PP–44PREPARATION – DRIVE SHAFT
PP
LUBRICANT
Item Capacity
Front drive shaft
2WD Outboard joint
grease35 to 55 g (1.2 to 1.9 oz.)
Inboard joint
grease95 to 115 g (3.4 to 4.1 oz.)
4WD Outboard joint
grease40 to 60 g (1.4 to 2.1 oz.)
Inboard joint
grease100 to 130 g (3.9 to 4.6 oz.)
Rear drive shaft
Outboard joint
grease90 to 110 g (3.2 to 3.9 oz.)
Inboard joint
grease130 to 150 g (4.6 to 5.3 oz.)

PREPARATION – DIFFERENTIALPP–47
PP
RECOMMENDED TOOLS
09011-12301 Socket Wrench 30 mm
09025-00010 Torque Wrench (30 kgf-cm)
09040-00011 Hexagon Wrench Set
09044-00020 "TORX" Socket E10

PP–48PREPARATION – DIFFERENTIAL
PP
EQUIPMENT
To r q u e w r e n c h
Dial gauge
Micrometer
Vernier caliper

PREPARATION – DIFFERENTIALPP–49
PP
LUBRICANT
Item Capacity Classification
Differential oil 0.90 +- 0.05 liters (0.95 +- 0.05 US qts, 0.75
+- 0.04 lmp.qts)Hypoid gear oil API GL-5 Above -18
C (0F)
SAE 90 Below -18
C (0F) SAE 80W or 80W-
90

PP–50PREPARATION – DIFFERENTIAL
PP
SSM
Toyota Genuine Seal Packing 1281,
Three Bond 1281 or equivalent

PREPARATION – AXLEPP–49
PP
RECOMMENDED TOOLS
HINT:
Trox is a registered trademark of Trxtron Inc.
09011-12301 Socket Wrench 30 mm
09042-00010 Torx Socket T30
09905-00013 Snap Ring Pliers

PP–50PREPARATION – AXLE
PP
EQUIPMENT
To r q u e w r e n c h
Dial Indicator with magnetic base

PREPARATION – SUSPENSIONPP–51
PP
RECOMMENDED TOOLS
09011-12301 Socket Wrench 30 mm
09040-00011 Hexagon Wrench Set
(09043-20060) Socket Hexagon Wrench 6

PP–52PREPARATION – SUSPENSION
PP
EQUIPMENT
To r q u e w r e n c h
Dial indicator with magnetic base
Wheel balancer
Tire pressure gauge
Alignment tester
Camber-caster-kingpin gauge
Toe-in gauge
Angle gauge
Drill
Plastic hammer
Engine Sling Device
Universal Engine Lifter
Chain Block
Slide calipers
Wooden block

DF–10DIFFERENTIAL – REAR DIFFERENTIAL CARRIER ASSEMBLY
DF
REMOVAL
1. REMOVE REAR WHEEL
2. REMOVE EXHAUST PIPE ASSEMBLY
HINT:
(See page EX-8)
3. REMOVE PROPELLER WITH CENTER BEARING
SHAFT ASSEMBLY
HINT:
(See page PR-3)
4. REMOVE REAR DIFFERENTIAL FILLER PLUG
(a) Using a hexagon wrench (10 mm), remove the filler
plug and gasket.
5. REMOVE REAR DIFFERENTIAL DRAIN PLUG
(a) Using a hexagon wrench (10 mm), remove the drain
plug and gasket, and drain the oil.
6. REMOVE REAR SPEED SENSOR LH
HINT:
Removal procedure or RH side is the same as that or LH
side. (See page DS-21)
7. REMOVE REAR AXLE SHAFT NUT LH
HINT:
Removal procedure or RH side is the same as that or LH
side. (See page DS-21)
8. REMOVE REAR DRIVE SHAFT ASSEMBLY LH
HINT:
Removal procedure or RH side is the same as that or LH
side. (See page DS-21)
9. REMOVE REAR DIFFERENTIAL CARRIER
ASSEMBLY
(a) Support the rear differential carrier assembly with a
jack.
(b) Remove the bolt and nut, separate the No. 1 rear
differential support.
D030574
