Page 51 of 106

86A-51
AFTER REPAIRCarry out another fault finding check on the system.
Clear the stored faults using command RZ003 Fault memory.
Deal with any other faults.
V1 MR-413-X44-86A150$120.mif
RADIO
Fault finding – Interpretation of faults86A
R2-08
Vdiag No.: 64
DF046
PRESENT
OR
STOREDUNIT LOCKED
1.DEF: System locked
NOTESThis fault is detected when the radio computer receives a radio programming key
(supplied from the VIN) that is invalid for the instrument panel via the multiplex network.
Use the diagnostic tool to check that the V.I.N. of the radio is identical to that of the instrument panel.
Configure the multimedia connection unit (see 86D, Multimedia connection unit, Configuration).
Enter the radio code (see Anti-theft code).
If the fault persists, contact your Techline.
R208_V64_DF046
Page 52 of 106

86A-52
AFTER REPAIRCarry out another fault finding check on the system.
Clear the stored faults using command RZ003 Fault memory.
Deal with any other faults.
V1 MR-413-X44-86A150$120.mif
RADIO
Fault finding – Interpretation of faults86A
R2-08
Vdiag No.: 64
DF051
PRESENT
OR
STOREDFRONT RIGHT-HAND TWEETER
CO: Open circuit
NOTESConditions for applying fault finding procedures to stored faults:
The fault is declared present after:
–The multimedia system was switched on using the on/off button for at least
10 seconds,
–Command AC004 Front right-hand speakers line test was run.
Check the speaker first when dealing with several faults.
Use the Wiring Diagrams Technical Note for Clio III or New Twingo.
Run command SC002 Computer configuration (see Configuration) and configure the equipment.
Check the condition and connection of the connectors of radio 261, of the front right-hand tweeter connector
365, of the front right-hand speaker connector 1598 (left-hand drive) or 1597 (right-hand drive) (bent or broken
tabs, etc.).
If the connector(s) is faulty and if there is a repair procedure (see Technical Note 6015A, Repairing electrical
wiring, Wiring: Precautions for repair), repair the connector, otherwise replace the wiring.
Check the continuity, insulation and absence of interference resistance on the following connections:
•34E between components 261 and 365, 1598 (left-hand drive) or 1597 (right-hand drive),
•34F between components 261 and 365, 1598 (left-hand drive) or 1597 (right-hand drive).
If the connection(s) are faulty and there is a repair method (see Technical Note 6015A, Repairing electrical
wiring, Wiring: Precautions for repair), repair the wiring, otherwise replace it.
If the connections are correct, replace component 365 (see MR 392 (Clio III) or MR 411 (New Twingo)
Mechanical, 86A, Radio, Tweeter: Removal - Refitting).
If the fault persists, contact your Techline.
R208_V64_DF051
Page 53 of 106

86A-53
AFTER REPAIRCarry out another fault finding check on the system.
Clear the stored faults using command RZ003 Fault memory.
Deal with any other faults.
V1 MR-413-X44-86A150$120.mif
RADIO
Fault finding – Interpretation of faults86A
R2-08
Vdiag No.: 64
DF052
PRESENT
OR
STOREDFRONT LEFT-HAND TWEETER
CO: Open circuit
NOTESConditions for applying fault finding procedures to stored faults:
The fault is declared present after:
–The multimedia system was switched on using the on/off button for at least
10 seconds,
–Command AC005 Front left-hand speaker line test was run.
Check the speaker first when dealing with several faults.
Use the Wiring Diagrams Technical Note for Clio III or New Twingo.
Run command SC002 Computer configuration and configure the equipment.
Check the condition and connection of the connectors of radio 261, of the front left-hand tweeter connector 366
and of the front left-hand speaker connector 1597 (left-hand drive) or 1598 (right-hand drive) (bent or broken tabs,
etc.).
If the connector(s) is faulty and if there is a repair procedure (see Technical Note 6015A, Repairing electrical
wiring, Wiring: Precautions for repair), repair the connector, otherwise replace the wiring.
Check the continuity, insulation and absence of interference resistance on the following connections:
•34G between components 261 and 366, 1597 (left-hand drive) or 1598 (right-hand drive),
•34H between components 261 and 366, 1597 (left-hand drive) or 1598 (right-hand drive).
If the connection(s) are faulty and there is a repair method (see Technical Note 6015A, Repairing electrical
wiring, Wiring: Precautions for repair), repair the wiring, otherwise replace it.
If the connections are correct, replace component 366 (see MR 392 (Clio III) or MR 411 (New Twingo)
Mechanical, 86A, Radio, Tweeter: Removal - Refitting).
If the fault persists, contact your Techline.
R208_V64_DF052
Page 54 of 106

86A-54
AFTER REPAIRCarry out another fault finding check on the system.
Clear the stored faults using command RZ003 Fault memory.
Deal with any other faults.
V1 MR-413-X44-86A150$120.mif
RADIO
Fault finding – Interpretation of faults86A
R2-08
Vdiag No.: 64
DF053
PRESENT
OR
STOREDREAR RIGHT-HAND TWEETER
CO: Open circuit
NOTESConditions for applying fault finding procedures to stored faults:
The fault is declared present after:
–The multimedia system was switched on using the on/off button for at least
10 seconds,
–Command AC006 Rear right-hand speaker line test was run,
–The fault can only be detected if the battery voltage is between:
12 V < X < 15 V.
Note:
The rear tweeters are integrated into the rear speakers and are only available on
New Twingo.
Use the Wiring Diagrams Technical Note for New Twingo.
Check the condition and connection of the connectors of radio 261, of the rear right-hand speaker 189 (bent or
broken tabs, etc.).
If the connector(s) is faulty and if there is a repair procedure (see Technical Note 6015A, Repairing electrical
wiring, Wiring: Precautions for repair), repair the connector, otherwise replace the wiring.
Disconnect the connector of component 189 (see MR 411 (New Twingo) Mechanical, 86A, Radio, Rear speaker:
Removal - Refitting).
Measure the resistance of component 189 using a multimeter, with the ignition off.
If the resistance is not between: 3.5 Ω < X < 4.5 Ω, replace component 189 (see MR 411 (New Twingo)
Mechanical, 86A, Radio, Rear speaker: Removal - Refitting).
Check the continuity, insulation and absence of interference resistance on the following connections:
•34D between components 261 and 189,
•34C between components 261 and 189.
If the connections are faulty and if there is a repair procedure (see Technical Note 6015A, Electrical wiring
repair, Wiring: Precautions for repair), repair the wiring, otherwise replace it.
If the fault persists, contact your Techline.
R208_V64_DF053
Page 55 of 106

86A-55
AFTER REPAIRCarry out another fault finding check on the system.
Clear the stored faults using command RZ003 Fault memory.
Deal with any other faults.
V1 MR-413-X44-86A150$120.mif
RADIO
Fault finding – Interpretation of faults86A
R2-08
Vdiag No.: 64
DF054
PRESENT
OR
STOREDREAR LEFT-HAND TWEETER
CO: Open circuit
NOTESConditions for applying fault finding procedures to stored faults:
The fault is declared present after:
–The multimedia system was switched on using the on/off button for at least
10 seconds,
–Command AC007 Rear left-hand speaker line test was run,
–The fault can only be detected if the battery voltage is between:
12 V < X < 15 V.
Note:
The rear tweeters are integrated into the rear speakers and are only available on
New Twingo.
Use the Wiring Diagrams Technical Note for New Twingo.
Check the condition and connection of the connectors of radio 261 and of the rear left-hand speaker 190 (bent or
broken tabs, etc.).
If any of the connectors are faulty and there is a repair method (see Technical Note 6015A, Electrical wiring
repair, Wiring: Precautions for repair), repair the connector, otherwise replace the wiring.
Disconnect the connector of component 190 (see MR 411 (New Twingo) Mechanical, 86A, Radio, Rear speaker:
Removal - Refitting).
Measure the resistance of component 190 using a multimeter, with the ignition off.
If the resistance is not between: 3.5 Ω < X < 4.5 Ω, replace component 190 (see MR 411 (New Twingo)
Mechanical, 86A, Radio, Rear speaker: Removal - Refitting).
Check the continuity, insulation and absence of interference resistance on the following connections:
•34A between components 261 and 190,
•34B between components 261 and 190.
If the connection(s) are faulty and there is a repair method (see Technical Note 6015A, Repairing electrical
wiring, Wiring: Precautions for repair), repair the wiring, otherwise replace it.
If the fault persists, contact your Techline.
R208_V64_DF054
Page 56 of 106

86A-56
AFTER REPAIRCarry out another fault finding check on the system.
Clear the stored faults using command RZ003 Fault memory.
Deal with any other faults.
V1 MR-413-X44-86A150$120.mif
RADIO
Fault finding – Interpretation of faults86A
R2-08
Vdiag No.: 64
DF055
PRESENT
OR
STOREDBUTTON JAMMED
1.DEF: Radio front panel button jammed.
NOTESConditions for applying fault finding procedures to stored faults:
The fault is declared present after:
–The + after ignition feed is activated,
–The multimedia system is switched on using the on/off button.
The button concerned is pressed for at least 2 minutes,
Check the conformity of the radio buttons by consulting the following statuses:
–ET002 Mode button,
–ET003 Right directional button,
–ET004 Left directional button,
–ET009 CD eject button,
–ET010 Radio preset button 1,
–ET011 Radio preset button 2,
–ET012 Radio preset button 3,
–ET013 Radio preset button 4,
–ET014 Radio preset button 5,
–ET015 Radio preset button 6,
–ET034 Rewind button,
–ET035 Fast forward button,
–ET036 Wheel press on/off,
–ET039 TEL button,
–ET040 SET button,
–ET060 Centre wheel press,
–ET062 Text info button,
–ET063 MEM button,
–ET064 Radio/CD button.
If the one of the statuses is Pressed, press on the corresponding button so that the status becomes Released.
R208_V64_DF055
Page 57 of 106

86A-57
AFTER REPAIRCarry out another fault finding check on the system.
Clear the stored faults using command RZ003 Fault memory.
Deal with any other faults.
V1 MR-413-X44-86A150$120.mif
RADIO
Fault finding – Interpretation of faults86A
R2-08
Vdiag No.: 64
DF055
CONTINUED
Check the conformity of the radio buttons by consulting the following statuses:
–ET043 "Wheel left turn",
–ET058 Central wheel left turn,
If one of the statuses is Left, turn the wheel so that the status becomes Released.
Check the conformity of the radio buttons by consulting the following statuses:
–ET044 Wheel right turn,
–ET059 Central wheel right turn,
If one of the statuses is Right, turn the wheel so that the status becomes Released.
If the fault is still present, replace the radio (see MR 392 (Clio III) or MR 411 (New Twingo) Mechanical, 86A,
Radio, Radio: Removal - Refitting).
Page 58 of 106

86A-58
AFTER REPAIRCarry out another fault finding check on the system.
Clear the stored faults using command RZ003 Fault memory.
Deal with any other faults.
V1 MR-413-X44-86A150$120.mif
RADIO
Fault finding – Interpretation of faults86A
R2-08
Vdiag No.: 64
DF056
PRESENT
OR
STOREDMICROPHONE
CC.0: Short circuit to earth
CO: Open circuit
NOTESConditions for applying the fault finding procedure to a stored fault:
The fault is declared present after:
–the + after ignition feed is activated,
–the multimedia system has been switched on using the on/off button,
–the "hands-free" function has been activated,
–the command AC010 Microphone test was run.
Use the Wiring Diagrams Technical Note for Clio III or New Twingo.
Look for any damage to the wiring harness and check the condition and connection of the connectors for
components 261 and 789.
If the connectors are faulty and if there is a repair method (see Technical Note 6015A, Repairing electrical
wiring, Wiring: Precautions for repair), repair the connector(s), otherwise replace the wiring.
Run command AC010 Microphone Test and check that the microphone, component code 789 is correctly
supplied between connections 107G and 107J.
Check the continuity, insulation and absence of interference resistance on the following connections:
•107F between components 261 and 789,
•107G between components 261 and 789,
•107J between components 261 and 789,
If the connection(s) are faulty and there is a repair method (see Technical Note 6015A, Repairing electrical
wiring, Wiring: Precautions for repair), repair the wiring, otherwise replace it.
If the fault is still present, replace the microphone (see MR 392 (Clio III) or MR 411 (New Twingo) Mechanical,
86B, Car phone, "Hands-free" microphone: Removal - Refitting).
R208_V64_DF056
Page 59 of 106

86A-59
AFTER REPAIRCarry out another fault finding check on the system.
Clear the stored faults using command RZ003 Fault memory, after pressing the ON/
OFF button.
Deal with any other faults.
V1 MR-413-X44-86A150$120.mif
RADIO
Fault finding – Interpretation of faults86A
R2-08
Vdiag No.: 64
DF064
PRESENT
OR
STOREDACTIVATION SIGNAL
CC.0: Short circuit to earth
CC.1: Short circuit to + 12 V
CO: Open circuit
NOTESConditions for applying fault finding procedures to stored faults:
The fault is declared present after:
–the + after ignition feed is activated,
–the multimedia system has been switched on using the on/off button.
Use the Wiring Diagrams Technical Note for Clio III or New Twingo.
For a vehicle equipped with a navigation system, use the multimedia connection unit
computer, component code 1714, for fault finding.
For a vehicle without a navigation system, use the display computer, component code
653, for fault finding.
Check the condition of the connector on the radio, component code 261, and, depending on the equipment level,
on the display, component code 653, or on the multimedia connection unit, component code 1714.
If the connector(s) is faulty and if there is a repair procedure (see Technical Note 6015A, Repairing electrical
wiring, Wiring: Precautions for repair), repair the connector, otherwise replace the wiring.
Check the insulation, continuity and absence of interference resistance on the following connections:
•34HY between,components 261 and 653 or 1714,
If the connection(s) are faulty and there is a repair method (see Technical Note 6015A, Repairing electrical
wiring, Wiring: Precautions for repair), repair the wiring, otherwise replace it.
If the connection is correct, replace the radio (see MR 392 (Clio III) or MR 411 (New Twingo) Mechanical, 86A,
Radio, Radio: Removal - Refitting).
If the fault persists, contact your Techline.
R208_V64_DF064
Page 60 of 106

86A-60V1 MR-413-X44-86A150$130.mif
86A
R2-08
Vdiag No.: 64
MAIN SCREEN
NOTESOnly carry out this conformity check after a complete check with the diagnostic tool.
The values shown in this conformity check are given as a guide.
Application condition: engine off, ignition on.
FunctionParameter or status
checked or actionDisplay and notes Fault finding
SupplyET057:Activation
signalPRESENT ABSENTIn the event of an
inconsistency, consult the
interpretation of fault DF064
Activation signal.
Presence of
another deviceET001:Presence
of another
devicePRESENT ABSENTIn the event of an
inconsistency, contact the
Techline.
Wake upET065:Activation
requestPRESENT ABSENTIn the event of an
inconsistency, consult the
interpretation of fault DF064
Activation signal.
Radio
receptionPR007:FM1 radio
field
intensity0 dBµV
interpretation of parameter
PR007.
R208_V64_CCONF
RADIO
Fault finding – Conformity check
