6-30
PERIODIC MAINTENANCE AND MINOR REPAIR
6
EAU00774
Adjusting the Autolube
pumpThe Autolube pump is a vital and
sophisticated component of the
engine, which must be adjusted by a
Yamaha dealer at the intervals speci-
fied in the periodic maintenance and
lubrication chart.
EAU03370
Checking and lubricating the
brake and shift pedalsThe operation of the brake and shift
pedals should be checked before
each ride, and the pedal pivots
should be lubricated if necessary.
EAU03164
Checking and lubricating the
brake and clutch leversThe operation of the brake and clutch
levers should be checked before
each ride, and the lever pivots should
be lubricated if necessary.
Recommended lubricant:
Lithium-soap-based grease
(all-purpose grease)
Recommended lubricant:
Lithium-soap-based grease
(all-purpose grease)
3MB-9-E8 6/13/01 10:55 AM Page 67

6-32
PERIODIC MAINTENANCE AND MINOR REPAIR
6 2. Hold the lower ends of the front
fork legs and try to move them
forward and backward. If any
free play can be felt, have a
Yamaha dealer check or repair
the steering.
EAU01144
Checking the wheel bearingsThe front and rear wheel bearings
must be checked at the intervals
specified in the periodic maintenance
and lubrication chart. If there is play
in the wheel hub or if the wheel does
not turn smoothly, have a Yamaha
dealer check the wheel bearings.
EAU00794
Checking the steeringWorn or loose steering bearings may
cause danger. Therefore, the opera-
tion of the steering must be checked
as follows at the intervals specified in
the periodic maintenance and lubrica-
tion chart.
1. Place a stand under the engine
to raise the front wheel off the
ground.
EW000115
wSecurely support the motorcycle
so that there is no danger of it
falling over.
3MB-9-E8 6/13/01 10:55 AM Page 69

6-39
PERIODIC MAINTENANCE AND MINOR REPAIR
6
EAU00898
Front wheelTo remove the front wheel
EW000122
w8It is advisable to have a
Yamaha dealer service the
wheel.
8Securely support the motorcy-
cle so that there is no danger
of it falling over.1. Remove the brake disc cover by
removing the screws.
122
1. Disc cover
2. Screw (×2)
To service the rear wheel
Raise the rear wheel off the ground
by using a motorcycle stand or, if a
motorcycle stand is not available, by
placing a jack either under each side
of the frame in front of the rear wheel
or under each side of the swingarm.
EAU01579
Supporting the motorcycleSince this model is not equipped with
a centerstand, follow these precau-
tions when removing the front and
rear wheel or performing other main-
tenance requiring the motorcycle to
stand upright. Check that the motor-
cycle is in a stable and level position
before starting any maintenance. A
strong wooden box can be placed
under the engine for added stability.
To service the front wheel
1. Stabilize the rear of the motorcy-
cle by using a motorcycle stand
or, if an additional motorcycle
stand is not available, by placing
a jack under the frame in front of
the rear wheel.
2. Raise the front wheel off the
ground by using a motorcycle
stand.
3MB-9-E8 6/13/01 10:55 AM Page 76

6-44
PERIODIC MAINTENANCE AND MINOR REPAIR
6
Check if there is fuel1. Fuel
Enough fuel.
No fuel.
Go to compression check.
Supply fuel.
Engine doesn’t start, go to compression check.
Use kickstarter.2. Compression
There is compression.
No compression.
Go to ignition check.
Ask a Yamaha dealer to
Remove spark plug3. Ignition
Wet.
Dry.
Wipe clean with dry cloth and correct
Ask a Yamaha dealer to inspect.
Engine doesn’t start, ask a YamahaOpen throttle half-way and start
in the fuel tank.
and check electrodes.spark gap or replace spark plug. the engine.
dealer to inspect. inspect.
EAU03108
Troubleshooting charts
EW000125
wKeep away open flames and do not smoke while checking or working on the fuel system.
3MB-9-E8 6/13/01 10:55 AM Page 81

6-45
PERIODIC MAINTENANCE AND MINOR REPAIR
6
Wait until the
Check the coolant level in the
Level is OK.Level is low, check the
NoLeakage.
Ask a Yamaha dealer to inspectAdd coolant. (See NOTE.)
Restart the engine. If the engine overheats again, ask a
engine has cooled.reservoir tank and/or radiator.cooling system for leakage.
Yamaha dealer to inspect and repair the cooling system.leakage.
and repair the cooling system.
4. Engine overheating
EW000070
w8Do not remove the radiator cap when the engine and radiator are hot. Scalding hot fluid and steam may be
blown out under pressure, which could cause serious injury. Be sure to wait until the engine has cooled.
8After removing the radiator cap retaining bolt, place a thick rag, like a towel, over the radiator cap, and then
slowly rotate the cap counterclockwise to the detent to allow any residual pressure to escape. When the
hissing sound has stopped, press down on the cap while turning it counterclockwise, and then remove the
cap.NOTE:
If it is difficult to get the recommended coolant, tap water can be temporarily used, provided that it is changed to the rec-
ommended coolant as soon as possible.
