TOYOTA HIGHLANDER 2019 Owners Manual (in English)

4616-1. Using the air conditioning system and defogger
6
Interior features
HIGHLANDER_U
Heated steering wheel/seat heaters/seat
ventilator s

: If equipped
The heated steering wheel and seat heaters heat the side grips
of the steering wheel and seats, respectively. Seat ventilators
maintain good airflow by blo wing air from the seats.
WARNING
●Care should be taken to prevent injury if anyone in the following categories
comes in contact with the steering wheel or seats when the heater is on:
• Babies, small children, the elderly, the sick and the physical ly chal-
lenged
• Persons with sensitive skin
• Persons who are fatigued
• Persons who have taken alcohol or drugs that induce sleep (sle eping
drugs, cold remedies, etc.)
● Observe the following precautions to prevent the minor burns or overheat-
ing
• Do not cover the seat with a blanket or cushion when using the seat
heater.
• Do not use the seat heaters more than necessary.
NOTICE
● Do not put heavy objects that have an uneven surface on the sea t and do
not stick sharp objects (needles, nails, etc.) into the seat.
● To prevent battery discharge, do not use the functions when the engine is
stopped.

4626-1. Using the air conditioning system and defogger
HIGHLANDER_U
Turn the heated steering wheel on/off
The indicator light comes on when
the heated steering wheel is oper-
ating.
The heated steering wheel will
automatically turn off after about 30
minutes.
■The heated steering wheel can be used when
The engine switch is in IGNITION ON mode.
■
Seat heaters
Turns the seat heater on
The indicator light comes on.
Adjusts the seat temperature
The further you move the dial
forward, the warmer the seat
becomes.
■
Seat heaters/ventilators Turns the seat heater on
The indicator light comes on.
The higher the number is, the
warmer the seat becomes.
Blows air from the seat
The indicator light comes on.
The higher the number is, the
stronger the airflow becomes.
Heated steering wheel
Front seat heaters and ventilators
1
2
1
2

4636-1. Using the air conditioning system and defogger
6
Interior features
HIGHLANDER_U
■The seat heaters and seat heaters/ventilators can be used when
Vehicles without a smart key system
The engine switch is in the “ON” position.
Vehicles with a smart key system
The engine switch is in IGNITION ON mode.
■ When not in use
Seat heaters
Turn the dial fully backward. The indicator light will turn off .
Seat heaters/ventilators
Set the knob at “0”. The indicator light will turn off.
Hi
Lo
Off
The indicator comes on when the
second seat heater is on.
■ The second seat heaters can be used when
The engine switch is in IGNITION ON mode.
Second seat heaters
1
2
3

464
HIGHLANDER_U
6-2. Using the interior lights
Rear interior/rear personal lights
Ambient lights (if equipped)
Front interior/front personal lights
Outer foot lights (if equipped)
Engine switch light (vehicles with a smart key system)
Front door courtesy lights
Turns the lights on/off
Turns the lights linked to door
position on/off
Interior lights list
Interior lights
1
2
3
4
5
6
1
2

4656-2. Using the interior lights
6
Interior features
HIGHLANDER_U
Turn the light on/off
■Illuminated entry system
Vehicles without a smart key system
The lights automatically turn on/off according to the engine sw itch position,
whether the doors are locked/unlocked, and whether the doors ar e open/
closed.
Vehicles with a smart key system
The lights automatically turn on/off according to engine switch mode, the
presence of the electronic key, whether the doors are locked/un locked, and
whether the doors are opened/closed.
■ To prevent battery discharge
If the following lights are left on when the engine switch is t urned off, the lights
will go off automatically after 20 minutes:
● Interior lights
● Personal lights
● Front door courtesy lights
● Ambient lights (if equipped)
● Engine switch light (vehicles with a smart key system)
■ Customization
Settings (e.g. the time elapsed before lights turn off) can be changed.
(Customizable features: P. 682)
Personal lights
FrontRear

466
HIGHLANDER_U
6-3. Using the storage features
List of storage features
Auxiliary boxes ( P. 4 7 1 )
Open tray ( P. 4 7 2 )
Glove box ( P. 4 6 7 ) Bottle holders (
P. 468)
Cup holders ( P. 469)
Console box ( P. 467)
WARNING
●Do not leave glasses, lighters or spray cans in the storage spa ces, as this
may cause the following when cabin temperature becomes high:
• Glasses may be deformed by heat or cracked if they come into c ontact
with other stored items.
• Lighters or spray cans may explode. If they come into contact with other
stored items, the lighter may catch fire or the spray can may r elease
gas, causing a fire hazard.
● When driving or when the storage compartments are not in use, k eep the
lids closed.
In the event of sudden braking or sudden swerving, an accident may
occur due to an occupant being struck by an open lid or the items stored
inside.
1
2
3
4
5
6

4676-3. Using the storage features
6
Interior features
HIGHLANDER_U
Unlock with the key (vehicles
without a smart key system) or
mechanical key ( vehicles with a
smart key system)
Lock with the key (vehicles
without a smart key system) or
mechanical key ( vehicles with a
smart key system)
Open (pull lever)
■ Power back door main switch (vehicles with power back door)
The power back door main switch is located in the glove box. ( P. 132)
To open the console box lids,
press on the knob and slide both
lids.
Glove box
1
2
3
Console box

4686-3. Using the storage features
HIGHLANDER_U
■Tray in the console box
■
Front
■Rear
The tray slides forward/backward and can
be removed.
Bottle holders

4696-3. Using the storage features
6
Interior features
HIGHLANDER_U
■When using the bottle holder
●When storing a bottle, close the cap.
● The bottle may not be stored depending on its size or shape.
■
Front
■Rear (second seats)
Ty p e A
Pull the armrest down.
(  P. 486)
WARNING
Do not place anything other than a bottle in the bottle holders .
Other items may be thrown out of the holders in the event of an accident or
sudden braking and cause injury.
Cup holders

4706-3. Using the storage features
HIGHLANDER_U
Ty p e B
Fold the side table up for use.
(
P. 4 8 8 )
■Rear (third seats)
■ Removing the cup holder insert (front cup holder)
The cup holder insert may be removed for
cleaning.
WARNING
Do not place anything other than cups or aluminum cans in the c up holders.
Other items may be thrown out of the holders in the event of an accident or
sudden braking, causing injury. If possible, cover hot drinks t o prevent
burns.
