ACURA CSX 2006 Service Repair Manual


µ
µ µ
µ
µ
µ
YES
NO
YES
NO
YES
NO
24-51
070AZ-SNAA100
07SAZ-TB4011A
A DASHBOARD WIRE HARNESS
4P CONNECTOR
070AZ-SNAA100
6. Reconnect the negative cable to the battery.
7. Clear the DTC memory.
8. Read the DTC (see page 24-22).Go to step 9.
Short in the driver’s airbag first or second
inflator; replace the driver’s airbag (see page
24-188), then clear the DTC.
9. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait at least 3
minutes.
10. Remove the column cover (see page 17-9), then disconnect dashboard wire harness 4P connector
(A) from the cable reel.
11. Connect the SRS inflator simulator (2 connectors) and the simulator lead to the
dashboard wire harness.
12. Reconnect the negative cable to the battery.
13. Clear the DTC memory. 14. Read the DTC.
Go to step 15.
Short in the cable reel; replace the cable reel
(see page 24-200), then clear the DTC.
15. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait at least 3
minutes.
16. Disconnect SRS unit connector A (28P) from the SRS unit (see step 9 on page 24-21).
17. Disconnect the SRS inflator simulator from the SRS simulator lead. Do not disconnect the simulator
lead from the dashboard wire harness 4P connector.
18. Connect the SRS short cancellers (070AZ-SAA0100) to SRS unit connector A (28P) terminals No. 7 and
No. 8 and terminals No. 1 and No. 2 (see page
24-18).
19. Measure the resistance between the terminals of both SRS simulator leads. There should be an open
circuitoratleast1M .
Faulty SRS unit or poor connection at SRS
unit connector A (28P) and the SRS unit. Check the
connection between the connector and the SRS
unit. If the connection is OK, replace the SRS unit
(see page 24-203).
Short in the dashboard wire harness; replace
dashboard wire harness, then clear the DTC.
I s DT C 11-3x or 11-6x i nd i cat ed ? I s DT C 11-3x or 11-6x i nd i cat ed ?
Is the resistance as specif ied?
08/08/21 13:55:41 61SNR030_240_0051
ProCarManuals.com
DYNOMITE -2009-

Î
(#'
'

-)
µ
µ
DTC 11-8x (‘‘x’’ can be 0 thru 9 or A thru F):
DTC 11-Ax (‘‘x’’ can be 0 thru 9 or A thru F):
Special Tools Required
YES
NO
24-52SRS
DTC Troubleshooting (cont’d)
A
070AZ-SNAA100 07SAZ-TB4011A
Short to Power in the Driver’s Airbag First
Inflator
Short to Power in the Driver’s Airbag Second
Inflator
 SRS inflator simulator 07SAZ-TB4011A
 SRS simulator lead J 070AZ-SNAA100
NOTE: Before doing this troubleshooting procedure,
review SRS Precautions and Procedures (see page
24-13), General Troubleshooting Information (see page
24-22), and Battery Terminal Disconnection and
Reconnection (see page 22-68).
1. Clear the DTC memory (see page 24-23).
2. Turn the ignition switch to ON (II), and check that the SRS indicator comes on for about 6 seconds
and then goes off.
Go to step 3.
Intermittent failure, system is OK at this time.
Go to Troubleshooting Intermittent Failures
(see page 24-24). If another DTC is indicated,
troubleshoot the DTC. 3. Turn the ignition switch to LOCK (0). Disconnect the
negative cable from the battery, then wait at least 3
minutes.
4. Disconnect the driver’s airbag 4P connector (A) from the cable reel.
5. Connect the SRS inflator simulator (2 connectors) and simulator lead J to the cable reel.
Does the SRS indicator stay on, and is DT C 11-8xor 11-Ax indicated?
08/08/21 13:55:41 61SNR030_240_0052
ProCarManuals.com
DYNOMITE -2009-


µ
µ µ
µ
µ
µ
YES
NO
YES
NO
YES
NO
24-53
070AZ-SNAA100
07SAZ-TB4011A
A DASHBOARD WIRE HARNESS
4P CONNECTOR
070AZ-SNAA100
6. Reconnect the negative cable to the battery.
7. Clear the DTC memory.
8. Read the DTC (see page 24-22).Go to step 9.
Short to power in the driver’s airbag first or
second inflator; replace the driver’s airbag
(see page 24-188), then clear the DTC.
9. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait at least 3
minutes.
10. Remove the column cover (see page 17-9), then disconnect the dashboard wire harness 4P
connector (A) from the cable reel.
11. Connect the SRS inflator simulator (2 connectors) and the simulator lead to the
dashboard wire harness.
12. Reconnect the negative cable to the battery.
13. Clear the DTC memory. 14. Read the DTC.
Go to step 15.
Short to power in the cable reel; replace the
cable reel (see page 24-200), then clear the DTC.
15. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait at least 3
minutes.
16. Disconnect SRS unit connector A (28P) from the SRS unit (see step 9 on page 24-21).
17. Disconnect the SRS inflator simulator from the SRS simulator lead. Do not disconnect the simulator
lead from the dashboard wire harness 4P connector.
18. Reconnect the negative cable to the battery.
19. Turn the ignition switch to ON (II).
20. Measure the voltage between each terminal of the SRS simulator lead and body ground. There should
be less than 0.2 V.
Faulty SRS unit or poor connection at SRS
unit connector A (28P) and the SRS unit. Check the
connection between the connector and the SRS
unit. If the connection is OK, replace the SRS unit
(see page 24-203).
Short to power in the dashboard wire
harness; replace the dashboard wire harness, then
clear the DTC.
I s DT C 11-8x or 11-Ax i nd i cat ed ? I s DT C 11-8x or 11-Ax i nd i cat ed ?
Is the voltage as specif ied?
08/08/21 13:55:41 61SNR030_240_0053
ProCarManuals.com
DYNOMITE -2009-

Î
(#'
'

-)
µ
µ
DTC 11-9x (‘‘x’’ can be 0 thru 9 or A thru F):
DTC 11-Bx (‘‘x’’ can be 0 thru 9 or A thru F):
Special Tools Required
YES
NO
24-54SRS
DTC Troubleshooting (cont’d)
A
070AZ-SNAA100 07SAZ-TB4011A
Short to Ground in the Driver’s Airbag First
Inflator
Short to Ground in the Driver’s Airbag
Second Inflator
 SRS inflator simulator 07SAZ-TB4011A
 SRS simulator lead J 070AZ-SNAA100
NOTE: Before doing this troubleshooting procedure,
review SRS Precautions and Procedures (see page
24-13), General Troubleshooting Information (see page
24-22), and Battery Terminal Disconnection and
Reconnection (see page 22-68).
1. Clear the DTC memory (see page 24-23).
2. Turn the ignition switch to ON (II), and check that the SRS indicator comes on for about 6 seconds
and then goes off.
Go to step 3.
Intermittent failure, system is OK at this time.
Go to Troubleshooting Intermittent Failures
(see page 24-24). If another DTC is indicated,
troubleshoot the DTC. 3. Turn the ignition switch to LOCK (0). Disconnect the
negative cable from the battery, then wait at least 3
minutes.
4. Disconnect the driver’s airbag 4P connector (A) from the cable reel.
5. Connect the SRS inflator simulator (2 connectors) and simulator lead J to the cable reel.
Does the SRS indicator stay on, and is DT C 11-9xor 11-Bx indicated?
08/08/21 13:55:42 61SNR030_240_0054
ProCarManuals.com
DYNOMITE -2009-


µ
µ µ
µ
µ
µ
YES
NO
YES
NO
YES
NO
24-55
070AZ-SNAA100
07SAZ-TB4011A
A DASHBOARD WIRE HARNESS
4P CONNECTOR
070AZ-SNAA100
6. Reconnect the negative cable to the battery.
7. Clear the DTC memory.
8. Read the DTC (see page 24-22).Go to step 9.
Short to ground in the driver’s airbag first or
second inflator; replace the driver’s airbag
(see page 24-188), then clear the DTC.
9. Turn the ignition switch to LOCK (0). Disconnect the battery negative cable, then wait at least 3 minutes.
10. Remove the column cover (see page 17-9), then disconnect the dashboard wire harness 4P
connector (A) from the cable reel.
11. Connect the SRS inflator simulator (2 connectors) and the simulator lead to the
dashboard wire harness.
12. Reconnect the negative cable to the battery.
13. Clear the DTC memory. 14. Read the DTC.
Go to step 15.
Short to ground in the cable reel; replace the
cable reel (see page 24-200), then clear the DTC.
15. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait at least 3
minutes.
16. Disconnect SRS unit connector A (28P) from the SRS unit (see step 9 on page 24-21).
17. Disconnect the SRS inflator simulator from the SRS simulator lead. Do not disconnect the simulator
lead from the dashboard wire harness 4P connector.
18. Measure the resistance between each terminal of the SRS simulator lead and body ground. There
should be an open circuit or at least 1 M .
Faulty SRS unit or poor connection at SRS
unit connector A (28P) and the SRS unit. Check the
connection between the connector and the SRS
unit. If the connection is OK, replace the SRS unit
(see page 24-203).
Short to ground in the dashboard wire
harness; replace the dashboard wire harness, then
clear the DTC.
I s DT C 11-9x or 11-Bx i nd i cat ed ? I s DT C 11-9x or 11-Bx i nd i cat ed ?
Is the resistance as specif ied?
08/08/21 13:55:42 61SNR030_240_0055
ProCarManuals.com
DYNOMITE -2009-


(#'
'

-)
µ
µ
DTC 12-1x (‘‘x’’ can be 0 thru 9 or A thru F):
DTC 12-4x (‘‘x’’ can be 0 thru 9 or A thru F):
Special Tools Required
YES
NO
24-56SRS
DTC Troubleshooting (cont’d)
A
070AZ-SNAA100
07SAZ-TB4011A
Open in the Front Passenger’s Airbag First
Inflator
Open in the Front Passenger’s Airbag Second
Inflator
 SRS inflator simulator 07SAZ-TB4011A
 SRS simulator lead J 070AZ-SNAA100
NOTE: Before doing this troubleshooting procedure,
review SRS Precautions and Procedures (see page
24-13), General Troubleshooting Information (see page
24-22), and Battery Terminal Disconnection and
Reconnection (see page 22-68).
1. Clear the DTC memory (see page 24-23).
2. Turn the ignition switch to ON (II), and check that the SRS indicator comes on for about 6 seconds
and then goes off.
Go to step 3.
Intermittent failure, system is OK at this time.
Go to Troubleshooting Intermittent Failures
(see page 24-24). If another DTC is indicated,
troubleshoot the DTC. 3. Turn the ignition switch to LOCK (0). Disconnect the
negative cable from the battery, then wait at least 3
minutes.
4. Remove the lower glove box (see page 20-104), then disconnect the front passenger’s airbag 4P
connector (A) from dashboard wire harness.
5. Connect the SRS inflator simulator (2 connectors) and simulator lead J to the dashboard
wire harness.
Does the SRS indicator stay on, and is DT C 12-1xor 12-4x i nd i cat ed ?
08/08/21 13:55:42 61SNR030_240_0056
ProCarManuals.com
DYNOMITE -2009-


µ
µ
µ
µ
YES
NO
YES
NO
24-57
DASHBOARD WIRE HARNESS
4P CONNECTOR070AZ-SNAA100
6. Reconnect the negative cable to the battery.
7. Clear the DTC memory.
8. Read the DTC (see page 24-22).Go to step 9.
Open in the front passenger’s airbag first or
second inflator; replace the front passenger’s
airbag (see page 24-189), then clear the DTC.
9. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait at least 3
minutes.
10. Disconnect SRS unit connector A (28P) from the SRS unit (see step 9 on page 24-21).
11. Disconnect the SRS inflator simulator from the SRS simulator lead. Do not disconnect the simulator
lead from the dashboard wire harness 4P connector. 12. Measure the resistance between the terminals of
both SRS simulator leads. There should be less
than 1.0 .
Faulty SRS unit or poor connection at SRS
unit connector A (28P). Check the connection; if the
connection is OK, replace the SRS unit (see page
24-203).
Open in the dashboard wire harness; replace
the dashboard wire harness, then clear the DTC.
I s DT C 12-1x or 12-4x i nd i cat ed ?
Is the resistance as specif ied?
08/08/21 13:55:43 61SNR030_240_0057
ProCarManuals.com
DYNOMITE -2009-


(#'
'
-)
µ
µ µ
µ
DTC 12-3x (‘‘x’’ can be 0 thru 9 or A thru F):
DTC 12-6x (‘‘x’’ can be 0 thru 9 or A thru F):
Special Tools Required
YES
NO YES
NO
24-58SRS
DTC Troubleshooting (cont’d)
A
070AZ-SNAA100
07SAZ-TB4011A
Short to Another Wire or Decreased
Resistance in the Front Passenger’s Airbag
First Inflator
Short to Another Wire or Decreased
Resistance in the Front Passenger’s Airbag
Second Inflator
 SRS inflator simulator 07SAZ-TB4011A
 SRS simulator lead J 070AZ-SNAA100
 SRS short canceller 070AZ-SAA0100
NOTE: Before doing this troubleshooting procedure,
review SRS Precautions and Procedures (see page
24-13), General Troubleshooting Information (see page
24-22), and Battery Terminal Disconnection and
Reconnection (see page 22-68).
1. Clear the DTC memory (see page 24-23).
2. Turn the ignition switch to ON (II), and check that the SRS indicator comes on for about 6 seconds
and then goes off.
Go to step 3.
Intermittent failure, system is OK at this time.
Go to Troubleshooting Intermittent Failures
(see page 24-24). If another DTC is indicated,
troubleshoot the DTC.
3. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait at least 3
minutes. 4. Remove the lower glove box (see page 20-104),
then disconnect the front passenger’s airbag 4P
connector (A) from the dashboard wire harness.
5. Connect the SRS inflator simulator (2 connectors) and simulator lead J to dashboard wire
harness.
6. Reconnect the negative cable to the battery.
7. Clear the DTC memory.
8. Read the DTC (see page 24-22).
Go to step 9.
Short in the front passenger’s airbag first or
second inflator; replace the front passenger’s
airbag (see page 24-189), then clear the DTC.
9. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait at least 3
minutes.
10. Disconnect SRS unit connector A (28P) from the SRS unit (see step 9 on page 24-21).
11. Disconnect the SRS inflator simulator from the SRS simulator lead. Do not disconnect the simulator
lead from the dashboard wire harness 4P connector.
12. Connect the SRS short cancellers (070AZ-SAA0100) to the SRS unit connector A (28P) terminals No. 9
and No. 10 and No. 3 and terminals No. 3 and No. 4
(see page 24-18).
Does the SRS indicator stay on, and is DT C 12-3xor 12-6x i nd i cat ed ? I s DT C 12-3x or 12-6x i nd i cat ed ?
08/08/21 13:55:43 61SNR030_240_0058
ProCarManuals.com
DYNOMITE -2009-


(#'
'
-)

µ
µµ µ
YES
NO Special Tools Required
YES
NO
DTC 12-8x (‘‘x’’ can be 0 thru 9 or A thru F):
DTC 12-Ax (‘‘x’’ can be 0 thru 9 or A thru F):
24-5924-59
DASHBOARD WIRE HARNESS
4P CONNECTOR 070AZ-SNAA100
13. Measure the resistance between the terminals ofboth SRS simulator leads. There should be an open
circuitoratleast1M .
Faulty SRS unit or poor connection at SRS
unit connector A (28P) and the SRS unit. Check the
connection between the connector and the SRS
unit. If the connection is OK, replace the SRS unit
(see page 24-203).
Short in the dashboard wire harness; replace
the dashboard wire harness, then clear the DTC.  SRS inflator simulator 07SAZ-TB4011A
 SRS simulator lead J 070AZ-SNAA100
NOTE: Before doing this troubleshooting procedure,
review SRS Precautions and Procedures (see page
24-13), General Troubleshooting Information (see page
24-22), and Battery Terminal Disconnection and
Reconnection (see page 22-68).
1. Clear the DTC memory (see page 24-23).
2. Turn the ignition switch to ON (II), and check that the SRS indicator comes on for about 6 seconds
and then goes off.
Go to step 3.
Intermittent failure, system is OK at this time.
Go to Troubleshooting Intermittent Failures
(see page 24-24). If another DTC is indicated,
troubleshoot the DTC.
(cont’d)
Short to Power in the Front Passenger’s
Airbag First Inflator
Short to Power in the Front Passenger’s
Airbag Second Inflator
Is the resistance as specif ied? Does the SRS indicator stay on, and is DT C 12-8xor 12-Ax i nd i cat ed ?
08/08/21 13:55:43 61SNR030_240_0059
ProCarManuals.com
DYNOMITE -2009-



µ
µ µ
µ
YES
NO YES
NO
24-60SRS
DTC Troubleshooting (cont’d)
A
070AZ-SNAA100
07SAZ-TB4011A DASHBOARD WIRE HARNESS
4P CONNECTOR
070AZ-SNAA100
3. Turn the ignition switch to LOCK (0). Disconnect thenegative cable from the battery, then wait at least 3
minutes.
4. Remove the lower glove box (see page 20-104), then disconnect the front passenger’s airbag 4P
connector (A) from dashboard wire harness.
5. Connect the SRS inflator simulator (2 connectors) and simulator lead J to the dashboard
wire harness.
6. Reconnect the negative cable to the battery.
7. Clear the DTC memory.
8. Read the DTC (see page 24-22).
Go to step 9.
Short to power in the front passenger’s airbag
first or second inflator; replace the front passenger’s
airbag (see page 24-189), then clear the DTC.
9. Turn the ignition switch to LOCK (0). Disconnect the negative cable from the battery, then wait at least 3
minutes.
10. Disconnect SRS unit connector A (28P) from the SRS unit (see step 9 on page 24-21).
11. Disconnect the SRS inflator simulator from the SRS simulator lead. Do not disconnect the simulator
lead from the dashboard wire harness 4P connector. 12. Reconnect the negative cable to the battery.
13. Turn the ignition switch to ON (II).
14. Measure the voltage between each terminal of the
SRS simulator lead and body ground. There should
be less than 0.2 V.
Faulty SRS unit or poor connection at SRS
unit connector A (28P) and the SRS unit. Check the
connection between the connector and the SRS
unit. If the connection is OK, replace the SRS unit
(see page 24-203).
Short to power in the dashboard wire
harness; replace the dashboard wire harness, then
clear the DTC.
I s DT C 12-8x or 12-Ax i nd i cat ed ? Is the voltage as specif ied?
08/08/21 13:55:43 61SNR030_240_0060
ProCarManuals.com
DYNOMITE -2009-
