Page 471 of 626

YAMAHA YZ426F 2001  Owners Manual 5 - 22
CHAS
FREIN AVANT ET FREIN ARRIERE
VORDER- UND HINTERRADBREMSE
2. Montieren:
lBremshebel 1
lSchraube (Bremshebel) 2
lMutter (Bremshebel) 3
HINWEIS:
Lithiumfett auf die Gleitfläche des Bremsh

Page 472 of 626

YAMAHA YZ426F 2001  Owners Manual 5 - 23
CHASFRONT BRAKE AND REAR BRAKE
4. Install:
lPin 1
lPlain washer 2
lCotter pin 3
NOTE:
After installing, check the brake pedal height.
Refer to “REAR BRAKE ADJUSTMENT” sec-
tion in the CH

Page 473 of 626

YAMAHA YZ426F 2001  Owners Manual 5 - 23
CHAS
FREIN AVANT ET FREIN ARRIERE
VORDER- UND HINTERRADBREMSE
4. Montieren:
lStift 1
lBeilagscheibe 2
lSplint 3
HINWEIS:
Nach der Montage die Fußbremshebelposition
kontrollieren.
Siehe unte

Page 474 of 626

YAMAHA YZ426F 2001  Owners Manual 5 - 24
CHASFRONT BRAKE AND REAR BRAKE
4. Install:
lCopper washer 1
lBrake hose 2
lUnion bolt 3
WARNING
Always use new copper washers.
ACHTUNG:CAUTION:
Install the brake hose so that its pipe por-
t

Page 475 of 626

YAMAHA YZ426F 2001  Owners Manual 5 - 24
CHAS
FREIN AVANT ET FREIN ARRIERE
VORDER- UND HINTERRADBREMSE
4. Montieren:
lKupferscheibe 1
lBremsschlauch 2
lHohlschraube 3
WARNUNG
Immer neue Kupferscheiben verwenden.
ACHTUNG:
Den Bremss

Page 476 of 626

YAMAHA YZ426F 2001  Owners Manual 5 - 25
CHASFRONT BRAKE AND REAR BRAKE
2. Install:
lBrake hose holder 1
lScrew (brake hose holder) 2
ACHTUNG:CAUTION:
After installing the brake hose holders,
make sure the brake hose does not contac

Page 477 of 626

YAMAHA YZ426F 2001  Owners Manual 5 - 25
CHAS
FREIN AVANT ET FREIN ARRIERE
VORDER- UND HINTERRADBREMSE
2. Montieren:
lBremsschlauch-Halterung 1
lSchraube (Halterung) 2
ACHTUNG:
Nach dem Einbau der Bremsschlauch-Hal-
terungen sichers

Page 478 of 626

YAMAHA YZ426F 2001  Owners Manual 5 - 26
CHASFRONT BRAKE AND REAR BRAKE
2. Air bleed:
lBrake system
Refer to “BRAKE SYSTEM AIR
BLEEDING” section in the CHAPTER
3.
3. Inspect:
lBrake fluid level
Fluid at lower level ® Fill up.
Ref

Page 479 of 626

YAMAHA YZ426F 2001  Owners Manual 5 - 26
CHAS
FREIN AVANT ET FREIN ARRIERE
VORDER- UND HINTERRADBREMSE
2. Entlüften:
lBremsanlage
Siehe unter “HYDRAULISCHE-BREMS-
ANLAGE ENTLÜFTEN” im KAPITEL 3.
3. Kontrollieren:
lBremsflüssigk

Page 480 of 626

YAMAHA YZ426F 2001  Owners Manual 5 - 27
CHASFRONT FORK
EC550000
FRONT FORK
Extent of removal:1 Front fork removal
Extent of removal Order Part name Q’ty Remarks
Preparation for removalFRONT FORK REMOVAL
Hold the machine by placing
