TOYOTA TACOMA 2010 Owners Manual (in English)

291 3-3. Using the hands-free phone system (for cellular phone)
3
Interior and exterior features
■Changing the PIN
Select “Set PIN” by using a voice command or .
Enter the registered PIN by using a voice command or .
Enter a new PIN by using a voice command or .
When using , input the number one digit at a time.
Locking or unlocking the phone book
Select “Phone book lock (PHBK LOCK)” or “Phone book
unlock (PHBK UNLOCK)” by using a voice command or
.
Input the PIN by either of the following methods and select
“Confirm” by using a voice command or :
a. Press and say the registered PIN.
b. Input a new PIN by using .
■When the phone book is locked
The following functions cannot be used:
●Dialing by inputting a name
●Speed dialing
●Dialing a phone number stored in the call history memory
●Using the phone book

292 3-3. Using the hands-free phone system (for cellular phone)
Setting voice guidance volume
Select “(GUIDANCE VOL)” by using .
Change the voice guidance volume.
To decrease the volume: Turn counterclockwise.
To increase the volume: Turn clockwise.
Initialization
Select “(INITIALIZE)” and then “(CONFIRM)” by using .
Select “(CONFIRM)” by using again.
■Initialization
●The following data in the system can be initialized:
• Phone book
• Outgoing and incoming history memory
• Speed dial data
• Registered cellular phone data
•PIN
●Once the initialization has been completed, the data cannot be restored.

293
3-3. Using the hands-free phone system (for cellular phone)
3
Interior and exterior features
Using the phone book
Adding a new phone number
The following methods can be used to add a new phone number:
●Inputting a phone number by using a voice command
●Transferring data from the cellular phone
●Selecting a phone number from outgoing or incoming history mem-
ory
●Inputting a phone number by using
To enter the menu of each setting, follow the steps below:
●Adding a new phone number
1. “Phone book”  2. “Add entry”
●Changing a registered name
1. “Phone book”  2. “Change name”
●Listing the registered data
1. “Phone book”  2. “List names”
●Setting speed dial
1. “Phone book”  2. “Set speed dial (SPEED DIAL)”
●Deleting registered data
1. “Phone book”  2. “Delete entry”
●Deleting speed dial
1. “Phone book”  2. “Delete speed dial (DEL SPD DIAL)”

294 3-3. Using the hands-free phone system (for cellular phone)
■Adding procedure
Select “Add entry” by using a voice command or .
Use one of the following methods to input a phone number:
Inputting a phone number by using voice commands
STEP2-1 Select “By voice” by using a voice command or
.
STEP2-2 Press , say the desired phone number, and
select “Confirm” by using a voice command.
Transferring data from the cellular phone
STEP2-1 Select “By phone” and then “Confirm” by using a
voice command or .
STEP2-2 Transfer the data from the cellular phone.
Refer to the manual that comes with the cellular phone for
the details of transferring data.
STEP2-3 Select the data to be registered by either of the fol-
lowing methods:
a. Say “Previous” or “Next” until the desired data is
displayed, and select “Confirm” by using a voice
command or .
b. Select the desired data by using .

295 3-3. Using the hands-free phone system (for cellular phone)
3
Interior and exterior features
Selecting a phone number from outgoing or incoming history mem-
ory
STEP2-1 Select “Call history” by using a voice command or
.
STEP2-2 Select “Outgoing” or “Incoming” by using a voice
command or .
STEP2-3 Select the data to be registered by either of the fol-
lowing methods:
a. Say “Previous” or “Go back” until the desired
data is displayed, and select “Confirm” by using
a voice command or .
b. Select the desired data by using .
Inputting a phone number by using
STEP2-1 Select “(MANUAL INPUT)” by using .
STEP2-2 Input a phone number by using , and press
once again.
Input the phone number one digit at a time.

296 3-3. Using the hands-free phone system (for cellular phone)
Select the name to be registered by either of the following
methods, and select “Confirm” by using a voice command or
:
a. Press and say the desired name.
b. Select “(RECORD NAME)” by using , and say the
desired name.
Select “Confirm” by using a voice command or again.
In , selecting “Set speed dial (SPEED DIAL)” instead of
“Confirm” registers the newly added phone number as speed dial.
Setting speed dial
Select “Set speed dial (SPEED DIAL)” by using a voice com-
mand or .
Select the data to be registered as speed dial by either of the
following methods:
a. Press , say the desired phone number, and select
“Confirm” by using a voice command or .
b. Press , and say “List names”. While the desired name
is being read aloud, press , and select “Confirm” by
using a voice command or .

297 3-3. Using the hands-free phone system (for cellular phone)
3
Interior and exterior features
c. Select the desired data by using .
Select the desired preset button, and register the data into
speed dial by either of the following methods:
a. Press the desired preset button, and select “Confirm” by
using a voice command or .
b. Press and hold the desired preset button.
Changing a registered name
Select “Change name” by using a voice command or .
Select a name to be changed by either of the following meth-
ods.
a. Press , say the desired name, and select “Confirm”
by using a voice command or .
b. Press , and say “List names”. While the desired name
is read aloud, press .
c. Select the desired name by using .
Select “(RECORD NAME)” by using .
Say a new name, and select “Confirm” by using a voice com-
mand or .

298 3-3. Using the hands-free phone system (for cellular phone)
Deleting registered data
Select “Delete entry” by using a voice command or .
Pattern A
Select data to be deleted by either of the following methods,
and select “Confirm” by using a voice command or :
a. Press , and say the name of the desired phone num-
ber to be deleted.
b. Press , say “List phones”. While the name of the
desired phone number is being read aloud, press .
Pattern B
Select data to be deleted by using , and select “(CON-
FIRM)” by using .
Deleting speed dial
Select “Delete speed dial (DEL SPD DIAL)” by using a voice
command or .
Press the preset button for which the desired speed dial is
registered, and select “Confirm” by using a voice command or
.

299 3-3. Using the hands-free phone system (for cellular phone)
3
Interior and exterior features
Listing the registered data
Select “List names” by using a voice command and the system
begins reading aloud the list of the registered data.
When listing is complete, the system returns to “Phone book”.
Pressing while an entry is being read aloud selects the entry,
and the following functions will be available.
• Dialing: “Dial”
• Changing a registered name: “Change name”
• Deleting an entry: “Delete entry”
• Setting speed dial: “Set speed dial (SPEED DIAL)”
■Limitation of number of digits
A phone number that exceeds 24 digits cannot be registered.

300
3-4. Using the interior lights
Interior lights list
■Illuminated entry system
When the interior light switch is in the DOOR position, the interior light auto-
matically turns on/off according to whether the doors are locked/unlocked
and whether the doors are open/closed.
■To prevent the battery from being discharged
If the interior light remains on when the door is not fully closed and the inte-
rior light switch is in the DOOR position, the light will go off automatically
after 20 minutes.
Interior light (P. 301)
Personal lights (if equipped) (P. 301)
