TOYOTA SOLARA 2004 Accessories, Audio & Navigation (in English)

AUDIO SYSTEM
121
Turn this knob to select the next or pre-
vious channel.
If you turn continuously, you can rapidly scroll
forward or down through the channels.
(d) Channel category
When the channel category appears, touch
either TYPE º or TYPE
º switch to switch
to the next or previous category.(e) Presetting a channel
1. Tune in the desired channel.
2. Touch one of the channel selector
switches (1 Ð 6) and hold it until a beep is
heard. This sets the channel to the switch
and the name and number of the channel
appears on the switch.
Each switch can store three SAT channels.
To change the preset channel to a different
one, follow the same procedure.
The preset channel memory is cancelled
when the power source is interrupted by bat-
tery disconnection or a blown fuse.
V

AUDIO SYSTEM
122
(f) Selecting a channel
Tune in the desired channel using one of the
following methods.
Preset tuning: Touch the switch (1 Ð 6) for
the channel you want. The switch (1 Ð 6) is
highlighted in green and channel number ap-
pears on the display.
To select channel within the current cate-
gory: Push the
º or º button of the
SEEK/TRACKº button.
To scan the currently selected channel
category: Touch the TYPE SCANº switch or
push the SCANº button briefly. SCANº ap-
pears on the display. The radio will find the
next channel in the same channel category,
stay there for a few seconds, and then scan
again. To select a channel, touch the TYPE
SCANº switch or push the SCANº button a
second time.
To scan the preset channels: Push the
SCANº button and hold it until you hear a
beep. P.SCANº appears on the display. The
radio will find the next preset channel, stay
there for a few seconds, and then move to the
next preset channel. To select a channel,
push the SCANº button a second time.(g) Displaying the title and name
When you touch the TEXTº switch, the song/
program title and the artist name/future are
displayed.
Up to 10 alphanumeric characters can be dis-
played. (Some information will not be fully
displayed.)
When you touch the TEXTº switch again, the
display returns.

AUDIO SYSTEM
123
(h) If the satellite radio tuner malfunctions
When problems occur with the XM tuner, a message will appear on the display. Referring to the table below to identify the problem, take the
suggested corrective action.
ANTENNAThe XM antenna is not connected. Check whether the XM antenna cable is \
attached securely.ANTENNAA short-circuit occurs in the antenna or the surrounding antenna cable. \
See a Toyota certified dealer.
UPDATING
You have not subscribed to the XM satellite radio. The radio is being up\
dated with the latest encryption code.
Contact the XM satellite radio for subscription information. When a con\
tact is canceled, you can choose the
CH000º and all free-to-air channels.
UPDATINGThe premium channel you selected is not authorized. Wait for about 2 seconds until the radio returns to the pre-
vious channel or CH001º. If it does not change automatically, select another channel. If you want to listen to the
premium channel, contact the XM satellite radio.
NO SIGNALThe XM signal is too weak at the current location. Wait until your vehicle reaches a location with a stronger signal.
LOADINGThe unit is acquiring audio or program information. Wait until the unit has received the information.
OFF AIRThe channel you selected is not broadcasting any programming. Select an\
other channel.
-----There is no song/program title or artist name/feature associated with th\
e channel at that time. No action needed.
---The channel you selected is no longer available. Wait for about 2 seconds until the radio returns to the previous
channel or CH001º. If it does not change automatically, select another channel.
The XM Listener Care Center is also available on the phone, please call \
(800) 852-9696 during the following hours:
Monday Ð Saturday: 7 a.m. Ð 1 a.m. Sunday: 12 p.m. Ð 12 a.m.
V

AUDIO SYSTEM
124
NOTICE
This equipment has been tested andfound to comply with the limits for aclass B digital device, pursuant to Part15 of the FCC Rules. These limits are de-signed to provide reasonable protection
against harmful interference in a resi-dential installation. This equipmentgenerates, uses and can radiate radiofrequency energy and, if not installedand used in accordance with the in-
structions, may cause harmful interfer-ence to radio communications. Howev-er, there is no guarantee that interfer-ence will not occur in a particular instal-
lation.
If this equipment does cause harmful in- terference to radio or television recep-tion, which can be determined by turn-ing the equipment off and on, the user isencouraged to try to correct the interfer-
ence by one or more of the followingmeasures:
Ð Reorient or relocate the receiving an-tenna.
Ð Increase the separation between theequipment and receiver.
Ð Connect the equipment into an outleton a circuit different from that to whichthe receiver is connected.
Ð Consult the dealer or an experiencedradio/TV technician for help.
Information to userAlternation or modifications carried outwithout appropriate authorization mayinvalidate the user's right to operate the
equipment.NOTICE
This XM tuner supports Audio Ser- vicesº (M usic and Talk) of only XM satel-
lite radio and Text Informationº* linked
to the respective Audio Servicesº.
*Text Information includes, StationName, (Artist) Name, (Song) Title andCategory Name.

AUDIO SYSTEM
125
Ð Compact disc player
operation(a) Playing a compact disc
The slot for the compact disc player is be-
hind the display.
To insert a compact disc, push the
OPENº button to lower the display. Put
the compact disc in the slot with the label
side up.
The player will automatically start when you
insert the compact disc. At this time, CDº ap-
pears on the screen.
If the label faces down, the disc cannot be
played. In this case, CD CHECKº appears
on the screen.
CAUTION
Do not place anything on the opened
display, as such items may be thrown
about in the compartment and possi-
bly injure people in the vehicle during
sudden braking or in an accident.
To reduce the chance of injury in case
of an accident or sudden stop while
driving, keep the display closed.
Take care not to jam your hand while
the display is moving. Otherwise, you
could be injured.
NOTICE
Do not obstruct the display while it ismoving. It could damage your audiosystem.
INFORMATION
Under extremely cold conditions, thedisplay may react slowly or operationsound may become louder.
V

AUDIO SYSTEM
126
To stop and eject the compact disc, push the
OPENº button to lower the display. Push the
DISC
º button.
Push the DISCº button if a compact disc
is already loaded in the slot.
CDº appears on the screen.

AUDIO SYSTEM
127
(b) Selecting a desired track
SEEK/TRACKº button: Use for a direct ac-
cess to a desired track.
Push either side of the SEEK/TRACKº but-
ton and hold it until the desired track number
appears on the screen. As you release the
button, the player will start playing the se-
lected track from the beginning.
Fast forward: Touch the
switch and
hold it to fast forward the disc. When you re-
lease the switch, the compact disc player will
resume playing from that position.
Reverse: Touch the
switch and hold
it to reverse the disc. When you release the
switch, the compact disc player will resume
playing.
(c) Searching for a desired track
Touch the SCANº switch on the screen or
push the SCANº button.
The compact disc player will play the next
track for 10 seconds, then scan again. To se-
lect a track, touch the SCANº switch on the
screen or push the SCANº button a second
time. If the player reaches the end of the disc,
it will continue scanning at track 1.
After all the tracks are scanned in one pass,
normal play resumes.
(d) Other compact disc player functions
RPTº switch: Use it for automatic repeat of
the track you are currently listening to.
Touch the switch while the track is playing.
When the track is finished, the player will au-
tomatically go back to the beginning of the
track and play the track again. To cancel it,
touch the switch once again.
RANDº switch: Use it for automatic and
random selection.
When the switch is touched, the system se-
lects a track in the disc. To cancel it, touch the
switch once again.
If a CD-TEXT disc is inserted, the title of the
disc and track will be displayed. Up to 29 let-
ters can be displayed.
V

AUDIO SYSTEM
128
(e) If the player malfunctions
If CD ERRORº appears on the screen, audio
signals of the disc cannot be read or the sys-
tem has trouble. Push the DISCº button once
again.
If the player does not operate, check that the
disc surface is not soiled or damaged. If the
disc is O.K., the temperature of the player's
internal mechanism may be raised because
of high external temperature. Remove the
disc from the player to cool it.
If the player still does not operate, have it
checked by your dealer.Car audio system operating
hints
NOTICE
To ensure correct audio system opera-tions:

Be careful not to spill beverages overthe audio system.

Do not put anything other than a Com-pact Disc into the slot.

The use of a cellular phone inside ornear the vehicle may cause a noisefrom the speakers of the audio sys-tem which you are listening to. How-ever, this does not indicate a malfunc-
tion.
RADIO RECEPTION
Usually, a problem with radio reception does
not mean there is a problem with your radio Ð
it is just the normal result of conditions outside
the vehicle. For example, nearby buildings and terrain
can interfere with FM reception. Power lines
or telephone wires can interfere with AM sig-
nals. And of course, radio signals have a lim-
ited
range. The farther you are from a station,
the weaker its signal will be. In addition, re-
ception conditions change constantly as your
vehicle moves.
Here are some common reception problems
that probably do not indicate a problem with
your radio:
FM
Fading and drifting stations Ð Generally, the
effective range of FM is about 40 km (25
miles). Once outside this range, you may no-
tice fading and drifting, which increase with
the distance from the radio transmitter. They
are often accompanied by distortion.
Multi-path Ð FM signals are reflective, mak-
ing it possible for two signals to reach your an-
tenna at the same time. If this happens, the
signals will cancel each other out, causing a
momentary flutter or loss of reception.
Static and fluttering Ð These occur when sig-
nals are blocked by buildings, trees, or other
large objects. Increasing the bass level may
reduce static and fluttering.

AUDIO SYSTEM
129
Station swapping Ð If the FM signal you are
listening to is interrupted or weakened, and
there is another strong station nearby on the
FM band, your radio may tune in the second
station until the original signal can be picked
up again.
AM
Fading Ð AM broadcasts are reflected by the
upper atmosphere Ð especially at night.
These reflected signals can interfere with
those received directly from the radio station,
causing the radio station to sound alternately
strong and weak.
Station interference Ð When a reflected sig-
nal and a signal received directly from a radio
station are very nearly the same frequency,
they can interfere with each other, making it
difficult to hear the broadcast.
Static Ð AM is easily affected by external
sources of electrical noise, such as high ten-
sion power lines, lightening, or electrical mo-
tors. This results in static. CARING FOR YOUR COMPACT DISC
PLAYER AND DISCS
Your compact disc player is intended for
use with 12 cm (4.7 in.) discs only.
Extremely high temperatures can keep
your compact disc player from working.
On hot days, use the air conditioning to
cool the vehicle interior before you listen
to a disc.
Bumpy roads or other vibrations may
make your compact disc player skip.
If moisture gets into your compact disc
player, you may not hear any sound even
though your compact disc player appears
to be working. Remove the disc from the
player and wait until it dries.
CAUTION
Compact disc players use an invisible
laser beam which could cause hazard-
ous radiation exposure if directed out-
side the unit. Be sure to operate the
player correctly.
Use only compact discs marked as shown
above. The following products
may not be
playable on your compact disc player.
Copy-protected CD
CD-R (CD-Recordable)
CD-R W (CD-Re-writable)
CD-ROM
V

AUDIO SYSTEM
130
Special shaped discs
Low quality discs
Labeled discs
NOTICE
To prevent damage to the player orchanger, do not use special shaped, lowquality or labeled discs such as thoseshown in the illustrations.

Correct
Wrong
Handle compact discs carefully, especial-
ly when you are inserting them. Hold them
on the edge and do not bend them. A void
getting fingerprints on them, particularly
on the shiny side.
Dirt, scrapes, warping, pin holes, or other
disc damage could cause the player to
skip or to repeat a section of a track. (To
see a pin hole, hold the disc up to the
light.)
Remove discs from the compact disc
player when you are not listening to them.
Store them in their plastic cases away
from moisture, heat, and direct sunlight.
