Page 481 of 3000

TOYOTA SIENNA 2007  Service Repair Manual 2GR-FE ENGINE CONTROL SYSTEM  –  SFI SYSTEMES–175
ES
WIRING DIAGRAM
A136092E05

Page 482 of 3000

TOYOTA SIENNA 2007  Service Repair Manual ES–1762GR-FE ENGINE CONTROL SYSTEM  –  SFI SYSTEM
ES
CONFIRMATION DRIVING PATTERN
HINT:
• This confirmation driving pattern is used in steps 5, 8 and 11 of the following diagnostic troubleshooti

Page 483 of 3000

TOYOTA SIENNA 2007  Service Repair Manual 2GR-FE ENGINE CONTROL SYSTEM  –  SFI SYSTEMES–177
ES
INSPECTION PROCEDURE
HINT:
For use of the intelligent tester only:
Malfunctioning areas can be identified by performing the A/F CONTROL functio

Page 484 of 3000

TOYOTA SIENNA 2007  Service Repair Manual ES–1782GR-FE ENGINE CONTROL SYSTEM  –  SFI SYSTEM
ES
– Following the A/F CONTROL procedure enables technicians to check the graph of the voltage
outputs of both the A/F and HO2 sensors.
– To

Page 485 of 3000

TOYOTA SIENNA 2007  Service Repair Manual 2GR-FE ENGINE CONTROL SYSTEM  –  SFI SYSTEMES–179
ES
(b) Turn the ignition switch to the ON position and turn the
tester on.
(c) Select the following menu items: DIAGNOSIS /
ENHANCED OBD II / DT

Page 486 of 3000

TOYOTA SIENNA 2007  Service Repair Manual ES–1802GR-FE ENGINE CONTROL SYSTEM  –  SFI SYSTEM
ES
OK
(a) Disconnect the H14 heated oxygen sensor connector
(Bank 1 Sensor 2) or H9 heated oxygen sensor
connector (Bank 2 Sensor 2).
(b) Measur

Page 487 of 3000

TOYOTA SIENNA 2007  Service Repair Manual 2GR-FE ENGINE CONTROL SYSTEM  –  SFI SYSTEMES–181
ES
(2) Drive the vehicle at 60 km/h (40 mph) or more for 10
minutes or more.
(3) Stop the vehicle.
(4) Accelerator the vehicle until 60 km/h (40

Page 488 of 3000

TOYOTA SIENNA 2007  Service Repair Manual ES–1822GR-FE ENGINE CONTROL SYSTEM  –  SFI SYSTEM
ES
(d) Select the following menu items: DIAGNOSIS /
ENHANCED OBD ll / DATA LIST / PRIMARY / O2S B1
S2 or O2S B2 S2.
(e) After warming up the eng

Page 489 of 3000

TOYOTA SIENNA 2007  Service Repair Manual 2GR-FE ENGINE CONTROL SYSTEM  –  SFI SYSTEMES–183
ES
(b) Read DTCs.
Result
B
A
(a) Connect the intelligent tester to the DLC3.
(b) Start the engine and turn the tester on.
(c) Warm up the engine.

Page 490 of 3000

TOYOTA SIENNA 2007  Service Repair Manual ES–1842GR-FE ENGINE CONTROL SYSTEM  –  SFI SYSTEM
ES
Result
B
C
A
OK:
No gas leakage.
NG
OK
A087979E15
Result Proceed to
OK A
NG (for 2WD model) B
NG (for 4WD model) C
REPLACE AIR FUEL RATIO SENSO
