TOYOTA BZ4X 2022 Owners Manual (in English)

449
6
Owners Manual_Europe_M42D76_en
6-4. Using the other interior features
Interior features
■The wireless charger can be oper- ated when
The power switch is in ACC or ON.
■Portable devices that can be charged
●Portable devices compatible with the Qi wireless charging standard can be charged by the wireless charger. How-
ever, compatibility with all devices which meet the Qi wireless charging
Green (comes on)Blue
AM radio stations are being automat-
ically selected
 Wait until the system has com-
pleted the automatic selection of
AM radio stations. In the case that
automatic selection cannot be
completed, stop automatic selec-
tion.
The smart entry & start system is
detecting the key
 Please wait until the key detection
is complete.
Orange (Repeat-
edly flashes 3 times
continuously)
Gray
Foreign substance detection:
A metallic foreign substance is in the
charge area, and so the abnormal
heating prevention function of the
charging coil operated
 Remove the foreign substance
from the charge area.
Portable device misaligned:
 The charging coil in the portable
device moved outside of the
charge area, and so the abnormal
heating prevention function of the
charging coil operated
Orange (Repeat-
edly flashes 4 times
continuously)
Gray
Safety shutdown resulting when the
temperature within the wireless char-
ger exceeded the set value
 Stop charging, remove the porta-
ble device from the charging tray,
wait for the temperature to drop,
and then start charging again.
Operation indicator
light
Multimedia system
screenSuspected causes/Handling method

450
Owners Manual_Europe_M42D76_en
6-4. Using the other interior features
standard is not guaranteed.
●The wireless charger is designed to supply low power electricity (5 W or
less) to a cellular phone, smartphone, or other portable device.
●Failure to do so may result in the pos-sibility of fire, However, portable devices, such as the following, can be
charged with more than 5 W. • 7.5 W charging compatible iPhones can be charged at 7.5 W or less.
• Portable devices which conform to WPC Ver 1.2.4 (Extended Power pro-file) can be charged at 10 W or less.
■When covers and accessories are
attached to portable devices
Do not charge in situations where cover and accessories not able to handle Qi
are attached to the portable device. Depending on the type of cover (includ-ing for certain genuine manufacturer
parts) and accessory, it may not be pos- sible to charge.When charging is not performed even
with the portable device placed on the charge area, remove the cover and accessories.
■Charging precautions
●If the electronic key cannot be detected in the cabin, charging cannot
be performed. When a door is opened and closed, charging may be tempo-rarily suspended.
●While charging, the wireless charger and the portable device will become
warm. This is not a malfunction. If a portable device becomes warm while charging and charging stops
due to the protection function of the portable device, wait until the portable device cools down and charge it
again.
●Depending on usage of the portable
device, it may not be fully charged. This is not a malfunction.
■Important points of the wireless charger
●If the electronic key cannot be
detected within the vehicle interior,
charging can not be done. When the door is opened and closed, charging may be temporarily suspended.
●When charging, the wireless charging device and portable device will get
warmer, however this is not a mal- function. When a portable device gets warm while charging may stop due to
the protection function on the portable device side. In this case, when the temperature of the portable drops sig-
nificantly, charge again. The fan may start operating to lower the temperature inside the wireless
charger, however this is not a mal- function.
■Sound generated during operation
When the power supply switch is turned
on or while a portable device is being identified, operation sounds may be heard. This is not a malfunction.
■Cleaning the wireless charger
 P. 4 6 0
■Certification
 P. 6 6 2
WARNING
■Caution while driving
When charging a portable device, for safety reasons, the driver should not operate the main part of the portable
device while driving.
■Caution while in motion
Do not charge lightweight devices such as wireless headphones while in motion. These devices are very light
and may be ejected from the charging tray, which may lead to unforeseen accidents.

451
6
Owners Manual_Europe_M42D76_en
6-4. Using the other interior features
Interior features
WARNING
■Caution regarding interference with electronic devices
People with implantable cardiac pace- makers, cardiac resynchronization therapy-pacemakers or implantable
cardioverters, as well as any other electrical medical device, should con-sult their physician about the usage of
the wireless charger.
■To prevent malfunctions or burns
Observe the following precautions. Failure to do so may result in a equip-ment failure and damage, catch fire,
burns due to overheat or electric shock.
●Do not insert any metallic objects
between the charge area and the portable device while charging
●Do not attach an aluminum sticker or other metallic object to the charge area
●Do not attach an aluminum sticker or other metallic object to the side
of the portable device (or to its case or cover) that touches the charge area
●Do not use the charging tray as a small storage space
●Do not subject to a strong force or impact
●Do not disassemble, modify or remove
●Do not charge devices other than specified portable devices
●Keep away from magnetic items
●Do not charge devices if the charge area is covered in dust
●Do not cover with a cloth or similar material
NOTICE
■Situations in which the function may not operate normally
Devices may not be charged normally in the following situations.
●The portable device is fully charged
●The portable device is being charged with a cable connected
●There is foreign matter between the charge area and portable device
●Charging has caused the portable device to heat up
●The temperature around the charging tray is 35°C (95°F) or
higher, such as in extreme heat
●The portable device is placed with
its charging side facing up
●The portable device is placed in an
area misaligned from the charge area
●The portable device is larger than the charging tray
●A foldable and portable device is placed outside the charge area
●The camera lens protrudes 3 mm. (0.12 in) or more from the surface of the portal device
●The vehicle is in an area where strong electrical waves or noise are
emitted, such as near a television tower, power plant, gasoline station, broadcasting station, large display,
airport, etc.
●Any of the following objects that is
protrudes 3 mm. (0.12 in) or thicker is stuck or installed between the charging side of the portable device
and the charge area.
• Thick cases or covers

452
Owners Manual_Europe_M42D76_en
6-4. Using the other interior features
Fold down the armrest for use.
NOTICE
• A case or cover attached with an uneven or tilted surface, so that the
charging side is not flat
• Thick decorations
• Accessories, such as finger rings, straps, etc.
●When the portable device is in con-tact with, or is covered by any of the
following metallic objects:
• A card that has metal on it, such as
aluminum foil, etc.
• A pack of cigarettes that includes
aluminum foil
• A wallet or bag that is made of
metal
•Coins
• A heating pad
• CDs, DVDs or other media
• A metal accessory
• A case or cover made of metal
●Electric wave type wireless remote controls are being used nearby
●The electronic key is not inside the vehicle
●2 or more portable devices are placed on the charging tray at the same time
If charging is abnormal or the opera- tion indicator light continues to flash
for any other reason, the wireless charger may be malfunctioning. Con-tact any authorized Toyota retailer or
Toyota authorized repairer, or any reli- able repairer.
■To prevent malfunctions and data corruptions
●When charging, bringing a credit, or
other magnetic card, or magnetic storage media close to the charge area may clear any stored data due
to magnetic influence. Also, do not bring a wristwatch or other preci-sion instrument close to the charge
area since doing so may cause it to malfunction.
●Do not charge with a non-contact IC card such as a transportation sys-tem IC card inserted between the
charging side of a portable device and the charge area. The IC chip may become extremely hot and
damage the portable device or IC card. Be especially careful not to charge a portable device inside a
case or cover with a non-contact IC card attached.
●Do not leave portable devices inside the vehicle. The inside of the vehicle can become hot in extreme
heat, which could cause a malfunc- tion.
■If the smartphone OS has been updated
If the smartphone OS has been
updated to a newer version, its charging specifications may have changed significantly.
For details, check the information on the manufacturer’s website.
■To prevent 12-volt battery dis-charge
Do not use the wireless charger for a
long period of time when the EV sys- tem is stopped.
Armrest

453
6
Owners Manual_Europe_M42D76_en
6-4. Using the other interior features
Interior features
The coat hooks are provided with
the rear assist grips.
An assist grip installed on the ceil-
ing can be used to support your
body while sitting on the seat.
NOTICE
■To prevent damage to the arm- rest
Do not apply too much load on the armrest.
Coat hooks
WARNING
■Items that must not be hung on the hook
Do not hang coat hangers or other hard or sharp objects on the hook. If the SRS curtain shield airbags deploy,
these items may become projectiles, causing death or serious injury.
Assist grips
WARNING
■Assist grips
Do not use the assist grip when get- ting in or out of the vehicle or rising
from your seat.
NOTICE
■To prevent damage to the assist grip
Do not hang any heavy object or put a
heavy load on the assist grip.

454
Owners Manual_Europe_M42D76_en
6-4. Using the other interior features

7
455
Owners Manual_Europe_M42D76_en
7
Maintenance and care
Maintenance and care
7-1. Maintenance and care
Cleaning and protecting the
vehicle exterior ............... 456
Cleaning and protecting the
vehicle interior ................ 459
7-2. Maintenance
Maintenance requirements 463
7-3. Do-it-yourself maintenance
Do-it-yourself service precau-
tions ................................ 465
Hood ................................. 467
Positioning a floor jack...... 468
Motor compartment .......... 470
Tires .................................. 476
Replacing the tire.............. 488
Tire inflation pressure ....... 494
Wheels.............................. 495
Air conditioning filter ......... 496
Electronic key battery ....... 499
Checking and replacing fuses
....................................... 501
Light bulbs ........................ 504

456
Owners Manual_Europe_M42D76_en
7-1. Maintenance and care
7-1.Mainte nance a nd care
Working from top to bottom, lib-
erally apply water to the vehicle
body, wheel wells and underside
of the vehicle to remove any dirt
and dust.
 Wash the vehicle body using a
sponge or soft cloth, such as a
chamois.
 For hard-to-remove marks, use
car wash soap and rinse thor-
oughly with water.
 Wipe away any water.
 Wax the vehicle when the water-
proof coating deteriorates.
If water does not bead on a clean sur-
face, apply wax when the vehicle body
is cool.
■Self-restoring coat
The vehicle body has a self-restoring coating that is resistant to small surface scratches caused in a car wash, etc.
●The coating lasts for 5 to 8 years from when the vehicle is delivered from the
plant.
●The restoration time differs depending
on the depth of the scratch and out- side temperature. The restoration time may become shorter when the coating
is warmed by applying warm water.
●Deep scratches caused by keys,
coins, etc., cannot be restored.
●Do not use wax that contain abra- sives.
■Automatic car washes
●Before washing the vehicle:• Fold the mirrors
• Turn off the power back door (if equipped)
Start washing from the front of the vehi-
cle. Extend the mirrors before driving.
●Brushes used in automatic car washes may scratch the vehicle sur-face, parts (wheel, etc.) and harm
your vehicle’s paint.
●Rear spoiler (if equipped) may not be
washable in some automatic car washes. There may also be an increased risk of damage to vehicle.
●When the shift position needs to be held in N, refer to P.251.
■High pressure car washes
As water may enter the cabin, do not bring the nozzle tip near the gaps around the doors or perimeter of the
windows, or spray these areas continu- ously.
■Note for a smart entry & start sys-tem
●If the door handle becomes wet while the electronic key is within the effec-
tive range, the door may lock and unlock repeatedly. In that case, follow the following correction procedures to
wash the vehicle: • Place the key in a position 2 m (6 ft.) or more separate from the vehicle
while the vehicle is being washed. (Take care to ensure that the key is not stolen.)
• Set the electronic key to battery-sav- ing mode to disable the smart entry & start system ( P.204)
●If the electronic key is inside the vehi- cle and a door handle becomes wet
during a car wash, a buzzer may sound outside the vehicle and “Key Detected In Vehicle” may be shown
Cleaning and protecting
the vehicle exterior
Perform cleaning in a manner
appropriate to each compo-
nent and its material.
Cleaning instructions

457
7
Owners Manual_Europe_M42D76_en
7-1. Maintenance and care
Maintenance and care
on the multi-information display. To
turn off the alarm, lock all the doors.
■Wheels and wheel ornaments
●Remove any dirt immediately by using
a neutral detergent.
●Wash detergent off with water immedi-
ately after use.
●To protect the paint from damage,
make sure to observe the following precautions.• Do not use acidic, alkaline or abrasive
detergent. • Do not use hard brushes.• Do not use detergent on the wheels
when they are hot, such as after driv- ing or parking in hot weather.
■Painted brake calipers (if equipped)
●When using detergent, use neutral detergent. Do not use hard brushes or abrasive cleaners, as they will dam-
age the paint.
●Do not use detergent on the brake cal-
ipers when they are hot.
●Wash detergent off immediately after
use.
■Brake pads and calipers
Rust may form if the vehicle is parked with wet brake pads or disc rotors, caus-
ing them to stick. Before parking the vehicle after it is washed, drive slowly and apply the brakes several times to
dry the parts.
■Bumpers
Do not scrub with abrasive cleaners.
■Plated portions
If dirt cannot be removed, clean the
parts as follows:
●Use a soft cloth dampened with an
approximately 5% solution of neutral detergent and water to clean the dirt off.
●Wipe the surface with a dry, soft cloth to remove any remaining moisture.
●To remove oily deposits, use alcohol wet wipes or a similar product.
WARNING
■When washing the vehicle
Do not apply water to the inside of the
motor compartment. Doing so may cause the electrical components, etc. to catch fire.
■When cleaning the windshield (vehicles with rain-sensing wind-
shield wipers)
Set the wiper switch to off. If the wiper switch is in AUTO, the
wipers may operate unexpectedly in the following situations, and may result in hands being caught or other
serious injuries and cause damage to the wiper blades.
Off
AUTO
●When the upper part of the wind- shield where the raindrop sensor is
located is touched by hand
●When a wet rag or similar is held
close to the raindrop sensor
●If something bumps against the
windshield
●If you directly touch the raindrop
sensor body or if something bumps into the raindrop sensor

458
Owners Manual_Europe_M42D76_en
7-1. Maintenance and care
WARNING
■Precaution regarding the rear bumper
If the paint of the rear bumper is chipped or scratched, the following systems may not function correctly. If
this occurs, consult any authorized Toyota retailer or Toyota authorized repairer, or any reliable repairer.
●Toyota Safety Sense
●BSM (if equipped)
●RCTA (if equipped)
●PKSB (if equipped)
NOTICE
■To prevent paint deterioration
and corrosion on the body and components (aluminum wheels, etc.)
●Wash the vehicle immediately in the following cases:
• After driving near the sea coast
• After driving on salted roads
• If coal tar or tree sap is present on
the paint surface
• If dead insects, insect droppings or
bird droppings are present on the paint surface
• After driving in an area contami- nated with soot, oily smoke, mine dust, iron powder or chemical sub-
stances
• If the vehicle becomes heavily
soiled with dust or mud
• If liquids such as benzene and gas-
oline are spilled on the paint sur- face
●If the paint is chipped or scratched, have it repaired immediately.
●To prevent the wheels from corrod-ing, remove any dirt and store in a place with low humidity when stor-
ing the wheels.
■Cleaning the exterior lights
●Wash carefully. Do not use organic substances or scrub with a hard brush.
This may damage the surfaces of the lights.
●Do not apply wax to the surfaces of the lights.Wax may cause damage to the
lenses.
■When using an automatic car
wash (vehicles with rain-sensing windshield wipers)
Set the wiper switch to the off posi-
tion. If the wiper switch is in AUTO, the wipers may operate and the wiper
blades may be damaged.
■When using a high pressure car
wash
●When washing the vehicle, do not spray the camera or its surrounding
area directly with a high pressure washer. Shock applied from high pressure water may cause the
device to not operate normally.
●Do not spray water directly on the
radar which is equipped behind the radar sensor cover. Otherwise it may cause the device to be dam-
aged.
●Do not bring the nozzle tip close to
boots (rubber or resin manufac- tured cover), connectors or the fol-lowing parts. The parts may be
damaged if they come into contact with high-pressure water.
• Traction related parts
• Steering parts
• Suspension parts
• Brake parts
