Downloaded from www.Manualslib.com manuals search engine DRIVING TIPS
Driving a four-wheel drive vehicle*
The drive concept
-h e syncro is equipped with a four-wheel
dri ve whi ch automatically distributes the
jnve force to the front and rear wheels by
eans of a viscous coupling.
n e distribution of the drive
is so regulated
- at in normal driving conditions the front
• heels alway s receive slightly more drive
' h an the
rear wheels.
owever , on very slippery surfaces when
-'l e grip at the front wheels is not adequate
t ransfer the drive to the road , the viscous
:ou pling automatically diverts more drive to
-'le rear wheels.
e four-wheel drive remains
in operation in 'ev erse gear.
Attention The style of driving must always be adapted to suit road surface and traffic conditions. The in­creased safety offered by this type of vehicle must not encour­age one to take unnecessary risks.
In particular, one must always re­member that the braking ability is limited by the adhesion of the tyres on the road surface and no different from a two-wheel drive vehicle. For this reason, one should never be tempted by the good acceler­ation capabilities, even on slip­pery road surfaces, into driving too fast. It should be noted that the front wheels can aquaplane when driv­ing at high speeds on wet road. When this happens -contrary to vehicles with front wheel drive only -the start of the aquaplan­ing is not indicated by a sudden revving up of the engine. For this reason, do not drive too fast, al­ways adapt the speed to the ex­isting road conditions.
What else should be noted?
Using winter tyres
With the four-wheel drive the vehicle has
good traction in winter road conditions even
with the standard tyres. However the use of
winter/all-we ather tyres on
all four wheels is recommended to further improve handl­
ing and braking.
Using snow chains
Snow chains must also be used on vehicles
with four wheel drive when snow chains are
obligatory . F urther details about using
snow chai ns are given on page 109
Renewing wheels/tyres
On the syncro all four wheels must always have the same rolling circumference. For
further information see page 107.
Output testing
If any time an output test is to be carried out
on a sin gle axle test stand the propshaft
must be detached
at the front
79

Downloaded from www.Manualslib.com manuals search engine DRIVING TIPS

Brake testing
For brake testing on a brake test stand th e
props haft does not have to be detached .
On the rear w heels the brake test is carried
out in the same way as on two-wheel drive
vehicle .
When testing the front w heel brakes how­
ever there are some special points to
be noted:
• The
ve hicle must be reversed onto the
te st stand so that the test stand rollers drive
the front w heels backwards .
• Then the gear lever
must be moved into
1 st gear w ith the ignition on and then back
into neutral again Th is disengages the free­
wheel lock in the back axle.
Note
On no account must the reverse gear be se­
lected when the rollers are running other­
wise the freewheel lock would be engaged
again.
This would cause the rear wheel s to
be driven suddenly.
80

Downloaded from www.Manualslib.com manuals search engine Filling the tank
B1H-040
When tank cap has been taken off it can be
placed on the tank flap -see illustration.
r::ljb As soon as the correctly oper­~ated automatic nozzle switches off for the first time, the tank is full. Do not try then to put more fuel in because the expansion space in tank will be filled -the fuel can then over­flow when it becomes warm.
After filling tank, screw cap on until it clicks
audibly .
The
filler neck
is under a small flap in the
right rear side panel.
With the central locking ' the tank flap is also locked and unlocked automatically. If the central locking system is defective the fiapcanbeopenedbyhand-seene~page.
The tank holds about
-55 Itr (12 gallons) on the Golf saloon
- 60 Itr.
(13 gal lons) on the Golf estate
- 651tr .
(14 gallons) on the Golf syncro
Open
tank flap as shown in left illustr ation.
Note
• Never drive until 1he fuel tank is completely empty on vehicles with a catalytic converter. The irregular fuel supply can cause misfiring, which allows unburnt fuel into the exhaust system. This can cause overheating and damage to the cata­lyst.
• Note any lega l requirements when carry­
ing a spa re fuel canis ter. For safety reasons we do not recommend carrying a spare fuel
canister. In the event of an accident the can­
ister could be damaged and the fuel spilt.
81

Downloaded from www.Manualslib.com manuals search engine GENERAL MAINTENANCE
Fuel
Releasing tank flap manually
If the central locking system * should be­come defective the flap can be released
manually :
• Open tailgate and -if
fitted -fold back
t he righ t luggage compartment trim from
side panel.
• Then reach through bet
ween body panel
and positioner and pull back loc king rod In directio n of arrow - see Illustration .
Petrol engines
Vehicles with catalyst
40. 44 and 55 kW engines
Unleaded regular petrol
RON1) not lower than 91
66 and 110 kW engines
Unleaded premium petrol
RON1) not lower than 95.
85 kW engine
Unleaded premium petrol
RON') 95
or unleaded regular petrol. 91
RON')
The use of unleaded regular petrol, with a
min imum of 91 RON ') leads to a slight loss
o f power
11 Re se arch O ctane Num b r, indicates anti
k nock properties of the pe rol
128 kW engine
Unleaded premium petrol
RON1) not lower than 95
When u sing un leaded premium petrol RON1) 98 the engine develops more pulling power (higher torque) at the same nominal output -see page 134.
140 kW engine
Unleaded premium petrol
RON') 98.
The use
of unleaded premium petrol. RON1) not less than 95. is possible with­out restrictions.
The automatic adaption
of the ignition tim­
ing to the quality of the fuel (knock control),
can during unfavou rable operating condi­
tions cause a s
light loss of performance
This can be partly compensated for by uS ing
un lead ed prem ium petro l RONlI 98 .
82

Downloaded from www.Manualslib.com manuals search engine GENERAL MAINTENANCE

Vehicles without catalytic
converter
44 and 55 kW engines
un leaded or leaded regular petrol
RON') not lower t han 91
66 kW engine
Unleaded or leaded premium petrol
RON') not lower than 95
85 kW engine
Premium petrol unleaded or leaded
RON') 95
or regular petrol unleaded or l eaded . RON1) 91.
The use of u n leaded regular petrol, with a
m inimum of 91 RON1) leads to a slight loss of power .
Research Octane Num ber , indicate s anti­
knock properties o f the petrol.
Notes
• Unleaded petrol must comp ly with DIN21 51 607 and leaded petrol with DIN 51 600.
• If i n an emergency the octane rating of
the available petrol is lower than that re­quired by the engine only drive with me­
dium engine speeds and low engine load­
ing. High engine loading with full throttle or high revs can cause en­gine dam ag e. Fill tank with petrol of the
correct rating as soon as possible &.., On vehicles with catalytic con­
~verter only unleaded petrol may
be used.
Even a single tank of leaded petrol
will reduce the effectiveness of the
catalytic converter.
In the interests of the environment,
unleaded petrol should always be
preferred to leaded fuel. even on ve­
hicles without a catalytic converter.

21 Stan dards issued by th e G rman Standards inslltu\l on
Petrol additives
The quality of the fuel has a decisive influ­
ence upon the running behaviour, perform­
ance and ser v ice life of the engine. The addi­
ti ves which are mixed into the petrol are of particular sign ificance. One is advised
theref ore only to use good quality pet­rol containing additives.
If such fu el is not available, or if eng ine troubles such as starting difficulties, stall ing during idling, vibratio n and loss of power
occur, the approp riate additives should be mixed with the petro l w hen filling the tank.
These additives have an anti-corrosion ef­
f ect, clean the fuel system and prevent de­
posits building up in the engine.
Petrol additives available
in accessory
outlets have not all shown themsel ves to be effective. Ther efore additives which have been tested for Volkswagen engines are
available from Volkswagen dealers in Ger­many and in many export countries . The Volks wagen dealers are also informed with
r e gard to the use of additives , and they
kno w what to do in cases where deposits have already built up.
83

Downloaded from www.Manualslib.com manuals search engine GENERAL MAINTENANCE ~~~~~~=--------------------
Diesel engines
Diesel fuel
to DIN 51 601. eN1) not lower than 45.
Driving in winter
When using summer Diesel trouble may be experienced at temperatures below Ooe because the fuel thickens due to wax separ­
ation.
For this reason, w inter Diesel which
is more
resistant to cold is sold during the winter in Germany, and this works satisfactorily
down to between -15 and -22°e, depend­
ing on the type of fuel used.
In countries with different climatic condi­
tions the Diesel fuels offered have a differ­
ent temperature characteristic. Check with
Volkswagen dealers or filling stations
in the
country concerned regarding the character­
istic s of Diesel fuels.
Filter preheating
The vehicle is fitted with a filter preheater.
This will ensure , that the fuel system re­mains operational down to about -25°e provided that winter Diesel which is cold re­sistant down to -15°e is used. Diluting with
petrol is then no longer necessary under
these conditions.
If, at temperatures below -25°e the fuel is waxed to such an extent that the engine w ill
not sta rt it is sufficient to place the vehicle in a warm room for a while .
Fuel additives (anti-waxing agents) and
similar fluids must not be mixed with the
Diesel fuel.
11 Cetane N u bee ind icates the ig nltabillty of
D iesel.
84

Downloaded from www.Manualslib.com manuals search engine GENERAL MAINTENANCE
Care of vehi cle
Reg ular and careful care helps to m aintain the value of th e vehicle.
F
urthermore it can be one of the sti­pulations for the upholding of war­
ranty claims should corros ion dam­age and paint defects occur.
Eve ry Volkswagen dealer carries stocks of su itabl e car care materials. The instr uctions for use on the containe r sh o uld be followed.
Attention • If misused, car care materials can be injurious to health. • Car care materials must al­ways be store d in a safe place w here they are out ofthe reach of children.
~W hen buying car care materials W one should select products which do not damage the environ­ment. Empty co n tainers which these materials wer e in do not be­long with household waste.
Washing
The best protection against environmental influences is frequent washing and waxing .
How often this treatment is require d de­
pends , amongst other things on how much
the vehicle is used, how it is parked (garage, in open under trees etc.), the seasons ,
w eather conditions and environmental in­
fluences.
The longer bird dropp
ings, insects, tree resin , road and industr ia l grime, tar spots ,
soot, road s alt and other aggress ive ma­
terials rema in o n the vehicle paint the more
l asting their destructive effect w ill be . High
temperatur es e .g . from strong sunli ght in­
t ensi fies th e corrosi ve effe ct.
In certain circumstances weekly washing can be necessary, but monthly washing
with appropr iate waxi ng may be fully ad­equa te.
After the pe riod when salt is put on the
r oads the underside of the vehic le should al­
w ay s be washed thoroughly.
Automatic wash plants
The vehic le paint is so durable that the ve­
hicle can norma lly be washed without prob­
lems in an aut omatic wash plant. However
the influe nce on the paint depends to a large
e xtent on the design of the plant, the filter­
ing of the wash water, the type of wash and
care mater i
al, etc. If the paint has a matt ap­pearance after gOing through the wash
p lant or is even scratched thi s shou ld be
brought to the notice of the plant operato r
immediately If necessary a different wash
p lant should
be used .
Notes
• Before going through the wash plant, apart from the usual precautions (closing windows and sliding roof, retrac ting the aer­ial) there is noth ing further to note . The VW
roof aerial does not have to be taken off.
• If there are specia l fittings on the vehicle
- such as spoilers, roof rack, two-way radio
aeria l etc . it is best to speak to the plant op­
erator.
85

Downloaded from www.Manualslib.com manuals search engine GENERAL MAINTENANCE

W ashing the vehicle by hand
~In the interests ofe n vironmental ~protection the vehicle s hould only be washed in specially pro­vided wash bays. In some districts, washing cars elsewhere may even be forbidden .
First soften the dirt
with plenty of water and

rinse off as well as possible.

Th en clean the car with a soft sponge, glove

or brush starting on the roof and going from

t o p to bottom using only slight pressure.

Pain t sham poo should only be used for very

p ersis tent dirt.

Rinse the s ponge or glove out thoroughly at

s l
lort intervals.

Wheels and sill panels should be cleaned
last, using a different sponge if possible.

After clea nin g the vehicle, rinse thoroughly
with water and leather it off.

Notes
• The vehicle should not be washed In strong sunshine.
• If the vehicle
is rinsed with a hose, do not
direct the jet of water at the lock cylinders
- they can freeze up in the winter.
Washing vehicle with high pressure
cleaner
• The operating instructions for the high
pressure cleaner must be followed closely
- particularly with regard to pressu re and working distance.
•
Do not use a concentrated Jet. • The water temperature must not be
above 60°e.
Attention
Tyres must never be cleaned with
a concentrated jet! Even at a rela­
tively large working distance and
a very short spraying time, dam­
age can occur.

Waxing
A good coat of "vax pro tects the vehicle
paintwork to a large extent again st the envi­
ronmental influences listed under "Wash­ing" on the previous page an d even against
light mechanical damage
At the latest
when water on th e clean paint
does not form small drops an d roll off, the
vehicle should be protec te d b y applying a
coat of good hard wax. Even when a wax
solution
is used regular ly in the washing water it is advisable to prote ct th e paint vVlth a coat of hard wax at least twice a year.
Polishing
Should only be done if paint has lost its
shine and gloss cannot be brought back
with wax. If the polish used does not con­
tain preservative compounds, th~ pain t must be waxed afterwards.
Note
Matt painted and plastic parts should
not be treated with pol is h or hard wax.
86

Downloaded from www.Manualslib.com manuals search engine GENERAL MAINTENANCE

Paint damage
Small marks in the paint su ch as scratches
or stone damage should be touched up im­
mediately with paint (Vol kswagen touch-up
stick or spray can) before the meta l starts to
rust.
H
owever, should rust be fou nd at any time it must be remo ved thoroughly and then the
area treated first with an ant i-corrosion
p rimer and then the correct pain t applied .
Y
ou can of course have this work done by a
V olkswagen dealer.
T he number of the original vehicl e paint
is given on the data sticke r (see page 147 )
Windows
Remov e sno w and ice from w indows and mirrors with a p lastic scraper only To avoid
s cratches due to dirt on the glass , the
s c raper should only be pushed in one direc­
t ion and not moved to and fro.
Traces of rubber , oil, grease or silicone can
b e remo ved with a window cleaning sol­ution or a si lic one remover.
- he
windows sho uld also be cleaned on the
n side at regular intervals.
0 0 not dry the w
indows with the leather
u sed for the paintwork because traces of paint cleaner wil l cause streaks to appear on the glass.
To avoid damaging the heating element wires in the rear window do not put
stickers over the wires on the inside.
Door, boot and window
weatherstrips
The w eatherstrips will rema in fle xible and last longer if the y are rubbed lightly with a
rubb er protec tive compound from time to
time . This will also stop the weatherstrips
from freezing on in the w inter.
Plastic parts and leatherette
Exterior plastic parts are cleaned with nor­mal w ashing and interior parts wit h a damp
cloth. If this is not suff ic ient. these parts and
leatherette may only be cleaned with special solvent-free plastic cleaners.
Upholstery cloth and textile
trim
Upho ls tery cloth and textile trim on door
panels, parcel shelv es, lu ggage compart­
ment co vers , h eadlining ete.
must be cleaned with special cleane rs or dry foam
and a soft brush .
Leather
Le athe r shou ld, depe nding on usage, be
treated from time to tim e in ac cordance with the follo wing instruc tions. It mus t be
not ed t hat on no account may solvents,
f loor w ax, shoe polish, spot re­mo vers and similar products be used for this purpose.
For the norma l clean ing of leather covered
steering wheels, seat upholstery etc . a cot­
ton or woollen cloth lightly moistened
with w ater should be used to clean dirty leath er
surfaces. Dirtie r areas can be cleaned with a mild soap solution (2 dess er t spoonfuls of
a neutral soap to 1 litre of water) . It is essen ­
t ia l to note that the leather must not be made too wet and that no water seeps
th roug h th e seams . After cleaning, wipe dry with a soft cloth .
F u rthermore we recomme nd th a
t. w ith nor­
mal usage, the leat her is treat ed at half­
y ear ly interva ls with a special leather care
age nt which can be obtained from Volks­wagen dealers. This age nt is to be app lied
very sparingly. After it has dried in, wipe w ith a soft cloth.
87

Downloaded from www.Manualslib.com manuals search engine GENERAL MAINTENANCE

Cleaning seat belts
Keep belts clean because they ma y not

retract properly if very dirty .

Dirt y be
lts can be cleaned by was hing w ith

a mild soap solutio n without taking the belts

out of the vehicle.

Note
Inert ia reel belts should be completel y dry
before they are allowed to roll up.
Attention Do not have the belts cleaned chemically because the cleaning compounds damage the webbing material. Ensure that the belts do not come into contact with cor­rosive fluids.
Steel wheels
The wheels and the whee l tr ims should be
cle aned thoroughly at regular inter vals w hen the vehicle is being washed. This w ill
prevent brake dust , dirt and road salt from
accu mulating on the wheel. Persistent
ingr ained brake dust can be removed With an industrial grim e remov er. P aint damage
should be repaired before rust can form.
Alloy wheels
In order to maintain th e smart appearan ce
of all oy wheels for a long period, regular
car e is necessary . In particular, salt and brake pad dust must be washed off th or­ ough
ly
at leas t every tw o w eeks otherwise
the surface of the alloy Will be damaged
After being w ashed, the w heels shou ld be treated with an acid-free cleaner for al loy wheels. About every three months it is necessary to give wheels a good rubbing
w ith hard wax. Paint polish or other abrasiv e
solutions must not
be used. If the protecti ve
paint coat has been damaged , eg. by stone
impact, the damaged spots should be dealt with as soon as possible.
Cleaning and anti-corrosion
treatment of engine compart­
ment
Attention Before doing any work in the en­gine compartment it is essential to read the notes on page 91!
The leaves, blossoms etc . w hich drop into
the water box (underneath the engine
bonnet
in f ront of the windscreen) should
be cleaned out occasional ly This w ill pre­
v ent the water drain holes becoming
blocked
and -on veh ic les w ithout a fresh air
filter -foreign bodies entering the vehicle
interior v
ia the heating and ventilat ion sys­
tem.
Attention For safety reasons pull out igni­tion key before reaching into the water box. Otherwise if the wind­screen wipers are switched on unintentionally the movement of the wiper linkage could cause in­jury.
The engine compartment an d th e outsi de
surface of the power unit are given anti-cor ­
rosion treatment at the factor y.
In th e winter w hen the vehicle is being
driven frequ entl y on salted roads, good anti­
corrosion treatment is very important. For
th is reason the entire engin e comp
artment and the plen um chamber should be thor­
ough ly cleaned before and after the salting
period
and then preserved so that the salt cannot have a damag ing effect
The ignition must be switched off before washing the engine.
If the engine compartment is cle aned at any
time with greas e removing solution s 1) or if
one has the engine washed, the anti-cor­
rosion compound is nearly alwa ys removed as wel l. It is the refore essential to ask for
durable preserv ation of all surfaces, seams,
joints and components in the engine com­partment to be carried out. This applies also
1) Only the corre e clean ing solutions may be use d -on no aecoun petrol or Diesel.
88
