No. Amperage
1. Backup lights 10A
2. Parking lights, foglights, cargo compartment lighting, license plate \
lights, brake light
diodes 20A
3. Accessories 15A
4. -
5. Rear electronic module 10A
6. Navigation system (option), radio receiver, rear seat entertainment\
(accessory) 7.5A
7. Trailer wiring (30-feed) 15A
8. 12-volt socket in cargo compartment 15A
9. Rear passenger's side door: power window, power window cutout functio\
n 20A
10. Rear driver's side door: power window, power window cutout function \
20A
11. -
12. -
13. -
14. Subwoofer (option), rear air conditioning system (option) 15A
15. -
16. -
17. Accessory audio 5A
18. -
19. Rear window wiper 15A
20. Trailer wiring (15-feed) 20A
21. -
22. -
23. All Wheel Drive 7.5A
24. -
25. -
26. Park assist 5A
27. Main fuse: trailer wiring, park assist, All Wheel Drive 30A
28. Central locking system 15A
29. Driver's side trailer lighting: parking light, turn signal 25A
30. Passenger's side trailer lighting: brake light, fog light, turn sign\
al 25A
31. Main fuse: fuses 37, 38 40A
32. -
file:///K|/ownersdocs/2006/2006_XC90/06xc90_09b.htm (23 of 24)12/30/20\
06 5:32:52 PM

2006 VOLVO XC90
33. -
34. -
pg. 169 Maintenance
Fuses (contd)
35. -
36. -
37. Heated rear
window 20A
38. Heated rear window 20A




Contents | Top of Page
file:///K|/ownersdocs/2006/2006_XC90/06xc90_09b.htm (24 of 24)12/30/20\
06 5:32:52 PM

2006 VOLVO XC90
2 0 0 6
VOLVO XC90
Specifications

pg. 171 Specifications
Label information172
Weights173
Dimensions 174
Fluid capacities175
Engine oil176
Lubricants177
Electrical system179
Engine specifications180
All specifications are subject to change without prior notice.
pg. 172 Specifications
file:///K|/ownersdocs/2006/2006_XC90/06xc90_10.htm (1 of 10)12/30/2006\
5:32:53 PM

2006 VOLVO XC90

Label information
1. Vehicle Emission Control Information
Your Volvo is designed to meet all applicable emission standards, as evi\
denced by the certification label
on the underside of the hood. For further information regarding these re\
gulations, please consult your
Volvo retailer.
2. Vacuum hose routing
(underside of hood)
3. Loads and Tire Pressures
(on inside of fuel filler door). Canadian models only.
4. Child safety lock label
5. Federal Motor Vehicle Safety
file:///K|/ownersdocs/2006/2006_XC90/06xc90_10.htm (2 of 10)12/30/2006\
5:32:53 PM

2006 VOLVO XC90
Standards (FMVSS) specifications (USA) and Ministry of Transport (C\
MVSS) standards (Canada) Your
Volvo is designed to meet all applicable safety standards, as evidenced \
by the certification label on the
facing side of the driver's door. For further information regarding thes\
e regulations, please consult your
Volvo retailer.
6. Loads and Tire Pressures U.S. models only
Certain models will only have one decal, depending on the specifications\
of the vehicle.
7. Vehicle Identification Number (VIN)
1
The VIN plate is located on the top left surface of the dashboard. The V\
IN is also stamped on the right
hand door pillar.
8. Model plate
Vehicle Identification Number (VIN). Codes for color and upholstery, e\
tc. The plate is located in the
engine compartment, on the inside of the left front fender.
1. The Vehicle Identification Number (VIN) should always be quoted in \
all correspondence concerning
your vehicle with the retailer and when ordering parts.
pg. 173 Specifications
Weights
Gross vehicle weight* USACanada
5-seat, 5-cyl, FWD 5640
lbs -
5-seat, 5-cyl, AWD 5790
lbs 2630 kg
5-seat, 8-cyl, AWD 5900
lbs 2680 kg
7-seat, 5-cyl, FWD 5840
lbs -
7-seat, 5-cyl, AWD 6005
lbs 2720 kg
7-seat, 8-cyl, AWD 6080
lbs 2760 kg
Capacity weight
file:///K|/ownersdocs/2006/2006_XC90/06xc90_10.htm (3 of 10)12/30/2006\
5:32:53 PM

2006 VOLVO XC90
5-seat models 1160
lbs 525 kg
7-seat models 1210
lbs 550 kg
Permissible axle weight, front*
5-seat, 5-cyl, FWD 2710
lbs -
5-seat, 5-cyl, AWD 2820
lbs 1280 kg
5-seat, 8-cyl, AWD 2910
lbs 1320 kg
7-seat, 5-cyl, FWD 2710
lbs -
7-seat, 5-cyl, AWD 2820
lbs 1280 kg
7-seat, 8-cyl, AWD 2910
lbs 1320 kg
FWD = Front Wheel Drive
AWD = All Wheel Drive
* Permissible axle weight or gross vehicle weight must never be exceeded\
. Permissible axle weight, rear* USA Canada
5-seat, 5-cyl, FWD 3060 lbs -
5-seat, 5-cyl, AWD 3150 lbs 1430 kg
5-seat, 8-cyl, AWD 3150 lbs 1430 kg
7-seat, 5-cyl, FWD 3170 lbs -
7-seat, 5-cyl, AWD 3240 lbs 1470 kg
7-seat, 8-cyl, AWD 3240 lbs 1470 kg
Curb weight
5-seat, FWD 4355-4390
lbs -
5-seat, AWD 4490-4670
lbs 2045-2125 kg
7-seat, FWD 4530-4565
lbs -
7-seat, AWD 4665-4830
lbs 2115-2190 kg
file:///K|/ownersdocs/2006/2006_XC90/06xc90_10.htm (4 of 10)12/30/2006\
5:32:53 PM

2006 VOLVO XC90
Max. roof load 220 lbs 100 kg
Trailer weight, w/o brakes 1700 lbs 750 kg
Trailer weight, with brakes See the table on
page 104
Max. tongue weight See the table on
page 104
pg. 174 Specifications
Dimensions
Dimensions
Length 188.9 in (479.8 cm)
Width 74.7 in (189.8 cm)
Height 70.2 in (178.4 cm)
Wheelbase 112.6 in (285.7 cm)
Front track 64.3 in (163.4 cm)
Rear track 63.9 (162.4 cm)
Turning
circle 39-40 ft. (11.9-12.3 m)
Cargo capacity
With optional 3rd row of seats folded down:
5-seat: 41.6 cu ft (1178 litres)
7-seat: 43.3 cu ft (1225 litres)
Behind 1st row of seats, with 2nd (and optional 3rd) row of seats fold\
ed down:
5-seat: 84.9 cu ft (2403 litres)
7-seat: 85.1 cu ft (2410 litres)
Behind 1st row of seats, with front passenger seat, 2nd row (and option\
al 3rd row) of seats folded
down:
5-seat: 92.0 cu ft (2606 litres)
7-seat: 93.2 cu ft (2640 litres)
pg. 175 Specifications
file:///K|/ownersdocs/2006/2006_XC90/06xc90_10.htm (5 of 10)12/30/2006\
5:32:53 PM

2006 VOLVO XC90
Fluid Capacities
Fuel tank 21.1 US gallons (80 liters).
Minimum octane requirement - AKI 87 (RON 91) - unleaded fuel (See
also
page 86)
Transmission oil
AW55-51 (5-cyl. turbo) 7.6 US qts. (7.2 liters) JWS 3309
TF-80SC (V8) 7.4 US qts. (7.0 liters) JWS 3309
Miscellaneous
Power steering 1.1 US qts. (1.0 liters)
Windshield washer
reservoir 6.9 US qts. (6.5 liters)
Brake fluid 0.63 US qts. (0.6 liters)
Air conditioning system Front - 2.2 lb. (1 kg), Rear (option) 2.9 lb. (1.3 kg) R 134a (HF\
C134a)
WARNING!
When adding accessories, equipment, luggage and other cargo to your vehi\
cle, the total capacity
weight must not be exceeded.
pg. 176 Specifications
Engine oil
Specifications
Engine oil must meet the minimum ILSAC specification GF-3, API SL, or AC\
EA A1/B1. Lower quality
oils may not offer the same fuel economy, engine performance, or engine \
protection.
Volume
Engine
designation Volume between MIN-MAX on dipstick
Volume
a
2.5T B5254T2 1.3 US qts (1.2 liters) 5.8 US qts. (5.5 liters)
V8 AWD B8444S 1.3 US qts (1.2 liters) 7.1 US qts. (6.7 liters)
a. Including filter replacement
file:///K|/ownersdocs/2006/2006_XC90/06xc90_10.htm (6 of 10)12/30/2006\
5:32:53 PM

2006 VOLVO XC90
pg. 177 Specifications

Lubricants
Transmission
Oil grade:
See the table on
page 175.
Different types of oil should never be mixed.
Power steering
Grade: Volvo synthetic power steering fluid (Pentosin CHF 11S) P/N 1161529 \
or equivalent.
Brake fluid
Fluid type: DOT 4+ boiling point >536°F (280°C), P/N 9437433
Cooling system
Type Positive pressure, closed system.
Coolant Volvo original coolant/antifreeze
Volume 5-cyl. turbo 9.5 US qts. (9.0 liters)
V8 10.7 US qts. (10.2 liters)
The thermostat begins to open at 194°F (90°C).
Suspension
Rear suspension
Individual rear wheel suspension with longitudinal support arms, double \
link arms and track rods.
file:///K|/ownersdocs/2006/2006_XC90/06xc90_10.htm (7 of 10)12/30/2006\
5:32:53 PM

2006 VOLVO XC90
Front suspension
Spring strut suspension with integrated shock absorbers and control arms\
linked to the support frame.
Power-assisted rack and pinion steering. Safety type steering column.
pg. 178 Specifications
Three-way catalytic converter cautions
