SSANGYONG TURISMO 2013 Service Manual

03-8
Transponder
3. VERIFICATION OF KEY
1) Verification
The immobilizer system prevents the vehicle theft by allowing only the authorized key to start the
engine. The transponder inside the key communicates with the immobilizer installed in the key box,
and the system permits the engine to start after confirming the encrypted coding from the engine ECU.
In the following cases, a driver may be unable to start the vehicle with the immobilizer.The immobilizer unit transmits
the encrypted code to the
transponder. (2)
The transponder sends an encrypted signal to the unit as a response.
The transmitted code is changed to an encrypted signal in the unit.
The system compares the signal from transponder and the encrypted signal in immobilizer unit. (3)
(4)
(5)
When two or more immobilizer keys come into contact with (each) other(s).
When the key is close to any device sending or receiving electromagnetic fields or waves.
When the key is close to any electronic or electric devices such as lightening equipment,
security keys or security cards.
When the key is close to a magnetic or metal object or a battery. -
-
-
-
Immobilizer Unit

03-97010-06
ECU
Immobilizer Indicator and Warning Lamp ▶
This indicator comes on when the ignition
key is communicating with the engine control
unit (during engine starting) and goes out
after starting the engine.
When turning the ignition key to ON position, the
ECU transmits the challenge message to the
immobilizer unit to verify whether the key is valid. (1)
Only when the two signals are identical, it
recognizes the key as the authorized one and
transmits the positive message to the ECU.
The ECU allows the engine to be started. (6)
(7)
Do not drop or shock to the transponder in the key as it may be damaged.
With a damaged transponder, the engine cannot be started.
When you erase the code or register an extra key, let the owner attend on the site.
In any case, the immobilizer system cannot be removed from the vehicle. If you attempt to
remove it and damage the system, starting will be impossible, so never attempt to remove,
damage or modify it.
The remote engine starter cannot be installed on the vehicle equipped with the immobilizer
system. -
-
-
-
-Lamp ON: in communication
Blinking twice for one second:
immobilizer system failure
Blinking once for two seconds:
immobilizer unit is not coded
The immobilizer indicator does not come
on if the communication time between
immobilizer key and ECU is too short.
Immobilizer Indicator and Warning Lamp

03-10
2) Circuit Diagram

04-38010-01
1. SPECIFICATIONS
1) Power, Voltage, Current
Description Specification
Rated voltage DC 12V
Operating voltage DC 9V ~ 16V
Inspection voltage DC 13.5V
Operating temperature Standard-30˚C ~ +75˚C (while driving)
Black face-30˚C ~ +80˚C
Storage temperature-40˚C ~ +85˚C
Performance guarantee voltage DC 10V ~ 15V
Dark current Standardbelow 3mA (12V, 25°C), Stabilized conditions (standby
mode) around 180 seconds after IGN OFF
Black facebelow 1mA (12V, 25°C), Stabilized conditions (standby
mode) around 180 seconds after IGN OFF

04-4
2) LCD Display
Description Specification
Color of display Black
Color of back-light Yellow/Green
Running type 1/4 Duty, 1/3 Bias
(1) Standard
(2) Black face
Description Specification
LCD display type Speedometer (segment)
LCD display
SpecificationSelective display TRIP A
TRIP B
Driving time
Average speed
Average fuel economy
Distance to empty
Illumination control
Constant display Odometer
Instant fuel economy
Gear selector lever position

04-58010-01
Warning box
- Warning box introduced
Instrument cluster
- Black face cluster introduced
2. MAJOR CHANGES
Warning/indicator lamp
LCD screen

04-6
Warning Box
Standard Black face
Cluster
Standard Black face
TRIP switch
2. LAYOUT 1. OVERVIEW
The instrument cluster for this vehicle consists of the Meter cluster and the Warning lamp/Indicator
cluster.

07-38310-01
1. BULB SPECIFICATIONS
Description AmountSpecification
(EU)Specification
(General)
Exterior
lampHeadlamp High beam + DRL 2 55W + 15W 55W
Low beam 2 55W←
Turn signal lamp 2 21W←
Position lamp 2 5W←
Front fog lamp 2 H16←
Side repeater 2 5W←
Rear
combination
lampTail (stop) lamp 4 5W(21W)←
Turn signal lamp 2 21W←
Back-up lamp 2 16W←
Rear fog lamp 2 21W -
License plate lamp 2 5W←
High mounted stop lamp 5 5W←
Interior lamp Front room lamp 2 5W←
Glove box lamp 1 5W←
Door courtesy lamp 4 5W←
Side room lamp 4 5W←
Rear room lamp 1 5W←

07-4
Front fog lamp
Fog lamp design changed
Headlamp
Design and function changed
2. MAJOR CHANGES
1) Exterior Lamp
Front view ▶
Headlamp
Tail lamp (12V-5W)
Turn signal lamp
(12V-28W)Low beam
(12V-55W)High beam
(12V-55W)Low beam
(H7-55W)
Tail lamp (W5W)Turn signal
lamp (P21W)
High beam + DRL
(EU: 55W+15W, GEN: 55W)
Front fog lamp
Headlamp
Front fog lamp
