SUBARU FORESTER 2004 Service Repair Manual

4AT-19
AUTOMATIC TRANSMISSION
General Description
D: PREPARATION TOOL
1. SPECIAL TOOL
ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS
498575400 OIL PRESSURE
GAUGE ASSYUsed for measuring oil pressure.
498897200 OIL PRESSURE
GAUGE ADAPTERUsed for oil pump housing when measuring
reverse clutch pressure and line pressure.
498897700 ADAPTER SET Used for measuring transfer clutch pressure.
498545400 FILTER WRENCH Used for removing and installing ATF filter.
ST-498575400
ST-498897200
ST-498897700
ST-498545400

4AT-20
AUTOMATIC TRANSMISSION
General Description
498277200 STOPPER SET Used for removing and installing automatic
transmission assembly.
41099AC000 ENGINE SUPPORT
ASSEMBLYUsed for supporting engine.
(1) ENGINE SUPPORT BRACKET
(41099AA010)
(2) ENGINE SUPPORT (41099AA020)
398527700 PULLER ASSY  Used for removing extension case roller bear-
ing.
 Used for removing extension oil seal.
 Used for removing front differential side
retainer bearing outer race.
 Used for removing front differential side
retainer oil seal.
498057300 INSTALLER Used for installing extension oil seal. ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS
ST-498277200
(2)(1)
ST41099AC000
ST-398527700
ST-498057300

4AT-21
AUTOMATIC TRANSMISSION
General Description
498077000 REMOVER Used for removing differential taper roller bear-
ing.
499247400 INSTALLER  Used for installing transfer outer snap ring.
 Used with GUIDE (499257300).
499257300 SNAP RING
OUTER GUIDE Used for installing transfer outer snap ring.
 Used with INSTALLER (499247400).
499787000 WRENCH ASSY Used for removing and installing differential side
retainer. ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS
ST-498077000
ST-499247400
ST-499257300
ST-499787000

4AT-22
AUTOMATIC TRANSMISSION
General Description
398437700 DRIFT Used for installing torque converter case oil seal.
398487700 INSTALLER Used for installing front differential taper roller
bearing.
398673600 COMPRESSOR Used for removing and installing clutch spring.
498255400 PLATE Used for measuring backlash of hypoid gear. ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS
ST-398437700
ST-398487700
ST-398673600
ST-498255400

4AT-23
AUTOMATIC TRANSMISSION
General Description
399893600 PLIERS Used for removing and installing clutch spring.
498247001 MAGNET BASE  Used for measuring gear backlash.
 Used with DIAL GAUGE (498247100).
498247100 DIAL GAUGE  Used for measuring gear backlash.
 Used with MAGNET BASE (498247001).
498517000 REPLACER Used for removing front roller bearing. ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS
ST-399893600
ST-498247001
ST-498247100
ST-498517000

4AT-24
AUTOMATIC TRANSMISSION
General Description
398623600 SEAT Used for removing spring of transfer clutch pis-
ton.
28399SA000 DRIVE SHAFT
REMOVERUsed for removing axle shaft.
28399SA010 OIL SEAL PROTEC-
TO RUsed for installing axle shaft.
499267300 STOPPER PIN Used for installing inhibitor switch. ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS
ST-398623600
ST28399SA000
ST28399SA010
ST-499267300

4AT-25
AUTOMATIC TRANSMISSION
General Description
499787700 WRENCH Used for removing and installing drive pinion lock
nut.
499787500 ADAPTER Used for removing and installing drive pinion lock
nut.
398643600 GAUGE Used for measuring total end play, extension end
play and drive pinion height.
498627100 SEAT Used for holding low clutch piston retainer spring
when installing snap ring. ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS
ST-499787700
ST-499787500
ST-398643600
ST-498627100

4AT-26
AUTOMATIC TRANSMISSION
General Description
499577000 GAUGE Used for measuring mating surface of transmis-
sion to end of reduction gear.
499737000 PULLER Used for removing reduction driven gear assem-
bly.
499737100 PULLER SET Used for removing reduction drive gear assem-
bly.
498077600 REMOVER Used for removing ball bearing. ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS
ST-499577000
ST-499737000
ST-499737100
ST-498077600

4AT-27
AUTOMATIC TRANSMISSION
General Description
498937110 HOLDER Used for removing and installing drive pinion lock
nut.
498677100 COMPRESSOR Used for installing 2-4 brake snap ring.
498437000 HIGH CLUTCH PIS-
TO N G UI DEUsed for installing high clutch piston.
498437100 LOW CLUTCH PIS-
TO N G UI DEUsed for installing low clutch piston. ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS
ST-498937110
ST-498677100
ST-498437000
ST-498437100

4AT-28
AUTOMATIC TRANSMISSION
General Description
899580100 INSTALLER Used for press-fitting the ball bearing for transfer
clutch.
18675AA000 DIFFERENTIAL OIL
SEAL INSTALLERUsed for installing differential side retainer oil
seal.
398497701 SEAT Used for installing needle bearing.
899524100 PULLER SET  Using the bolt only.
(1) BOLT
 Used with PULLER SET (499737100).
 Used with PULLER (499737000).
(1) Puller
(2) Cap ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS
ST-899580100
ST18675AA000
ST-398497701
ST-899524100
