DAEWOO NUBIRA 2004  Service Repair Manual AISIN AUTOMATIC TRANSAXLE  5A2 – 151
DAEWOO V–121 BL4
63.  Install the flange, 2 discs and 2 plates.
S  Install in order : F  D  P  D  P
(D = Disc, P = Plate, F = Flange)
64.  Install the 2nd

Page 1742 of 2643

DAEWOO NUBIRA 2004  Service Repair Manual 5A2 – 152IAISIN AUTOMATIC TRANSAXLE
DAEWOO V–121 BL4
68.  Using brake spring compressor bolt / nut
DW240–060–01 and 2nd brake adapter
DW240–080, compress the 2nd brake piston return
spring.

Page 1743 of 2643

DAEWOO NUBIRA 2004  Service Repair Manual AISIN AUTOMATIC TRANSAXLE  5A2 – 153
DAEWOO V–121 BL4
73.  Coat the thrust bearing race with petroleum jelly
and install it onto the rear planetary sun gear and
one–way clutch assembly.
S Bearig

Page 1744 of 2643

DAEWOO NUBIRA 2004  Service Repair Manual 5A2 – 154IAISIN AUTOMATIC TRANSAXLE
DAEWOO V–121 BL4
77.  Install the forward clutch hub to the transaxle case.
78.  Coat the thrust bearing race with petroleum jelly
and install it onto the forwa

Page 1745 of 2643

DAEWOO NUBIRA 2004  Service Repair Manual AISIN AUTOMATIC TRANSAXLE  5A2 – 155
DAEWOO V–121 BL4
81.  Check to see if the sliding surface of the disc, plate
and flange of 2nd coast & O/D brake are worn or
burnt. If necessary, replace them.

Page 1746 of 2643

DAEWOO NUBIRA 2004  Service Repair Manual 5A2 – 156IAISIN AUTOMATIC TRANSAXLE
DAEWOO V–121 BL4
86.  As shown in the illustration, place a straight edge
on the O/D brake piston and measure the distance
between the transaxle rear cover and

Page 1747 of 2643

DAEWOO NUBIRA 2004  Service Repair Manual AISIN AUTOMATIC TRANSAXLE  5A2 – 157
DAEWOO V–121 BL4
91.  Apply formed in place gasket (FIPG) to the trans-
axle rear cover.
FIPG: three bond 1281 or equivalent
Seal bend width: 1.2 mm (0.047 in.

Page 1748 of 2643

DAEWOO NUBIRA 2004  Service Repair Manual 5A2 – 158IAISIN AUTOMATIC TRANSAXLE
DAEWOO V–121 BL4
95.  Install the direct clutch hub to the transaxle case.
96.  Install the thrust bearing race and thrust needle roll-
er bearing to the transa

Page 1749 of 2643

DAEWOO NUBIRA 2004  Service Repair Manual AISIN AUTOMATIC TRANSAXLE  5A2 – 159
DAEWOO V–121 BL4
99.  Install the thrust needle roller bearing to the trans-
axle case.
Notice : Check the direction of the bearing.
100.  Place the oil pump t

Page 1750 of 2643

DAEWOO NUBIRA 2004  Service Repair Manual 5A2 – 160IAISIN AUTOMATIC TRANSAXLE
DAEWOO V–121 BL4
104.  Remove any packing material and be careful
not to get oil on the contacting surfaces of the
transaxle housing or transaxle case.
105.  Ap
