TOYOTA CAMRY 2000 Service Repair Manual

INSTALLATION
BODY PANEL REPLACEMENTRE-59

REAR FLOOR SIDE PANEL (ASSY): Left Side
REMOVAL (With the rear floor pan removed.)
BODY PANEL REPLACEMENTRE-60

INSTALLATION
BODY PANEL REPLACEMENTRE-61

REAR FLOOR SIDE REAR MEMBER (ASSY)
RH:
LH:RH:
LH:
REMOVAL (With the rear floor No. 3 crossmember
removed.)
BODY PANEL REPLACEMENTRE-62

RH:
LH:RH:
LH:
INSTALLATION
Assembly Mark
1. When temporarily installing the new parts,
determine the installation position by the as-
sembly mark. Then, measure each part in ac-
cordance with the body dimension diagram.
BODY PANEL REPLACEMENTRE-63

REAR FLOOR NO. 2 CROSSMEMBER (ASSY)
REMOVAL
BODY PANEL REPLACEMENTRE-64

INSTALLATION
BODY PANEL REPLACEMENTRE-65

ROOF PANEL (ASSY): w/o Moon Roof
REMOVAL
Arc Brazing
(Both sides)
1. Grind off the roof panel tip at the quarter panel
arc brazing connection with a cut grinder.
BODY PANEL REPLACEMENTRE-66

INSTALLATION
Body Sealer
Braze
(Both sides)
[Foamed Material
Application Areas]
1. Before temporarily installing the new parts,
apply body sealer to the windshield header
panel, roof panel reinforcement and back
window frame.
HINT: Apply just enough sealer for the new parts
to make contact.
2. Braze the quarter panel connection.
HINT: Before performing these operations, place
a wet rag on the roof panel to protect it from dam-
age.
BODY PANEL REPLACEMENTRE-67

ROOF PANEL: w/ Moon Roof
REMOVAL
Arc Brazing
(Both sides)
1. Grind off the roof panel tip at the quarter panel
arc brazing connection with a cut grinder.
BODY PANEL REPLACEMENTRE-68
