- BODYLOWER BACK DOOR
2604 Author
: Date
:
2004 LAND CRUISER (RM1071U)
REASSEMBLY
Reassembly is in the reverse order of disassembly (See page BO-27).

BO1LD-03
H18905
Rear Door Opening TrimRoof Headlining Rear Trim
Upper Roof Side
Inner Garnish
Quarter Trim Jack CoverStriker Plate
Quarter Trim Panel Rear Door Scuff PlateQuarter Belt MouldingRear Mat
Rear Mat Set Plate Quarter Window
GlassStriker Plate Quarter Window
Glass Weatherstrip
Striker Plate
x5 Rear
Assist Grip Rear Vent Window Motor
Assist Grip
Plug
Assist Grip
Plug
- BODYQUARTER WINDOW GLASS
BO-61
2635 Author
: Date
:
2004 LAND CRUISER (RM1071U)
QUARTER WINDOW GLASS
COMPONENTS

BO1LF-02
BO-64
- BODYQUARTER WINDOW GLASS
2638 Author
: Date
:
2004 LAND CRUISER (RM1071U)
INSTALLATION
Installation is in the reverse order of removal (See page BO-62).

BO4IW-01
H05257
: 5 Clips
H05258
H05259
H07941
11 Clips BO-62
- BODYQUARTER WINDOW GLASS
2636 Author
: Date
:
2004 LAND CRUISER (RM1071U)
REMOVAL
1. REMOVE ROOF HEADLINING REAR TRIM
Using a screwdriver, remove the roof headlining rear trim.
HINT:
Tape up the screwdriver tip before use.
2. REMOVE REAR NO. 2 SEATS
3. REMOVE REAR MAT SET PLATE
(a) Remove the 5 screws.
(b) Using a screwdriver, remove the rear mat set plate.
HINT:
Tape up the screwdriver tip before use.
4. REMOVE STRIKER PLATE
(a) Remove the 6 screws.
(b) Using a screwdriver, remove the striker plates.
HINT:
Tape up the screwdriver tip before use.
5. REMOVE REAR MAT
6. REMOVE REAR NO. 2 SEAT OUTER BELT FLOOR AN-
CHOR
Torque:42 N´m (430 kgf´cm, 31 ft´lbf)
7. REMOVE REAR NO. 1 SEAT OUTER BELT FLOOR AN-
CHOR
Torque:42 N´m (430 kgf´cm, 31 ft´lbf)
8. REMOVE REAR DOOR SCUFF PLATE
9. REMOVE REAR DOOR OPENING TRIM
10. REMOVE QUARTER TRIM PANEL
(a) Remove the quarter trim jack cover.
(b) Using a clip remover, remove the 2 clips.
(c) Remove the quarter trim panel, then disconnect the con-
nector.
11. REMOVE REAR NO. 2 SEAT OUTER BELT SHOUL-
DER ANCHOR
12. REMOVE REAR NO. 1 SEAT OUTER BELT SHOUL-
DER ANCHOR

H18906
: 9 Clips
H04108
H05403
Quarter Belt
Moulding
Clip
: 4 Clips
H04110
- BODYQUARTER WINDOW GLASS
BO-63
2637 Author
: Date
:
2004 LAND CRUISER (RM1071U)
13. REMOVE UPPER ROOF SIDE INNER GARNISH
(a) Using a screwdriver, remove the assist grip plugs, then re-
move the 2 screws and the rear assist grip.
HINT:
Tape up the screwdriver tip before use.
(b) Using a clip remover, remove the clip.
(c) Using a screwdriver, remove the upper roof side inner gar-
nish.
HINT:
Tape the screwdriver tip before use.
14. REMOVE QUARTER WINDOW GLASS
(a) Disconnect the connector.
(b) w/ Antenna:
Disconnect the connector.
(c) Remove the 2 bolts, the 2 nuts and the quarter window
glass.
15. REMOVE QUARTER WINDOW GLASS WEATH-
ERSTRIP
16. REMOVE QUARTER BELT MOULDING
(a) Remove the screw.
(b) Using a screwdriver, remove the quarter belt moulding.
HINT:
Tape up the screwdriver tip before use.
17. REMOVE REAR VENT WINDOW MOTOR
Remove the screw and the rear vent window motor.
18. REMOVE QUARTER WINDOW LOCK
Remove the screw and the quarter window lock.

BO1K4-05
H05401
No. 2 Roof Drip Side Finish Center Moulding
Roof Drip Side Finish Moulding
No. 2 Roof Drip Side
Finish Moulding Clip



Non-reusable part BO-48
- BODYROOF DRIP SIDE FINISH MOULDING
2622 Author
: Date
:
2004 LAND CRUISER (RM1071U)
ROOF DRIP SIDE FINISH MOULDING
COMPONENTS

BO1K6-05
BO-50
- BODYROOF DRIP SIDE FINISH MOULDING
2624 Author
: Date
:
2004 LAND CRUISER (RM1071U)
INSTALLATION
1. INSTALL NO. 2 ROOF DRIP SIDE FINISH MOULDING CLIP
If the No. 2 roof drip side finish moulding clip comes off.
(a) Using a heat light, heat the body mounting surface to 40 - 60 °C (104 - 140 °F).
NOTICE:
Do not heat the body excessively.
(b) Remove the adhesive tape and adhesive from the body.
(c) Wipe off stains with cleaner.
(d) Using a heat light, heat the body and clip.
Body: 40 - 60 °C (104 - 140 °F)
Clip: 20 - 30 °C (68 - 86 °F)
NOTICE:
Do not heat the body and clip excessively.
(e) Install the clip.
2. INSTALL NO. 2 ROOF DRIP SIDE FINISH CENTER MOULDING
Install the No. 2 roof drip side finish center moulding to the roof drip side finish moulding.
3. INSTALL ROOF DRIP SIDE FINISH MOULDING

BO1K5-03
H05400
Roof Drip Side Finish Moulding
Moulding Remover
No. 2 Roof Drip Side
Finish Moulding Clip
- BODYROOF DRIP SIDE FINISH MOULDING
BO-49
2623 Author
: Date
:
2004 LAND CRUISER (RM1071U)
REMOVAL
1. REMOVE NO. 2 ROOF DRIP SIDE FINISH CENTER
MOULDINGS
2. REMOVE ROOF DRIP SIDE FINISH MOULDING
Using a moulding remover, remove the roof drip side finish
moulding.
NOTICE:

Do not damage the body.

Do not remove the No. 2 roof drip side finish moulding
clip.

When the clip comes off, replace it with a new one.
HINT:
Tape the moulding remover tip before use.

BO1J7-03
Spare Wheel
Carrier No.1 Lid
H18902
: Specified torqueN´m (kgf´cm, ft´lbf)
Rear Bumper Step Reinforcement
Extension
Mounting
Bracket
Rear Bumper CoverExtension Mounting Bracket
Reflex Reflector
4.9 (50, 43 in.´lbf)
19 (195, 14)
4.9 (50, 43 in.´lbf)
20 (204, 15)
20 (204, 15)
20 (204, 15)
Reflex Reflector
19 (195, 14)
Rear Bumper Lower Cover
12.5 (127, 11)
12.5 (127, 11)
20 (204, 15)
w/ Tow Hitch Receiver
Tow Hitch Receiver
85 (867, 63)
HINT:
REMOVAL: Remove the Tow hitch receiver
after loosening the rear bumper cover.
INSTALLATION: Install the Tow hitch receiver
after installing the rear bumper cover temporarily.
Rear Bumper Reinforcement20 (204, 15)
20 (204, 15)
85 (867, 63)
- BODYREAR BUMPER
BO-5
2579 Author
: Date
:
2004 LAND CRUISER (RM1071U)
REAR BUMPER
COMPONENTS

BO1JG-03
H04832
H04833
BO2556
BO-18
- BODYREAR DOOR
2592 Author
: Date
:
2004 LAND CRUISER (RM1071U)
ADJUSTMENT
1. ADJUST DOOR IN FORWARD/BACKWARD AND VER-
TICAL DIRECTIONS
(a) Remove the front door scuff plate.
(b) Remove the rear door scuff plate.
(c) Remove the front door opening trim.
(d) Remove the rear door opening trim.
(e) Remove the center pillar lower garnish.
(f) Loosen the body side hinge nuts to adjust.
Torque: 23 N´m (235 kgf´cm, 17 ft´lbf)
(g) Install the removed parts.
2. ADJUST DOOR IN RIGHT/LEFT AND VERTICAL
DIRECTIONS
Loosen the door side hinge bolts to adjust.
Torque: 26 N´m (265 kgf´cm, 19 ft´lbf)
3. ADJUST DOOR LOCK STRIKER
(a) Check that the door fit and door lock linkages are adjusted
correctly.
(b) Loosen the striker mounting screws to adjust.
Torque: 11 N´m (115 kgf´cm, 8 ft´lbf)
(c) Using a plastic hammer, tap the striker to adjust it.
