RENAULT MEGANE 2005 X84 / 2.G Manual Online

Downloaded from www.Manualslib.com manuals search engine
23559

23560

23503

NU761_2_G1-FRA.qxd 10/11/05 15:54 Page 1.71
1.71
TRIP COMPUTER AND WARNING SYSTEM (continued)
Examples of selections Interpreting the display selectedd) Cruise Control/Speed Limiter programmed speed (depending on vehicle)
See see information on Speed Limiter and Cruise Control in Section 2.
e) Computer log Successive display:
- of information messages (depending on vehicle: heated seats, automaticheadlight illumination, etc.),
- of operating fault messages (check the injection system, etc.).
NU761_2_G1-ENG.qxp 1/6/2006 12:23 PM Page 1.71 (Black plate)

Downloaded from www.Manualslib.com manuals search engine
NU761_2_G1-FRA.qxd 10/11/05 15:54 Page 1.72
1.72
TRIP COMPUTER AND WARNING SYSTEM (continued)
Warning messages
They warn you to stop immediately
(as soon as traffic conditions allow)
and to call a RENAULT Dealer.
They appear with the
ûwarning
light. Examples of warning messages
are given on the following pages.
N.B.: the messages appear on the
display either individually or
alternately (when there are several
messages to be displayed), and may
be accompanied by a warning light
and/or a beep.
Information messages
These can help either in the vehicle
starting phase, or give information
about a choice or a driving status.
Examples of information messages
are given on the following pages.
Fault messages
You should immediately go to your
RENAULT Dealer for work to be
carried out on your vehicle.
These messages appear accompanied
by the warning light.
They disappear when the display
selection key is pressed or after
several seconds and are stored in the
computer log.
The warning light remains
lit. Examples of fault messages are
given on the following pages.
NU761_2_G1-ENG.qxp 1/6/2006 12:23 PM Page 1.72 (Black plate)

Downloaded from www.Manualslib.com manuals search engine
23505

23507

23508

NU761_2_G1-FRA.qxd 10/11/05 15:54 Page 1.73
1.73
TRIP COMPUTER AND WARNING SYSTEM (continued)
Examples of information messages
Message Display
Instrument panel variant 1 Message Display
Instrument panel variant 2 Interpretation of messages
"Insert the card"
Request to insert the RENAULT card in the reader.
"Oil level OK"
Indicates that the oil level is correct when the ignition is switched on\
.
"Automatic lights function off"
Indicates that the automatic lights function is deactivated.
NU761_2_G1-ENG.qxp 1/6/2006 12:23 PM Page 1.73 (Black plate)

Downloaded from www.Manualslib.com manuals search engine
23511

NU761_2_G1-FRA.qxd 10/11/05 15:54 Page 1.74
1.74
TRIP COMPUTER AND WARNING SYSTEM (continued)
Examples of fault messages
Message Display
Instrument panel variant 2 Interpretation of messages
"ESP/ASR deactivated"
ASR traction control deactivated (see information on traction control \
in
section 2) and ESP, electronic stability program (see “electronic stability
program: ESP with understeer control” paragraph in section 2).
"No tyre sensor" or "Tyre sensor out of order"
Sensor fault on the missing wheel in zone Aof the display: this is displayed, for
example, when the emergency spare wheel is fitted on the vehicle (see T\
yre
pressure monitor in Section 2).
"Check tyre pressure"
Wheel inflation fault (underinflation) indicated on the multifunction \
display or
in zone Aon the information display; adjust the pressure as soon as possible.
"Bleed diesel filter" or "Check diesel filter"
Indicates that there is water present in the diesel fuel.
Consult your RENAULT Dealer as soon as possible.
Message Display
Instrument panel variant 1
NU761_2_G1-ENG.qxp 1/6/2006 12:23 PM Page 1.74 (Black plate)

Downloaded from www.Manualslib.com manuals search engine
23512

23513

23514

NU761_2_G1-FRA.qxd 10/11/05 15:54 Page 1.75
1.75
TRIP COMPUTER AND WARNING SYSTEM (continued)
Examples of fault messages
Message Display
Instrument panel variant 1 Message Display
Instrument panel variant 2 Interpretation of messages
"Check gearbox"
Indicates that a fault has occurred in the gearbox, contact your RENAULT
Dealer as soon as possible.
"Card not detected"
The Hands-Free RENAULT card is not in the detection zone, or the vehicle has
not been able to detect it. Insert it in the reader, if the fault persists contact your
RENAULT Dealer.
"Change card battery"
Your RENAULT card battery has a service life of approximately two years.
This message appears when the battery begins to run flat (refer to RENA\
ULT
card: batteries in Section 5).
NU761_2_G1-ENG.qxp 1/6/2006 12:23 PM Page 1.75 (Black plate)

Downloaded from www.Manualslib.com manuals search engine
23501

23500

NU761_2_G1-FRA.qxd 10/11/05 15:54 Page 1.76
1.76
TRIP COMPUTER AND WARNING SYSTEM (continued)
Warning messages
These require you to stop immediately or as soon as the traffic conditio\
ns allow
Message Display
Instrument panel variant 1 Message Display
Instrument panel variant 2 Interpretation of messages
"Injection fault" or "Faulty injection"
Indicates that the vehicle has a serious engine fault.
"Stop! Tyre puncture"
Indicates a puncture on the wheel shown in zone A of the display.
"Engine overheating"
Indicates that the engine is overheating.
NU761_2_G1-ENG.qxp 1/6/2006 12:23 PM Page 1.76 (Black plate)

Downloaded from www.Manualslib.com manuals search engine
23502

NU761_2_G1-FRA.qxd 10/11/05 15:54 Page 1.77
1.77
TRIP COMPUTER AND WARNING SYSTEM (continued)
Warning messages
These require you to stop immediately or as soon as the traffic conditio\
ns allow
Message Display
Instrument panel variant 1 Message Display
Instrument panel variant 2 Interpretation of messages
"Steering fault" or "Faulty steering"
Indicates a fault in the vehicle’s power assisted steering.
"Electronic fault"
Indicates a problem with the vehicle electronic management system.
NU761_2_G1-ENG.qxp 1/6/2006 12:23 PM Page 1.77 (Black plate)

Downloaded from www.Manualslib.com manuals search engine
3

1
2

NU761_2_G1-FRA.qxd 10/11/05 15:55 Page 1.78
1.78
Exterior temperature
indicator
As ice formation is related
to exposure, local air
humidity and temperature, the
external temperature alone is not
sufficient to detect ice.
CLOCK AND OUTSIDE TEMPERATURE
Vehicles equipped with a
navigation system, a radio, etc.
For vehicles not equipped with
buttons 2and 3, refer to the specific
equipment manual for details on
these vehicles.
Exterior temperature indicator
Special note:
When the outside temperature is
–3°C to +3°C, the °C characters flash
(signalling a risk of ice on the road).
With the ignition on , the time and,
depending on the vehicle, the
temperature is displayed.
Setting the time 1
For vehicles equipped with these
functions, setting buttons 2and 3
are used to set the clock.
Press button 2to set the hours and
press button 3to set the minutes. If the electrical supply is cut
(battery disconnected, power
supply wire broken, etc.), the
clock will lose its time setting.
The clock must be reset.
We recommend that you do not
adjust these settings while
driving.
NU761_2_G1-ENG.qxp 1/6/2006 12:23 PM Page 1.78 (Black plate)

Downloaded from www.Manualslib.com manuals search engine
C

F
1

D

E

2

A
B

NU761_2_G1-FRA.qxd 10/11/05 15:55 Page 1.79
1.79
The driver’s door mirror
may have two clearly
defined zones. Zone Bis
what can normally be seen
in a conventional door mirror. For
your safety, zone Aincreases the
area you can see at the rear and to
the side of your car.
The objects in zone Alook much
further away than they really are.
DOOR MIRRORS
Door mirrors with manual
control
To adjust the door mirror, move
lever 1.
Door mirrors
With the ignition on , move control 2
to:
- position Cto adjust the left-hand
door mirror;
- position Eto adjust the right-hand
door mirror;
D being the central neutral position.
Folding door mirrors
Move control 2to position Fand the
door mirrors fold in.
To put them back into driving
position, return to position C, D or E.
Heated door mirrors
The door mirrors are de-iced when
the rear screen demisting/de-icing is
active.
NU761_2_G1-ENG.qxp 1/6/2006 12:23 PM Page 1.79 (Black plate)

Downloaded from www.Manualslib.com manuals search engine
1

2

NU761_2_G1-FRA.qxd 10/11/05 15:55 Page 1.80
1.80
REAR-VIEW MIRRORS
Interior rear-view mirror
Its position can be adjusted. For
night driving, to avoid being dazzled
by the headlights of the car behind
you, move the small lever 1located
behind the mirror.
Auto-dimming rear-view mirror 2
The rear-view mirror darkens
automatically at night when you are
followed by a vehicle with lights
(main beam headlights).
NU761_2_G1-ENG.qxp 1/6/2006 12:23 PM Page 1.80 (Black plate)
