VOLVO XC90 TWIN ENGINE 2018 Owners Manual

DRIVER SUPPORT
}}
349
given, the indicator light will become brighter and
begin flashing.
NOTE
The light illuminates on the side of the vehicle
where the system has detected the vehicle. If
the vehicle is passed on both sides simulta-
neously, both lights come on.
WARNING
•
The BLIS function is supplementary driver
support intended to facilitate driving and
help make it safer – it cannot handle all
situations in all traffic, weather and road
conditions.
• The responsibility for changing lanes
safely and using good judgment always
rests with the driver.
• BLIS is not a substitute for the driver's
attention and judgment. The driver is
always responsible for ensuring the vehi-
cle is driven in a safe manner, at the
appropriate speed, with an appropriate
distance to other vehicles, and in accord-
ance with current traffic rules and regula-
tions.
Related information
•Activating/deactivating BLIS (p. 349)
• BLIS limitations (p. 350) •
Recommended maintenance for BLIS
(p. 351)
• BLIS messages (p. 352) Activating/deactivating BLIS
The BLIS
80
function can be activated/deacti-
vated. Location of BLIS indicator light.
81 Indicator light
The BLIS button in the center display's Func-
tion view is used to activate/deactivate the
function.
– Tap the
BLIS button in Function view.
>
The BLIS indicator light shows the status
of the function: GREEN (on) or GRAY
(off).
If BLIS is activated when the engine is started,
the indicator lights in the rearview mirrors will
flash once.
If BLIS is deactivated when the engine is turned
off, it will remain off the next time the engine is
started and the indicator lights will not illuminate.

||DRIVER SUPPORT
* Option/accessory.
350
Related information
• BLIS* (p. 348) BLIS limitations
BLIS 82
functionality may be reduced in certain
situations. Keep this area clean (on both the left and right sides of
the vehicle)
83
.
Examples of limitations:
• Dirt, ice and snow covering the sensors may
reduce functionality and prevent the system
from providing warnings.
• The BLIS function is automatically deacti-
vated if a trailer, bicycle holder or similar is
connected to the vehicle's electrical system.
• For BLIS to function optimally, bicycle hold-
ers, luggage racks or similar should not be
mounted on the vehicle's towbar.WARNING •
BLIS does not work in sharp curves.
• BLIS does not work when the vehicle is
being reversed.
Related information
•
BLIS* (p. 348) 80
Blind Spot Information
81 Note: This illustration is general and details may vary depending on mod\
el.
82 Blind Spot Information
83 Note: This illustration is general and details may vary depending on mod\
el.

DRIVER SUPPORT
* Option/accessory.351
Recommended maintenance for
BLIS
•
For optimal performance, it is important to
keep the areas in front of the sensors clean.
• Do not attach any objects, tape or decals to
the surface of the sensors. Keep this area clean (on both the left and right sides of
the vehicle)
84
.
The BLIS sensors are located on the inside of
each of the rear fenders/bumpers and are also
used by the Cross Traffic Alert (CTA) and Rear
Collision Warning functions.
CAUTION Repair of BLIS and CTA components or
repainting of the bumper may only be per-
formed by a workshop – an authorized Volvo
workshop is recommended.
Related information
•
BLIS* (p. 348)
• Cross Traffic Alert* (p. 353)
• Activating/deactivating Cross Traffic Alert
(p. 354)
• Cross Traffic Alert limitations (p. 354)
• Recommended maintenance for Cross
Traffic Alert (p. 355)
• Cross Traffic Alert messages (p. 356)
• Rear Collision Warning (p. 347) 84
Note: This illustration is general and details may vary depending on mod\
el.

DRIVER SUPPORT
* Option/accessory.
352 BLIS messages
A number of messages related to BLIS 85
may
be displayed in the instrument panel.
Some examples of symbols and messages are shown in the table below. Message
Meaning
Blind spot sensor
Service required The system is not functioning as intended. Contact a workshop ‒ an authorized Volvo workshop is recommended.
Blind spot system off
Trailer attached BLIS and CTA have been deactivated because a trailer has been connected \
to the vehicle's electrical system.A text message can be erased by briefly pressing
the
button in the center of the right-side
steering wheel keypad.
If the message persists: Contact a workshop ‒ an
authorized Volvo workshop is recommended.
Related information
• BLIS* (p. 348) 85
Blind Spot Information

DRIVER SUPPORT
* Option/accessory.353
Cross Traffic Alert*
CTA 86
is a supplementary driver support system
to BLIS 87
that is intended to help the driver
detect vehicles crossing behind the vehicle
while backing up. CTA overview.
CTA supplements BLIS by detecting traffic cross-
ing from the side, e.g. when backing out of a
parking space.
CTA is primarily designed to detect vehicles, but
in certain cases can also detect pedestrians or
smaller objects such as bicycles.
CTA is only active when the vehicle is moving
backward or if reverse gear is engaged. If CTA detects that something is approaching
your vehicle from the side:
• an audible signal will sound from either the
left or right speaker, depending on which
side of your vehicle the object is approaching
from.
• an icon will illuminate in the PAS 88
graphic
on the screen.
• an icon will appear in the Park Assist Cam-
era's Top view. Illuminated CTA icon in the PAS
88
graphic 89
on the
screen.
WARNING •
The Cross Traffic Alert function is supple-
mentary driver support intended to facili-
tate driving and make it safer – it cannot
handle all situations in all traffic, weather
and road conditions.
• The responsibility for reversing the vehicle
safely and using good judgment always
rests with the driver.
• Cross Traffic Alert is not a substitute for
the driver's attention and judgment. The
driver is always responsible for ensuring
the vehicle is driven in a safe manner, at
the appropriate speed, with an appropri-
ate distance to other vehicles, and in
accordance with current traffic rules and
regulations.
Related information
• Activating/deactivating Cross Traffic Alert
(p. 354)
• Cross Traffic Alert limitations (p. 354)
• Recommended maintenance for Cross
Traffic Alert (p. 355)
• Cross Traffic Alert messages (p. 356) 86
Cross Traffic Alert
87 Blind Spot Information
88 Park Assist System: Parking assistance with reversing sensors
89 Note: This illustration is general and details may vary depending on mod\
el.

DRIVER SUPPORT
* Option/accessory.
354 Activating/deactivating Cross Traffic
Alert
The driver can choose to deactivate the CTA 90
function as follows: Press the Cross Traffic Alertbutton in the center display's
Function view. •
GRAY button indicator light - CTA is deacti-
vated.
• GREEN button indicator light - CTA is acti-
vated.
CTA is automatically activated each time the
engine is started.
Related information
• Cross Traffic Alert* (p. 353) Cross Traffic Alert limitations
CTA 91
functionality may be reduced in certain
situations.
CTA does not function optimally in all situations
and has certain limitations. The CTA sensors, for
example, cannot "see" through other parked
vehicles or objects blocking the vehicle.
Below are a few examples of situations in which
CTA's field of vision may be initially limited and
approaching vehicles may therefore not be
detected until they are very close to your vehicle: The vehicle is parked very far into a parking space. In a diagonal parking space, CTA may be completely
"blind" on one side of your vehicle.
CTA's blind zone.
CTA's field of vision.
However, as you back your vehicle slowly out of a
parking space, CTA's field of vision changes in
relation to the obstructing vehicle/object and its
blind zone is reduced. 90
Cross Traffic Alert
91 Cross Traffic Alert

DRIVER SUPPORT
* Option/accessory.355
Examples of further limitations
•Dirt, ice and snow covering the sensors may
reduce functionality and prevent the system
from providing warnings. For additional infor-
mation, see the section "Recommended
maintenance for Cross Traffic Alert".
• CTA is automatically deactivated if a trailer,
bicycle holder or similar is connected to the
vehicle's electrical system.
• For CTA to function optimally, bicycle hold-
ers, luggage racks or similar should not be
mounted on the vehicle's towbar.
Related information
•
Cross Traffic Alert* (p. 353) Recommended maintenance for
Cross Traffic Alert
•
For optimal performance, it is important to
keep the areas in front of the sensors clean.
• Do not attach any objects, tape or decals to
the surface of the sensors. Keep this area clean (on both the left and right sides of
the vehicle)
92
.
The CTA sensors are located on the inside of
each of the rear fenders/bumpers and are also
used by the BLIS 93
and Rear Collision Warning
functions.
CAUTION Repair of BLIS and CTA components or
repainting of the bumper may only be per-
formed by a workshop – an authorized Volvo
workshop is recommended.
Related information
•
Cross Traffic Alert* (p. 353)
• BLIS* (p. 348)
• Rear Collision Warning (p. 347) 92
Note: This illustration is general and details may vary depending on mod\
el.
93 Blind Spot Information

DRIVER SUPPORT
* Option/accessory.
356 Cross Traffic Alert messages
A number of messages related to CTA 94
may be
displayed in the instrument panel.
Some examples of symbols and messages are shown in the table below. Message
Meaning
Blind spot sensor
Service required The system is not functioning as intended. Contact a workshop ‒ an authorized Volvo workshop is recommended.
Blind spot system off
Trailer attached BLIS and CTA have been deactivated because a trailer has been connected \
to the vehicle's electrical system.A text message can be erased by briefly pressing
the
button in the center of the right-side
steering wheel keypad.
If the message persists: Contact a workshop ‒ an
authorized Volvo workshop is recommended.
Related information
• Cross Traffic Alert* (p. 353) 94
Cross Traffic Alert

DRIVER SUPPORT
* Option/accessory.357
Road Sign Information*
The Road Sign Information (RSI
95
) function noti-
fies the driver of speed-related road signs the
vehicle is passing. Examples of signs that can be detected
96
.
If the vehicle passes a speed limit sign, it will be
displayed in the instrument panel and the head-
up display*.
NOTE In certain markets, the Road Sign Information
function (RSI) is only available in combination
with Sensus Navigation.
WARNING •
The Road Sign Information function is
supplementary driver support intended to
facilitate driving and help make it safer –
it cannot handle all situations in all traffic,
weather and road conditions.
• Road Sign Information is not a substitute
for the driver's attention and judgment.
The driver is always responsible for
ensuring the vehicle is driven in a safe
manner, at the appropriate speed, with an
appropriate distance to other vehicles,
and in accordance with current traffic
rules and regulations.
Related information
•Activating/deactivating Road Sign Informa-
tion (p. 358)
• Road Sign Information and sign displays
(p. 358)
• Road Sign Information and Sensus
Navigation (p. 359)
• Road Sign Information with Speed Warning
and Settings (p. 359)
• Activating/deactivating Speed Warning in
Road Sign Information (p. 360) •
Road Sign Information with speed camera
information (p. 361)
• Road Sign Information limitations (p. 361) 95
Road Sign Information
96 Road signs differ according to market ‒ the illustrations shown here are just some examples.

DRIVER SUPPORT
* Option/accessory.
358 Activating/deactivating Road Sign
Information
The Road Sign Information function can be
switched On or Off.
Press the Road Sign
Information button in the cen-
ter display's Function view. •
GREEN button indicator light - RSI is acti-
vated.
• GRAY button indicator light - RSI is deacti-
vated.
NOTE •
If the Automatic Speed Limiter function is
activated, road sign information is shown
in the driver display even if RSI is not
activated.
• To remove road sign information from the
driver display, you must deactivate both
Automatic Speed Limiter and RSI.
• When the Automatic Speed Limiter func-
tion is activated but RSI is deactivated, no
warnings are given from RSI. In this situa-
tion, settings for RSI cannot be adjusted
either - to be able to adjust settings as
well as receive warnings, RSI must be
activated.
Related information
•
Road Sign Information* (p. 357) Road Sign Information and sign
displays
Road Sign Information (RSI 97
) displays road
signs in different ways depending on the sign
and situation. Example
98
of registered speed information.
When RSI has registered a speed limit sign, the
sign will be displayed as a symbol in the instru-
ment panel and a RED marking will be shown in
the speedometer's speed scale. 97
Road Sign Information
98 Road signs differ according to market ‒ the illustrations shown here are just examples.
