TOYOTA CAMRY 2000 Service Repair Manual

INSTALLATION
Assembly Mark
1. Determine the position of the new parts by the
assembly marks of the inner and outer panels.2. Before welding the new parts, temporarily
install the quarter panel and check the fit.
BODY PANEL REPLACEMENTRE-49

BODY LOWER BACK PANEL (ASSY)
REMOVAL
BODY PANEL REPLACEMENTRE-50

INSTALLATION
1. Temporarily installing the new parts, check
the fit of the luggage compartment door and
rear combination light.
BODY PANEL REPLACEMENTRE-51

LUGGAGE COMPARTMENT OPENING
TROUGH (ASSY)
REMOVAL
Braze
BODY PANEL REPLACEMENTRE-52

INSTALLATION
Braze
Braze
1. Temporarily install the new parts and check
the fit of the luggage compartment door and
rear combination light.
BODY PANEL REPLACEMENTRE-53

REAR FLOOR NO. 3 CROSSMEMBER (ASSY)
REMOVAL (With the body lower back panel removed.)
BODY PANEL REPLACEMENTRE-54

INSTALLATION
1. Before welding the new parts, temporarily
install the body lower back panel and check
the fit.
BODY PANEL REPLACEMENTRE-55

REAR FLOOR PAN (ASSY)
REMOVAL (With the rear floor No. 3 crossmember
removed.)
Rear Floor Pan
Reinforcement
1. After removing the rear floor pan reinforce-
ment, remove the rear floor pan.
BODY PANEL REPLACEMENTRE-56

INSTALLATION
BODY PANEL REPLACEMENTRE-57

REAR FLOOR SIDE PANEL (ASSY): Right Side
REMOVAL (With the rear floor pan removed.)
BODY PANEL REPLACEMENTRE-58
