- BODYINSTRUMENT PANEL
BO-55
2135 Author: Date:
1997 SUPRA (RM502U)
(l) Cluster finish center panel
(m) Cluster finish panel LH
(n) Cluster finish panel RH
(o) Combination meter
(p) Heater to register No.2 duct
(q) Combination switch
(r) Audio receiver assembly
(s) Computer cover
3. REMOVE INSTRUMENT PANEL BOX
(a) Remove the glove compartment door finish plate inside
the instrument panel box.
NOTICE:
When handling the airbag connector, take care not to dam-
age the airbag wire harness.
(b) Pull up and disconnect the airbag connector.
(c) Remove the instrument panel box.
4. REMOVE THESE PARTS:
(a) Finish panel mounting No.3 and No.4 brackets
(b) Heater to register No.4 duct
(c) Finish panel mounting No.5 bracket
Page 312 of 1807
H01987
N08465
N09351
N11635
BO-56
- BODYINSTRUMENT PANEL
2136 Author: Date:
1997 SUPRA (RM502U)
5. REMOVE FRONT PASSENGER AIRBAG ASSEMBLY
(a) Remove the 2 bolts from instrument panel.
Torque: 8.5 N´m (87 kgf´cm, 75 in.´lbf)
(b) Remove the 2 bolts from instrument panel reinforcement.
Torque: 20 N´m (204 kgf´cm, 15 ft´lbf)
(c) Remove the front passenger airbag assembly.
CAUTION:
Do not store the front passenger airbag assembly
with the airbag door facing down.
Never disassemble the front passenger airbag as-
sembly.
NOTICE:
At the time of installation, please refer to the following
items.
Make sure the front passenger airbag assembly is
installed to the specified torque.
Take care that the wirings do not interfere with other
parts and not pinched between other parts.
6. REMOVE THESE PARTS:
(a) Parking brake lever (2 bolts)
Torque: 59 N´m (600 kgf´cm, 43 ft´lbf)
(b) Side defroster No.2 nozzle
(c) Steering column (4 nuts)
Torque: 25 N´m (260 kgf´cm, 19 ft´lbf)
7. REMOVE INSTRUMENT PANEL
(a) Disconnect the connectors.
(b) Remove the nut, screw, 8 bolts and instrument panel.
Torque: 8.8 N´m (90 kgf´cm, 78 ft´lbf)
8. REMOVE INSTRUMENT PANEL REINFORCEMENT
(a) Remove the bolt, 2 nuts and instrument panel No.1 brace.
Torque: 21 N´m (210 kgf´cm, 15 ft´lbf)
(b) Remove the 6 bolts, 4 nuts and instrument panel rein-
forcement.
(c) Remove the bolt, 2 nuts and instrument panel side No.3
bracket.
Page 313 of 1807
BO0RC-02
- BODYINSTRUMENT PANEL
BO-57
2137 Author: Date:
1997 SUPRA (RM502U)
DISASSEMBLY
1. REMOVE THESE PARTS FROM INSTRUMENT PANEL
(a) Defroster nozzle No.1 garnish
(b) Defroster nozzle
(c) Defroster lower nozzle
(d) Heater to register No.3 duct
(e) Solar sensor
(f) Tweeter speakers
(g) Side defroster No.1 nozzle
(h) Heater to register No.5 duct
(i) No.4 register
(j) Heater to register No.1 duct
(k) No.3 register
(l) Room temperature sensor
(m) Theft deterrent and door lock ECU
(n) PPS ECU
(o) No.1 pins
2. REMOVE INSTRUMENT PANEL WIRE HARNESS
Page 314 of 1807
BO0RF-01
N19535
Sport Roof:
Roof Side Rail Weatherstrip RH
Removable Roof Moulding RH
Removable Roof Headlining
Front Pillar GarnishRear Roof Headlining
Front Roof
Headlining
Assist Grip Removable Roof
Moulding LH Roof Side Rail
Weatherstrip LH Roof Headlining
Visor Holder
Sun VisorInterior LightClip
Front Pillar GarnishRoof Side Inner GarnishCoat Hook
Deck Trim Side BoardTonneau Cover
Tonneau
Cover
Clamp
Deck Trim Rear Cover
Quarter Wheel House Cover
Rear Seat Outer Belt
Speaker Grille Assist GripFront Seat
Outer Belt
Deck Trim
Side Service
Hole Cover
Front Door Scuff Inside Plate
Rear Quarter Trim Board
Rear Seatback
5XLuggage Compartment Mat
Rear Seat Cushion
Spare Wheel Cover
Non-reusable partSport Roof:
Removable Roof StayLower Back Service
Hole Cover
Stay Support Cover
Holder Garnish
Removable Roof Holder
43 (440, 32)
43 (440, 32)
25 (260, 19)
N´m (kgf´cm, ft´lbf) : Specified torqueClip
BO-60
- BODYROOF HEADLINING
2140 Author: Date:
1997 SUPRA (RM502U)
ROOF HEADLINING
COMPONENTS
Page 315 of 1807
BO0RG-01
N08498
N08499
N08501
3 Clips
2 Clips
N08502
- BODYROOF HEADLINING
BO-61
2141 Author: Date:
1997 SUPRA (RM502U)
REMOVAL
1. REMOVE THESE PARTS:
(a) Tonneau cover
(b) Luggage compartment mat
(c) Spare wheel cover
(d) Rear seat cushion
(e) Rear seatback
Torque: 25 N´m (260 kgf´cm, 19 ft´lbf)
(f) Removable roof stay RH and LH (Sport roof)
(g) Deck trim rear cover
(h) Removable roof holder RH and LH (Sport roof)
(i) Quarter wheel house cover
(j) Deck trim side boards
(k) Front door scuff inside plates
(l) Speaker grilles
(m) Rear quarter trim boards
(n) Front seat outer belts
Torque: 43 N´m (440 kgf´cm, 32 ft´lbf)
(o) Rear seat outer belts
Torque: 43 N´m (440 kgf´cm, 32 ft´lbf)
(p) Deck trim side service hole covers
Page 316 of 1807
N08503
2 Clips
1 Clip
N08631
N08470
2 Clips
3 Clips Normal Roof:
N08664
Sport Roof:
2 Clips
1 Clips
N08510
BO-62
- BODYROOF HEADLINING
2142 Author: Date:
1997 SUPRA (RM502U)
(q) Roof side inner garnishes
(r) Removable roof (Sport roof)
(s) Assist grip
HINT:
Tape a screwdriver tip before use.
(t) Front pillar garnishes
(u) Interior light
(v) Sun visors and holders
2. REMOVE ROOF HEADLINING
(a) Using a clip remover, remove the 2 clips.
Page 317 of 1807
N08505
Normal Roof:
1 Clip 5 Fasteners
N08506
Sport Roof:
1 Clip
4 Fasteners
N08668
Sport Roof:
N08504
Sport Roof:
9 Clips
- BODYROOF HEADLINING
BO-63
2143 Author: Date:
1997 SUPRA (RM502U)
(b) Normal roof - Remove the roof headlining.
3. SPORT ROOF:
REMOVE ROOF HEADLINING
(a) Remove the rear roof headlining.
(b) Remove the front roof headlining.
(c) Remove the removable roof headlining.
(See page BO-47)
Page 318 of 1807
BO0RI-01
N19398
Manual Seat:Front Seat Cushion
Inside Inner Shield
Seat Track
Cover Front Seat
Cushion Inside
Shield
Connecting
Tube
Front Seat Inner
Adjuster
Front Seat
Equalizing
Wire
Seat Track Cover
Front Seat outer Adjuster
Front Seat Cushion Inside Outer ShieldReclining Release
HandleSeat Track Cover Front Seat Cushion
Inside Outer ShieldPower Seat:
Seatback CoverSeatback Frame
Seatback Pad
Hog Ring
Seat Cushion Cover
Seat Cushion
Heater Relay
Seat Cushion Frame
Seat Track Cover
Front Seat Cushion
Inside Inner Shield
Front Seat Cushion
Inside Outer Shield Front Seat Cushion
Inner Shield
Front Seat Inner Belt
Front Seat Adjuster
Seat Track CoverSeat Track Cover
Power Seat Switch
Front Seat Cushion Inside Outer Shield
Seat Track Cover
Snap RingReclining
Release Handle
Power Seat
Switch Knob
Vertical Adjuste Knob Seat Wire Harness Motor Support Bracket Cover
Non-reusable part
18 (185, 13)
18 (185, 13)
37 (375, 27)
N´m (kgf´cm, ft´lbf): Specified torque
- BODYFRONT SEAT
BO-65
2145 Author: Date:
1997 SUPRA (RM502U)
FRONT SEAT
COMPONENTS
Page 319 of 1807
BO0RO-01
N16673
Luggage Compartment Mat
Seatback Lock KnobSeatback Board
Lock Knob Cover
Reclining Control
Cable LH Seatback Frame Reclining Control Cable RH
Tension Spring
Reclining Adjuster
Cover RH
Reclining
Adjuster RH
Reclining Adjuster
Cover LH
Tension Spring
Reclining Adjuster LH
Seatback Pad
Hog Ring
Seatback Cover
Seat Cushion Pad
Seat Cushion Cover
Non-reusable part
25 (260, 19)
18 (185, 13)
N´m (kgf´cm, ft´lbf): Specified torque BO-66
- BODYREAR SEAT
2146 Author: Date:
1997 SUPRA (RM502U)
REAR SEAT
COMPONENTS
Page 320 of 1807
BO0RT-01
N19399
Rear Seatback
Rear Seat Cushion
Seat Hook
Roof Side Inner GarnishTonneau Cover
Luggage Compartment
Mat
Spare Wheel Cover
Sport Roof:
Holder Garnish
Removable Roof Holder
Tonneau Cover
ClampDeck Trim Side Board
Deck Trim Rear Cover
Rear Quarter
Trim Board Quarter Wheel
House Inner Cover
Quarter Wheel
House Inner
Front Cover
Speaker Grille
Front Door Scuff Inside Plate
Rear Seat Outer BeltSport Roof:
Lower Back
Service Hole Cover
Stay Support
Cover
Rear Seat Inner Belt
Seat Track Cover Front Seat
Outer BeltFront Seat
Front Seat Cushion
Inner Shield
Seat Track CoverFront Seat Inner Belt
43 (440, 32)
7.8 (80, 69 in.´lbf)
43 (440, 32)
43 (440, 32)
43 (440, 32)
43 (440, 32)
43 (440, 32)
43 (440, 32): Specified torqueN´m (kgf´cm, ft´lbf)
- BODYSEAT BELT
BO-67
2147 Author: Date:
1997 SUPRA (RM502U)
SEAT BELT
COMPONENTS
