TOYOTA CAMRY 1994 XV10 / 4.G Wiring Diagrams Workshop Manual

171
CURRENT ALWAYS FLOWS TO TERMINAL 1 OF THE INTEGRATION RELAY THROUGH THE DOME FUSE.
1. SEAT BELT WARNING SYSTEM
WHEN THE IGNITION SW IS TURNED ON, CURRENT FLOWS FROM THE GAUGE FUSE TO THE TERMINAL 7 OF THE INTEGRATION
RELAY AT THE SAME TIME, CURRENT FLOWS TO TERMINAL 9 OF THE RELAY FROM THE GAUGE FUSE THROUGH THE SEAT BELT
WARNING LIGHT. THIS CURRENT ACTIVATES THE SEAT BELT WARNING RELAY AND, CURRENT FLOWING THROUGH THE WARNING
LIGHT FLOWS FROM TERMINAL 9 OF THE RELAY" TERMINAL 10 " GROUND, CAUSING THE WARNING LIGHT TO LIGHT UP. AT THE
SAME AS THE WARNING LIGHT LIGHTS UP. A BUCKLE SW OFF SIGNAL IS INPUT TO TERMINAL 8 OF THE RELAY, THE CURRENT
FLOWING TO TERMINAL 1 OF THE RELAY FLOWS FROM TERMINAL 10 " GROUND AND THE SEAT BELT WARNING BUZZER SOUNDS
FOR APPROX. 4±8 SECONDS. HOWEVER, IF SEAT BELT IS PUT ON DURING THIS PERIOD (WHILE THE BUZZER IS SOUNDING),
SIGNAL INPUT TO TERMINAL 8 OF THE RELAY STOPS AND THE CURRENT FLOW FROM TERMINAL 1 OF THE RELAY " TERMINAL 10
" GROUND IS CUT, CAUSING THE BUZZER TO STOP.
2. UNLOCK WARNING SYSTEM
WITH THE IGNITION KEY INSERTED IN THE KEY CYLINDER (UNLOCK WARNING SW ON), THE IGNITION SW STILL OFF AND DOOR
OPEN (DOOR COURTESY SW ON), WHEN A SIGNAL IS INPUT TERMINAL 5 AND 6 OF THE RELAY, THE INTEGRATION RELAY
OPERATES, CURRENT FLOWS FROM TERMINAL 1 OF THE RELAY " TERMINAL 10 " GROUND AND THE UNLOCK WARNING
BUZZER SOUNDS.
B 7, B 8 BUCKLE SW
1±2 : CLOSED WITH DRIVR'S LAP BELT IN USE
D12 DOOR COURTESY SW FRONT LH
1±GROUND : CLOSED WITH FRONT LH DOOR OPEN
INTEGRATION RELAY
10±GROUND : ALWAYS CONTINUITY
6±GROUND : CONTINUITY WITH FRONT LH DOOR OPEN
5±GROUND : CONTINUITY WITH IGNITION KEY IN CYLINDER
8±GROUND : CONTINUITY UNLESS DRIVER'S LAP BELT IN USE
9±GROUND :0 VOLTS WITH IGNITION SW ON AND BUCKLE SW OFF
1±GROUND : ALWAYS APPROX. 12 VOLTS
7±GROUND : APPROX. 12 VOLTS WITH IGNITION SW AT ON POSITION
I12 UNLOCK WARNING SW [IGNITION SW]
1±5 : CLOSED WITH IGNITION KEY IN CYLINDER
: PARTS LOCATION
CODESEE PAGECODESEE PAGECODESEE PAGE
B 732D1234 (S/D), 35 (C/P), 36 (W/G)J 536 (W/G)
B 832I1233
C 932J 133
: JUNCTION BLOCK AND WIRE HARNESS CONNECTOR
CODESEE PAGEJUNCTION BLOCK AND WIRE HARNESS (CONNECTOR LOCATION)
1B
1C20COWL WIRE AND J/B NO. 1 (INSTRUMENT PANEL LEFT)
1G
20COWL WIRE AND J/B NO. 1 (INSTRUMENT PANEL LEFT)
1H20FLOOR NO. 1 WIRE J/B NO. 1 (INSTRUMENT PANEL LEFT)
1M20COWL WIRE AND J/B NO. 1 (INSTRUMENT PANEL LEFT)
2E22ENGINE ROOM MAIN WIRE AND J/B NO. 2 (ENGINE COMPARTMENT LEFT)
: CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS
CODESEE PAGEJOINING WIRE HARNESS AND WIRE HARNESS (CONNECTOR LOCATION)
IO142FLOOR NO. 1 WIRE AND SEAT WIRE
: GROUND POINTS
CODESEE PAGEGROUND POINTS LOCATION
IG42INSTRUMENT PANEL BRACE LH
46 (S/D)
BL48 (C/P)UNDER THE LEFT QUARTER PILLARBL
50 (W/G)
UNDER THE LEFT QUARTER PILLAR
SYSTEM OUTLINE
SERVICE HINTS

172
UNLOCK AND SEAT BELT WARNING

173
HORN
10
11
G±B
G±W
G±W FROM POWER SOURCE SYSTEM(
SEE PAGE 64)
HORN SW
[COMB. SW]
HORN
LHHORN
RH C12
H5 H6
2G 52A3 10A
HORN
HORN
RELAY
13 2
HORN RELAY
2±3 : CLOSED WITH HORN SW ON
: PARTS LOCATION
CODESEE PAGECODESEE PAGECODESEE PAGE
C1232H 528 (1MZ±FE), 30 (5S±FE)H 628 (1MZ±FE), 30 (5S±FE)
: CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS
CODESEE PAGEJOINING WIRE HARNESS AND WIRE HARNESS (CONNECTOR LOCATION)
2A22ENGINE ROOM MAIN WIRE AND J/B NO 2 (ENGINE COMPARTMENT LEFT)2E22ENGINE ROOM MAIN WIRE AND J/B NO. 2 (ENGINE COMPARTMENT LEFT)
1 BLACK BLACK C12 H 5, H 6
XXX
X
10
SERVICE HINTS

174
SRS (SUPPLEMENTAL RESTRAINT SYSTEM)
NOTICE: When inspecting or repairing the SRS (supplemental restraint system), perform the operation in
accordance with the following precautionary instructions and the procedure and precautions in the Repair
Manual for the applicable model year.

Malfunction symptoms of the supplemental restraint system are difficult to confirm, so the diagnostic trouble
codes become the most important source of information when troubleshooting.
When troubleshooting the supplemental restraint system, always inspect the diagnostic trouble codes before
disconnecting the battery.

Work must be started after 90 seconds from the time the Ignition SW is set to the ªLOCKº position and the
negative (±) terminal cable is disconnected from the battery.
(The supplemental restraint system is equipped with a back±up power source so that if work is started within
90 seconds of disconnecting the negative (±) terminal cable of the battery, the SRS may be activated.)
When the negative (±) terminal cable is disconnected from the battery, memory of the clock and audio systems
will be cancelled. So before starting work, make a record of the contents momorized by each memory system.
When work is finished, reset the clock and audio system as before and adjust the clock. This vehicle has tilt
and telescopic steering, power seat and outside rear view mirror and power shoulder belt anchorage, which
are all equipped with memory function, it is not possible to make a record of the customer, and ask the
customer to adjust the features and reset the memory.
To avoid erasing the memory of each memory system, never use a back±up power supply from outside the
vehicle.

When removing the steering wheel pad or handling a new steering wheel pad, keep the pad upper surface
facing upward. Also, lock the lock lever of the twin lock type connector at the rear of the pad and take care
not to damage the connector.
(Storing the pad with its metallic surface up may lead to a serious accident if the SRS inflates for some reason.)

Store the steering wheel pad where the ambient temperature remains below 93°C (200°F), without high
humidity and away from electrical noise.

Never use SRS parts from another vehicle. When replacing SRS parts, replace them with new parts.

Never disassemble and repair the steering wheel pad, center SRS sensor assembly or front airbag sensors.

Before repairing the body, remove the airbag sensors if during repair shocks are likely to be applied to the
sensors due to vibration of the body or direct tapping with tools or other parts.

Do not reuse a steering wheel pad or front airbag sensors.
After evaluating whether the center airbag sensor assembly is damaged or not, decide whether or not to reuse
it. (See the Repair Manual for the method for evaluating the center airbag sensor assembly.)

When troubleshooting the supplemental restraint system, use a high±impedance (Min. 10k
/V) tester.

The wire harness of the supplemental restraint system is integrated with the cowl wire harness assembly and
engine wire harness assembly.
The vehicle wiring harness exclusively for the airbag system is distinguished by corrugated yellow tubing, as
are the connectors.

Do not measure the resistance of the airbag squib.
(It is possible this will deploy the airbag and is very dangerous.)

If the wire harness used in the supplemental restraint system is damaged, replace the whole wire harness
assembly.
When the connector to the airbag front sensors can be repaired alone (when there is no damage to the wire
harness), use the repair wire specially designed for the purpose.
(Refer to the Repair Manual for the applicable Model year for details of the replacement method.)

INFORMATION LABELS (NOTICES) are attached to the periphery of the SRS components. Follow the
instructions on the notices.

175
The supplemental restraint system has connectors which possess the functions described below:
1. SRS ACTIVATION PREVENTION MECHANISM
Each connector contains a short spring plate. When the
connector is disconnected, the short spring plate
automatically connects the power source and grounding
terminals of the squib to preclude a potential difference
between the terminals.
2. ELECTRICAL CONNECTION CHECK MECHANISM
This mechanism is designed to electrically check if
connectors are connected correctly and completely.
The electrical connection check mechanism is designed so
that the connection detection pin connects with the
diagnosis terminals when the connector housing lock is in
the locked condition.

176
SRS (SUPPLEMENTAL RESTRAINT SYSTEM)
3. CONNECTOR TWIN±LOCK MECHANISM
With this mechanism connectors (male and female
connectors) are locked by two locking devices to increase
connection reliability. If the primary lock is incomplete, ribs
interfere and prevent the secondary lock.

177
IP 1 12 IP38
12
FRONT AIRBAG
SENSOR LHAIRBAG SQUIB
(
STEERING
WHEEL PAD) SPIRAL
CABLE
F1A1512 4 5 11B±O
P±L
B±Y
Y±B
LG±RB±Y
W±B W±BWB WB
±SL +SLD+ D± E1 E2 IG2 ACCLA FROM POWER SOURCE SYSTEM(
SEE PAGE 64)
DATA LINK CONNE CTOR 2
(
TDCL)DATA LINK CONNECOR 1
(
CHECK CONNECTOR)
AB TC AB TC D3 D1
CENTER AIRBAG SENSOR
ASSEMBLY C3 SRS WARNING LIGHT
[COMB. METER] C10
Y±B
21
W±B W±BW±R
B±Y
Y±BB±Y
LG±R B±Y
TC
IG IEC C B B B
13 1412 7C B
11 1034 5 6JUNCTION CONNECTOR
(
FOR SRS) J4
21
AIRBAG SQUIB
(
FRONT PASSENGER
AIRBAG ASSEMBLY) A22
B W
P± P+
12
12
AB CONNE CTION
DE TECTION
PIN12
AB CONNE CTION
DE TE CTION
PIN
WB
±SR +SR
89
FRONT AI RB AG
SENSOR RH F2
1F 91F 31F7. 5A
IGN15A
CIG/RADIO7. 5A
SRS
5
3D 16
3D 17
1M 11M51F 2 1F 1

178
SRS (SUPPLEMENTAL RESTRAINT SYSTEM)
THE SRS (SUPPLEMENTAL RESTRAINT SYSTEM) IS A DRIVER AND PASSENGER PROTECTION DEVICE WHICH HAS A
SUPPLEMENTAL ROLE TO THE SEAT BELTS.
WHEN THE IGNITION SW IS TURNED TO ACC OR ON, CURRENT FROM THE CIG/RADIO FUSE FLOWS TO TERMINAL 14 OF THE
CENTER AIRBAG SENSOR ASSEMBLY. ONLY WHEN THE IGNITION SW IS ON DOES THE CURRENT FROM THE IGN FUSE FLOW TO
TERMINAL 13.
IF AN ACCIDENT OCCURS WHILE DRIVING, DECELERATION CAUSED BY A FRONTAL IMPACT IS DETECTED BY EACH SENSOR AND
SWITCH, AND WHEN THE FRONTAL IMPACT EXCEEDS A SET LEVEL (WHEN THE SAFING SENSOR BUILT INTO THE CENTER AIRBAG
SENSOR ASSEMBLY IS ON AND THE CENTER AIRBAG SENSOR IS ON, FRONT AIRBAG SENSORS ARE OFF), CURRENT FROM THE
CIG/RADIO OR IGN FUSE FLOWS TO TERMINALS 2, 3 OF THE CENTER AIRBAG SENSOR ASSEMBLY " TERMINAL 1 OF THE AIRBAG
SQUIB " SQUIB " TERMINAL 2 " TERMINALS 1, 4 OF CENTER AIRBAG SENSOR ASSEMBLY " TERMINAL 6, TERMINAL 5 OR BODY
GROUND " GROUND.
WHEN THE SAFING SENSOR BUILT INTO THE CENTER AIRBAG SENSOR ASSEMBLY IS ON AND THE FRONT AIRBAG SENSOR LH OR
RH IS ON, CENTER AIRBAG SENSOR IS OFF CURRENT FROM THE CIG/RADIO OR IGN FUSE FLOWS TO TERMINALS 2, 3 OF THE
CENTER AIRBAG SENSOR ASSEMBLY " TERMINAL 1 OF THE AIRBAG SQUIB " SQUIB " TERMINAL 2 " TERMINALS 1, 4 OF
CENTER AIRBAG SENSOR ASSEMBLY " TERMINAL 8 OR 11 " TERMINAL 1 OF FRONT AIRBAG SENSOR " TERMINAL 2 "
TERMINAL 9 OR 10 OF CENTER AIRBAG SENSOR ASSEMBLY " TERMINAL 6, TERMINAL 5 OR BODY GROUND " GROUND.
WHEN THE SAFING SENSOR BUILT INTO THE CENTER AIRBAG SENSOR ASSEMBLY IS ON, AND THE FRONT AIRBAG SENSOR LH OR
RH IS ON AND CENTER AIRBAG SENSOR IS ON ONE OF THE ABOVE±MENTIONED CIRCUITS IS ACTIVATED SO THAT CURRENT
FLOWS TO THE AIRBAG SQUIB AND CAUSES IT TO OPERATE. THE BAG STORED INSIDE THE STEERING WHEEL PAD IS
INSTANTANEOUSLY EXPANDED TO SOFTEN THE SHOCK TO THE DRIVER.
: PARTS LOCATION
CODESEE PAGECODESEE PAGECODESEE PAGE
A1532D 128 (1MZ±FE), 30 (5S±FE)F 228 (1MZ±FE), 30 (5S±FE)
C 332D 332J 433
C1032F 128 (1MZ±FE), 30 (5S±FE)
: JUNCTION BLOCK AND WIRE HARNESS CONNECTOR
CODESEE PAGEJUNCTION BLOCK AND WIRE HARNESS (CONNECTOR LOCATION)
1F20COWL WIRE AND J/B NO 1 (INSTRUMENT PANEL LEFT)1M20COWL WIRE AND J/B NO. 1 (INSTRUMENT PANEL LEFT)
3D24COWL WIRE AND J/B NO. 3 (BEHIND COMBINATION METER)
: CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS
CODESEE PAGEJOINING WIRE HARNESS AND WIRE HARNESS (CONNECTOR LOCATION)
IP144ENGINE WIRE AND COWL WIREIP344ENGINE WIRE AND COWL WIRE
: GROUND POINTS
CODESEE PAGEGROUND POINTS LOCATION
IE42LEFT KICK PANEL
IG42INSTRUMENT PANEL BRACE LH
SYSTEM OUTLINE

179

180
POWER SEAT
IO 1 4
IO1 5
BLM 21
M 12
M 12
M 21 5826121147 10
9
FR RR UP DOWN UP DOWN FR RR FROM POWER SOURCE SYSTEM(
SEEPAGE64)
POWER SEAT CONTROL SW
POWER SEAT MOTOR
(
FOR S LIDE CO NTROL)POWER SEAT MOTOR
(
FOR REAR VERTICAL
CONTROL)POWER SEAT MOTOR
(
FOR FRONT VERTICAL
CONTROL)POWER SEAT MOTOR
(
FOR RECLINING MOTOR
CONTROL)
R±W R±W W±B W±B
L
L±B
L±Y
R
L±R
L±W
R±G
R±B
P4
P8 P5 P6 P7
C C
W±B
JUNCTION
CONNECTOR J5
W±B
(
S/D, C/P)
(
W/G) (
W/G)
(
EX. C/P)
(
EX. C/P)
1H 2030A
POWER
