AB0158
SSTBattery
AB0152
SST
AB0158
SSTBattery
H01580
SST
H11075
BO-132
- BODYSEAT BELT PRETENSIONER
1917 Author: Date:
2001 AVALON (RM808U)
1. SEAT BELT PRETENSIONER ACTIVATION WHEN
SCRAPPING VEHICLE
HINT:
Have a battery ready as the power source to activate the seat
belt pretensioner.
(a) Check the functioning of SST.
CAUTION:
When activating the seat belt pretensioner, always use the
specified SST: SRS Airbag Deployment Tool.
SST 09082-00700, 09082-00740
(1) Connect the SST to the battery.
Connect the red clip of the SST to the battery posi-
tive (+) terminal and the black clip to the battery neg-
ative (-) terminal.
HINT:
Do not connect the yellow connector which will be connected
with the seat belt pretensioner.
(2) Press the SST activation switch, and check the LED
of the SST activation switch lights up.
CAUTION:
If the LED lights up when the activation switch is not being
pressed, SST malfunction is probable, so definitely do not
use the SST.
(b) Disconnect the pretensioner connector.
(1) Remove the front door scuff inside plate.
(2) Remove lower center pillar garnish.
(3) Disconnect the pretensioner connector as shown in
the illustration.
(c) Install the SST.
(1) Buckle the front seat belt and check that there is no
looseness and slack in the front seat inner belt and
front seat outer belt.
Page 452 of 1897
H11079
SST SST
Battery
R13455
10 m (33 ft) or moreSSTBattery
- BODYSEAT BELT PRETENSIONER
BO-133
1918 Author: Date:
2001 AVALON (RM808U)
(2) Connect the 2 SST, then connect them to the seat
belt pretensioner.
SST 09082-00700, 09082-00740
NOTICE:
To avoid damaging the SST connector and wire harness,
do not lock the secondary lock of the twin lock.
(3) Move the SST to at least 10 m (33 ft) away from the
front of the vehicle.
(4) Close all the doors and windows of the vehicle.
NOTICE:
Take care not to damage the SST wire harness.
(5) Connect the SST red clip to the battery positive (+)
terminal and the black clip to the negative (-) termi-
nal.
(d) Activate the seat belt pretensioner.
(1) Confirm that no one is inside the vehicle or within 10
m (33 ft) area around the vehicle.
(2) Press the SST activation switch and activate the
seat belt pretensioner.
HINT:
The seat belt pretensioner operates simultaneously as the LED
of the SST activation switch lights up.
(e) Dispose of the front seat outer belt (with seat belt preten-
sioner).
CAUTION:
The front seat outer belt is very hot when the seat belt
pretensioner is activated, so leave it alone for at least
30 minutes after activation.
Use gloves and safety glasses when handling a front
seat outer belt with the activated seat belt pretension-
er.
Always wash your hands with water after completing
the operation.
Do not apply water, etc. to a front seat outer belt with
the activated seat belt pretensioner.
HINT:
When scrapping a vehicle, activate the seat belt pretensioner
and scrap the vehicle with the activated front seat outer belt still
installed.
2. ACTIVATION WHEN DISPOSING OF FRONT SEAT
OUTER BELT ONLY
NOTICE:
When disposing of the front seat outer belt (with seat
belt pretensioner) only, never use the customer's ve-
hicle to activate the seat belt pretensioner.
Page 453 of 1897
AB0158
SSTBattery
H11079
SST SST
Battery
H11080SST SST BO-134
- BODYSEAT BELT PRETENSIONER
1919 Author: Date:
2001 AVALON (RM808U)
Be sure to follow the procedure given on the next
page when activating the seat belt pretensioner.
HINT:
Have a battery ready as the power source when activating the
seat belt pretensioner.
(a) Remove the front seat outer belt (See page BO-128).
HINT:
Cut the belt near the seat belt retractor.
(b) Check the functioning of SST (See step 1-(a)).
SST 09082-00700, 09082-00740
(c) Install the SST.
(1) Connect the 2 SST, then connect them to the seat
belt pretensioner.
SST 09082-00700, 09082-00740
NOTICE:
To avoid damaging the SST connector and wire harness,
do not lock the secondary lock of the twin lock.
(2) Place the front seat outer belt on the ground and
cover it with the disc wheel with tire.
NOTICE:
Place the front seat outer belt as shown in the illustration.
(3) Move the SST at least 10 m (33 ft) away from the
disc wheel.
NOTICE:
Take care not to damage the SST wire harness.
(d) Activate the seat belt pretensioner.
(1) Connect the SST red clip to the battery positive (+)
terminal and black clip to the battery negative (-)
terminal.
(2) Check that no one is within 10 m (33 ft) area around
the disc wheel.
(3) Press the SST activation switch and activate the
seat belt pretensioner.
Page 454 of 1897
R05181
10 m (33 ft) or more
SSTBattery
H11081
- BODYSEAT BELT PRETENSIONER
BO-135
1920 Author: Date:
2001 AVALON (RM808U)
HINT:
The seat belt pretensioner operates simultaneously as the LED
of the SST activation switch lights up.
(e) Dispose of the front seat outer belt (with seat belt preten-
sioner).
CAUTION:
The front seat outer belt is very hot when the seat belt
pretensioner is activated, so leave it alone for at least
30 minutes after activation.
Use gloves and safety glasses when handling a front
seat outer belt with the activated seat belt pretension-
er.
Always wash your hands with water after completing
the operation.
Do not apply water, etc. to a front seat outer belt with
the activated seat belt pretensioner.
(1) Remove the disc wheel and SST.
(2) Place the front seat outer belt in a vinyl bag, tie the
end tightly and dispose of it in the same way as oth-
er general parts.
Page 455 of 1897
BO2QL-01
H03712
H12223
H11078
H12223
BO-130
- BODYSEAT BELT PRETENSIONER
1915 Author: Date:
2001 AVALON (RM808U)
INSPECTION
1. PRETENSIONER IS NOT ACTIVATED
(a) Perform a diagnostic system check (See page DI-349).
(b) Perform a visual check which includes the following items
with the front seat outer belt removed from the vehicle.
Check for cuts and cracks in, or marked discolor-
ation on the front quarter trim or center pillar lower
garnish.
Check for cuts and cracks in wire harness, and for
chipping in connectors.
Check for deformation of the quarter panel or center
pillar.
Check for cuts and minute cracks in wire harness or
marked discoloration on the front seat outer belt.
CAUTION:
For removal and installation of the front seat outer belt, see
page BO-128 and BO-137.
Be sure to follow the correct procedure.
2. PRETENSIONER IS ACTIVATED
(a) Perform a diagnostic system check (See page DI-349).
(b) Perform a visual check which includes the following items
with the front seat outer belt removed from the vehicle.
Check for deformation of the quarter panel or center
pillar.
Check for damage on the connector and wire har-
ness.
Page 456 of 1897
BO2QO-01
H11075
- BODYSEAT BELT PRETENSIONER
BO-137
1922 Author: Date:
2001 AVALON (RM808U)
INSTALLATION
NOTICE:
Never use seat belt pretensioner from another ve-
hicle. When replacing parts, replace them with new
parts.
Make sure that the front seat outer belt is installed in
the specified torque.
If the front seat outer belt has been dropped, or there
are cracks, dents or any identified other defects in the
case or connector, replace the front seat outer belt
with a new one.
When installing the front seat outer belt, take care that
the wiring does not interfere with other parts and is
not pinched between other parts.
1. INSTALL RETRACTOR OF FRONT SEAT OUTER BELT
(a) Install the retractor of front seat outer belt with the 2 bolts.
Torque:
Upper bolt: 7.5 N´m (76 kgf´cm, 66 in.´lbf)
Lower bolt: 41 N´m (420 kgf´cm, 30 ft´lbf)
(b) Connect the pretensioner connector as shown in the il-
lustration.
2. INSTALL FRONT SEAT OUTER BELT SHOULDER AN-
CHOR
Torque: 41 N´m (420 kgf´cm, 30 ft´lbf)
3. INSTALL CENTER PILLAR GARNISH
4. INSTALL LOWER CENTER PILLAR GARNISH
5. INSTALL FRONT SEAT OUTER BELT FLOOR AN-
CHOR
Torque: 41 N´m (420 kgf´cm, 30 ft´lbf)
6. INSTALL FRONT DOOR SCUFF INSIDE PLATE
Page 457 of 1897
BO2QK-01
H12175
H12198
H12199
:5 Clips
H12200Clip BO-128
- BODYSEAT BELT PRETENSIONER
1913 Author: Date:
2001 AVALON (RM808U)
SEAT BELT PRETENSIONER
REMOVAL
NOTICE:
If the wiring connector of the seat belt pretensioner is
disconnected with the ignition switch at ON or ACC,
diagnostic trouble codes will be recorded.
Never use SRS parts from another vehicle. When re-
place parts, replace them with new parts.
1. REMOVE FRONT DOOR SCUFF INSIDE PLATE
Remove the front door scuff inside plate.
2. REMOVE LOWER CENTER PILLAR GARNISH
(a) Using a screwdriver, remove the lap belt outer anchor
cover.
(b) Remove the front seat outer belt floor anchor.
(c) Remove the lower center pillar garnish as shown in the il-
lustration.
3. REMOVE CENTER PILLAR GARNISH
(a) Remove the 2 clips.
(b) Using a screwdriver, remove the center pillar garnish.
HINT:
Tape the screwdriver tip before use.
4. REMOVE FRONT SEAT OUTER BELT SHOULDER AN-
CHOR
5. REMOVE RETRACTOR OF FRONT SEAT OUTER
BELT
Page 458 of 1897
H11075
- BODYSEAT BELT PRETENSIONER
BO-129
1914 Author: Date:
2001 AVALON (RM808U)
CAUTION:
Never disassemble the front seat outer belt.
NOTICE:
When removing the retractor of front seat outer belt, take
care not to pull the seat belt pretensioner wire harness.
(a) Disconnect the pretensioner connector as shown in the
illustration.
CAUTION:
When removing the seat belt pretensioner, work must be
started 90 seconds after the ignition switch is turned to the
ºLOCKº position and negative (-) terminal cable is discon-
nected from the battery.
(b) Remove the 2 bolts and retractor of front seat outer belt.
Page 459 of 1897
BO2QN-01
BO-136
- BODYSEAT BELT PRETENSIONER
1921 Author: Date:
2001 AVALON (RM808U)
REPLACEMENT
REPLACE REQUIREMENTS
In the following cases, replace the seat belt pretensioner.
If the seat belt pretensioner has been activated.
If the seat belt pretensioner has been found to be faulty in troubleshooting.
If the front seat outer belt has been found to be faulty during checking item 1-(b) or 2-(b)
(See page BO-130).
If the front seat outer belt has been dropped.
CAUTION:
For removal and installation of the seat belt pretensioner, see page BO-128 and BO-137.
Be sure to follow the correct procedure.
Page 460 of 1897
BO2QI-01
H12221
Lower Center Pillar Garnish
Front Seat
Inner Belt
Front Seat Center Belt Front Seat
Front Seat Adjustable Anchor
Center Pillar Garnish
Front Door Scuff
Inside Plate
Manual seat:
Front Seat
Inner Belt
Front Seat Outer Belt
Lap Belt Outer
Anchor Cover
Bench type:
Front Seat Inner Belt
41 (420, 30)
41 (420, 30)
41 (420, 30)
41 (420, 30)
41 (420, 30)
41 (420, 30)
41 (420, 30)
41 (420, 30)
Front Seat Inner Belt
7.5 (76, 66 in.´lbf)
: Specified torqueN´m (kgf´cm, ft´lbf) BO-124
- BODYSEAT BELT
1909 Author: Date:
2001 AVALON (RM808U)
SEAT BELT
COMPONENTS
