TOYOTA SOLARA 2007 Accessories, Audio & Navigation (in English)

140
3. Touch “Yes”.
Displaying the information of the
Bluetooth phone you delete
You can display the information of the
Bluetooth phone before you delete it and
you can make sure whether the telephone
you delete is correct or not.
1. Select the telephone you want to dis-
play the information about.
2. When you complete confirming it,
touch
.

141
Speech command system
The speech command system enables
you to operate the navigation system and
audio system by giving a command.
1. Push the speech command switch.
A beep sounds and on screen message is
displayed with an indicator at the top left.
2. Give a command while an indicator is
shown in the display.
If you want to check the command list,
touch “Help” to display the help screen.
(See “Help screen” on page 143.) When
you touch “Cancel”, the previous screen
returns.
If the navigation system does not respond or
the confirmation screen does not disappear,
please push the speech command switch
and try again.
If no command is given, a beep sounds and
the indicator disappears 6 seconds later.
If the system does not recognize your
speech, the system will respond with this
message (“System does not recognize this
command, please rephrase your com-
mand.”). Start the operation from the begin-
ning.
Microphone
It is unnecessary to speak directly into the
microphone when giving a command.
Speech command example: Searching for
a route to your home.
1. Push the speech command switch.
2. Say “Home”.
You can also say the street name or address.
(ex. say “Woodridge Avenue”.)
If your home is not registered, you will hear
“Home is not registered”.

142
3. If the system recognized the command,
the recognition result “Home” is dis-
played on the top of the screen with the
screen message. (Displayed message
and the touchscreen buttons on the
screen depend on the situation.)
Touch or say “Cancel”, and the system will be
canceled. Touch or say “Help”, and displays
the help screen.4. Touch “Enter” or say “Enter destina-
tion”, and the system starts searching for
a route to your home. (If the destination is
already registered, “Add to
” or “Re-
place
” is displayed on the screen.)
Touch or say “Cancel”, and the search will be
canceled.
When you search the destination by “POI
Name”, this screen is displayed.
Touch “Enter” or say “Enter destination”.
When you touch “Show List”, you can
search another spot in its category.
INFORMATION
In the following conditions, the system
may not recognize the command proper-
ly.
The command is not correct or clear.
There are some noises such as wind
noise, etc.

143
Help screen
This system has a function which displays
the voice recognition help screen. You
can see the command list and operating
guide on it.
(a) Command list
1. If the “Operating Guide” screen is dis-
played, touch “Command List” on the up-
per side of the screen.
2. Select the desired category by touch-
ing the buttons on the right side of the
“Command List” screen.
3. You can scroll through the list of the
command list by touching
or .
Touch “OK” after you check it.(b) Operating guide
1. If the “Command List” screen is dis-
played, touch “Operating Guide” on the
upper side of the screen.
2. Select the desired category by touch-
ing the buttons on the right side of the
“Operating Guide” screen.
3. You can scroll through the list of the op-
erating guide by touching
or .
Touch “OK” after you check it.
Screen adjustment
The brightness or contrast of the screen can
be adjusted depending on the brightness of
your surroundings. You can also turn the dis-
play off.
To display the “Display” screen, push the
“DISPLAY” button.
1. Touch the desired button to adjust con-
trast and brightness.
“Contrast” “+”: Strengthens the contrast of
the screen.
“Contrast” “–”: Weakens the contrast of the
screen.
“Brightness” “+”: Brightens the screen.
“Brightness” “–”: Darkens the screen.
2. After adjusting the screen, touch “OK”.

144 The screen goes off when “Screen Off” is
touched. To turn the display screen back on,
push any button such as “INFO”, etc. The se-
lected screen appears.
INFORMATION
When you do not touch any button on
the “Display” screen for 20 seconds, the
previous screen will be displayed.
Depending on the position of the headlight
switch, the screen changes to the day mode
or night mode.
To display the screen in the day mode even
with the headlight switch on, touch “Day
Mode” on the adjustment screen for bright-
ness and contrast control.
If the screen is set in the day mode with the
headlight switch turned on, this condition is
memorized in the system even with the en-
gine turned off.
Screen setting
1. Push the “INFO” button to display the
“Information” screen.
2. Touch “Screen Setting”.

145 (a) Automatic transition
You can select a function that enables auto-
matic return to the navigation screen from the
audio screen.
Select “ON” or “OFF” and then touch
“OK”.
“ON”: The navigation screen automatically
returns from the audio screen 20 seconds af-
ter the end of audio screen operation.
“OFF”: The audio screen remains on.(b) Switch color
You can select the color of the touch−screen
buttons.Select “Green” or “Orange” and then
touch “OK”.(c) Delete personal data
The following personal data can be deleted or
returned to their default settings:
Maintenance conditions
Maintenance information “off” setting
Memory points
Areas to avoid
Previous points
Route trace
User selection settings
Phone book data
Dialed numbers and received calls
Speed dial
Bluetooth phone data
Security code
This function is available only when the ve-
hicle is not moving.

146
1. Touch “Delete personal data”.
The “Delete personal data” screen appears.
2. Touch “Delete”.
The “Confirmation to delete all personal data”
screen appears.
3. Touch “Yes”.
Beep setting
You can set a beep sound off.
1. Push the “INFO” button.
2. Touch “Beep Off”.
“Beep Off” is highlighted.
To switch the beep sound on, touch “Beep
Off” again.

147
Selecting a language
The language of the touch−screen buttons,
pop−up messages and the voice guidance
can be changed.
1. Push the “INFO” button.
2. Touch “Language”.
3. Touch “English”, “Français” or “Es-
pañol” to select a language.
If a screen other than for the navigation sys-
tem is displayed, the current screen would
change to the “CAUTION” screen by pushing
the “MAP/VOICE”, “DEST” or “MENU” but-
ton.
4. Touch “I Agree”.
The language is changed and the screen re-
turns to the map display.

148

149
AUDIO SYSTEM
Audio system
Quick reference150 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Using your audio system151 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Some basics151 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Radio operation155 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
CD changer operation162 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Audio remote controls173 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Audio system operating hints174 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SECTION VI
