display CITROEN C-ELYSÉE 2016 Workshop Manual

04
202
C-elysee_en_Chap12a_RD5(RD45)_ed01-2016
AUDIO
Audio CD
Insert 12 cm diameter circular compact discs only.
Some   anti-pirating   systems,   on   original   discs   or   CDs   copied   using   a
personal

  recorder,   may   cause   faults   which   are   no   reflection   on   the
quality

  of   the   original   player.
Without
  pressing   the   EJECT button, insert a CD in the player, play
begins
  automatically.
To
  play   a   disc   which   has   already   been
inserted,

  press   the   SRC/TEL button
several
  times   in   succession   and
select

"CD".
Press one of the buttons to select a
track
  on   the   CD.
Playing a CD
Press LIST  to   display   the   list   of   tracks
on

  the   CD.
Press
  and   hold   one   of   the   buttons   for
fast

  forward   or   backward.

04
203
C-elysee_en_Chap12a_RD5(RD45)_ed01-2016
AUDIO
CD, USB
Information and adviceOn   a   single   disc,   the   CD   player   can   read   up   to   255   MP3   files   spread
over

  8   directory   levels.   However,   it   is   recommended   that   this   be   kept
to

  2   levels   so   as   to   limit   the   time   taken   to   access   and   play   the   CD.
During
  play,   the   folder   structure   is   not   observed.
In
  order   to   be   able   to   play   a   recorded   CDR   or   CDRW,   when   recording
it

  is   preferable   to   select   standards   ISO   9660   level   1.2   or   Joliet.
If
  the   disc   is   recorded   in   another   format,   it   may   not   be   played   correctly.
It
  is   recommended   that   the   same   recording   standard   is   always   used
for

  an   individual   disc,   with   as   low   a   speed   as   possible   (4x   maximum)
for

  optimum   sound   quality.
In
  the   particular   case   of   a   multi-session   CD,   the   Joliet   standard   is
recommended.
Do

  not   connect   a   hard   disk   or   USB   device   other   than   audio   players   to
the

  USB   port.
This
  may   cause   damage   to   your   installation.
The
  audio   system   will   only   play   files   with   extension   ".mp3"   or   ".wma"
and

  a   compression   rate   that   is   constant   or   variable   between   32   Kbps
and

  320   Kbps.
It
  is   advisable   to   restrict   file   names   to   20   characters   without   using
special

  characters   (e.g.   "   ?   ;   ù)   to   avoid   any   playing   or   displaying
problems.
The

  playlists   accepted   are   types   .m3u   and   .pls.
The
  number   of   files   is   limited   to   5   000   in   500   directories   on   a
maximum

  of   8   levels.

04
204
C-elysee_en_Chap12a_RD5(RD45)_ed01-2016
CD, USB
AUDIO
Playing a compilationInsert   an   MP3   compilation   in   the   CD   player
or

  connect   a   memory   stick   to   the   USB   port,
directly

  or   via   an   extension   lead.
The
  system   creates   playlists   (temporary   memory)   the   creation   time
for

  which   can   take   from   a   few   seconds   to   several   minutes.
The
  playlists   are   updated   every   time   the   ignition   is   switched   off   or   a
USB

  memory   stick   is   connected.
Play
  starts   automatically   after   a   period   which   depends   on   the
capacity

  of   the   USB   memory   stick.
Use
  only   USB   memory   sticks   formatted   FAT32   (File
Allocation

T
able).
At
  a   first   connection,   the   order   suggested   is   by   folder.
When

  connecting   again,   the   order   previously   chosen   is
retained.T

o   play   a   disc   or   memory   stick   which
has

  already   been   inserted,   press
SRC
/
TEL
  several   times   in   succession   and
select "

CD" or "USB". Turn
  the   control   knob   to   select   the   next
or

  previous   track.
Press one of the buttons to select the
next
  or   previous   folder   in   the   order
chosen.
Press

  and   hold   one   of   the   buttons   for
fast

  forwards   or   backwards.
Press LIST


to   display   the   menu   of
folders

  in   the   compilation.

04
BACK
205
C-elysee_en_Chap12a_RD5(RD45)_ed01-2016
Select a line in the list.
Select   a   track   or   a   folder.
Skip
  a   track.
Up
  a   level   in   the   menu.
AUDIO
USB memory stick - File classification
Having selected the desired classification
(" By folders", "By artists", "By genres",
"By playlists")
  press   the   control   knob.
Then
  press   the   control   knob   to   confirm   and
save

  the   modifications.
-

By folders
:   all   folders   containing   audio
files

  recognised   on   the   peripheral   device,
in

  alphabetical   order   without   following   the
folder

  structure.
-

By artists :

  all   of   the   artist   names   defined
in

  the   ID3
T
ags,   in   alphabetical   order.
-

By genres
:   all   of   the   genres   defined   in   the
ID3


T
ags.
-

By playlists
:   if   playlists   have   been   saved.
Make
  a   long   press   on
LIST or press
MENU
, select "Multimedia", then
"Media parameters "   and   finally   "
Choice
of track listing "   to   display   the   different
classifications.

04
VOL+
VOL-
207
C-elysee_en_Chap12a_RD5(RD45)_ed01-2016
AUDIO
Auxiliary socket (AUX)
Auxiliary JACK socket
Do  not   connect   a   device   to   the   USB   port   and   to   the   auxiliary   Jack
socket

  at   the   same   time.
The
  auxiliary   Jack   socket   permits   the   connection   of   a
portable

  non-mass   storage   device   or   an
Apple® player if
not

recognised

by

the

USB

port.
Connect

the

portable

device

to

the

auxiliary

Jack

socket

using   a
suitable


cable

(not

supplied). Press the
SRC/TEL
 button  several  times
in

  succession   and   select   "AUX".
First
  adjust   the   volume   on   your   portable   device.
Then
  adjust   the   volume   of   the   audio
system.
The

  display   and   management   of   controls   is   on   the
portable

  device.

04
208
C-elysee_en_Chap12a_RD5(RD45)_ed01-2016
AUDIO
Streaming - Playing audio files via
Bluetooth
Depending on the compatibility of the phonePair/connect   the   telephone:   see   the   "USING
THE

TELEPHONE"

  section.
Streaming
  allows   music   files   on   a   telephone   to   be   heard   via   the
vehicle's

  speakers.
The
  telephone   must   support   the   appropriate   bluetooth   profiles
(Profiles


A2DP
/
A
VRCP).
Activate
  the   streaming   source   by   pressing
SRC/TEL
.
Control
  of   playback   is   via   the   audio   system.
The

contextual

  information   can   be   displayed   in   the   screen.
In
  certain   cases,   playing   of   the   audio   files   must   be   initiated   from
the telephone.
The

  audio   quality   depends   on   the   quality   of   the   transmission   from
the

  telephone.
Play mode
The play modes available are:
-
Normal:
  the   tracks   are   played   in   order,   depending   on   the
classification

  of   the   selected   files.
-

Random:
  the   tracks   in   an   album   or   folder   are   played   in   a   random
order

.
-

Random
  all:   all   of   the   tracks   saved   in   the   media   are   played   in
random

  order.
-

Repeat:
  the   tracks   played   are   only   those   from   the   current   album
or

  folder. Press
  the   control   knob   for   access   to
the

  contextual   menu.
or
Press MENU.
Select "Multimedia"
  and   confirm.
Select "Media parameters "
  and
confirm.
Select "

Playback mode"   and   confirm.
Select
  the   desired   play   mode   then
press

  the   control   knob   to   confirm   and
save

  the   modifications.

05
209
C-elysee_en_Chap12a_RD5(RD45)_ed01-2016
USING THE TELEPHONE
Pairing a telephone
First connection
The services offered depend on the network, the SIM card and the compatibility of the Bluetooth telephone used.
Consult   your   telephone's   manual   and   your   operator   to   find   out   which   services   are   available   to   you.
Activate
  the   telephone's   Bluetooth   function   and
ensure that

it is "visible to all" (refer to the telephone
user
  guide). Press MENU. A


window   is   displayed   "Search in progress…".
Select
  the   telephone   to   be   connected
from

  the   list.   Only   one   telephone   can
be

  connected   at   a   time.
Select "Search for a device".
For
  safety   reasons   and   because   they   require   prolonged   attention   on   the   part   of   the   driver,   the   operations   for   pairing   of   the   Bluetooth   mobile
telephone

  with   the   Bluetooth   hands-free   system   of   your   audio   system   must   be   carried   out   with   the
vehicle stationary
  and   the   ignition   on.
Visit
  www.citroen.co.uk   for   more   information   (compatibility,   additional   help,   ...).
Select "Bluetooth connection "
  and
confirm.

05

210
C-elysee_en_Chap12a_RD5(RD45)_ed01-2016
USING THE TELEPHONE
A  virtual   keypad   is   displayed   on   the  screen:
  enter   a   code   of   at   least   4   digits
then

  press   the   control   knob   to   confirm.
A


message

is   displayed   on   the   screen   of   the
telephone:


enter   the   same   code   and   confirm. A


message   appears   in   the   screen   to   confirm   the   result   of   the
connection.
Pairing

  can   also   be   initiated   from   the   telephone   by   searching   for
detected

  Bluetooth   devices.
Accept
  the   connection   to   the   telephone.
If

pairing

fails,   try   again;   the   number   of   attempts   is   not   limited.The
  directory   and   the   calls   list   can   be   accessed   after   the
synchronisation

  period   (if   the   telephone   is   compatible).
Automatic
  connection   must   be   configured   in   the   telephone   to   allow
the

  connection   each   time   the   vehicle   is   started.
In

some

cases,   the   reference   number   of   the   telephone   or   the
Bluetooth


address   may   appear   instead   of   the   name   of   the   telephone.
Pair/connect   the   telephone   then   listen:   see   the
AUDIO
  section.
Streaming - Playing audio files via
Bluetooth

05
2 11
C-elysee_en_Chap12a_RD5(RD45)_ed01-2016
USING THE TELEPHONE
To see the telephone status,
press MENU.
Select "Telephone"
  and   confirm.
Select "Telephone management"
and
  confirm. Select "Telephone status"
  and   confirm.
Telephone status
The screen displays: the name of the telephone, the name of the network,  network   signal   strength,   confirmation   of   the   Bluetooth
connection

  and   the   streaming   connection.

05


212
C-elysee_en_Chap12a_RD5(RD45)_ed01-2016
USING THE TELEPHONE
The telephone connection automatically includes hands free operation and   audio   streaming.
The
  ability   of   the   system   to   connect   to   just   one   profile   depends   on   the
telephone.

  Both   profiles   may   connect   by   default.
Press MENU.
Select "Bluetooth connection "
  and
confirm. Indicates

  connection   of   the   audio   steaming   profile.
Managing connections
Select "Connections management"
and  confirm.  The   list   of   paired
telephones

  is   displayed. Select
  a   telephone   and   confirm.
Indicates   connection   of   the   hands-free   profile.
Then   select   and   confirm:
-
"
Connect telephone
"   /   "
Disconnect
telephone":   to   connect   /   disconnect
the

  telephone   or   the   hands-free
connection

  only.
-
"
Connect media player"   /
"

Disconnect media player":   to
connect

  /   disconnect   only   streaming.
-
"
Connect telephone + media
player"   /   "Disconnect telephone +
media player":   to   connect   /  disconnect
  the   telephone   (hands-free
and

  streaming).
-

"
Delete connection":   to   delete   the
pairing.
Indicates

  that   a   device   is   connected.
