TOYOTA YARIS HATCHBACK 2020 Owners Manual (in English)

5518-2. Specifications
YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
8
Specifications
4-Door
5-Door
The type of refrigerant used is indicated on a label attached t o the
inside of the engine compartment. Check the label before rechar ging
the refrigerant. Refer to Clim ate Control System on P. 256.
Weights
ItemWeight
Manual transaxleAutomatic transaxle
GVWR (Gross Vehicle Weight
Rating)3,344 lb. (1,517 kg)3,393 lb. (1,539 kg)
GAWR (Gross Axle
Weight Rating)Front1,753 lb. (795 kg)1,795 lb. (814 kg)
Rear1,638 lb. (743 kg)1,627 lb. (738 kg)
ItemWeight
Manual transaxleAutomatic transaxle
GVWR (Gross Vehicle Weight
Rating)3,314 lb. (1,503 kg)3,360 lb. (1,524 kg)
GAWR (Gross Axle
Weight Rating)Front1,733 lb. (786 kg)1,786 lb. (810 kg)
Rear1,585 lb. (719 kg)1,581 lb. (717 kg)
Air Conditioner
ItemSpecification
Refrigerant TypeHFC134a (R-134a)

5528-2. Specifications
YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
■Exterior light
*1: UN-R stands for United Nations Regulation.
*2: LED is the abbreviation for Light Emitting Diode.
*3: Double-filament light bulb, however, only 60 W filament bulb is used in the
daytime running lights.
Light Bulbs
Light bulb
Category
WattageUN-R*1
(SAE)
Headlights Halogen
headlights
High/Low
beam
60/55 H4 (H4)
LED
headlightsHigh beamLED*2 (
)Low beam
Daytime
running lightsWith halogen bulb headlights60/55*3H4 (H4)
With LED headlightsLED*2 ()
Front side-marker lights5WY5W ()
Front turn signal lights/Parking lights28/8
(7444NA)
Fog lights (if equipped)55H11 (H11)
Side turn signal lights (if equipped)LED*2 ( )
High-mount brake lightLED*2 ()
Rear turn signal lights21WY21W
(7443NA)
Brake lights/Taillights/Rear side-marker lights
(4-Door)21/5W21/5W (7443)
Brake lights/Taillights (5 Door)21/5W21/5W (7443)
Rear side-marker lights (5-Door)5W5W ( )
Reverse lights18W16W
(921)
License plate lights5W5W ( )

5538-2. Specifications
YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
8
Specifications
■Interior light
*1: UN-R stands for United Nations Regulation.
Check the tire pressure label for tire size and inflation pressure.
Refer to Tire Pres sure Label on P. 547.
Refer to Tire Inflati on Pressure on P. 413.
After adjusting the tire pressur e, initialization of the tire p ressure mon-
itoring system is necessary to m ake the system operates normall y.
Refer to Tire Pressure Monitorin g System Initialization on P. 244.
■Standard tire
■Temporary spare tire
Light bulbCategory
WattageUN-R*1
Trunk light (4-Door) 3
Luggage compartment light (5-Door) 5
Overhead lights/Map lights8
Tires
Tire sizeInflation pressure
FrontRear
P185/65R15 86H255 kPa (37 psi)230 kPa (33 psi)
P185/60R16 86H250 kPa (36 psi)230 kPa (33 psi)
Tire sizeInflation pressure
T125/70D15 95M420 kPa (60 psi)

5548-2. Specifications
YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
■Lug nut tightening torque
When installing a tire, tighten the lug nut to the following torque.
80-108 ft
•lbf (108-147 N•m, 12-14 kgf•m)
The tires have been optimally matched with the chassis of your vehicle.
When replacing tires, Toyota recommends that you replace tires of the
same type originally fitted to your vehicle. For details, conta ct your Toyota
dealer.
Refer to Fuses on P. 435.
Fuses

555
YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
8
Specifications
8-3. Customizable Features
Customizable Features
The following customizable features can be set or changed by your
Toyota dealer. Consult your Toyota dealer for details.
Additionally, some of the custom izable features can be changed by
the customer depen ding on the feature.
Customizable features which can be changed differ depending on the
market and specification.
Settings can be changed by opera ting the center display screen.
A: Refer to Settings on P. 300.
B: Refer to Fuel Economy Monitor on P. 221.
Settings can be changed by ope rating the vehicle switches.
C: Refer to Stopping The Low Speed Pre-Collision System Opera- tion on P. 233.
D: Refer to Auto Lock/Unlock Function on P. 108.
E: Refer to Smart Key on P. 93.
F: Refer to Locking, Unlocking with Request Switch (With the advanced keyless f unction) on P. 103.
Settings can be changed by your Toyota dealer.
■Safety
●Low Speed Pre-Co llision System (P. 228)
*: Though these systems can be turned Off, doing so will defeat t he purpose
of the system and Toyota recommends that these systems remain O n.
Settings Change Method
1
2
3
FeatureFactory
SettingAvailable SettingsSettings Change Method
The system can be
changed so that Low
Speed Pre-Collision Sys-
tem does not operate.
*
On On
AC –
Off
123

5568-3. Customizable Features
YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
■Ve h i c l e
●Power Door locks ( P. 1 0 8 )
● Keyless entry system ( P. 9 2 )
FeatureFactory
SettingAvailable SettingsSettings Change Method
Changes the auto lock/
unlock function setting for
all the doors according to
the vehicle speed, the
vehicle power supply con-
dition, and the selector
lever position. Lock: When
Driving/
Unlock: IGN Off Lock: Out of
Park/Unlock:
In Park
AD 
Lock: Shift-
ing Out of Park
Lock: When Driving/
Unlock: In
Park
Lock: When Driving/
Unlock: IGN Off
Lock: When
Driving
Off
123
FeatureFactory SettingAvailable SettingsSettings Change
Method
The method for unlocking
the doors using the smart
key can be changed. Driver’s:
Once/All Doors: Tw i c e All Doors:
Once
AE Driver’s:
Once/All
Doors: Twice
The time required for the
doors to relock automati-
cally after unlocking with
the smart key can be
changed.
60 seconds
90 seconds
A–
60 seconds
30 seconds
123

5578-3. Customizable Features
YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
8
Specifications
●Advanced keyless entry system (P. 99)
● Illuminated ent ry system (P. 377)
FeatureFactory
SettingAvailable SettingsSettings Change Method
The method for unlocking
the doors using the
request switch/transmitter
can be changed. Driver’s:
Once/
All Doors: Tw i c e All Doors:
Once
AE/F 
Driver’s:
Once/
All Doors: Twice
The volume of the
answer-back beep during
advanced keyless entry
system operation can be
changed.
Medium
High
AFMedium
Low
Off
The function to automati-
cally lock the doors when
leaving the vehicle while
carrying the key can be
changed. OffOn
A– 
Off
The time required for the
doors to relock automati-
cally after unlocking with
the request switch/trans-
mitter can be changed.
60 seconds
90 seconds
A–60 seconds
30 seconds
123
FeatureFactory
SettingAvailable SettingsSettings Change Method
Time until interior lights
turn off after closing door 15 seconds60 seconds
A–30 seconds
15 seconds
7.5 seconds
Time until interior lights
turn off automatically
when any door is not
closed completely
30 minutes
60 minutes
A–
30 minutes
10 minutes
123

5588-3. Customizable Features
YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
●Auto-wiper control ( P. 2 0 1 )
*: If the auto-wiper control is set to Off, the wiper lever posi tion is set to
intermittent operation.
● Daytime running lights ( P. 1 9 7 )
● Auto-light control ( P. 1 9 2 )
FeatureFactory
SettingAvailable SettingsSettings Change Method
Operational/
non-operational OnOn
A– 
Off*
123
FeatureFactory
SettingAvailable SettingsSettings Change Method
Operational/non-opera-
tional OnOn
A– 
Off
123
FeatureFactory
SettingAvailable SettingsSettings Change Method
Timing by which lights turn
on MediumHigh
A– 
Med.High
Medium
Med.Low
Low
123

5598-3. Customizable Features
YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
8
Specifications
●Auto headlight off ( P. 192)
*: When set to Off, the lights-on reminder is operable.
● Lights-on reminder* ( P. 5 0 2 )
*: The setting of the lights-on reminder can be changed with the time set-
ting of auto headlight off function set to Off. Refer to Lights-On Reminder
on P. 502.
● Turn indicator ( P. 199)
● Three-flash turn signal ( P. 200)
FeatureFactory
SettingAvailable SettingsSettings Change Method
Time until headlights turn
off 30 seconds120 seconds
A–
90 seconds
60 seconds
30 seconds
Off
*
123
FeatureFactory SettingAvailable SettingsSettings Change Method
Warning beep volume High High
A– 
Low
Off
123
FeatureFactory SettingAvailable SettingsSettings Change
Method
Beep volume HighHigh
A– 
Low
123
FeatureFactory
SettingAvailable SettingsSettings Change Method
Operational/non-opera-
tional OnOn
A– 
Off
123

5608-3. Customizable Features
YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
■System
●Language
*: Available only in display from the center display.
●Temperature unit
● Distance unit
■Fuel Economy Monitor ( P. 221)
●
Ending display
FeatureFactory SettingAvailable SettingsSettings Change Method
Language indicated in dis-
play US EnglishDepends on
market
*A– 
123
FeatureFactory
SettingAvailable SettingsSettings Change Method
Temperature unit indi-
cated in display °F or °C°F
A– 
°C
123
FeatureFactory
SettingAvailable SettingsSettings Change Method
Distance unit indicated in
display miles or kmmiles
A– 
km
123
FeatureFactory
SettingAvailable SettingsSettings Change Method
On/off OffOn
B– 
Off
123
