RENAULT MEGANE 2005 X84 / 2.G Owners Manual

Downloaded from www.Manualslib.com manuals search engine
1

A

NU761_2_G2-FRA.qxd 4/11/05 10:48 Page 2.21
TRACTION CONTROL: ASR (continued)Operating faults
If the system detects an operating
fault, the message Check traction
control or ESP/ASR not functioning
is displayed on the instrument panel
display along with the
warning light and warning light A.
Contact your RENAULT Dealer.
If the warning light comes on
accompanied by the “ASR
deselected” message when the engine
is started, slowly turn the steering
wheel from lock to lock to reinitialise
the system.
Disabling the function also disables
the ESP function.
Correct this as soon as possible by
pressing switch 1again.
The function is reactivated
automatically when the ignition is
switched on or when a speed of
approximately 30 mph (50 km/h) is
exceeded.
It is impossible to deselect this
function when travelling above a
threshold of approximately 30 mph
(50 km/h).
Disabling the function
In some situations (driving on very
wet ground: snow, mud, etc. or
driving with snow chains fitted), the
system may reduce the engine
output to limit wheelspin. If this is
not required, it is possible to
deactivate the function by pressing
switch 1.
The “ESP/ASR deactivated” message
is displayed on the instrument panel
along with warning light Ato inform
you.
2.21
NU761_2_G2-ENG.qxp 03-Jan-06 20:48 Page 2.21 (Black/Process Black\
plate)

Downloaded from www.Manualslib.com manuals search engine
NU761_2_G2-FRA.qxd 4/11/05 10:48 Page 2.22
2.22
ANTI-LOCK BRAKING SYSTEM: ABS
You will feel pulsing through the
brake pedal when the system has
been activated. These tangible signs
will warn you that the grip of the
tyres on the ground has reached its
limit and enable you to adapt your
driving style to suit the road
conditions.
This system also allows you to
optimise stopping distances when
the grip of one or more wheels may
be lost (wet roads, slippery or
varying road surfaces).
Although this system allows you to
make maximum use of stopping
distances, even with the ABS you
still have to take account of the
actual condition of the road surface.
It is still essential to follow the rules
of good driving practice (such as
driving at a safe distance from the
vehicle in front).
The fact that the
vehicle’s safety has been increased
should not encourage you to take
risks.
Under heavy braking, the system has
two principal aims; to reduce the
stopping distance and keep your
vehicle under control. However,
there is a risk that roadholding and
directional control may be lost and
the wheels may lock under braking,
depending on the nature of the
ground, weather conditions and
your reactions. The Anti-lock
Braking System (ABS) has been
designed to combat this danger.
The safety enhancement is that the
brake control system prevents the
wheels from locking, even if the
brakes are applied too sharply, and
allows the vehicle to be steered and
thus its direction to be controlled.
Under these circumstances it is
quite possible for the driver to steer
the vehicle and to avoid an obstacle
whilst at the same time applying the
brake.
NU761_2_G2-ENG.qxp 03-Jan-06 20:48 Page 2.22 (Black/Process Black\
plate)

Downloaded from www.Manualslib.com manuals search engine
NU761_2_G2-FRA.qxd 4/11/05 10:48 Page 2.23
ANTI-LOCK BRAKING SYSTEM: ABS (continued)
One of two situations may arise if
there is a fault in the ABS system:
1 - Orange warning lights
x
and light up on the
instrument panel.
Braking is still performed, but
without the ABS system. Contact
a RENAULT Dealer as soon as
possible.
The braking modulation provided
by the ABS is independent of the
effort applied to the brake pedal. In
an emergency, apply firm and
continuous pressure to the brake
pedal There is no need to pump it
repeatedly.
2.23
2 - The orange x
warning light and the red
dbrake fault warning
light accompanied by and
ûand, depending on vehicle,
the message Brake fault are
illuminated on the instrument panel.
This indicates that both the braking
system and the ABS system are
faulty. Your braking systems are only
partially operational. However, it is
dangerous to brake suddenly and it
is essential to stop immediately, as
soon as traffic conditions allow.
Contact a RENAULT Dealer.
NU761_2_G2-ENG.qxp 03-Jan-06 20:48 Page 2.23 (Black/Process Black\
plate)

Downloaded from www.Manualslib.com manuals search engine
NU761_2_G2-FRA.qxd 4/11/05 10:48 Page 2.24
2.24
EMERGENCY BRAKE ASSIST
This system is complementary to
ABS and helps reduce vehicle
stopping distances.
Operating principle
The system is for detecting an
emergency braking situation. In this
case, the braking assistance
immediately develops maximum
power and may trigger ABS
regulation.
ABS braking is maintained as long
as the brake pedal is not released.
Hazard warning lights switching
on
Depending on the vehicle, these
may light up in the event of sudden
deceleration.This function is an
additional aid in case of
critical driving conditions
to enable the vehicle
behaviour to be adapted to suit the
driving conditions.
However, the function does not take
the place of the driver. I t does not
increase the vehicle’s limits and
should not encourage you to drive
more quickly.
Therefore, it can under no
circumstances replace the vigilance
or responsibility of the driver when
manoeuvring the vehicle (the driver
must always be ready for sudden
incidents which may occur when
driving).
NU761_2_G2-ENG.qxp 03-Jan-06 20:48 Page 2.24 (Black/Process Black\
plate)

Downloaded from www.Manualslib.com manuals search engine
1

2

5

3

4

6

NU761_2_G2-FRA.qxd 4/11/05 10:48 Page 2.25
CRUISE CONTROL/SPEED LIMITER: limiter function
The speed limiter function helps
you stay within the driving speed
limit that you choose.
This may be useful, for example, in
town driving or in areas with speed
restriction (roadworks), etc.
The system operates from a driving
speed of about 18 mph (30 km/h).Controls
1 On/Off switch.
2 Limit speed storage and increase
switch.
3 Recall of stored limit speed.
4 Switching the function off (with
limit speed storage).
5 Limit speed storage and decrease
switch.
Indicator light 6î
This orange indicator light on the
instrument panel lights up to
indicate that the limiter function is
in operation.
When the function is activated, the
message “Limiter” appears on the
instrument panel accompanied by
dashes.
2.25
NU761_2_G2-ENG.qxp 03-Jan-06 20:48 Page 2.25 (Black/Process Black\
plate)

Downloaded from www.Manualslib.com manuals search engine
1

2

5

NU761_2_G2-FRA.qxd 4/11/05 10:48 Page 2.26
2.26
CRUISE CONTROL/SPEED LIMITER: limiter function (continued)
Driving
When a limited speed has been
stored and this speed is not reached,
driving is similar to driving a
vehicle without the speed limiter
function.
From this point, no effort on the
accelerator pedal will allow you to
exceed the programmed speed
except in an emergency (see
information on exceeding the
limited speed).
Switching on
Press switch 1ðside.
The indicator light on the
instrument panel comes on and the
computer switches to the “speed
limiter” function.
Limiting the speed
At a constant speed (above about 18
mph (30 km/h)) and in the correct
gear (for vehicles with manual
gearboxes), press switch 2: the speed
is stored.
Varying the limit speed
The limit speed may be changed by
pressing repeatedly or holding
down:
- key 2to increase the speed,
- key 5to decrease the speed.
The system is designed in such a
way that it is possible to detect a
difference between the cruising
speed and the speed shown on
the instrument panel.
NU761_2_G2-ENG.qxp 03-Jan-06 20:48 Page 2.26 (Black/Process Black\
plate)

Downloaded from www.Manualslib.com manuals search engine
1

3

4

NU761_2_G2-FRA.qxd 4/11/05 10:48 Page 2.27
CRUISE CONTROL/SPEED LIMITER: limiter function (continued)
Exceeding the limit speed
In the event of an emergency
It is possible to exceed the limit
speed at any moment. To do this:
depress the accelerator pedal firmly
and fully (beyond the kickdown
point).
While it is being exceeded, the limit
speed flashes on the instrument
panel.
When the emergency situation is
over, release the accelerator pedal:
the speed limiter function returns as
soon as you reach a speed that is
lower than the speed set before the
emergency action.
Limit speed cannot be maintained
In some driving conditions (for
example when driving up or down a
steep gradient), the system is unable
to maintain the cruising speed: the
stored speed on the instrument
panel information display will flash
to inform you of this situation.
Recalling the limit speed
If a speed is stored, it is possible to
recall it by pressing button 3until
the message “Limiter” is displayed.
Stopping the function
The speed limiter function is
interrupted when you press:
- button 4, in which case the limit
speed remains stored and the
message “stored” appears on the
instrument panel,
- button 1, in this case the limit
speed is no longer stored, and the
indicator light on the instrument
panel goes out to confirm that the
function has been cancelled.
2.27
NU761_2_G2-ENG.qxp 03-Jan-06 20:48 Page 2.27 (Black/Process Black\
plate)

Downloaded from www.Manualslib.com manuals search engine
1

2

5

3

4

NU761_2_G2-FRA.qxd 4/11/05 10:48 Page 2.28
2.28
CRUISE CONTROL/SPEED LIMITER: cruise control function
The cruise control function helps
you to maintain your driving speed
at a speed that you choose, called
the cruising speed .
This cruising speed can be adjusted
continuously from 18 mph or
(30 km/h).Controls
1 Main On/Off switch.
2 Cruising speed storage and
activation Increase the cruising
speed.
3 Recall of stored cruising speed.
4 Switching the function off (with
cruising speed storage).
5 Cruising speed storage and
activation Decrease the cruising
speed.
The cruising function
does not affect the braking
system. This function is an
additional driving aid.
However, the function does
not take the place of the
driver. Thus, it can under no
circumstances replace the driver’s
responsibility to respect speed limits
and to be vigilant (the driver must
always be ready to brake). Cruise
control must not be used in heavy
traffic, on undulating or slippery
roads (black ice, aquaplaning,
gravel) and during bad weather (fog,
rain, side winds etc.).
There is a risk of accident.
NU761_2_G2-ENG.qxp 03-Jan-06 20:48 Page 2.28 (Black/Process Black\
plate)

Downloaded from www.Manualslib.com manuals search engine
6

2

5

1

NU761_2_G2-FRA.qxd 4/11/05 10:48 Page 2.29
CRUISE CONTROL/SPEED LIMITER: cruise control function (continued)
Activating cruise control
At a steady speed (above 18 mph
(30 km/h)) and in the correct gear
(for vehicles with manual gearboxes),
press switch 2or 5:the function is
activated and the speed is stored.
Driving
Once a cruising speed is stored and
the cruise control function is active,
you may lift your foot off the
accelerator pedal.
The system is designed in such a
way that it is possible to detect a
difference between the cruising
speed and the speed shown on
the instrument panel.
Switching on
Press switch 1ïside.
The green indicator light 6 on the
instrument panel comes on to
indicate that the cruise control
function is in operation.
When the function is activated, the
message “Cruise control” appears on
the instrument panel accompanied
by dashes.
2.29
Note, it is still advised
that you keep your feet
close to the pedals in case
ofemergency.
NU761_2_G2-ENG.qxp 03-Jan-06 20:48 Page 2.29 (Black/Process Black\
plate)

Downloaded from www.Manualslib.com manuals search engine
2

5

NU761_2_G2-FRA.qxd 4/11/05 10:48 Page 2.30
2.30
CRUISE CONTROL/SPEED LIMITER: cruise control function (continued)
Adjusting the cruising speed
The cruising speed may be changed
by pressing repeatedly or
continuously on:
- key 2to increase the speed,
- key 5to decrease the speed.
Exceeding the cruising speed
In the event of an emergency
The cruising speed may be exceeded
at any time by pressing the
accelerator pedal. Whilst the speed
is being exceeded, the cruising
speed displayed on the instrument
panel flashes.
When the emergency is over, the
vehicle will return to its set cruising
speed as soon as you lift your foot
off the pedal.
Cruising speed cannot be
maintained
In some driving conditions (for
example when driving up or down a
steep gradient), the system is unable
to maintain the cruising speed: the
speed flashes on the instrument
panel to inform you of this situation.
The cruising function
does not affect the braking
system.
NU761_2_G2-ENG.qxp 03-Jan-06 20:48 Page 2.30 (Black/Process Black\
plate)
