DESTINATION INPUT AND ROUTE GUIDANCE
51
Route overview
1. Touch the Map Viewº switch.
2. Touch the Route Overviewºswitch.
The entire route from the current position to
the destination is displayed.
Guideº: To start guidance.
Routeº: To change the route. (For details,
see pages 42 and 44.)
Turn Listº: The following screen displays
the list of the roads up to your destination.You can scroll through the list of roads by
touching
or . However, not all road
names in the route may appear on the list. If
a road changes its name without requiring a
turn (such as on a street that runs through two
or more cities), the name change will not ap-
pear on the list. The street name closest to
the starting point will be displayed with a mile-
age to the next turn.
These marks indicate the
direction in which you should turn
at an intersection.

DESTINATION INPUT AND ROUTE GUIDANCE
53
Screen configuration
You can choose any one of the screen
configurations.
1. Touch this switch to display the follow-
ing screen.
2. To select the desired screen configura-
tion, touch one of the following switches. Depending on the conditions, it may not be
possible to select certain screen configura-
tion switches.
:
To display single map screen. (See
page 53.)
: To display dual map screen. (See
page 54.)
: To display compass mode screen.
(See page 54.)
: To display turn list screen. (See page
55.)
: To display arrow screen. (See page
55.)
: To display freeway information
screen. (See page 55.)
: To display intersection guidance
screen or guidance screen on free-
way. (See page 56.)
(a) Single map
The screen shows the single map.

DESTINATION INPUT AND ROUTE GUIDANCE
54
(b) Dual map
The screen shows the dual map. The map on
the left is the main map.
You can edit the right side map by touching
any specific point on the right side map.
This screen can perform the following
procedures.
Changing the map scale
Displaying the POI icon
Changing the orientation of the map
Touch the
OKº switch when you complete
editing. The screen returns to the dual map
screen.
(c) Compass mode
Information about the destination and current
position, as well as a compass, is displayed
on the screen.
The destination mark is displayed in the direc-
tion of the destination. When driving, refer to
the longitude and latitude coordinates and the
compass, to make sure that your vehicle is
headed in the direction of the destination.
INFORMATION
When the vehicle goes out of the disc area, the guidance screen changes intocompass mode.

DESTINATION INPUT AND ROUTE GUIDANCE
55
(d) Turn list screen
The screen shows the turn list. You cannot
scroll through the list of roads.
(e) Arrow screen
The screen shows the current road name and
the distance to the next corner.
(f) Freeway information screen
This screen displays the distance to the next
junction and exit, or POIs in the vicinity of the
freeway exit.
Mapº: To display the selected map of the
exit vicinity.
On the left side of the
Mapº switch, up to
five POIs around the selected exit are dis-
played.
: To scroll for farther junctions or exits.
:To scroll for closer junctions or exits.
:To scroll for the closest three junctions
or exits.

DESTINATION INPUT AND ROUTE GUIDANCE
57
Distance and time to
destination
When the vehicle is on the guidance route,
the distance and the estimated travel time
to the destination are displayed. When the
vehicle is not on the guidance route, the
distance to and the direction of the des-
tination are displayed.
When driving on the guidance route and more
than one destination is set, the distance and
the estimated travel time from current position
to each destination are displayed.
1. Touch this switch to display the follow-
ing screen.
2. Touch the number switch of the des-
tination you wish to display.
The distance and the estimated travel time
from the current position to the selected des-
tination are displayed.
Displayed while driving along the
guidance route.
Displayed while driving off the
guidance route. The destination
direction is indicated by an arrow.
INFORMATION
When the vehicle is on the guidance route, the distance measured along theroute is displayed. Travel time is calcu-lated based on the set vehicle speed in-formation. (For details, see page 79.)However, when the vehicle is not on theguidance route, the distance is the linear
distance between the current position and the destination.

DESTINATION INPUT AND ROUTE GUIDANCE
58
Foot print map
For the area which is covered by the foot print
map (Some areas in the following cities; De-
troit, Chicago, N.Y., L.A), you can switch to
the foot print map on a scale of 75 feet (25 m).
To switch to the foot print map
The
switch changes into the
switch when the map is scaled down to 150
feet (50 m).
To display the foot print map, touch the
switch.
To delete the foot print map display
Touch the
switch.
INFORMATION
If the map or the current position is moved to the area which is not cov-ered by the foot print map, the screenscale automatically changes to 150feet (50 m).
On the foot print map, a one waystreet is displayed by .
It is not possible to perform scrollingon the foot print map (one-touchscroll) while driving.
To display building information
Information is available only for buildings for
which information is recorded on the map
disc.
1. Touch the Info.º switch while the
foot print map is displayed.
If the map is displayed in sprit screen, it turned
into a single map display.

DESTINATION INPUT AND ROUTE GUIDANCE
59
2. Using an eight-direction arrow, move
the cursor to the position of the building
you wish to display information.
3. Touch the
Building Info.º switch.
4. Details of POIs in some buildings may
be displayed. If you wish to see detailed
POI information, touch the building name.
You can see the detail of the selected
POIs.

ADVANCED FUNCTIONS
61
ADVANCED FUNCTIONS
Descriptions of functions for more effective use
Suspending and resuming guidance62
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Volume 63
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . . . . . . . . . . . .
User selection 63
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . . . . . .
My places 66
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . . . . . . . . . .
Area to avoid 73
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . . . . . . .
Setup 76
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . . . . . . . . . . . . . .
Current position calibration 77
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . .
Distance unit 79
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . . . . . . .
Estimated travel time 79
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . .
Auto reroute 81
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . . . . . . . .
Adjusting time zone 81
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . .
Auto voice guidance 82
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . .
Voice guidance in all modes 83
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . .
Notifying traffic restriction 84
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . .
Intersection guidance 85
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . .
Guidance screen on freeway 86
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . .
Street name on scroll map 87
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . .
Display of building shape 88
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . .
Screen layout function (
Function) 89
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
POI category change (Show POI Icons) 90
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Delete previous point 91
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . .
Map color 92
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . . . . . . . . . .
Screen animation 93
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . . . .
SECTION III

ADVANCED FUNCTIONS
62
Suspending and resuming
guidance

To suspend guidance
You can suspend route guidance.
Push the MENUº button to display the
Menuº screen and touch the Suspend
Guidanceº
switch.
INFORMATION
When you do not have route guidance,
the
Suspend Guidanceº switch
cannot be used.
The screen will return to the current posi-
tion map without route guidance.

To resume guidance
You can resume the suspended route
guidance.
Push the MENUº button to display the
Menuº screen and touch the Resume
Guidanceº
switch.
The screen will change to the current posi-
tion map with route guidance.

ADVANCED FUNCTIONS
63
Volume
You can use voice guidance when ap-
proaching a destination.
You can adjust the volume of the voice or turn
off voice guidance.
Push the MENUº button to display the
Menuº screen, and touch the Volumeº
switch.
To adjust the volume, select the desired level
by touching the appropriate number.
If you do not need voice guidance, touch the
Offº switch.
The selected item is highlighted in green.
INFORMATION
During route guidance, the voice guid- ance continues even if the navigationscreen is changed to other screens.
Adaptive Volume Controlº: If you turn the
Adaptive Volume Controlº on, the volume is
turned up automatically when the vehicle
speed exceeds 50 mph (80 km/h).
To turn the Adaptive Volume Controlº system
on, touch the switch. The indicator will be
highlighted.
User selection
The system can memorize the following
settings for up to three users.

Map direction

Map scale

Guidance mode

Setup

Volume

Language
Push the MENUº button to display the
Menuº screen. Then touch the
Select
Userº
switch.
