TOYOTA COROLLA iM 2018 Owners Manual (in English)

COROLL A iM
2 0 18www.toyota.com/owners
CUSTOMER EXPERIENCE CENTER
1- 8 0 0 - 3 31- 4 3 31
Printed in U.S.A. 8 /17
17 - M K G - 1 0 18 8
QUICK REFERENCE GUIDE

COROLLA iM 2018
This Quick Reference Guide is a summary of basic vehicle
operations. It contains brief descriptions of fundamental
operations so you can locate and use the vehicle’s main
equipment quickly and easily.
The Quick Reference Guide is not intended as a substitute for
the Owner’s Manual located in your vehicle’s glove box. We
strongly encourage you to review the Owner’s Manual and
supplementary manuals so you will have a better understanding
of your vehicle’s capabilities and limitations.
Your dealership and the entire staff of Toyota Motor North
America, Inc. wish you many years of satisfi ed driving in your
new Corolla iM.
A word about safe vehicle operations
This Quick Reference Guide is not a full description of Corolla iM operations.
Every Corolla iM owner should review the Owner’s Manual that accompanies this
vehicle.
Pay special attention to the boxed information highlighted in color throughout the
Owner’s Manual. Each box contains safe operating instructions to help you avoi\
d
injury or equipment malfunction.
All information in this Quick Reference Guide is current at the time of printing.
Toyota reserves the right to make changes at any time without notice.
33
PAIRING BLUETOOTH® PHONE FOR THE FIRST TIME
5. A message will display on the
head unit requesting messaging
access.6. Touch “OK” when the connection status changes from “Connection
waiting...” to “Connected”.
7. For Navigation
1 Units Only: Confi rm that the passkey number displayed
on screen matches the passkey displayed on your Bluetooth®2 device and
press “Yes”. iPhone
®4: Using your smartphone,
you may need to allow head unit
access to your messaging and
contacts. [See Figure 6]
Only current iPhone®4 text messages
can be viewed on the head unit.
iPhone
®4 does not allow text message
reply.
Android™: Using your smartphone,
you may need to allow head unit
access to your messaging and
contacts. [See Figure 7]
It is recommended to check the “Don’t
ask again” box, so as not to have to
press OK every time the phone makes
a Bluetooth
®2 connection with your
Toyota.
4. Next, search for “My Toyota”
from your phone’s Bluetooth®2
screen and select “My Toyota” [See
Figure 5] • To cancel the registration, touch
“Cancel”.
• Navigation units - skip to step 7
1. Availability & accuracy of the information provided by the navigation sys\
tem is dependent upon many factors. Use common sense when
relying on information provided. Services & programming subject to change. Services not available in every city or roadway. Updates may
be available from your dealer at an additional cost. See Owner’s Manual for details. 2. The Bluetooth® word mark and logos are regis\
tered
trademarks owned by Bluetooth® SIG, Inc. and any use of such marks by\
Toyota is under license. A compatible Bluetooth® enabled phone
must first be paired. Phone performance depends on software, coverage & \
carrier. 3. Concentrating on the road should always be your
first priority while driving. Do not use the hands-free phone system if \
it will distract you. 4. iPhone® is not included. iPhone® is registered
trademarks of Apple, Inc.
Figure 6: iOS Figure 7: Android
Figure 5: Without Navigation
NOTE: A message will display on the head unit requesting messaging
access. Please refer to step 5

1
INDEX
Engine maintenance 7
Fuel tank door release & cap
6
Hood release
7
Indicator symbols
4-5
Instrument cluster
4
Instrument panel
2-3
Keyless entry*
6
* Visit your Toyota dealer for information on customizing this feature.
OVERVIEW
FEATURES & OPERATIONS TOYOTA SAFETY SENSE™ C (TSS-C)
SAFETY & EMERGENCY FEATURES
Automatic air conditioning/heating 14
Automatic transmission
8
AUX/USB port
13
Bottle holders/cup holders
14
Cruise control
12
Door locks
15
Lights & turn signals
10-11
Manual transmission
8
Multi-Information Display (MID)
9
Parking brake
8
Power outlet
13
Rear view monitor system
17-19
Seat adjustments-Front
15
Seat-Folding down rear seat
16
Seats-Head restraints
15
Steering wheel switches
10
Tilt steering wheel
13
Trip information/meter light contr

ol
9
Windows
12
W

indshield wipers & washers
11 Floor mat installation
30
Rear door child safety locks
26
Seat belts
27
Seat belts-Shoulder belt anchor
26
Spare tir

e & tools
28
Star Safety System™ 29-30
Tir
e Pressure Monitoring
(warning) System (TPMS)
27
Automatic High Beams (AHB)
25
Lane Departure Alert (LDA)
23-24
Pre-Collision System (PCS)
21-22
Quick overview-
Toyota Safety Sense
™ C (TSS-C) 20
Sensors
20
PAIRING BLUETOOTH® PHONE FOR
THE FIRST TIME 32-33
OVERVIEW
FEATURES & OPERATIONS
TOYOTA SAFETY SENSE
SAFETY & EMERGENCY FEATURES

2
OVERVIEWInstrument panel
Steering wheel controls
Tilt and telescopic steering
lock release lever
Cruise control switchLane Departure Alert
(LDA) switch
Multi-Information Display
(MID) controls
Multimedia
controls Voice
command switch
Headlight and turn signal controls
Power outside rearview
mirror controls
Pre-Colllision System
(PCS) switch
Hood lock release lever Ignition switch
Wiper and washer controls
Multi-information display (MID)

3
OVERVIEW
FEATURES & OPERATIONS
TOYOTA SAFETY SENSE
SAFETY & EMERGENCY FEATURES
Air conditioning controls
“SPORT” mode switch
2
Tire pressure warning reset switch
(inside glovebox) “VSC OFF”
(vehicle stability control) switch
Rear window and outside rearview
mirror defogger button
Emergency flasher button
Audio/Navigation system
1
Front passenger occupant classification indicator/
Engine immobilizer system indicator
1 For more information, refer to Toyota.com to download the Toyota Audio System Owner’s Manual.2 If equipped.

4
OVERVIEWInstrument cluster
For details, refer to “Indicators and warning lights,” Section 2-2\
, 2018 Owner’s
Manual.
Cruise control indicator
Anti-lock Brake System (ABS)
warning
1
Brake system warning1
Airbag SRS warning1
Automatic High Beam indicator1
Cruise control SET indicator Tachometer
Speedometer
Outside temperature
Engine coolant temperature gauge Shift and gear position indicator (if equipped)
Fuel gauge
Multi-Information Display (MID) Odometer and trip meter display
Indicator symbols
Service indicators and reminders

5
OVERVIEW
FEATURES & OPERATIONS
TOYOTA SAFETY SENSE
SAFETY & EMERGENCY FEATURES
Headlight low beam indicator
Turn signal indicator
Headlight high beam indicator
Electric power steering system warning1
Slip indicator1
Vehicle Stability Control OFF indicator1
Low fuel level warning
Front passenger occupant classification indicator1
Seat belt reminder
(alarm will sound if speed is over 12 mph)
Malfunction/Check Engine indicator1
Low Tire Pressure Warning1
Low outside temperature indicator
Engine immobilizer indicator
ECO driving indicator light1,2
Master warning1
SPORT mode indicator2
Lane Departure Alert (LDA) indicator
Pre-Collision System (PCS) warning1
Fuel tank door position
1 If indicator does not come on or turn off within a few seconds of starting engine, there may be a
malfunction. Have vehicle inspected by your Toyota dealer.
2 If equipped.

6
LOCKING OPERATIONUNLOCKING OPERATION
PANIC BUTTON
Fuel tank door release & cap
NOTE: Tighten until one click is heard. If the cap is not locked or tigh\
tened,
Check Engine “
” indicator may illuminate.
Keyless entry
NOTE: If a door is not opened within 60 seconds of unlocking, all doors will
relock for safety.
Push
ONCE: Driver door TWICE: All doorsPush
Push and hold
OVERVIEW
Turn to open
Store
Pull up

7
OVERVIEW
FEATURES & OPERATIONS
TOYOTA SAFETY SENSE
SAFETY & EMERGENCY FEATURES
-
Hood release
Windshield washer
fluid tank Engine coolant reservoir
Engine oil filler capEngine oil level dipstick
Engage support rod
PullPull up latch and raise hood
NOTE: Regularly scheduled maintenance, including oil changes, will help \
extend the life of your vehicle and maintain performance. Please refer t\
o the
“Warranty Maintenance Guide.”
Engine maintenance

8
Pull(2) Push(1) Pull slightly
(3) LowerRelease
Set
* The ignition switch must be “ON” and the brake pedal depressed t\
o shift from
Park.
Push shift lever to the left from “D” position, to “M” posit\
ion.
+ :
Upshift (push and release)
-

:
Downshift (pull and release)
Downshifting increases power going uphill, or provides engine braking do\
wnhill. For
best fuel economy during normal driving conditions, always drive with th\
e shift lever in
the “D” position.
Lift up ring to shift into reverse
“M”
-
++ (“M” mode)
- (“M” mode)
P
R
N
D
M
Park*
Reverse
Neutral
Drive
“M” mode
Shift lever
FEATURES & OPERATIONS
“M” 7-SPEED SPORT SEQUENTIAL SHIFTMATIC MODE
Automatic transmission (if equipped)
Manual transmission (if equipped)
Parking brake
