TOYOTA RAV4 2006 Service Repair Manual

2AZ-FE COOLING – COOLING FAN SYSTEMCO–5
CO
(c) Check that the cooling fan rotates.
If it does not, check the engine coolant temperature
sensor, cooling fan, harness or connector.
A127843

CO–42GR-FE COOLING – COOLING FAN SYSTEM
CO
SYSTEM DIAGRAM
A132454E01

2GR-FE COOLING – COOLING FAN SYSTEMCO–5
CO
A132455E01

LU–122AZ-FE LUBRICATION – OIL PUMP
LU
REMOVAL
1. REMOVE CHAIN SUB-ASSEMBLY
(a) Remove the chain (see page EM-22).
2. REMOVE OIL PUMP ASSEMBLY
(a) Remove the 3 bolts, oil pump and gasket.
DISASSEMBLY
1. REMOVE OIL PUMP STRAINER
(a) Remove the 2 nuts, oil pump strainer and gasket.
2. REMOVE OIL PUMP RELIEF VALVE
(a) Using a 27 mm socket wrench, remove the plug.
(b) Remove the valve spring and relief valve.
3. REMOVE OIL PUMP COVER
(a) Remove the 5 bolts and oil pump cover.
B011673E01
B011430E01
A052074E02
B011431E01

2AZ-FE LUBRICATION – OIL PUMPLU–13
LU
INSPECTION
1. INSPECT OIL JET
(a) Check the oil jet for damage or clogging.
If necessary, repair the cylinder block.
2. INSPECT OIL PUMP RELIEF VALVE
(a) Check the relief valve.
(1) Coat the valve with engine oil, and then check
that the valve falls smoothly into the valve hole
by its own weight.
If it does not, replace the relief valve. If
necessary, replace the oil pump assembly.
3. INSPECT OIL PUMP ROTOR
(a) Check the side clearance.
(1) Using a feeler gauge and precision
straightedge, measure the clearance between
the rotors and precision straightedge.
Standard clearance:
0.030 to 0.085 mm (0.0012 to 0.0033 in.)
Maximum clearance:
0.16 mm (0.0063 in.)
If the side clearance is greater than the
maximum, replace the oil pump assembly.
(b) Check the tip clearance.
(1) Using a feeler gauge, measure the clearance
between the drive and driven rotor tips.
Standard clearance:
0.080 to 0.160 mm (0.0031 to 0.0063 in.)
Maximum clearance:
0.35 mm (0.0138 in.)
If the tip clearance is greater than the
maximum, replace the oil pump assembly.
(c) Check the body clearance.
(1) Using a feeler gauge, measure the clearance
between the driven rotor and pump body.
Standard clearance:
0.100 to 0.170 mm (0.0039 to 0.0067 in.)
Maximum clearance:
0.325 mm (0.01128 in.)
If the body clearance is greater than the
maximum, replace the oil pump assembly.
A126890
A114340
B011420E02
A114223E01
B011422E01

LU–142AZ-FE LUBRICATION – OIL PUMP
LU
4. INSPECT OIL PUMP DRIVE CHAIN AND 2 OIL PUMP
SPROCKETS
(a) Using vernier calipers, measure the length of the 8
links with the chain fully stretched.
Maximum chain elongation:
52.4 mm (2.063 in.)
If the elongation is greater than the maximum,
replace the chain.
HINT:
Make the measurements at 3 or more places
selected at random.
(b) Wrap the chain around the oil pump sprocket.
(c) Using vernier calipers, measure the sprocket
diameter with the chain.
NOTICE:
Vernier calipers must contact the chain rollers
when measuring.
Minimum sprocket diameter (with chain):
Crankshaft 48.2 mm (1.898 in.)
Oil pump drive shaft 48.2 mm (1.898 in.)
If the diameter is less than the minimum, replace the
chain and sprockets.
5. INSPECT CHAIN TENSIONER PLATE
(a) Measure the chain tensioner plate wear.
Maximum wear:
0.5 mm (0.020 in.)
If the wear is greater than the maximum, replace the
chain tensioner plate.
A126891E01
A126892
A126893E01

LU–122GR-FE LUBRICATION – OIL PUMP
LU
REMOVAL
1. DISCHARGE FUEL SYSTEM PRESSURE (See page
FU-9)
2. DISCONNECT CABLE FROM NEGATIVE BATTERY
TERMINAL
CAUTION:
Wait at least 90 seconds after disconnecting the
cable from the negative (-) battery terminal to
prevent airbag and seat belt pretensioner activation.
3. REMOVE ENGINE ASSEMBLY
(a) Remove the engine from the vehicle (see page EM-
21).
4. INSTALL ENGINE TO STAND
5. REMOVE NO. 2 OIL DIPSTICK GUIDE
(a) Remove the oil dipstick.
(b) Remove the bolt and dipstick guide.
6. REMOVE OIL DIPSTICK GUIDE
(a) Remove the bolt and dipstick guide.
7. REMOVE OIL FILTER CAP ASSEMBLY (See page LU-
4)
8. REMOVE OIL FILTER ELEMENT KIT (See page LU-5)
9. REMOVE NO. 2 OIL PAN SUB-ASSEMBLY
(a) Remove the 16 bolts and 2 nuts.
A132179
A132180
A132107

2GR-FE LUBRICATION – OIL PUMPLU–13
LU
(b) Insert the blade of SST between the oil pan, cut
through the applied sealer and remove the oil pan.
SST 09032-00100
NOTICE:
Be careful not to damage the contact surfaces of
the oil pan.
10. REMOVE OIL STRAINER SUB-ASSEMBLY
(a) Remove the bolt, 2 nuts, oil strainer and gasket.
11. REMOVE OIL PAN SUB-ASSEMBLY
(a) Remove the 16 bolts and 2 nuts.
HINT:
Be sure to clean the bolts and stud bolts and check
the threads for cracks or other damage.
(b) Remove the oil pan by prying between the oil pan
and cylinder block with a screwdriver.
NOTICE:
Be careful not to damage the contact surfaces of
the cylinder block and oil pan.
HINT:
Tape the screwdriver tip before use.
A132161E01
A132108
A132109
A132110

LU–142GR-FE LUBRICATION – OIL PUMP
LU
(c) Remove the 2 O-rings from the oil pump.
12. REMOVE WATER INLET HOUSING (See page CO-12)
13. REMOVE OIL PIPE (See page EM-52)
14. REMOVE CYLINDER HEAD COVER SUB-ASSEMBLY
(for Bank 1) (See page EM-52)
15. REMOVE NO. 1 OIL PIPE (See page EM-53)
16. REMOVE CYLINDER HEAD COVER SUB-ASSEMBLY
(for Bank 2) (See page EM-53)
17. REMOVE CRANKSHAFT PULLEY (See page EM-54)
18. REMOVE TIMING CHAIN COVER SUB-ASSEMBLY
(w/ Oil Pump)
(a) Remove the 23 bolts and 2 nuts as shown in the
illustration.
(b) Remove the timing chain cover by prying between
the timing chain cover and cylinder head or cylinder
block with a screwdriver.
HINT:
Tape the screwdriver tip before use.
NOTICE:
Do not damage the contact surfaces of the
cylinder head, cylinder block and timing chain
cover.
A132111
A132150
A132099

2GR-FE LUBRICATION – OIL PUMPLU–15
LU
(c) Remove the gasket.
DISASSEMBLY
1. REMOVE OIL PUMP RELIEF VALVE
(a) Using a 27 mm socket wrench, remove the plug.
(b) Remove the valve spring and oil pump relief valve.
2. REMOVE OIL PUMP COVER
(a) Remove the 8 bolts, oil pump cover, drive rotor and
driven rotor.
NOTICE:
Be careful not to damage the drive and driven
rotors.
A132100
A132097
A131927
