sensor TOYOTA SUPRA 2021 Owners Manual (in English)

2
Supra Owner's Manual_U (from Nov. '20 Prod.)TABLE OF CONTENTS
1-1. NOTES
Information ..............................4
2-1. QUICK REFERENCE
Entering .................................16
Set-up and use ......................22
In transit ................................25
3-1. CONTROLS
Cockpit ..................................36
Sensors of the vehicle ...........40
Operating state of the vehicle
............................................43
Toyota Supra Command .......46
General settings ....................60
Personal settings ..................64
Connections ..........................69
Opening and closing .............77
Seats, mirrors, and steering
wheel...................................96
Transporting children safely
.........................................109
Driving ................................115
Displays .............................133
Lights .................................153
Safety .................................160
Driving stability control systems
.........................................194
Driver assistance systems .199
Driving comfort ...................225
Climate control ...................226
Interior equipment ..............235
Storage compartments .......244Cargo area .........................246
4-1. DRIVING TIPS
Things to remember when driv-
ing ....................................252
Saving fuel .........................257
5-1. MOBILITY
Refueling ............................262
Wheels and tires ................264
Engine compartment ..........290
Operating materials............293
Maintenance ......................301
Replacing components ......303
Breakdown assistance .......313
Care ...................................322
6-1. REFERENCE
Technical data ....................330
Certification ........................333
Alphabetical Index..............344
1NOTES
2QUICK REFERENCE
3CONTROLS
4DRIVING TIPS
5MOBILITY
6REFERENCE
Index

61-1. NOTES
Supra Owner's Manual_U (from Nov. '20 Prod.)
Advanced technology, e.g. the
use of modern materials and
high-performance electronics,
requires suitable maintenance
and repair work.
If work is performed improperly,
for instance maintenance and
repair, there is a risk of subse-
quent damage and related
safety risks.
Improperly performed work on
the vehicle paint can lead to a
failure or malfunction of compo-
nents, e.g., the radar sensors,
and thereby result in a safety
risk.
Toyota recommends the use of
parts and accessory products
approved by Toyota.
Approved parts and accesso-
ries, and advice on their use and
installation are available from
To y o t a .
Toyota parts and accessories
have been tested by Toyota for
their safety and suitability in Toy-
ota vehicles.
Toyota warrants genuine Toyota
parts and accessories.
Toyota does not evaluate
whether each Customize prod-
uct from another manufacturer
can be used with Toyota vehi-cles without presenting a safety
hazard, even if a country-spe-
cific official approval was issued.
Toyota does not evaluate
whether these products are suit-
able for Toyota vehicles under
all usage conditions.
California law requires vehicle
manufacturers provide the fol-
lowing warning: Maintenance and repairs
Parts and accessories
California Proposition 65
Warning
WA R N I N G
Engine exhaust and a wide vari-
ety of Automobile components
and parts, including components
found in the interior furnishings in
a vehicle, contain or emit chemi-
cals known to the State of Califor-
nia to cause cancer and birth
defects and reproductive harm. In
addition, certain fluids contained
in vehicles and certain products of
component wear contain or emit
chemicals known to the State of
California to cause cancer and
birth defects or other reproduc-
tive harm. Battery posts, terminals
and related accessories contain
lead and lead compounds. Batter-
ies also contain other chemicals
known to the State of California to
cause cancer. Wash your hands
after handling. Used engine oil
contains chemicals that have
caused cancer in laboratory ani-
mals. Always protect your skin by
washing thoroughly with soap and
water. For more information go to
www.P65Warnings.ca.gov/pas-
senger-vehicle.

81-1. NOTES
Supra Owner's Manual_U (from Nov. '20 Prod.)
assistance during driving, for
instance driver assistance sys-
tems. Furthermore, control units
facilitate comfort or infotainment
functions.
Information about stored or
exchanged data can be
requested from the manufac-
turer of the vehicle, in a sepa-
rate booklet, for example.
Each vehicle is marked with a
unique vehicle identification
number. Depending on the
country, the vehicle owner can
be identified with the vehicle
identification number, license
plate and corresponding authori-
ties. In addition, there are other
options to track data collected in
the vehicle to the driver or vehi-
cle owner, e.g. via the Toyota
Supra Connect account that is
used.
Control units process data to
operate the vehicle.
For example, this includes:
• Status messages for the vehi-
cle and its Customize compo-
nents, e.g., wheel rotational
speed, wheel speed, deceler-
ation, transverse acceleration,
engaged safety belt indicator.
• Ambient conditions, e.g., tem-perature, rain sensor signals.
The processed data is only pro-
cessed in the vehicle itself and
generally volatile. The data is
not stored beyond the operating
period.
Electronic components, e.g.
control units and ignition keys,
contain components for storing
technical information. Informa-
tion about the vehicle condition,
component usage, mainte-
nance requirements or faults
can be stored temporarily or
permanently.
This information generally
records the state of a compo-
nent, a module, a system, or the
environment, for instance:
• Operating states of system
components, e.g., fill levels,
tire inflation pressure, battery
status.
• Malfunctions and faults in
important system compo-
nents, for instance lights and
brakes.
• Responses by the vehicle to
special situations such as air-
bag deployment or engage-
ment of the driving stability
control systems.
• Information on vehicle-dam-
aging events.
The data is required to perform
the control unit functions. Fur-
thermore, it also serves to rec-
ognize and correct malfunctions,
and helps the vehicle manufac- Personal reference
Operating data in the vehi-
cle

192-1. QUICK REFERENCE
2
QUICK REFERENCE
Supra Owner's Manual_U (from Nov. '20 Prod.)
The fuel filler flap remains
unlocked.
You can trigger the alarm sys-
tem if you find yourself in a dan-
gerous situation.
• Press the button on the
remote control and hold for at
least 3 seconds.
• Briefly press the button on the
remote control three times in
succession.
To switch off the alarm: press
any button.
The vehicle can be accessed
without operating the vehicle
key.
Carrying the vehicle key with
you, e.g., in your pants pocket,
is sufficient.The vehicle automatically
detects the remote control when
it is in close proximity or in the
car's interior.
Grasp the handle of a vehicle
door completely.
With the doors closed, touch the
indentation (lock sensor) on the
door handle with a finger for
approximately 1 second. Locking
Pressing the button
locks the vehicle if the
front doors are closed.
Unlocking
Pressing the button
unlocks the vehicle.
Panic mode
Smart Key System
Concept
Unlocking the vehicle
Locking the vehicle

282-1. QUICK REFERENCE
Supra Owner's Manual_U (from Nov. '20 Prod.)
3Lane change to the left
(movethe lever partway and
release it)
The left hand signals will flash 3
times.
4Left turn
The wipers can be operated in
the standby state.
■Switching on
Press the lever up until the
desired position is reached.
• Resting position of the wipers:
position 0.
• Rain sensor: position 1.
• Normal wiper speed: position
2.
• Fast wiper speed: position 3.
■Brief wipe and switching off
Press the lever down.
• Switching off: press the lever
down until it reaches its stan-
dard position (position 0).
• Brief wipe: press the lever
down from the standard posi-
tion (position 0). Lights and lighting
Light functions
SymbolFunction
Lights off.
Daytime running lights.
Parking lights.
Automatic headlight
control.
Low beams.
Instrument lighting.
Right roadside parking
light.
Left roadside parking
light.
Washer/wiper system
Switching the wipers on/off
and brief wipe

292-1. QUICK REFERENCE
2
QUICK REFERENCE
Supra Owner's Manual_U (from Nov. '20 Prod.)
■Activating/deactivating
To activate: press the lever up
once from its standard position,
arrow 1.
To deactivate: press the lever
back into the standard position.
■Adjusting the sensitivity
Turn the thumbwheel on the
wiper lever.Pull the wiper lever towards you.
Rain sensor
Cleaning the windshield
Climate control
ButtonFunction
Temperature.
Recirculated-air mode.
Maximum cooling.
AUTO program.
Air distribution, manual.
Switching off.
Defrost and defog the
windshield.
Rear window defroster.

35
3
3
CONTROLS
Supra Owner's Manual_U (from Nov. '20 Prod.)
CONTROLS
.3-1. CONTROLS
Cockpit ...........................36
Sensors of the vehicle....40
Operating state of the vehi-
cle.................................43
Toyota Supra Command
.....................................46
General settings .............60
Personal settings ...........64
Connections ...................69
Opening and closing ......77
Seats, mirrors, and steering
wheel ............................96
Transporting children safely
..................................109
Driving .........................115
Displays ......................133
Lights ..........................153
Safety ..........................160
Driving stability control sys-
tems ..........................194
Driver assistance systems
..................................199
Driving comfort ............225
Climate control ............226
Interior equipment .......235
Storage compartments
..................................244
Cargo area ..................246

373-1. CONTROLS
3
CONTROLS
Supra Owner's Manual_U (from Nov. '20 Prod.)
Automatic high-beam P.157
Low beams P.155
Instrument lighting
P.159
Right roadside parking
light P.155
Left roadside parking
light P.155
5Steering column stalk, left
Turn signal P.121
High beams, headlight
flasher P.122
Automatic high-beam
P.157
Onboard Computer
P.133
6Shift paddle P.129
7Steering wheel buttons, left
Cruise control on/off
P.199
Dynamic radar cruise
control on/off P.203
Cruise control: store
speed
Speed Limit Assist: take over
suggested speed P.211
Continuing cruise con-
trol/Pausing cruise control P. 1 9 9
Dynamic radar cruise
control: increase distance
P. 1 9 9
Dynamic radar cruise
control: reduce distance
P. 1 9 9
Cruise control rocker switch
P. 1 9 9
8Instrument cluster P.133
9Steering wheel buttons, right
Selection lists P.145
Volume, see Owner's
Manual for Navigation, Enter-
tainment and Communication
Voice activation system
P. 5 7
Telephone, see
Owner's Manual for Naviga-
tion, Entertainment and Com-
munication
Thumbwheel for selection
lists P.145
10Shift paddle P.129
11Steering column stalk, right
Wiper P.122
Rain sensor P.123
Clean the windshield
P. 1 2 4
12Adjust the steering wheel
P. 1 0 7

383-1. CONTROLS
Supra Owner's Manual_U (from Nov. '20 Prod.)
13 Horn, entire surface
14 Unlock hood P.29215 Unlocking the trunk lid
P. 8 0
1Control Display P.48
2 Hazard warning sys-
tem P.315
3Ventilation P.232
4Glove compartment P.245
5Radio/multimedia, see
Owner's Manual for Naviga-
tion, Entertainment, and
Communication
6Automatic air conditioning
P.226
7Controller with buttons P.48
8 Sport mode button P. 1 3 2
SPORT driving mode
Toyota Supra Safety
P. 1 7 3
Auto Start/Stop func-
tion P.116
Parking Sensors P.42
Rearview camera P.218
RCTA (Rear cross traffic
alert) function P.222
VSC Vehicle Stability
Control System P.195
In the vicinity of the center console
1
4
23
5
6
7
89
10
11

403-1. CONTROLS
Supra Owner's Manual_U (from Nov. '20 Prod.)
This chapter describes all stan-
dard, country-specific and
optional features offered with
the series. It also describes fea-
tures and functions that are not
necessarily available in your
vehicle, e.g., due to the selected
options or country versions. This
also applies to safety-related
functions and systems. When
using these functions and sys-
tems, the applicable laws and
regulations must be observed.
Depending on the equipment,
the following cameras and sen-
sors are installed in the vehicle:
• Cameras behind the wind-
shield.
• Rearview camera.
• Front radar sensor.
• Radar sensors, side, rear.
• Ultrasound sensors in the
bumpers.
Keep the vehicle cameras and
sensors, as well as surrounding
areas, clean and unobstructed.The cameras are located in the
area of the interior mirror.
The camera is located in the
handle of the trunk lid.
The cameras may not be fully
functional and may provide
incorrect information in the fol-
lowing situations:
• In heavy fog, wet conditions,
or snow fall.
• On steep hills, in steep
Sensors of the vehicle
Vehicle equipment
Overview
Cameras
Cameras behind the wind-
shield
Rearview camera
System limits of the cam-
eras
