ACURA CSX 2006 Service Repair Manual


Without navigation 1 CD type
23-81
A
AB
B C
5. Remove the screws and the brackets (A).
6. Install the audio unit in the reverse order of
removal, and make sure all connectors and
antenna lead are secure. SRS components are located in this area. Review the
SRS component location (see page 24-11).
Also review the precautions and procedures (see page
24-13) in the SRS section before doing repairs or
service.
NOTE:
 Put on gloves to protect your hands.
 Take care not to scratch the dashboard and related parts.
 Lay a workshop towel under the parts when working on them to protect the face panel from scratches or
other damage.
 Do not work in a dusty or dirty place.
 Discharge static electricity from your body before and during the work.
 Do not touch the circuit board(s) with your bare hands.
 Do not work with dirty hands.
 Be careful not to fold the flat plate cable.
 Do not touch the terminal connector of the flat plate cable with your bare hands. (If you have touched it,
wipe it off thoroughly.)
 Eject all the discs before removing the audio unit to prevent damaging the CD player’s load mechanism.
 If you are replacing the audio unit, write down the sudio presets (if possible), and enter them into the
new audio unit.
1. Remove the meter inner visor (see page 20-100).
2. Remove the center pocket hole lid and bolts, then pull out the center panel (A).
3. Disconnect the connectors (B) and the air hose (C), then remove the center panel.
(cont’d)
08/08/21 14:05:36 61SNR030_230_0084
ProCarManuals.com
DYNOMITE -2009-


Î
(#'#




 )
’08 model with navigation
23-8223-82 Audio System
Audio Unit Removal/Installation
(cont’d)
XM Receiver Removal/Installation
A
A
A B
A
C A
A
B
4. Remove the bolts, screws and the brackets (A).
5. Remove the screws, rear covers (A) and the audio
unit (B) from the center panel display (C).
6. Install the audio unit in the reverse order of removal, and make sure all connectors and
antenna lead are secure. 1. Open the trunk lid and remove the right trunk side
trim panel (see page 20-82).
2. Disconnect the connectors (A) from the XM receiver (B).
3. Loosen the three bolts, and remove the XM receiver.
4. Install the XM receiver in the reverse order of removal.
08/08/21 14:05:36 61SNR030_230_0085
ProCarManuals.com
DYNOMITE -2009-


Î
(#'#




 )
’08 model with navigation
23-8223-82 Audio System
Audio Unit Removal/Installation
(cont’d)
XM Receiver Removal/Installation
A
A
A B
A
C A
A
B
4. Remove the bolts, screws and the brackets (A).
5. Remove the screws, rear covers (A) and the audio
unit (B) from the center panel display (C).
6. Install the audio unit in the reverse order of removal, and make sure all connectors and
antenna lead are secure. 1. Open the trunk lid and remove the right trunk side
trim panel (see page 20-82).
2. Disconnect the connectors (A) from the XM receiver (B).
3. Loosen the three bolts, and remove the XM receiver.
4. Install the XM receiver in the reverse order of removal.
08/08/21 14:05:36 61SNR030_230_0085
ProCarManuals.com
DYNOMITE -2009-


(#'#





 ) 
(#'

 )
Type S model Front Door Speaker
23-8323-83
Stereo Amplifier Removal/
Installation
Speaker Replacement
A
CB AB
C
B
1. Slide the driver’s front seat forward fully.
2. Remove the amp cover (A), then disconnect the connectors (B).
3. Remove the mounting bolts, then remove the stereo amplifier (C).
4. Install the stereo amplifier in the reverse order of removal. 1. Remove the front door panel (see page 20-7).
2. Remove the screw. Then lift the speaker (A) straight
up to release the lower clips (B).
3. Disconnect the 2P connector (C), and remove the speaker.
4. Install the speaker in the reverse order of removal.
(cont’d)
08/08/21 14:05:37 61SNR030_230_0086
ProCarManuals.com
DYNOMITE -2009-


Î


Tweeter
Rear Speaker
23-84Audio System
Speaker Replacement (cont’d)
A
B
A A
A
C
B
1. Carefully pry the tweeter grille (A) out of the
dashboard. Be careful not to damage the tweeter
grille and the dashboard.
2. Disconnect the 2P connector (B) from the tweeter.
3. Remove the tweeter (A) from the speaker grille.
4. Install the tweeter in the reverse order of removal. 1. Remove the rear speaker grille (A).
2. Remove the screw. Then lift the speaker (A) straight
up to release the clips (B).
3. Disconnect the 2P connector (C), and remove the speaker.
4. Install the speaker in the reverse order of removal.
08/08/21 14:05:37 61SNR030_230_0087
ProCarManuals.com
DYNOMITE -2009-



(#'


 )
Subwoofer (Type S model) ’07-08 models
23-8523-85
Auxiliary Jack Assembly
Replacement
A
B A
B
1. Remove the rear tray (see page 20-78).
2. Remove the four mounting bolts from the
subwoofer (A).
3. Disconnect the 2P connector (B), and remove the subwoofer.
4. Install the subwoofer in the reverse order of removal. 1. With navigation: Remove the navigation unit
(see page 23-155).
Without navigation: Remove the audio unit
(see page 23-80).
2. Carefully pull out the auxiliary jack assembly (A), then disconnect the 5P connector (B).
3. Install the auxiliary jack assembly in the reverse order of removal.
08/08/21 14:05:38 61SNR030_230_0088
ProCarManuals.com
DYNOMITE -2009-



(#'


 )
Subwoofer (Type S model) ’07-08 models
23-8523-85
Auxiliary Jack Assembly
Replacement
A
B A
B
1. Remove the rear tray (see page 20-78).
2. Remove the four mounting bolts from the
subwoofer (A).
3. Disconnect the 2P connector (B), and remove the subwoofer.
4. Install the subwoofer in the reverse order of removal. 1. With navigation: Remove the navigation unit
(see page 23-155).
Without navigation: Remove the audio unit
(see page 23-80).
2. Carefully pull out the auxiliary jack assembly (A), then disconnect the 5P connector (B).
3. Install the auxiliary jack assembly in the reverse order of removal.
08/08/21 14:05:38 61SNR030_230_0088
ProCarManuals.com
DYNOMITE -2009-

´
µ
Û
Ý

(#'





) (#'





 )Position Resistance
23-8623-86
Audio System
Audio Remote Switch Test
Audio Remote Switch Replacement
A
B
1. Remove the driver’s airbag assembly (see page
24-188).
2. Remove the 20P connector (A) from the cable reel (B).
3. Measure the resistance between terminals No. 9 andNo.10ineachswitchpositionaccordingtothe
table.
No buttonpressed About 10 k
MODE About 3.7 k
CH ( ) About 1.7 k
CH ( ) About 775
(VOL.UP) About 357
(VOL.DOWN) About 100
4. If the resistance is not as specified, replace the audio remote switch (see page 23-86). 1. Remove the steering wheel (see page 17-6).
2. Remove the audio remote switch (see page 17-7).
3. Install the audio remote switch in the reverse order
of removal.
08/08/21 14:05:38 61SNR030_230_0089
ProCarManuals.com
DYNOMITE -2009-

Î
(#'



 ) 

(#'



!)
23-8723-87
AM/FM Antenna Amplifier
Replacement AM/FM Antenna Repair
A
B
C
B A
A
1. Remove the right side C-pillar trim (see page 20-75).
2. Disconnect the connectors (A) from the AM/FMantenna amplifier (B).
3. Remove the bolt and AM/FM antenna amplifier.
4. Install the AM/FM antenna amplifier in the reverse order of removal. NOTE: To make an effective repair, the broken section
must not be longer than one inch.
1. Lightly rub the area around the broken section (A) with fine steel wool, then clean it with alcohol.
2. Carefully mask above and below the broken portion of the window antenna wire (B) with cellophane
tape (C).
3. Mix the silver conductive paint thoroughly. Using a small brush, apply a heavy coat of paint (A)
extending about 1/8’’ on both sides of the break.
Allow 30 minutes to dry.
4. Check for continuity in the repaired wire.
5. Apply a second coat of paint in the same way. Let it dry 3 hours before removing the tape.
08/08/21 14:05:38 61SNR030_230_0090
ProCarManuals.com
DYNOMITE -2009-


(#'#



 )
’08 model with navigation
23-88Audio System
XM Antenna Replacement
A
B
C
1. Remove the headliner (see page 20-84).
2. Remove the nut (A) from the XM antenna (B).
3. Disconnect the connector (C) and remove the XM antenna.
4. Install the antenna in the reverse order of removal.
