811-4. Theft deterrent system
1
For safety and security
C-HR_OM_USA_OM10634U
Engine immobilizer system
Vehicles without a smart key sys-
tem:
The indicator light flashes after
the key has been removed from
the engine switch to indicate that
the system is operating.
The indicator light stops flashing
after the registered key has been
inserted into the engine switch to
indicate that the system has been
canceled.
Vehicles with a smart key system:
The indicator light flashes after the engine switch has been tu rned off
to indicate that the sy stem is operating.
The indicator light stops flashi ng after the engine switch has been
turned to ACCESSORY or IGNITION ON mode to indicate that the
system has been canceled.
The vehicle’s keys ha ve built-in transponder chips that prevent
the engine from starting if a key has not been previously regis -
tered in the vehicle’s on-board computer.
Never leave the keys inside the vehicle when you leave the vehi-
cle.
This system is designed to help prevent vehicle theft but does
not guarantee absolute security against all vehicle thefts.

821-4. Theft deterrent system
C-HR_OM_USA_OM10634U
■System maintenance
The vehicle has a maintenance-free type engine immobilizer syst em.
■ Conditions that may cause the system to malfunction
●If the grip portion of the key is in contact with a metallic ob ject
● If the key is in close proximity to or touching a key to the security system
(key with a built-in transponder chip) of another vehicle
■ Certifications for the engine immobilizer system
For vehicles sold in the U.S.A.
For vehicles sold in Canada

831-4. Theft deterrent system
1
For safety and security
C-HR_OM_USA_OM10634U
For vehicles sold in the U.S.A.
For vehicles sold in Canada
NOTICE
■To ensure the system operates correctly
Do not modify or remove the system. If modified or removed, the proper
operation of the system cannot be guaranteed.

841-4. Theft deterrent system
C-HR_OM_USA_OM10634U

85
Instrument cluster2
C-HR_OM_USA_OM10634U2. Instrument cluster
Warning lights and indicators .......................... 86
Gauges and meters ............ 94
Multi-information display ..... 97
Fuel consumption information ...................... 105

862. Instrument cluster
C-HR_OM_USA_OM10634U
Warning lights and indicators
The units used on the meters and some indicators may differ depending on
the target region.
The warning lights and indicators on the instrument cluster and
center panel inform the driver of the status of the vehicle’s vari-
ous systems.
For the purpose of explanation, t he following illustration dis-
plays all warning lights a nd indicators illuminated.

872. Instrument cluster
2
Instrument cluster
C-HR_OM_USA_OM10634U
Warning lights inform the driver of malfunctions in the indicated vehi-
cle’s systems.
Warning lights
Warning lightsPages
*1Brake system warning light (red) (U.S.A.) P. 421
*1Brake system warning light (red) (Canada) P. 421
*1Malfunction indicator lamp (U.S.A.) P. 422
*1Malfunction indicator lamp (Canada)P. 422
*1SRS warning light P. 422
*1ABS warning light (U.S.A.)P. 422
*1ABS warning light (Canada)P. 422
*1Electric power steering system warning light
(red) P. 422
*1Electric power steering system warning light
(yellow)P. 422
*2“RCTA OFF” indicator (if equipped)
P. 422
*1, 3Slip indicator lightP. 423
*1Brake system warning light (yellow)P. 423
*1PCS warning light P. 423

882. Instrument cluster
C-HR_OM_USA_OM10634U
*1: These lights turn on when the engine switch is turned to the “ON” position
(vehicles without a smart key system) or IGNITION ON mode (vehicles
with a smart key system) to indicate that a system check is being per-
formed. They will turn off after the engine is started, or after a few seconds.
There may be a malfunction in a system if a light does not come on, or if
the lights do not turn off. Have the vehicle inspected by your Toyota dealer.
*2: The light flashes to indicate a malfunction.
*3: The light comes on to indicate a malfunction.
*2Parking brake indicator (U.S.A.)P. 423
*2Parking brake indicator (Canada)P. 423
Low fuel level warning lightP. 423
Driver’s and front passenger’s seat belt
reminder light P. 424
Rear passengers’ seat belt reminder lights (on
the center panel)
P. 424
*1Tire pressure warning light
P. 424
Warning lightsPages

892. Instrument cluster
2
Instrument cluster
C-HR_OM_USA_OM10634U
The indicators inform the driver of the operating state of the vehicle’s
various systems.
Indicators
IndicatorsPages
Turn signal indicator P. 193
Headlight indicator (U.S.A.) P. 202
Tail light indicator (Canada)P. 202
Front fog light indicator (if equipped) P. 212
Headlight high beam indicatorP. 203
Automatic High Beam indicator P. 207
Parking brake indicator (U.S.A.) P. 194
Parking brake indicator (Canada)P. 194
*1, 2BSM OFF indicator (if equipped)P. 269
*1BSM outside rear view mirror indicator
(on the outside rear view mirrors) (if equipped)P. 269,
278
*2“RCTA OFF” indicator (if equipped) P. 278
Security indicator (on the center panel) P. 81
*1, 3Slip indicator lightP. 287

902. Instrument cluster
C-HR_OM_USA_OM10634U
*1: These lights turn on when the engine switch is turned to the “ON” position
(vehicles without a smart key system) or IGNITION ON mode (vehicles
with a smart key system) to indicate that a system check is being per-
formed. They will turn off after the engine is started, or after a few seconds.
There may be a malfunction in a system if a light does not come on, or if
the lights do not turn off. Have the vehicle inspected by your Toyota dealer.
*2: The light turns on when the system is off.
*3: The light flashes to indicate that the system is operating.
*1, 2VSC off indicatorP. 287
*1, 2PCS warning lightP. 232
*1“AIR BAG ON/OFF” indicator (U.S.A.)
(on the center panel) P. 46
*1“AIR BAG ON/OFF” indicator (Canada)
(on the center panel)P. 46
IndicatorsPages
