The buttons for radio, CD player, DVD
player, iPod and AUX operation are dis-
played on the function button display
screen when the audio control mode is se-
lected.
Touch them lightly and directly on the
screen.
The selected button is highlighted.
INFORMATION
DIf the system does not respond to
a touch of a touch −screen button,
move your finger away from the
screen and then touch it again.
D You cannot operate dimmed
touch− screen buttons.
D Wipe off fingerprints on the sur-
face of the display using a glass
cleaning cloth.
DMain volume adjustment
1. Adjust with the “VOL” button.
The volume changes one step each time
the “Y ” or “B ” button of “VOL”is
pushed. Furthermore, the volume will con-
tinue to change if the switch is pushed con-
tinuously.
INFORMATION
D Adjust to an appropriate volume
that ensures accident −free, safe
driving.
D The volume may alter when the au-
dio mode is changed. Adjust the
volume to suit the audio mode
used.
—Adjusting the volume and
the sound quality

127
SCION V398
AUDIO/VIDEO SYSTEM
DMuting the sound
If you wish to cancel all sound from the
audio system, push the “MUTE” but-
ton. Push the “MUTE” button again to
restore the sound.
DSound menu screen display
The sound quality inside the cabin will be
altered greatly by such factors as the type
of media or music used, and the vehicle
body type. This system allows you to set
the most appropriate sound quality to suit
these factors.
1. Push the “SOUND” button at the re-
spective audio screen or DVD screen to
display the “Sound” screen.

128AUDIO/VIDEO SYSTEM
SCION V398
2. Touch “Sound2” or “Sound1”.
Settings such as the following can be
made from the“Sound”screen.
“CSE”: Allows the compressed sound
range to be returned to its original sound,
and music to be played back with en-
hanced clarity. (See page 128.)
“BASS”: Allows low range sound qualities
(sound sharpness, build −up and fade −out)
that could not be set with the existing Tone
Control/EQ to be adjusted through CSE
settings. (See page 129.)
“DSP”: Allows the acoustic field (perfor-
mance venue) to be reproduced to match
the image conjured up by the music genre
or source. (See page 130.)
“FOCUS”: Allows the time taken for the
sound to reach the listener ’s ear from each
speaker to be adjusted. (See page 130.)
“AUTO VOL”: Detects the vehicle speed
and adjusts the volume accordingly. (See
page 131.)
“EQ”: Allows the previously set equalizer
curve to be adjusted and the preferred
equalizer curve to be created. (See page
131.)
“SSP”: The optimum acoustic environ-
ment can be created by setting vehicle in-
formation. (See page 132.)
“FAD BAL”: Allows the front, rear, left,
and right volume balance to be adjusted.
(See page 133.)
INFORMATION
D The sound quality can be set and
registered for each audio mode at
CSE and CSE·BASS.
D It is recommended that each sound
quality characteristic be set in the
following order to create the opti-
mum acoustic environment.
CSE
SSP
FAD BAL
FOCUS

AUTO VOL
DCSE (Clear Sound Effecter) settings
When recording from the original source to
other media, sound range inaudible to the
human ear are compressed. CSE returns
the compressed sound range as near as
possible to their original source, enabling
the listener to enjoy impressive high −quali-
ty sound inside the cabin. CSE also allows
the listener to enjoy real, high −clarity
sound in order to deliver clearer playback
of radio sound, etc.
SETTING CSE
1. Touch “CSE”.
The indicator will turn yellow.
Touch “CSE” again to cancel the settings.
Touch “OK”when settings are complete.
CHANGING THE CSE OFFSET
The CSE offset can be changed based on
the listener ’s preference.
1. Touch the CSE “Setting” switch to
display the “CSE Setting” screen.
2. Touch the preferred level switch.
Touch “OK”when settings are complete.
When “OFF” is touched, CSE is only can-
celled for the audio mode currently being
listened to.
Offset level 3 is not available for AM radio.
All audio mode CSE offset values can be
returned to their default values by touching
“Reset” .

129
SCION V398
AUDIO/VIDEO SYSTEM
DCSE·BASS settings
Even if the compressed sound range is
semi− reproduced with CSE, there is a ten-
dency for low −pitch sound (bass under
approximately 200Hz, deep bass) to be in-
sufficient due to road noise. CSE·BASS
allows adjustments to be made to low −
pitch sections of sound that tend to be in-
sufficient.
CSE·BASS features
With standard Tone Control/EQ, sound
sharpness is lost, booming occurs, and it
is not possible to adjust to the preferred
bass when the BASS level is raised.
DYNAMICS: Used to adjust bass build −
up/fade− out and level.
BASS RESPONSE: Used to adjust the
bass constricting/emanating sound and
level.
SETTING CSE·BASS
1. Touch “BASS”.
The indicator will turn yellow.
Touch “BASS“ again to cancel the set-
tings.
Touch “OK“when settings are complete.
Operation will not be possible if CSE has
not been set.
If CSE settings are cancelled, CSE·BASS
settings are also cancelled automatically. BASS LEVEL SETTINGS
1. Touch the BASS “Setting” switch to
display the “CSE·BASS Setting”
screen.
2. Touch the preferred level switch.
All audio mode CSE·BASS levels can be
returned to their default values by touching
“Reset”
.
Touch “OK”when settings are complete.
“DYNAMICS” “MAX” or “MIN”: Used to
adjust the impact of bass instruments.
“BASS RESPONSE” “MAX” or “MIN”:
Used to adjust the quality (presence) of
bass instruments.

130AUDIO/VIDEO SYSTEM
SCION V398
DDSP (Acoustic Field) settings
The DSP settings can be used to add a re-
verberant sound to the played back music
in order to simulate a variety of perfor-
mance venues, reproducing a realistic
acoustic field.
1. Touch “DSP” to display the “DSP”
screen.
2. Touch the touch −screen button to
select the desired acoustic field mode,
from the list written below.
Touch
when settings are complete.
The currently selected DSP is displayed
on the operation screen for each audio
mode.
“CONCERT”: Concert venue
“LIVE”: Live venue
“STADIUM”: Outdoor stadium
“CLUB”: Disco, club
“CATHEDRAL”: Church with powerful re-
verberant sound
“OFF”: DSP OFF
DSound travel time adjustment (FO-
CUS)
It is possible to offset the variations in
sound travel time that occur due to differ-
ences in distance, by adjusting the time al-
lowed for sound to reach the listener ’s
ears.
1. Touch “FOCUS” to display the “FO-
CUS” screen.
2. Touch the preferred point.
Touch “Y ”, “B ”, “A ”,or “" ”to make
fine adjustments.
Touch “OK”when adjustment is com-
plete.
Touch “Reset” to clear the setting.

131
SCION V398
AUDIO/VIDEO SYSTEM
DAuto volume adjustment
(AUTO VOLUME)
The volume can be set to increase auto-
matically to match road noise, which varies
based on the driving speed.
1. Touch “AUTO VOL” to display the
“AUTO VOLUME” screen.
2. Touch “AUTO VOL 1” to “AUTO VOL
5”.
Touch “OFF” to clear the settings.
Touch
when settings are complete.
DEQ (Equalizer) adjustments
The equalizer can be adjusted to the pre-
ferred sound quality based on a variety of
music genres and sources.
ADJUSTING THE SOUND QUALITY
The currently set equalizer curve can be
selected and set to the preferred sound
quality.
1. Touch “EQ” to display the “EQUAL-
IZER” screen.
2. Touch the touch −screen button to
select the desired sound quality mode,
from the list written below.
Touch
when settings are complete.
EQ 1: POP
EQ 2: ROCK
EQ 3: JAZZ
EQ 4: CLASSICAL
EQ 5: VOCAL
FLAT: No EQ offset

132AUDIO/VIDEO SYSTEM
SCION V398
ADJUSTING AND STORING THE EQ
CURVE
Allows the equalizer curve to be adjusted
to a sound quality other than the currently
set equalizer curve and then stored in the
memory.
1. Imagine your preferred equalizer
curve and then trace that curve slowly
with a finger.
2. To perform fine adjustments, direct-
ly touch the frequency bar to be ad-
justed, and then touch the “+” and “−”
switches on the right of the screen.
The selected frequency bar is then high-
lighted.
3. Touch the switch to be stored in the
memory from “EQ 1” to “EQ 5” until a
beep sounds.
By touching “FLAT“until a beep sounds,
it is possible to return the stored equalizer
curve to the originally setting.
Touch
when settings are complete.
DSSP (SCION SOUND PROCESSING)
settings
SSP is a modified DSP (Digital Signal
Processing) system that provides a cus-
tomized sound for your vehicle. You can
select from the modes below.
“NEUTRAL”: A subdued sound that does
not interfere with conversations.
“HEAR”: A powerful, energetic, “live”
sound.
“FEEL”: Player ’s sound −> reproduces
the sound on the stage that musicians
hear.
For more details, please visit the SCION
Web site at http://www.scion.com/ .
1. Touch “SSP” to display the “SCION
SOUND PROCESSING” screen.
2. Touch sound type.
Touch “OFF” to cancel the SSP settings
and return to the “Sound”screen.
3. Touch vehicle type.

133
SCION V398
AUDIO/VIDEO SYSTEM
4. Touch “OK”.
Touch
to change the setting.
When SSP has been determined, the sys-
tem is automatically set to the optimum EQ
value.
DVolume balance adjustments
(FAD BAL)
By individually adjusting the volume bal-
ance for the front, rear, left, and right
speakers, it is possible to enhance the
sound from distant speakers.
1. Touch “FAD BAL” to display the
“FAD·BAL” screen.
2. Touch the preferred balance point.
Touch “Y ”, “B ”, “A ”,or “" ”to make
fine adjustments.
Touch “OK”when adjustment is com-
plete.
Touch “Reset” to clear the setting.

134AUDIO/VIDEO SYSTEM
SCION V398
DListening to the radio
Push the “MODE” button and touch
“FM” to receive FM radio broadcasts,
and “AM” to receive AM radio broad-
casts.
Push the “AUDIO” button to display the
radio operation screen.
Your radio automatically changes to stereo
reception when a stereo broadcast is re-
ceived. “ST” appears on the screen. If the
signal becomes weak, the radio reduces
the amount of channel separation to pre-
vent the weak signal from creating noise.
If the signal becomes extremely weak, the
radio switches from stereo to mono recep-
tion. In this case, “ST” disappears from the
screen.
DPresetting a station
1. Select the broadcasting station to
be stored in the memory.
2. Touch the preset switch (1 — 8) to be
stored in the memory until a beep
sounds.
The broadcasting station (frequency) will
be stored in the memory.
Each radio mode can store up to 8 station-
s. Follow the same procedure to change
the preset station to a different one.
Touch
to display preset switches “5”to
“8” .
The preset station memory is cleared if the
power source is interrupted by a battery
disconnection or a blown fuse.
DSelecting a station
Tune in the desired station using one of the
following methods.
Normal station selection: Push the“Y ”
or “B ”button of “TRACK/TUNE” .
The displayed frequency moves UP/
DOWN one step each time one of the but-
tons is pushed. (1step is 10kHz for AM and
0.2MHz for FM.)
Auto station selection: Push the“Y ”or
“ B ” button of “TRACK/TUNE” until a
beep sounds.
The broadcasting station nearest to the
frequency displayed at the screen is auto-
matically selected and the search process
stops when the station is received. Push
again to cancel in the middle of a search.
Preset switch station selection: Sta-
tions can be selected by touching their pre-
set switches. Touch
to display preset
switches “5”to“8” .
INFORMATION
It may not be possible to perform auto
station selection in areas with weak
reception area.
To scan all the frequencies: Touch
“SCAN” . The system searches for a
broadcasting station and after receiving a
detected station for several seconds, then
searches for the next station. Touch
“SCAN” again when the desired station is
reached.
To scan the preset stations: Touch
“P.SCAN” . After receiving the preset
broadcasting station for several seconds,
the system moves on to the next preset
station. Touch “P.SCAN”again when the
desired station is reached.
— Radio operation
