display TOYOTA SOLARA 2004 Accessories, Audio & Navigation (in English)

ADVANCED FUNCTIONS
77
Voice Guidance in All Modesº: You can set
the voice guidance in all modes.
Notify Traffic Restrictionº: You can select
notification of seasonal restrictions.
Intersection Guidanceº: You can select
ON or OFF to display of intersection guid-
ance.
Guidance Screen on Freewayº: You can
select ON or OFF to display the guidance
screen on the freeway.
Street Name on Scroll Mapº: You can se-
lect ON or OFF to display the street name on
the scroll map.
Display Building Shapeº: You can select
ON or OFF to display the building shape on
the map screen.

Functionº: You can set to display or
not to display each switches and current
street name on the map screen.
Show POI Iconsº: You can choose 6 icons
displayed on Show POI Iconsº top screen.
Previous Pointº: You can delete the pre-
vious destination.
Map Color (Day)º: You can select the de-
sired map color.
Map Color (Night)º: You can select the de-
sired map color.
Screen Animationº: You can set some
screen displays to be animated.
Current position calibration
When driving, the current vehicle position
mark will be automatically corrected by
GPS signals. If GPS reception is poor due
to location, you can manually adjust the
current vehicle position mark.
1. Push the MENUº button to display
the Menuº screen, and then touch the
Setupº switch.
2. Touch the Adjustº switch of Cal-
ibrationº.
3. Touch the Position/Directionº
switch.
INFORMATION
For additional information on the accu- racy of a current vehicle position, seeLimitations of the navigation systemº
on page 10.

ADVANCED FUNCTIONS
78

Position/direction calibration
1. Touch the scroll arrows to move the
cursor to your desired location.
Touch the
Enterº switch.
2. Touch either the or switch to ad-
just the direction of the current vehicle
position mark.
Touch the
Enterº switch and the map
screen will be displayed.

Tire change calibration
The tire change calibration function will be
used when replacing the tires. This func-
tion will adjust the mis-calculation caused
by the circumference difference between
the old tires and new ones. If this proce-
dure is not performed when tires are re-
placed, the current vehicle position mark
may be incorrectly displayed.
To perform a distance calibration procedure,
touch the
Tire Changeº switch on the
Calibrationº screen.
The message appears and the quick distance
calibration is automatically started. A few
seconds later, a map screen will be displayed.

ADVANCED FUNCTIONS
80
2. Touch the Setupº switch.
3. Touch the Set Speedº switch of the
Estimated Travel Timeº.
4. Touch or to set the average ve-
hicle speeds for driving on a Freeway,
Main street, and Residential.
To set the default speeds, touch the
De-
faultº
switch.
5. When you finish setting the desired
speeds, touch the
OKº switch.
INFORMATION

The displayed time to the destination is the approximate driving time that is
calculated based on the speeds you
selected and your actual positionalong the guidance route.

The time shown on the screen may
vary greatly depending on your prog-
ress along the route, which may be af-
fected by road conditions such as traffic jams, construction work.

It is possible to display up to 99 hours59 minutes.

ADVANCED FUNCTIONS
82
3. Touch the Changeº switch. The
Adjust T ime Zoneº screen appears on the
display.4. Touch the desired time zone.
The selected switch is highlighted in green.
5. Touch the
OKº switch on the screen
and the Setupº screen will be displayed.
Auto voice guidance
When the Auto Voice Guidanceº feature
is turned on, the voice guidance can be
heard automatically.
When the Auto Voice Guidanceº feature
is turned off, the voice guidance can be
heard only if you push the
MAP/
VOICEº
button.
To turn the Auto Voice Guidanceº mode
on:
1. Push the
MENUº button.
2. Touch the Setupº switch. Then
touch
switch to display page 2 of the
Setupº screen.

ADVANCED FUNCTIONS
83
3. Touch the Onº switch of Auto V oice
Guidanceº.
The selected switch is highlighted in
green.
Voice guidance in all modes
When the Voice Guidance in All Modesº
feature is turned on, you can hear the
voice guidance in all modes.
When the Voice Guidance in All Modesº
feature is turned off, voice guidance can-
not be heard when you using the audio
system.
To turn the Voice Guidance in All Modesº
on:
1. Push the
MENUº button.2. Touch the Setupº switch. Then
touch
switch to display page 2 of the
Setupº screen.

ADVANCED FUNCTIONS
84
3. Touch the Onº switch of Voice Guid-
ance in All Modesº and touch the
OKºswitch.
Notifying traffic restriction
When the Notify Traffic Restrictionº fea-
ture is turned on, the system notifies you
of traffic or seasonal restriction.
To turn the Notify Traffic Restrictionº
mode on:
1. Push the
MENUº button.
2. Touch the Setupº switch. Then
touch
switch to display page 2 of the
Setupº screen.

ADVANCED FUNCTIONS
85
3. Touch the Onº switch of Notify Traf-
fic Restrictionº and touch the
OKº
switch.
Intersection guidance
When the Intersection Guidanceº feature
is turned on, the system will display the in-
tersection guidance screen if you drive
with route guidance.
To turn the Intersection Guidanceº mode
on:
1. Push the
MENUº button.
2. Touch the Setupº switch. Then
touch
switch to display page 2 of the
Setupº screen.

ADVANCED FUNCTIONS
86
3. Touch the Onº switch of Intersec-
tion Guidanceº and touch the
OKºswitch.
Guidance screen on freeway
When the Guidance Screen on Freewayº
feature is turned on, the system will dis-
play the lane guidance screen if you drive
on a freeway with route guidance.
To turn the Guidance Screen on Free-
wayº mode on:
1. Push the
MENUº button.
2. Touch the Setupº switch. Then
touch
switch to display page 2 of the
Setupº screen.

ADVANCED FUNCTIONS
87
3. Touch the Onº switch of Guidance
Screen on Freewayº and touch the
OKºswitch.
Street name on scroll map
When the Street Name on Scroll Mapº
feature is turned on, the system will dis-
play the name of a street where the cursor
is positioned on the scroll map.
To turn the Street Name on Scroll Mapº
mode on:
1. Push the
MENUº button.
2. Touch the Setupº switch. Then
touch
switch twice to display page 3 of
the Setupº screen.

ADVANCED FUNCTIONS
88
3. Touch the Onº switch of Street
Name on Scroll Mapº and touch the
OKºswitch.
Display of building shape
When the Display Building Shapeº fea-
ture is turned on, the system will display
the building shape on the map screen us-
ing a scale of 150 feet (50 m) to 300 feet
(100 m).
To turn the Display Building Shapeº
mode on:
1. Push the
MENUº button.
2. Touch the Setupº switch. Then
touch
switch twice to display page 3 of
the Setupº screen.
