBILISER
Coded key immobiliser system
82
Removal - Refitting
The dashboard must be partially removed to re-
move the decoder unit.
Remove:
- the steering wheel with the wheels straight,
- the half

Page 16 of 83

RENAULT KANGOO 1997 KC / 1.G Electrical Equipment Workshop Manual IMMOBILISER
Coded key immobiliser system
OPERATION
When the immobiliser system is activated (ap-
proximately 10 seconds after cutting + after igni-
tion feed), the red immobiliser warning light
flashe

Page 18 of 83

RENAULT KANGOO 1997 KC / 1.G Electrical Equipment Workshop Manual 5.Check the immobiliser system operates cor-
rectly with both keys.
Ignition off, the red immobiliser warning light
should flash 10 seconds after switching the
ignition off (slow flashing). Bargraph

Page 19 of 83

RENAULT KANGOO 1997 KC / 1.G Electrical Equipment Workshop Manual 5.Connect the XR25, setting the ISO selector to
S8.
Enter  code
Bargraphs
19 RH and 19 LH must be illumina-
ted (programming not carried out).
6. With one of the keys switch the ignition on
for appro

Page 22 of 83

RENAULT KANGOO 1997 KC / 1.G Electrical Equipment Workshop Manual IMPORTANT: if an uncoded injection computer  or
solenoid valve is being tested from stock (test
part), the decoder unit
MUST NOT be supplied du-
ring the operation.
If the decoder unit is supplied, s
