RS0B8±15
H23200
Spiral Cable
Steering Column Cover Lower
Steering Wheel Pad
N´m (kgf´cm, ft´lbf): Specified torque
Steering Wheel
Steering Wheel Cover Lower No. 2
Steering Wheel Cover Lower No. 3
8.8 (90, 78 in.´lbf)
8.8 (90, 78 in.´lbf)
Torx® Screw Torx® Screw RS±20
± SUPPLEMENTAL RESTRAINT SYSTEMSTEERING WHEEL PAD AND SPIRAL CABLE
3303 Author: Date:
2005 SEQUOIA (RM1146U)
STEERING WHEEL PAD AND SPIRAL CABLE
COMPONENTS

RS0B9±13
± SUPPLEMENTAL RESTRAINT SYSTEMSTEERING WHEEL PAD AND SPIRAL CABLE
RS±21
3304 Author: Date:
2005 SEQUOIA (RM1146U)
REMOVAL
NOTICE:

If the wiring connector of the SRS is disconnected and the ignition switch is in the ON or ACC
position, DTCs will be recorded.

Never use airbag parts from another vehicle. When replacing parts, replace them with new
ones.
1. PRECAUTION (SEE PAGE RS±1 and RS±3)
2. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL
Wait for 90 seconds after disconnecting the cable to prevent the airbag working.
3. REMOVE STEERING WHEEL PAD (SEE PAGE SR±14)
4. REMOVE STEERING WHEEL (SEE PAGE SR±14)
5. REMOVE STEERING COLUMN COVER LOWER (SEE PAGE SR±14)
6. REMOVE SPIRAL CABLE (SEE PAGE SR±14)

H24695
RS117±01
H20642
H23201
Horn Button Contact Plate
H24696
RS±22
± SUPPLEMENTAL RESTRAINT SYSTEMSTEERING WHEEL PAD AND SPIRAL CABLE
3305 Author: Date:
2005 SEQUOIA (RM1146U)
INSPECTION
1. VEHICLE NOT INVOLVED IN COLLISION
(a) Perform a diagnostic system check (see page DI±1147).
(b) With the steering wheel pad installed on the vehicle, per-
form a visual check. If there are any defects as mentioned
below, replace the steering wheel pad with a new one:
Cuts, minute cracks or marked discoloration on the steer-
ing wheel pad top surface or in the grooved portion.
2. VEHICLE INVOLVED IN A COLLISION AND AIRBAG IS
NOT DEPLOYED
(a) Perform a diagnostic system check (see page DI±1147).
(b) With the steering wheel pad removed from the vehicle,
perform a visual check. If there are any defects as men-
tioned below, replace the steering wheel pad or steering
wheel assembly with a new one:

Cuts, minute cracks or marked discoloration on the
steering wheel pad top surface or in the grooved
portion.

Cracks or other damage to the connectors.

Deformation of the steering wheel assembly.

Deformation of the horn button contact plate of the horn
button assembly.

There should be no interference between the steering
wheel pad and steering wheel assembly, and the clear-
ance should be uniform all the way around when a new
steering wheel pad is installed on the steering wheel as-
sembly.
CAUTION:
For removal and installation procedures of the steering
wheel pad, see page RS±21 and RS±31. Be sure to follow
the correct procedure.

RS118±01
AB0152
SST
AB0152
SST
± SUPPLEMENTAL RESTRAINT SYSTEMSTEERING WHEEL PAD AND SPIRAL CABLE
RS±23
3306 Author: Date:
2005 SEQUOIA (RM1146U)
DISPOSAL
HINT:
When scrapping a vehicle equipped with SRS or disposing of
the steering wheel pad, be sure to deploy the airbag first in ac-
cordance with the procedure described below. If any abnormal-
ity occurs with the airbag deployment, contact the SERVICE
DEPT. of TOYOTA MOTOR SALES, USA, INC.
CAUTION:

Never dispose of a steering wheel pad which has an
undeployed airbag.

The airbag produces an exploding sound when it is
deployed, so perform the operation outdoors and
where it will not create a nuisance to nearby resi-
dents.

When deploying the airbag, always use the specified
SST (SRS Airbag Deployment Tool). Perform the op-
eration in a place away from electrical noise.

When deploying an airbag, perform the operation at
least 10 m (33 ft) away from the steering wheel pad.

The steering wheel pad becomes extremely hot when
the airbag is deployed, so do not touch it for at least
30 minutes after deployment.

Use gloves and safety glasses when handling a steer-
ing wheel pad with the deployed airbag.

Do not apply water, etc. to a steering wheel pad with
a deployed airbag.

Always wash your hands with water after completing
the operation.
1. AIRBAG DEPLOYMENT WHEN SCRAPPING VE-
HICLE
HINT:
Prepare a battery as the power source to deploy the airbag.
(a) Check the function of the SST.
SST 09082±00700
CAUTION:
When deploying the airbag, always use the specified SST:
SRS Airbag Deployment Tool.

AB0158
SSTBattery
H01580
SST
H23202
H20645H23684SST
RS±24
± SUPPLEMENTAL RESTRAINT SYSTEMSTEERING WHEEL PAD AND SPIRAL CABLE
3307 Author: Date:
2005 SEQUOIA (RM1146U)
(1) Connect the SST to the battery.
Connect the red clip of the SST to the battery posi-
tive (+) terminal and the black clip to the battery neg-
ative (±) terminal.
(2) Check the function of the SST.
Press the SST activation switch, and check that the
LED of the SST activation switch comes on.
CAUTION:

Do not connect the SST connector (yellow colored
one) to the airbag.

If the LED comes on when the activation switch is not
being pressed, SST malfunction is possible, so re-
place the SST with a new one.
(3) Disconnect the SST from the battery.
(b) Precaution (see page RS±1 and RS±3).
(c) Disconnect the cable from the negative battery terminal.
Wait for 90 seconds after disconnecting the cable to prevent the
airbag working.
(d) Remove the steering column cover lower.
(1) While turning the steering wheel assembly to the
right and left, remove the 3 screws and steering col-
umn cover lower.
(e) Install the SST.
CAUTION:
Check that there is no looseness in the steering wheel as-
sembly and steering wheel pad.
(1) Disconnect the airbag connector (yellow colored
one) from the spiral cable.
NOTICE:
When handling the airbag connector, take care not to dam-
age the airbag wire harness.

R13455
10 m (33 ft) or more
SSTBattery
± SUPPLEMENTAL RESTRAINT SYSTEMSTEERING WHEEL PAD AND SPIRAL CABLE
RS±25
3308 Author: Date:
2005 SEQUOIA (RM1146U)
(2) Connect the SST connector to the airbag connector
of the spiral cable.
SST 09082±00700, 09082±00780
NOTICE:
To avoid damaging the SST connector and wire harness,
do not lock the secondary lock of the twin lock.
(3) Move the SST at least 10 m (33 ft) away from the ve-
hicle front side window.
(4) Maintaining enough clearance for the SST wire har-
ness in the front side window, close all doors and
windows of the vehicle.
NOTICE:
Take care not to damage the SST wire harness.
(5) Connect the red clip of the SST to the battery posi-
tive (+) terminal and the black clip of the SST to the
negative (±) terminal.
(f) Deploy the airbag.
(1) Check that no one is inside the vehicle or within a
10 m (33 ft) radius of the vehicle.
(2) Press the SST activation switch and deploy the air-
bag.
CAUTION:

When deploying the airbag, make sure that no one is
near the vehicle.

The steering wheel pad becomes extremely hot when
the airbag is deployed, so do not touch it for at least
30 minutes after deployment.

Use gloves and safety glasses when handling a steer-
ing wheel pad with a deployed airbag.

Do not apply water, etc. to a steering wheel pad with
a deployed airbag.

Always wash your hands with water after completing
the operation.
2. DEPLOYMENT WHEN DISPOSING OF STEERING
WHEEL PAD ONLY
NOTICE:

When disposing of the steering wheel pad, never use
the customer's vehicle to deploy the airbag.

Be sure to follow the procedure given below when de-
ploying the airbag.
HINT:
Prepare a battery as the power source to deploy the airbag.

AB0152
SST
AB0163
Wire Harness
Diameter
Stripped Wire Harness Section
H23203
L
M
H23207
SST
RS±26
± SUPPLEMENTAL RESTRAINT SYSTEMSTEERING WHEEL PAD AND SPIRAL CABLE
3309 Author: Date:
2005 SEQUOIA (RM1146U)
(a) Check the function of the SST (see step 1±(a)).
(b) Remove the steering wheel pad (see page SR±14).
CAUTION:

When removing the steering wheel pad, work must be
started 90 seconds after the ignition switch is turned
to the ºLOCKº position and the negative (±) terminal
cable is disconnected from the battery.

When storing the steering wheel pad, keep the airbag
deployment side facing upward.
(c) Using a service±purpose wire harness for the vehicle, tie
down the steering wheel pad to the disc wheel.
Wire harness: Stripped wire harness section
1.25 mm
2
or more (0.0019 in2. or more).
CAUTION:
If the wire harness is too thin or an alternative object is
used to tie down the steering wheel pad, it may be snapped
by the shock when the airbag is deployed. Always use a
wire harness for vehicle use with an area of at least 1.25
mm
2
(0.0019 in.2).
HINT:
To calculate the area of the stripped wire harness section:
Area = 3.14 x (Diameter)
2
divided by 4
(1) Install the 2 bolts with washers into the 2 bolt holes
on the steering wheel pad.
Bolt:
L: 35.0 mm (1.378 in.)
M: 6.0 mm (0.236 in.)
Pitch: 1.0 mm (0.039 in.)
NOTICE:

Tighten the bolts by hand until the bolts become diffi-
cult to turn.

Do not tighten the bolts excessively.
(2) After connecting the SST below to each other, con-
nect them to the steering wheel pad connectors.
SST 09082±00802 (09082±10801, 09082±30801)

H23204
2 Times or more
H23205
H23206
SST
± SUPPLEMENTAL RESTRAINT SYSTEMSTEERING WHEEL PAD AND SPIRAL CABLE
RS±27
3310 Author: Date:
2005 SEQUOIA (RM1146U)
(3) Using 3 wire harnesses, wind wire harness at least
2 times each around the bolts installed on the left
and right sides of the steering wheel pad.
CAUTION:

Tightly wind the wire harness around the bolts so that
there is no slack.

Make sure that the wire harness is tight. If there is
slack in wire harness, the steering wheel pad may be-
come loose due to the shock when the airbag is
deployed.
(4) Face the airbag deployment side of the steering
wheel pad upward. Separately tie the left and right
sides of the steering wheel pad to the disc wheel
through the hub nut holes. Position the SST con-
nector so that it hangs downward through the hub
hole in the disc wheel.
CAUTION:

Make sure that the wire harness is tight. If there is
slack in wire harness, the steering wheel pad may be-
come loose due to the shock when the airbag is
deployed.

Always tie down the steering wheel pad with the air-
bag deployment side facing upward.
NOTICE:
The disc wheel will be marked by the airbag deployment,
so use an extra disc wheel.
(d) Install the SST.
CAUTION:
Place the disc wheel on level ground.
(1) Connect the SST connector.
SST 09082±00700
CAUTION:
To avoid damaging the SST connector and wire harness,
do not lock the secondary lock of the twin lock. Also, se-
cure some slack for the SST wire harness inside the disc
wheel.

R13763
10 m (33 ft) or more SSTBattery
H00401Weight
X Y
Y
H23914
Inner Diam.
Tires
(3 or More)Width RS±28
± SUPPLEMENTAL RESTRAINT SYSTEMSTEERING WHEEL PAD AND SPIRAL CABLE
3311 Author: Date:
2005 SEQUOIA (RM1146U)
(2) Move the SST at least 10 m (33 ft) away from the
steering wheel pad tied down to the disc wheel.
(e) Cover the steering wheel pad with a cardboard box or
tires.
Covering method using cardboard box:
Cover the steering wheel pad with the cardboard box and
place the weights on the cardboard box in 4 places total-
ling at least 190 N (19 kg, 43 lb).
Cardboard box size:
Must exceed the following dimensions:
X = 460 mm (18.11 in.)
Y = 650 mm (25.59 in.)
NOTICE:

When dimension Y of the cardboard box exceeds the
diameter of the disc wheel with tire which the steering
wheel pad is tied to, X should be the following size.
X = 460 mm (18.11 in.) + width of tire

If a cardboard box smaller than the specified size is
used, the cardboard box will be broken by the shock
from the airbag deployment.

Covering method using tires:
Place at least 3 tires without disc wheels on the tire
with disc wheel which the steering wheel pad is tied
to. Place the tire with disc wheel on them.
Tire size: Must exceed the following dimensions:
Width: 185 mm (7.28 in.)
Inner diameter: 360 mm (14.17 in.)
CAUTION:
Do not use tires with disc wheels except on the top and bot-
tom.
NOTICE:

The tires may be marked by the airbag deployment,
so use the redundant tires.

Do not place the SST connector under the tire be-
cause it could be damaged.

H23917
H2391510 m (33 ft) or more SSTBattery
H23208
± SUPPLEMENTAL RESTRAINT SYSTEMSTEERING WHEEL PAD AND SPIRAL CABLE
RS±29
3312 Author: Date:
2005 SEQUOIA (RM1146U)
(1) Tie the tires together with 2 wire harnesses.
CAUTION:
Make sure that the wire harness is tight. Looseness in the
wire harness results in the tires coming free due to the
shock when the airbag is deployed.
(f) Deploy the airbag.
(1) Connect the red clip of the SST to the battery posi-
tive (+) terminal and the black clip of the SST to the
battery negative (±) terminal.
(2) Check that no one is within a 10 m (33 ft) radius of
the disc wheel which the steering wheel pad is tied
to.
(3) Press the SST activation switch and deploy the air-
bag.
CAUTION:
When deploying the airbag, make sure that no one is near
the tire.
HINT:
The airbag is deployed as the LED of the SST activation switch
comes on.
(g) Dispose of the steering wheel pad.
CAUTION:

The steering wheel pad becomes extremely hot when
the airbag is deployed, so do not touch it for at least
30 minutes after deployment.

Use gloves and safety glasses when handling a steer-
ing wheel pad with a deployed airbag.

Do not apply water, etc. to a steering wheel pad with
a deployed airbag.

Always wash your hands with water after completing
the operation.
(1) Remove the steering wheel pad from the disc
wheel.
(2) Place the steering wheel pad in a plastic bag, tie it
tightly and dispose of it as other general part dispos-
al.
