“MSG” (Message)
When an RDS radio station transmits a
text message, “MSG” will be displayed.
At this time, touch the “MSG” switch to
view the text message. The message dis-
play will be canceled if any button that
affects the display is pushed. To view the
message again, touch the “MSG” switch
again. After the entire message has been
displayed, the message will disappear.
The RDS audio system has memory to
store three 64 character messages. To
store a message in memory, touch and
hold the “STORE” switch until you hear
a beep.
If 3 messages are already stored in
memory, the oldest message will be over-
written by the new message.To recall a radio text messages stored in
memory, touch the “RECALL” switch.
Touching the “LATEST MESSAGE” will
display the most recent message.
If no messages have been stored, or if
there are no more messages to be re-
called, “RECALL” switch is dimmed. The
message display will be canceled if you
activate any function that affects the dis-
play.
“TYPE” switch
This switch is used for changing the pro-
gram type (PTY) of RDS stations in all
RDS mode. 8 program types are avail-
able as listed here.
The following program type names are avail-
able.
ROCK
EASY LIS
CLS/JAZZ
R & B
INFORM
RELIGION
MISC
ALERT (Emergency message)
Z00007
L00179
(e) Traffic announcement
“TRAF” button
This button turns the traffic announce-
ment (TA) feature on and off.

Camry_Navi_U (L/O 0108)
1352002 MY CAMRY NAVI_U (OM33559U)
Pushing this button turns on, RDS if it
was off, and the traffic announcement
feature will come on (“TRAF” will appear
and start blinking). When the radio is
tuned to a traffic station, “TRAF” will stop
blinking.
If the current station is not a traffic sta-
tion, the radio will start a traffic program
search in increasing frequency order. Dur-
ing a traffic program search, “TRAF
SEEK” will display. If no traffic programs
are found, “NOTHING” will display.
If the radio receives a traffic announce-
ment, it will interrupt the cassette player
or compact disc mode (if either one is
on), adjust the volume to Traffic An-
nouncement level, and broadcast the traf-
fic announcement. During a traffic an-
nouncement, “Traffic” will appear on the
screen. After traffic announcement is fin-
ished, it will return to the previous mode
and volume level.
TA volume memory function—The volume
level when receiving the traffic announce-
ment is memorized. When “TA” is received next time, the sys-
tem compares the volume before “TA” is
received and the memorized TA volume
and automatically selects the louder vol-
ume. However, the range of volume
memory is limited: if the volume received
previously is less than the minimum, this
volume will be used.
You can adjust the volume independently
from the memorized TA volume range
while receiving a TA station.
Traffic announcement can be canceled by
turning RDS off, or pressing the “TRAF”
button again.
L00172
—Cassette tape player
operation

Camry_Navi_U (L/O 0108)
1362002 MY CAMRY NAVI_U (OM33559U)
(a) Playing a cassette tape
To insert a cassette tape, push the
“OPEN” button to lower the display.
Put the cassette tape in the slot with
the exposed tape side to the right and
lightly push it in.
The player will automatically start when
you insert the cassette tape. At this time,
“Tape” appears on the screen.
If a metal or chrome equivalent cassette
tape is put in the cassette player, the
player will automatically adapt to it and
“MTL” appears on the screen.
L00173
To stop and eject the cassette tape, push
the “OPEN” button to lower the display.
Push the “TAPE
” button.

Camry_Navi_U (L/O 0108)
1372002 MY CAMRY NAVI_U (OM33559U)
L00177
Push the “TAPE” button if a cassette
tape is already in the slot.
Dolby Noise Reduction
∗ feature: If you
are listening to a tape that was recorded
with Dolby
∗ Noise Reduction, touch the
switch on the screen. The symbol is
highlighted in green.
The Dolby NR mode reduces tape noise by
about 10 dB. For best sound reproduction,
play your tapes with the Dolby NR on or off
according to the mode used for recording the
tape.
To play a tape recorded without Dolby NR,
touch the switch once again.
∗ Dolby noise reduction manufactured under li-
cense from Dolby Laboratories Licensing Corpo-
ration. “DOLBY” and the doubleD symbol
are trademarks of Dolby Laboratories Li-
censing Corporation.
(b) Manual program selection
Program switch: Touch the “
\b”
switch on the screen to select the other
side of a cassette tape. The display indi-
cates which side is currently selected (
indicates top side,
indicates bottom
side).
Fast forward switch: Touch the “”
switch on the screen to fast forward a
cassette tape. “FF” appears on the
screen.
To stop fast forwarding, touch the same
switch or push the “TAPE” button.
Rewind switch: Touch the “\b\b” switch
on the lower side to rewind a tape.
“REW” appears on the screen.
To stop rewinding, touch the same switch
or push the “TAPE” button. Autoreverse feature:
After the cassette
player reaches the end of a tape, it auto-
matically reverses and begins to play the
other side, regardless of whether the cas-
sette was playing or fast forwarding.
(c) Automatic program selection
“RPT” switch: The repeat feature auto-
matically replays the current program.
Touch the “RPT” switch while the pro-
gram is playing. When the program ends,
it will automatically be rewound and re-
played. Touch the switch again to turn off
the repeat feature.
There must be at least 5 seconds of
blank space between programs for the
repeat feature to work correctly.
“SKIP” switch: The skip feature allows
you to fast forward past long stretches of
blank tape. This is especially useful at
the end of cassettes.
Touch the “SKIP” switch. The player will
automatically skip any blank portions of 15
seconds or more and play the next program.
To cancel it, touch the switch once again.

Camry_Navi_U (L/O 0108)
1382002 MY CAMRY NAVI_U (OM33559U)
L00176
“SEEK/TRACK” button: The automatic
program selection feature allows you to
program your cassette player to skip for-
ward or backward to locate the track you
want to listen to. You can skip up to 9
programs at a time.
Push the upper side of this button to skip
forward. “FF” and the number will appear
on the screen. Push the button until the
number of programs you want to skip
appears on the screen. After that, the
player will automatically skip forward.
When the end of the tape is reached, the
player automatically reverses sides and
resumes normal play. Push the lower side of this button to skip
backward. Push the button until “REW”
and the number of programs you want to
skip appears on the screen.
If you set “REW 1”, the player will
rewind to the beginning of the current
program.
When counting the number of pro-
grams you want to rewind, remember
to count the current program as well.
For example, if you want to rewind to
a program that is two before the pro-
gram you are listening to, push this
button until “REW 3” appears on the
screen.
When the beginning of the tape is
reached, the player automatically resumes
normal play.
There must be at least 5 seconds of
blank space between programs for this
feature to work correctly.
“RPT”, “SKIP” or Automatic program
selection features: These features may
not work well with some spoken word,
live or classical recordings.
L00174
—Compact disc player
operation

Camry_Navi_U (L/O 0108)
1392002 MY CAMRY NAVI_U (OM33559U)
(a) Playing a compact disc
To insert a compact disc, push the
“OPEN” button to lower the display.
Put the compact disc in the slot with
the label side up.
The player will automatically start when
you insert the compact disc. At this time,
“CD” appears on the screen.
If the label faces down, the disc cannot be
played. In this case, “CD ERROR” appears
on the screen.
L00175
To stop and eject the compact disc, push
the “OPEN” button to lower the display.
Push the “CD
” button.

Camry_Navi_U (L/O 0108)
1402002 MY CAMRY NAVI_U (OM33559U)
L00178
Push the “DISC” button if a compact
disc is already loaded in the slot.
“CD” appears on the screen.
L00176
(b) Selecting a desired track
“SEEK/TRACK” button: Use for a direct
access to a desired track.
Push either side of the “SEEK/TRACK”
button and hold it un til the desired track
number appears on the screen. As you
release the button, the player will start
playing the selected track from the begin-
ning.
Fast forward: Touch the “
” switch and
hold it to fast forward the disc. When you
release the switch, the compact disc
player will resume playing from that posi-
tion. Reverse:
Touch the “
” switch and hold
it to reverse the disc. When you release
the switch, the compact disc player will
resume playing.

Camry_Navi_U (L/O 0108)
1412002 MY CAMRY NAVI_U (OM33559U)
L00180
(c) Searching for a desired track
Touch the “SCAN” switch on the
screen or push the “SCAN” button.
The compact disc player will play the
next track for 10 seconds, then scan
again. To select a track, touch the
“SCAN” switch on the screen or push the
“SCAN” button a second time. If the play-
er reaches the end of the disc, it will
continue scanning at track 1.
After all the tracks are scanned in one
pass, normal play resumes.
Z00004
(d) Other compact disc player func-tions
“RPT” switch: Use it for automatic re-
peat of the track you are currently listen-
ing to.
Touch the switch while the track is play-
ing. When the track is finished, the player
will automatically go back to the begin-
ning of the track and play the track
again. To cancel it, touch the switch once
again.
“RAND” switch: Use it for automatic and
random selection.
When the switch is touched, the system
selects a track in the disc. To cancel it,
touch the switch once again. (e) If the player malfunctions
If “WAIT” appears on the screen, audio
signals of the disc cannot be read or the
system has trouble. Push the “CD” button
once again.
If the player does not operate, check that
the disc surface is not soiled or dama-
ged. If the disc is O.K., the temperature
of the player’s internal mechanism may
be raised because of high external tem-
perature. Remove the disc from the play-
er to cool it.
If the player still does not operate, have
it checked by your Toyota dealer.

Camry_Navi_U (L/O 0108)
1422002 MY CAMRY NAVI_U (OM33559U)
NOTICE
To ensure the correct audio system
operation:
Be careful not to spill beverages
over the audio system.
 Do not put anything other than a
cassette tape or Compact Disc into
the slot.
 The use of cellular phone inside or
near the vehicle may cause a noise
from the speakers of the audio
system which you are listening to.
However, this does not indicate a
malfunction.
RADIO RECEPTION
Usually, a problem with radio reception
does not mean there is a problem with
your radio—it is just the normal result of
conditions outside the vehicle.
For example, nearby buildings and terrain
can interfere with FM reception. Power
lines or telephone wires can interfere with
AM signals. And of course, radio signals
have a limited range. The farther you are
from a station, the weaker its signal will
be. In addition, reception conditions
change constantly as your vehicle moves. Here are some common reception prob-
lems that probably do not indicate a
problem with your radio:
FM
Fading and drifting stations—Generally,
the effective range of FM is about 40 km
(25 miles). Once outside this range, you
may notice fading and drifting, which in-
crease with the distance from the radio
transmitter. They are often accompanied
by distortion.
Multi
−path—FM signals are reflective,
making it possible for two signals to
reach your antenna at the same time. If
this happens, the signals will cancel each
other out, causing a momentary flutter or
loss of reception.
Static and fluttering—These occur when
signals are blocked by buildings, trees, or
other large objects. Increasing the bass
level may reduce static and fluttering.
Station swapping—If the FM signal you
are listening to is interrupted or weak-
ened, and there is anot her strong station
nearby on the FM band, your radio may
tune in the second station until the origi-
nal signal can be picked up again. AM
Fading—AM broadcasts are reflected by
the upper atmosphere—especially at
night. These reflected signals can inter-
fere with those received directly from the
radio station, causin
g the radio station to
sound alternately strong and weak.
Station interference—When a reflected
signal and a signal received directly from
a radio station are very nearly the same
frequency, they can interfere with each
other, making it difficult to hear the
broadcast.
Static—AM is easily affected by external
sources of electrical noise, such as high
tension power lines, lightening, or electri-
cal motors. This results in static.
CARING FOR YOUR CASSETTE
PLAYER AND TAPES
For the best performance for your cas-
sette player and tapes:
Clean the tape head and other parts reg-
ularly.
A dirty tape head or tape path can
decrease sound quality and tangle
your cassette tapes. The easiest way
to clean them is by using a cleaning
tape. (A wet type is recommended.)
Car audio system operating
hints

Camry_Navi_U (L/O 0108)
1432002 MY CAMRY NAVI_U (OM33559U)
Use high−quality cassettes.
Low−quality cassette tapes can cause
many problems, including poor sound,
inconsistent playing speed, and
constant auto −reversing. They can
also get stuck or tangled in the cas-
sette player.
Do not use a cassette if it has been
damaged or tangled or if its label is
peeling off.
Do not leave a cassette in the player
if you are not listening to it, especially
if it is hot outside.
Store cassettes in their cases and out
of direct sunlight.
Avoid using cassettes with a total
playing time longer than 100 minutes
(50 minutes per side). The tape used
in these cassettes is thin and could
get stuck or tangled in the cassette
player.
CARING FOR YOUR COMPACT DISC
PLAYER AND DISCS
Use only compact discs labeled as
shown above. CD− R (CD−Recordable),
CD− RW (CD −Re− writable) and
personal computer use CD −ROMs may
not be playable on your compact disc
player.
Your compact disc player is intended
for use with 12 cm (4.7 in.) discs only.
Extremely high temperatures can keep
your compact disc player from work-
ing. On hot days, use the air condi-
tioning to cool the vehicle interior be-
fore you listen to a disc.
Bumpy roads or other vibrations may
make your compact disc player skip.
If moisture gets into your compact
disc player, you may not hear any
sound even though your compact disc
player appears to be working. Remove
the disc from the player and wait until
it dries.
