TOYOTA LAND CRUISER 1998 Factory Repair Manual
Manufacturer: TOYOTA, Model Year: 1998, Model line: LAND CRUISER, Model: TOYOTA LAND CRUISER 1998Pages: 3115, PDF Size: 54.88 MB
Page 401 of 3115
BO1JR-03
H04846
Wiper Arm
Cowl Top Ventilator
Louver LH Cowl Top Ventilator
Louver RH
Hood to Cowl Top Seal
Wiper Motor
Wiper Link
20 (204, 15)
20 (204, 15)
5.4 (55, 48 in.´lbf)
: Specified torqueN´m (kgf´cm, ft´lbf)
5.4 (55, 48 in.´lbf)
5.4 (55, 48 in.´lbf)
BO-32
- BODYFRONT WIPER AND WASHER
2606 Author: Date:
2004 LAND CRUISER (RM1071U)
FRONT WIPER AND WASHER
COMPONENTS
Page 402 of 3115
BO1JT-03
H04842
AA
M
BH
D
I
J E
S F
O NL G
P
Q
X
TK R FE U
C
S W
V
BO-34
- BODYFRONT WIPER AND WASHER
2608 Author: Date:
2004 LAND CRUISER (RM1071U)
INSPECTION
INSPECT WASHER NOZZLE
While operating the washer, check if the point where the washer
fluid hits the windshield is within the range indicated by the
hatched line.
A: Approx. 311 mm (12.24 in.)
B: Approx. 110 mm (4.33 in.)
C: Approx. 86 mm (3.39 in.)
D: Approx. 116 mm (4.57 in.)
E: Approx. 205 mm (8.07 in.)
F: Approx. 22 mm (0.87 in.)
G: Approx. 138 mm (5.43 in.)
H: Approx. 60 mm (2.36 in.)
I: Approx. 85 mm (3.35 in.)
J: Approx. 364 mm (14.33 in.)
K: Approx. 496 mm (19.53 in.)
L: Approx. 81 mm (3.19 in.)
M: Approx. 35 mm (1.38 in.)
N: Approx. 157 mm (6.18 in.)
O: Approx. 159 mm (6.26 in.)
P: Approx. 63 mm (2.48 in.)
Q: Approx. 169 mm (6.65 in.)
R: Approx. 331 mm (13.03 in.)
S: Approx. 465 mm (18.31 in.)
T: Approx. 468 mm (18.43 in.)
U: Approx. 45 mm (1.77 in.)
V: Approx. 104 mm (4.09 in.)
W: Approx. 119 mm (4.69 in.)
X: Approx. 44 mm (1.73 in.)
Page 403 of 3115
BO1JV-04
H04844
H04845
A
B BO-36
- BODYFRONT WIPER AND WASHER
2610 Author: Date:
2004 LAND CRUISER (RM1071U)
INSTALLATION
1. INSTALL WASHER NOZZLES
2. INSTALL WIPER LINK
Install the wiper link through the service hole, then torque the
6 bolts.
Torque: 5.4 N´m (55 kgf´cm, 48 in.´lbf)
HINT:
When installing the wiper link, connect the claw of wiper link to
the panel.
3. INSTALL WIPER MOTOR
(a) Connect the wiper motor to wiper link.
(b) Torque the 4 bolts.
(c) Connect the connector.
4. INSTALL COWL TOP VENTILATOR LOUVERS
(a) Install the cowl top ventilator louver LH.
(b) Install the cowl top ventilator louver RH.
5. INSTALL HOOD TO COWL TOP SEAL
6. INSTALL WIPER ARMS
(a) Operate the wipers once and turn the wiper switch OFF.
(b) Install the wiper arms and tighten nuts by hand.
(c) Adjust the installation position of the wiper arms to the
positions shown in the illustration.
A: Approx. 40 mm (1.57 in.)
B: Approx. 16 - 26 mm (0.63 - 1.02 in.)
(d) Torque the nuts.
Torque: 20 N´m (204 kgf´cm, 15 ft´lbf)
(e) Install the wiper arm caps.
Page 404 of 3115
BO1JS-03
H04841
H00735
- BODYFRONT WIPER AND WASHER
BO-33
2607 Author: Date:
2004 LAND CRUISER (RM1071U)
REMOVAL
1. REMOVE WIPER ARMS
(a) Remove the 2 caps and 2 nuts.
(b) Remove the 2 wiper arms.
2. REMOVE HOOD TO COWL TOP SEAL
3. REMOVE COWL TOP VENTILATOR LOUVERS
(a) Remove the cowl top ventilator louver RH.
(b) Remove the cowl top ventilator louver LH.
4. REMOVE WIPER MOTOR
(a) Disconnect the connector, unfasten the 4 bolts.
(b) Disconnect the wiper motor from the wiper link, then re-
move the wiper motor.
5. REMOVE WIPER LINK
(a) Loosen the 6 bolts.
(b) Remove the wiper link through the service hole.
6. REMOVE WASHER NOZZLE
(a) Disconnect the washer hose.
(b) Using a screwdriver, remove the washer nozzle.
HINT:
Tape the screwdriver tip before use.
(c) Employ the same manner described above to the other
side.
Page 405 of 3115
BO1JU-03
BE3367
2 - 2.5 mm
(0.024 - 0.026 in.)0.6 - 0.65 mm(0.079 - 0.098 in.)
- BODYFRONT WIPER AND WASHER
BO-35
2609 Author: Date:
2004 LAND CRUISER (RM1071U)
ADJUSTMENT
ADJUST WASHER NOZZLE
Using a tool like the one shown in the illustration, change the
direction of the nozzle hole to adjust the point where washer
fluid hits the windshield.
Page 406 of 3115
BO1JR-03
H04846
Wiper Arm
Cowl Top Ventilator
Louver LH Cowl Top Ventilator
Louver RH
Hood to Cowl Top Seal
Wiper Motor
Wiper Link
20 (204, 15)
20 (204, 15)
5.4 (55, 48 in.´lbf)
: Specified torqueN´m (kgf´cm, ft´lbf)
5.4 (55, 48 in.´lbf)
5.4 (55, 48 in.´lbf)
BO-32
- BODYFRONT WIPER AND WASHER
2606 Author: Date:
2004 LAND CRUISER (RM1071U)
FRONT WIPER AND WASHER
COMPONENTS
Page 407 of 3115
BO1JT-03
H04842
AA
M
BH
D
I
J E
S F
O NL G
P
Q
X
TK R FE U
C
S W
V
BO-34
- BODYFRONT WIPER AND WASHER
2608 Author: Date:
2004 LAND CRUISER (RM1071U)
INSPECTION
INSPECT WASHER NOZZLE
While operating the washer, check if the point where the washer
fluid hits the windshield is within the range indicated by the
hatched line.
A: Approx. 311 mm (12.24 in.)
B: Approx. 110 mm (4.33 in.)
C: Approx. 86 mm (3.39 in.)
D: Approx. 116 mm (4.57 in.)
E: Approx. 205 mm (8.07 in.)
F: Approx. 22 mm (0.87 in.)
G: Approx. 138 mm (5.43 in.)
H: Approx. 60 mm (2.36 in.)
I: Approx. 85 mm (3.35 in.)
J: Approx. 364 mm (14.33 in.)
K: Approx. 496 mm (19.53 in.)
L: Approx. 81 mm (3.19 in.)
M: Approx. 35 mm (1.38 in.)
N: Approx. 157 mm (6.18 in.)
O: Approx. 159 mm (6.26 in.)
P: Approx. 63 mm (2.48 in.)
Q: Approx. 169 mm (6.65 in.)
R: Approx. 331 mm (13.03 in.)
S: Approx. 465 mm (18.31 in.)
T: Approx. 468 mm (18.43 in.)
U: Approx. 45 mm (1.77 in.)
V: Approx. 104 mm (4.09 in.)
W: Approx. 119 mm (4.69 in.)
X: Approx. 44 mm (1.73 in.)
Page 408 of 3115
BO1JV-04
H04844
H04845
A
B BO-36
- BODYFRONT WIPER AND WASHER
2610 Author: Date:
2004 LAND CRUISER (RM1071U)
INSTALLATION
1. INSTALL WASHER NOZZLES
2. INSTALL WIPER LINK
Install the wiper link through the service hole, then torque the
6 bolts.
Torque: 5.4 N´m (55 kgf´cm, 48 in.´lbf)
HINT:
When installing the wiper link, connect the claw of wiper link to
the panel.
3. INSTALL WIPER MOTOR
(a) Connect the wiper motor to wiper link.
(b) Torque the 4 bolts.
(c) Connect the connector.
4. INSTALL COWL TOP VENTILATOR LOUVERS
(a) Install the cowl top ventilator louver LH.
(b) Install the cowl top ventilator louver RH.
5. INSTALL HOOD TO COWL TOP SEAL
6. INSTALL WIPER ARMS
(a) Operate the wipers once and turn the wiper switch OFF.
(b) Install the wiper arms and tighten nuts by hand.
(c) Adjust the installation position of the wiper arms to the
positions shown in the illustration.
A: Approx. 40 mm (1.57 in.)
B: Approx. 16 - 26 mm (0.63 - 1.02 in.)
(d) Torque the nuts.
Torque: 20 N´m (204 kgf´cm, 15 ft´lbf)
(e) Install the wiper arm caps.
Page 409 of 3115
BO1JS-03
H04841
H00735
- BODYFRONT WIPER AND WASHER
BO-33
2607 Author: Date:
2004 LAND CRUISER (RM1071U)
REMOVAL
1. REMOVE WIPER ARMS
(a) Remove the 2 caps and 2 nuts.
(b) Remove the 2 wiper arms.
2. REMOVE HOOD TO COWL TOP SEAL
3. REMOVE COWL TOP VENTILATOR LOUVERS
(a) Remove the cowl top ventilator louver RH.
(b) Remove the cowl top ventilator louver LH.
4. REMOVE WIPER MOTOR
(a) Disconnect the connector, unfasten the 4 bolts.
(b) Disconnect the wiper motor from the wiper link, then re-
move the wiper motor.
5. REMOVE WIPER LINK
(a) Loosen the 6 bolts.
(b) Remove the wiper link through the service hole.
6. REMOVE WASHER NOZZLE
(a) Disconnect the washer hose.
(b) Using a screwdriver, remove the washer nozzle.
HINT:
Tape the screwdriver tip before use.
(c) Employ the same manner described above to the other
side.
Page 410 of 3115
BO5235
Centering Bolt
Bolt with Washer
BO1J8-03
H04837
H04838
H04839
BO-6
- BODYHOOD
2580 Author: Date:
2004 LAND CRUISER (RM1071U)
HOOD
ADJUSTMENT
HINT:
Since the centering bolt is used as a hood hinge set bolt, the
hood cannot be adjusted with it on. Substitute the bolt with a
washer for the centering bolt.
1. ADJUST HOOD IN FORWARD/REARWARD AND
LEFT/RIGHT DIRECTIONS
Adjust the hood by loosening the hood side hinge bolts.
Torque: 18 N´m (185 kgf´cm, 13 ft´lbf)
2. ADJUST FRONT EDGE OF HOOD IN VERTICAL
DIRECTION
Adjust the hood by turning the cushions.
3. ADJUST HOOD LOCK
Adjust the lock by loosening the bolts.
