Vehicle IdentificationChassis Serial Number
The chassis and/or engine serial numbers
are used to register the vehicle. They are
also used to assist your dealer when order-
ing or referring to special service informa-
tion. Whenever you have occasion to
consult your MARUTI SUZUKI authorized
dealer, remember to identify your vehicle
with this number. Should you find the num-
ber difficult to read, you will also find it on
the identification plate.Engine Serial Number
83K-10-00183K-10-002
EXAMPLE
83K-10-003
The engine serial number is stamped on the
cylinder block as shown in the illustration.
EXAMPLE
12-1

Downloaded from www.Manualslib.com manuals search engine 13283K
Radio frequency identification
(RFID) tag (if equipped)As per Ministry of Road Transport and
Highways, the Radio frequency identification
(RFID) tag (1) is mandatory for each vehicle
for the purpose of electronic toll collection or
any other purpose as may be defined by the
Government of India.
In case of any damage to RFID tag or
replacement of front windscreen, please
contact your nearest Maruti Suzuki Authorized
workshop.
Note:
RFID tag needs to be registered by
government authorized agency (if
applicable).
Any attempt to remove the tag from the
windscreen will result in permanent damage
to the tag.
Use of chemical cleaners to clean the
windscreen area where the tag is mounted
can damage the tag.
Use of any sharp objects on the tag can
damage the tag.
(1)
As seen from outside of the vehicle As seen from inside of the vehicleNote:
The picture shown is for indicative purpose
only. Internal structure of actual device
mounted on vehicle may be different. Note:
The picture shown is for indicative purpose
only. Internal structure of actual device
mounted on vehicle may be different.
GENERAL INFORMATION
12-1

Downloaded from www.Manualslib.com manuals search engine 13383KSPECIFICATIONSNOTE:ITEM: Dimensions UNIT: mmPetrol Diesel
A/T M/T M/T only
Overall length3775 3775 3775
Overall width1680/1687 1680/1687 1680/1687
Overall height1620 1620 1620
Wheelbase2360 2360 2360
Track front165 tyre1470 1470 1470
185 tyre -1460 1460
rear 165 tyre1480 1480 1480
185 tyre -1470 1470
Ground clearanpce 170 170 170ITEM: Mass (weight) UNIT: kgPetrol Diesel
AT MT M/T only
Curb mass (weight)1035 990~1030 1075~1125
Gross vehicle mass (weight) rating1430 143001520
Gross axle mass (weight) rating front 800 800 835
rear 800 800 800
SPECIFICATIONS
13-1
M/T: Manual TransmissionA/T: Automatic Transmission
Specifications are subject to change without notice.

Downloaded from www.Manualslib.com manuals search engine 13483K
ITEM: EnginePetrol Diesel
TypeK12M D13A
Number of cylinders44
Bore73.0 mm 69.6 mm
Stroke71.5 mm 82.0 mm
Piston displacement1197 cm3 1248 cm3
Compression ratio10.0 : 1 17.6 : 1ITEM: Electrical
Standard spark plugIridium plugNGK KR6A-10
BatteryPetrol34B20R
Diesel DIN 65
FusesSee “INSPECTION AND MAINTENANCE” section.SPECIFICATIONS
13-2

Downloaded from www.Manualslib.com manuals search engine 13583KITEM: LightsWATTAGEBULB No.
Headlight12V 60/55W H4
Turn signal light front 12V 21WWY21W
rear 12V 21WPY21W
Side turn signal light12V 5WWY5W
Clearance light12V 5W W5W
Brake/tail light12V 21/5WP21/5W
License plate light12V 5W W5W
Reversing light 12V 21WP21W
Interior light 12V 10W –
Front fog light 12V 35W H8
Rear fog light 12V 21WP21W
High mount stop light12V 5W W5W
SPECIFICATIONS
13-3
ITEM: SteeringPetrol Diesel
Toe-in Front (0 - 12’) / Rear (–5’ - 25’) Front (0 - 12’) / Rear (–5’ - 25’)
Camber angle Front (–1° - 1°) / Rear (–2° - 0°) Front (–1° - 1°) / Rear (–2° - 0°)
Caster angleFront (5° 06’ ± 2°) / Rear (-) Front (5° 06’ ± 2°) / Rear (-)

Downloaded from www.Manualslib.com manuals search engine 13683K
ITEM: Capacities (approx.)
CoolantPetrol M/T4.27 L
(including reservoir tank)A/T 4.9 L
Diesel M/T 5.9 L
Fuel tank 43 L
Engine oil Petrol/Diesel3.1 L (with filter)
Transmission oil M/T Petrol 2.2 L
Diesel 2.6 L
A/T 2.7 L (5.6 L when overhauling)SPECIFICATIONS
13-4ITEM: Wheel and Suspension
Tire Size 165/80R14 85S / 85T 185/70R14 88S
Rim Size14X5J 14X5.5J
Front Rear Front Rear
Tire Pressure (kg/cm2) Petrol MT 2.0 2.0
AT2.3 2.3
——
Diesel MT 2.5 2.3 2.2 2.0
