TOYOTA MIRAI 2022 Owners Manual

3416-1. Using the air conditioning system and defogger
Owners Manual_USA_M62084_en
6
Interior features
*: If equipped
■Rear control panel
The rear A/C can be operated
by turning the rear control panel
ON using the ON/OFF switch.
When the front seat A/C is OFF,
the rear A/C cannot be turned
ON independently.
Rear control panel ON/OFF
switch. Rear seat Airflow mode con-
trol switch
Rear seat temperature con-
trol switch
The temperature setting of the
rear seats can be adjusted using
the following methods:
 When the “3-ZONE” indicator
is off: Adjust the driver’s seat
temperature.
 Adjust the temperature setting
of rear seat using the Toyota
multi-operation touch (rear air
conditioning control screen)
or rear control panel.
■Location of air outlets
The air outlets and air volume
changes according to the
selected air flow mode.
: Air flows to the upper body
: Air flows to the upper body
and feet
: Air flows to the feet
Rear automatic air
conditioning system*
The air outlets and fan
speed are automatically
adjusted according to the
temperature setting.
Rear air conditioning con-
trol
Adjusting the temperature
setting of the rear seats
Air outlet lay out and oper-
ations

3426-1. Using the air conditioning system and defogger
Owners Manual_USA_M62084_en
■Adjusting the position of
and opening and closing
the air outlets
Rear
1 Direct air flow to the left or
right, up or down
2 Open the vent
3 Close the vent
*: If equipped
NOTICE
■To prevent 12-volt battery dis-
charge
Do not leave the air conditioning
system on longer than necessary
when the fuel cell system is off.
Heated steering
wheel*/seat heat-
ers*/seat ventilators*
 Heated steering wheel
Warms up the grip of the
steering wheel
 Front seat heaters/Rear
seat heaters
Warm up the seat upholstery
 Front seat ventilators/Rear
seat ventilators
Maintain good ventilation by
pulling air through the seat
upholstery
It can be operated using the
front air conditioner
switches and the Toyota
multi-operation touch, as
well as the rear control
panel (if equipped).
WARNING
■To prevent minor burn inju-
ries
Care should be taken if anyone in
the following categories comes in
contact with the steering wheel or
seats when the heater is on:
●Babies, small children, the
elderly, the sick and the physi-
cally challenged
●Persons with sensitive skin
●Persons who are fatigued

3436-1. Using the air conditioning system and defogger
Owners Manual_USA_M62084_en
6
Interior features
■Front (air conditioning con-
trol panel: vehicle with a
12.3-inch display) Adjust the front seat heater
temperature level
The seat heater can be adjusted in
3 levels. (Low, Mid or Hi)
Seat heater/seat ventilator
auto mode Indicator Adjust the front seat ventila-
tor fan speed level
The seat ventilator can be adjusted
in 3 levels. (Low, Mid or Hi)
■Toyota multi-operation
touch (Vehicle with a 12.3-
inch display)
Select the displayed on the
Toyota multi-operation touch
and the Seat/Steering Climate
screen is displayed.
Adjust the seat heater tem-
perature level
The seat heater c an be adjusted in
3 levels. (Low, Mid or Hi)
Adjust the heated steering
wheel temperature level
*
The heated steering wheel can be
adjusted in 2 le vels. (Low or Hi)
Adjust the seat ventilator fan
speed level
The seat ventilator can be adjusted
in 3 levels. (Low, Mid or Hi)
ALL AUTO control switch
When the ALL AUTO control is on,
the indicator illu minates on the
screen. ( P.324)
WARNING
●Persons who have taken alco-
hol or drugs that induce sleep
(sleeping drugs, cold remedies,
etc.)
NOTICE
■To prevent damage to the
seat heaters and seat ventila-
tors
Do not put heavy objects that
have an uneven surface on the
seat and do not stick sharp
objects (needles, nails, etc.) into
the seat.
■To prevent 12-volt battery dis-
charge
Do not use the functions when the
fuel cell system is off.
Operating instructions

3446-1. Using the air conditioning system and defogger
Owners Manual_USA_M62084_en
■Rear control panel (if
equipped)Adjust the rear seat heater
temperature level
The seat heater can be adjusted in
3 levels. (Low, Mid or Hi)
Adjust the rear right side seat
ventilator fan speed level
The seat ventilator can be adjusted
in 3 levels. (Low, Mid or Hi)
Indicators
■The heated steering wheel, seat
heaters and seat ventilators can
be used when
The power swit ch is in ON.
■Air conditioning system-linked
control mode
When the seat ventilator fan speed
level is Hi, the s eat ventilator fan
speed becomes higher according to
the fan speed of the air conditioning
system.
■When the air conditioning sys-
tem is operating in S-FLOW
mode
If a passenger is not detected in the
passenger seat, the seat ventilator
and seat heater of the passenger’s
seat will be turne d off if on.
(  P.338)
■Change settings for the rear
control panel
The following settings can be
changed.
• Reaction time after touching the button.
• Turn button operation sounds ON/OFF
1 Stop the vehicle in a safe place
and stop the fuel cell system.
2 Press the power switch 1 time
with brake pedal released and
switch the mode to ACC.
The setting cannot be changed
when the power switch is ON.
3 Press for 10 seconds or
more while pressing the but-
ton.
4 Release the button after the
buzzer sounds.
5 Select customizable item
Change the reaction time for button
operations:
When is pressed it becomes
faster, when is pressed it
becomes slower.
Change the button operation
sounds ON/OFF
When is pressed it turns ON,
when is pressed it turns OFF.
6 When changes are complete, the
indicators for the seat
heater/seat ventilator turns on as
shown in the following table.

3456-1. Using the air conditioning system and defogger
Owners Manual_USA_M62084_en
6
Interior features
7 Settings are complete with any of
the following.
• Operate the button and turn OFF the rear control panel.
• Press the power switch.
• Do not operate the power switch for approximately 10 seconds.
■Customization
Some functions can be customized.
(  P.508)
FunctionSettingsIndicator
Reaction
Time
Fast
A little fast
Normal
A little
slow
Slow
Operation
sounds
ON
OFF
WARNING
■To prevent overheating and
minor burn injuries
Observe the following precautions
when using the seat heaters.
●Do not cover the seat with a
blanket or cushion when using
the seat heater.
●Do not use seat heater more
than necessary.

3466-2. Using the interior lights
Owners Manual_USA_M62084_en
6-2.Using the interior lights
Door trim ornament lights (P.347) (if equipped)
Rear personal lights ( P.347)
Inside door handle lights ( P.347) (if equipped)
Front personal lights ( P.347)
Shift lever lights (if equipped)
Interior lights ( P.347)
Outer foot lights (if equipped)
Front footwell lights (if equipped)
Instrument panel ornament lights ( P.347) (if equipped)
Cup holder lights ( P.347)
Rear footwell lights (if equipped)
Door courtesy lights
Interior lights list
Location of the i nterior lights

3476-2. Using the interior lights
Owners Manual_USA_M62084_en
6
Interior features
■Turning the door position
on
Press the door-linked interior
light switch
The lights are turned on and off
according to whether the doors are
opened/closed.
■Turning the lights on/off
Touch the light
The rear personal lights turn on/off
along with the in terior lights.
■Turning the lights on/off
Touch the light
■Turning the lights on/off
Press the switch
The rear personal lights turn on/off
along with the interior lights.
Using the Toyota multi-operation
touch ( P.353), one of 8 colors
of following lights can be
selected. However, it cannot be
changed individually.
 Inside door handle lights
 Door trim ornament lights
 Cup holder lights
 Instrument panel ornament
lights
Operating the interior
lights
Operating the front per-
sonal lights
Operating the rear per-
sonal lights
Changing the illumina-
tion color (if equipped)

3486-2. Using the interior lights
Owners Manual_USA_M62084_en
1Select .
2 Select “Illumination Color”.
3 Select the desired color.
■Illuminated entry system
The lights automatically turn on/off
according to the power switch
mode, the presence of the elec-
tronic key, whether the doors are
locked/unlocked, and whether the
doors are open/closed.
■To prevent the 12-volt battery
from being discharged
If the interior lights remain on when
the power switch is turned off, the
lights will go off automatically after
20 minutes.
■When the interior lights or front
personal lights do not respond
as normal
●When water, dirt, etc., have
adhered to the lens surface
●When operated with a wet hand
●When wearing gloves, etc.
■The interior lights may turn on
automatically when
If any of the SRS airbags deploy
(inflate) or in the event of a strong
rear impact, the interior lights will
turn on automatically.
The interior lights will turn off auto-
matically after approximately 20min-
utes.
The interior lights can be turned off
manually. However, in order to help
prevent further collisions, it is rec-
ommended that they be left on until
safety can be ensured.
(The interior lights may not turn on
automatically depending on the
force of the impact and conditions of
the collision.)
■Customization
Some functions can be customized.
(  P.498)
NOTICE
■To prevent 12-volt battery dis-
charge
Do not leave the lights on longer
than necessary when the fuel cell
system is off.
■Removing light lenses
Never remove the lens for the
interior lights and front personal
lights. Otherwise, the lights will be
damaged. If a lens needs to be
removed, contact your Toyota
dealer.

3496-3. Using the storage features
Owners Manual_USA_M62084_en
6
Interior features
6-3.Using the storage features
Auxiliary boxes* (  P.351)
Cup holders ( P.350)
Console box ( P.351)
Glove box ( P.349)
*: If equipped
Pull up the lever to open.
List of storage features
Location of the storage features
WARNING
■Items that should not be left
in the storage spaces
Do not leave glasses, lighters or
spray cans in the storage spaces,
as this may cau se the following
when cabin temperature becomes
high:
●Glasses may be deformed by
heat or cracked if they come
into contact with other stored
items.
●Lighters or spray cans may
explode. If they come into con-
tact with other stored items, the
lighter may catch fire or the
spray can may release gas,
causing a fire hazard.
Glove box

3506-3. Using the storage features
Owners Manual_USA_M62084_en
1Unlock with the mechanical
key
2 Lock with the mechanical key
■Glove box light
The glove box light turns on when
the tail lights are on.
■Trunk opener main switch
The trunk opener main switch is
located in the glove box. ( P.129)
Front
Rear (vehicles without rear
seat heater)
Press in and release the button.
Rear (vehicles with rear seat
heater)
Press in and release the button.
WARNING
■Caution while driving
Keep the glove box closed. In the
event of sudden braking or sud-
den swerving, an accident may
occur due to an occupant being
struck by the open glove box or
the items stored inside.
Cup holders
WARNING
■Items unsuitable for the cup
holder
Do not place anyth ing other than
cups or beverage cans in the cup
holders.
Inappropriate items must not be
stored in the cup holders even if
the lid is closed.
Other items may be thrown out of
the holders in the event of an
accident or sudden braking and
cause injury. If possible, cover hot
drinks to pre vent burns.
■When not in use
Keep the cup holders closed.
Injuries may resul t in the event of
an accident or sudden braking.
