PVC Chipping Primer
BODY PANEL ANTI±CHIPPING PAINT APPLICATION AREAS
HINT:
1. Anti±chipping paint should be applied to some areas before the second coat and to others after the top
coat.
2. If other areas are accidentally coated, wipe of the paint immediately with a rag soaked in a grease, wax
and silicone remover.
Soft±Chip Primer
Anti±Chipping Paint
ANTI±RUST TREATMENTAR-10

SILENCER SHEET INSTALLATION AREAS
Thickness of Asphalt Sheet
1.5 mm (0.059 in.) . . . . . . .
2.5 mm (0.098 in.) . . . . . . .
3.7 mm (0.146 in.) . . . . . . .
APPENDIXAP-3

GENERAL INFORMATION
1. BASIC DIMENSIONS
(a) There are two types of dimensions in the diagram.
(Three±dimensional distance)

Straight±line distance between the centers of two
measuring points.
(Two±dimensional distance)

Horizontal distance in forward/rearward between
the centers of two measuring points.

The height from an imaginary standard line.
(b) In cases in which only one dimension is given, left
and right are symmetrical.
(c) The dimensions in the following drawing indicate
actual distance. Therefore, please use the dimen-
sions as a reference.
2. MEASURING
(a) Basically, all measurements are to be done with a
tracking gauge. For portions where it is not possible
to use a tracking gauge, a tape measure should be
used.
(b) Use only a tracking gauge that has no looseness in
the body, measuring plate, or pointers.
HINT:
1. The height of the left and right pointers must be equal.
2. Always calibrate the tracking gauge before measuring or
after adjusting the pointer height.
3. Take care not to drop the tracking gauge or otherwise
shock it.
4. Confirm that the pointers are securely in the holes.
(c) When using a tape measure, avoid twists and
bends in the tape.
(d) When tracking a diagonal measurement from the
front spring support inner hole to the suspension
member upper rear installation hole, measure
along the front spring support panel surface.
Center±to±center
straight±line
distance Three±dimensional
distance
Front Spring Support Inner Hole
Tape Measure
Along Body
Surface
Front Suspension Member Rear Side
Upper Installation HoleMaster Gauge PointerPointer LoosenessBody LoosenessPlate Looseness Two±dimensional
distanceCenter±to±center
Horizontal distance in
forward/rearward
Vertical distance
in lower surface Vertical distance
in center
Imaginary Standard Line
WrongCorrect
Pointer
BODY DIMENSIONSDI-2

K±k
1,526
(60.08)
Vehicle Dimensions Left e Right
C±K
or
c±k
826
(35.52)1,712
(67.40)C±k
or
c±K
HINT: For symbols, capital letters indicate right side of vehicle,
small letters indicate left side of vehicle (Seen from rear.)
mm (in.)
(Three±Dimensional Distance)
Hole dia.
10 (0.39)
10 (0.39)
12 (0.47)
8 (0.315) nut
3R (0.12) Name
Radiator support standard hole
Radiator support standard hole
Front crossmember standard hole
Hood hinge installation nut±rear
Front Fender apron to cowl side member cut±out
portion Symbol
G, g
H, h
I, i
J, j
K, k Hole dia.
6 (0.24) nut
11 (0.43)
6 (0.24) nut
7 (0.28)
13 (0.51)
15 (0.59) Name
Front fender installation nut±front
Front spring support hole±inner
Front fender installation nut±raar
Cowl ventilator louver installation hole
Front side member standard hole
Front side member working hole Symbol
A, a
B, b
C, c
D
E, e
F, f
BODY DIMENSION DRAWINGS
ENGINE COMPARTMENT
BODY DIMENSIONSDI-3

1,312
(51.65)E±eF±f
1,484
(58.43)1,494
(58.82)G±gVehicle Dimensions Left e Right
1,496
(58.90)H±h
1,134
(44.65)I±i
1,238
(48.74)J±jK±k
1,492
(58.74)E±f
or
e±F
1,577
(62.09)1, 632
(64.25)E±h
or
e±H
1,454
(57.24)E±j
or
e±J
1,856
(69.13)F±j
or
f±JF±k
or
f±K
1,695
(66.73)H±i
or
h±I
1,626
(64.02)J±k
or
j±K
1,568
(61.73)
HINT: For symbols, capital letters indicate right side of vehicle,
small letters indicate left side of vehicle (Seen from rear).
(Three±Dimensional Distance)
mm (in.)
Hole dia.
13 (0.51)
13 (0.51) Name
Rocker panel assembly mark
Roof side rail assembly mark
Center body pillar assembly mark
Center body pillar assembly mark
Rear door hinge installation hole ± upper
Rear door hinge installation hole ± front Symbol
H, h
I, i
J, j
K, k
L, l
M, m Hole dia.
10 (0.39) nut
10 (0.39) nut Name
Roof panel / Front body pillar assembly mark
Cowl top panel / Front body pillar assembly mark
Front door hinge installation nut±rear
Front door hinge installation nut±rear
Front body pillar assembly mark
Front body pillar assembly mark
Rocker panel assembly mark Symbol
A, a
B, b
C, c
D, d
E, e
F, f
G, g
BODY OPENING AREAS (Side View: Front)
BODY DIMENSIONSDI-4

N±n
1,238
(48.74)O±o
1,492
(58,74)P±p
1,492
(58.74)
Vehicle Dimensions Left e Right
Q±q
1,130
(44.49)R±r
1,270
(50.00)S±s
1,492
(58.74)1,843
(72.56)G±p
or
g±PI±q
or
i±Q
1,281
(50.43)1,405
(55.32)N±r
or
n±RN±s
or
n±S
1,641
(64.61)O±S
or
o±S
1,611
(63.43)P±q
or
p±Q
1,626
(64.02)1,554
(61.18)R±s
or
r±S
mm (in.)
HINT: For symbols, capital letters indicate right side of vehicle,
small letters indicate left side of vehicle (Seen from rear.)
(Three±Dimensional Distance)
Hole dia. Name
Rocker panel assembly mark
Roof side rail assembly mark
Quarter panel assembly mark
Quarter panel assembly mark Symbol
P, p
Q, q
R, r
S, s Hole dia. Name
Rocker panel assembly mark
Roof side rail assembly mark
Center body pillar assembly mark
Center body pillar assembly mark Symbol
G, g
I, i
N, n
O, c
BODY OPENING AREAS (Side View: Rear)
BODY DIMENSIONSDI-5

HINT: For symbols, capital letters indicate right side of vehicle,
small letters indicate left side of vehicle (Seen from rear).
(Three±Dimensional Distance)
mm (in.)
Hole dia.
7 (0.28)
9.5 (0.374) Name
Luggage opening trough / Quarter panel adjoining
portion
Rear foor finish plate installation hole
Rear spring support hole inner±rear Symbol
E, e
F, f
G, g Hole dia. Name
Center body pillar assembly mark
Roof panel / Quarter panel adjoining portion
Upper back panel / Quarter panel adjoining portion
Quarter panel / Upper back panel adjoining portion Symbol
A, a
B, b
C, c
D, d
BODY OPENING AREA (Rear View)
BODY DIMENSIONSDI-6

(Three±Dimensional Distance)
mm (in.)
Hole dia.
15 (0.59)
12 (0.47)
18 (0.71)
12 (0.47) nut
18 (0.71)
18 (0.71) Name
Front floor under reinforcement standard hole
Strut bar installation hole ± inner
Rear floor side member standard hole
Rear suspension member installation nut
Rear floor side member standard hole
Rear floor side member standard hole Symbol
G, g
H, h
I, i
J
K, k
L, l Hole dia.
15 (0.59)
14 (0.55) nut
18 (0.71)
14 (0.55) nut
18 (0.71)
15 (0.59) Name
Front crossmember standard hole
Front frame installation nut
Front side member standard hole
Front frame installation nut
Front side member standard hole
Front side member working hole Symbol
A, a
B, b
C, c
D, d
E, e
F, f
UNDER BODY
BODY DIMENSIONSDI-7

Wheel base
2,670 (105.12)
Imaginary
Standard
Line
(Two±Dimensional Distance)
mm (in.)
Hole dia.
15 (0.59)
12 (0.47)
18 (0.71)
12 (0.47) nut
9.5 (0.374)
18 (0.71)
18 (0.71) Name
Front floor under reinforcement standard hole
Strut bar installation hole±inner
Rear floor side member standard hole
Rear suspension member installation nut
Rear spring support hole±outer
Rear floor side member standard hole
Rear floor side member standard hole Symbol
H, h
I, i
J, j
K, k
L, l
M, m
N, n Hole dia.
15 (0.59)
14 (0.55) nut
18 (0.71)
11 (0.43)
14 (0.55) nut
18 (0.71)
15 (0.59) Name
Front crossmember standard hole
Front frame installation nut
Front side member standard hole
Front spring support hole outer ± front
Front frame installation nut
Front side member standard hole
Front side member working hole Symbol
A, a
B, b
C, c
D, d
E, e
F, f
G, g
UNDER BODY (Cont'd)
BODY DIMENSIONSDI-8

(Three±Dimensional Distance)
(Two±Dimensional Distance)
Imaginary
Standard
Line
mm (in.)Hole dia.
13 (0.51)
15 (0.59) Name
Front frame standard hole
Lower control link installation hole±lower Symbol
D, d
E, e Hole dia.
13 (0.51)
13 (0.51)
13 (0.51) Name
Front frame standard hole
Front frame standard hole
Front frame standard hole Symbol
A, a
B, b
C, c
FRONT FRAME
