ADJUSTMENTS
1. Locate the access hole in the door to adjust the
door latch (1) and remove the mylar tape (2).
2. Loosen the adjustment screw (3).
3. Operate the door handles several times to reduce
any possible linkage binding and tighten the adjust-
mentscrewto3Nꞏm(30in.lbs.).
4. Operate the door handles again to verify proper
operation and reinstall the mylar tape.

LATCH STRIKER
REMOVAL
1. Using a grease pencil or equivalent, mark the loca-
tion of the door latch striker (1) on the B-pillar (2).
2. Remove the two bolts (3) that secure the door latch
striker to the B-pillar and remove the striker.
INSTALLATION
1. Position the door latch striker (1) onto the B-pillar
(2) and loosely install the two bolts (3).
2. Align the door latch striker to the B-pillar using the
reference marks made during the removal proce-
dure and tighten the bolts to 28 Nꞏm (21 ft. lbs.).
3. If necessary, adjust the door latch striker (Refer to
23 - BODY/DOOR - FRONT/LATCH STRIKER -
ADJUSTMENTS).

ADJUSTMENTS
1. Using a grease pencil or equivalent, mark the loca-
tion of the door latch striker (1) on the B-pillar (2)
to aid in adjustment.
2. Loosen the two bolts (3) that secure the door latch
striker to the B-pillar.
3. To adjust the rear gap and flush measurement,
change the position of the door latch striker and
then tighten the two bolts to 28 Nꞏm (21 ft. lbs.)
(Refer to 23 - BODY/BODY STRUCTURE/GAP
AND FLUSH - SPECIFICATIONS).
4. Verify correct door and latch position.

LOCK CYLINDER
REMOVAL
1. Remove the exterior door handle (1) (Refer to 23 -
BODY/DOOR - FRONT/EXTERIOR HANDLE -
REMOVAL).
2. Remove the clip (3) that secures the lock cylinder
lever (5) and the electric lock switch (4), if
equipped, to the door lock cylinder (6).
3. Remove the screw (2) that secures the door lock
cylinder to the exterior handle and remove the lock
cylinder.
INSTALLATION
1. Position the door lock cylinder (6) into the exterior
door handle (1).
2. Install the screw (2) that secures the door lock cyl-
inder to the exterior door handle. Tighten the screw
securely.
3. Install the electric lock switch (4), if equipped, and
the lock cylinder lever (5) to the door lock cylinder.
4. Install the clip (3) that secures the lock cylinder
lever and the electric lock switch, if equipped, to
the door lock cylinder.
5. Install the exterior door handle (Refer to 23 -
BODY/DOOR - FRONT/EXTERIOR HANDLE -
INSTALLATION).

TRIM PANEL
REMOVAL
1. Remove the screw (1) that secures the interior
door handle (2) to the interior door handle actuator
(3).
2. Remove the interior door handle from the interior
door handle actuator.
3. If equipped, remove the manual window crank (1)
using a window crank removal tool (2).
4. Remove the two screws (2) that secure the door
trim panel (3) to the two screw inserts (1).
5. Remove the two screws (4) that secure the door
trim panel to the bottom of the door.
CAUTION: The door trim panel is attached to the
door by molded plastic retaining clips that are
integral to the door trim panel. Do not pull the
door trim panel directly off of the door or damage
to the trim panel and/or the power switch assem-
bly will occur.
6. Lift the door trim panel straight upward to discon-
nect the molded plastic retaining clips (5) from the
door.
7. If equipped, disconnect the door wire harness from
the power door switch assembly and remove the
door trim panel.

INSTALLATION
1. If equipped, connect the door wire harness to the
power door switch assembly.
CAUTION: The door trim panel is attached to the
door by molded plastic retaining clips that are
integral to the door trim panel. Do not force the
door trim panel onto the door or damage to the
trim panel and/or the power switch assembly will
occur.
2. Position the door trim panel (3) and align the
molded plastic retaining clips (5) to the door.
3. Push the door trim panel straight downward until all
of the retaining clips are fully engaged to the door.
4. Install the two screws (2) that secure the door trim
panel to the two screw inserts (1).
5. Install the two screws (4) that secure the door trim
panel to the bottom of the door.
6. if equipped, install the manual window crank.
7. Position the interior door handle (2) onto the inte-
rior door handle actuator (3).
8. Install the screw (1) that secures the interior door
handle to the interior door handle actuator. Tighten
the screw securely.

WATERDAM
REMOVAL
1. Remove the interior door handle actuator (Refer to
23 - BODY/DOOR - FRONT/INTERIOR HANDLE
ACTUATOR - REMOVAL).
2. Remove the speaker (Refer to 8 - ELECTRICAL/
AUDIO/SPEAKER - REMOVAL).
CAUTION: Do not allow the waterdam adhesive to
become contaminated with dirt or other foreign
substances. If the waterdam becomes contami-
nated or damaged, replace it.
3. Carefully remove the waterdam (1) from around the
perimeter of the door (2).
4. Separate the waterdam from the interior handle
actuator rod and the door wire harness (if
equipped) and remove the waterdam.
INSTALLATION
CAUTION: Do not allow the waterdam or adhesive
to become contaminated with dirt or other foreign
substances. If the waterdam becomes contami-
nated or damaged, replace it.
NOTE: Be sure that the waterdam is fully sealed
around the perimeter of the door.
1. Position the interior handle actuator rod and the
wire harness (if equipped) through the holes in the
waterdam (1) and install the waterdam to the door
(2).
2. Install the speaker (Refer to 8 - ELECTRICAL/AU-
DIO/SPEAKER - INSTALLATION)
3. Install the interior door handle actuator (Refer to 23
- BODY/DOOR - FRONT/INTERIOR HANDLE
A C T U AT O R - I N S TA L L AT I O N ) .

WINDOW REGULATOR - POWER
REMOVAL
1. Remove the inner belt molding (Refer to 23 -
BODY/WEATHERSTRIP/SEALS/FRONT DOOR
INNER BELT WEATHERSTRIP - REMOVAL).
2. Remove the waterdam (Refer to 23 - BODY/DOOR
- FRONT/WATERDAM - REMOVAL).
3. Remove the electric window switch from the door
trim panel and connect it to the door wire harness
(Refer to 8 - ELECTRICAL/POWER WINDOWS/
POWER WINDOW SWITCH - REMOVAL).
4. Raisethedoorglasstothepositionshown.
5. Remove the two nuts (1) that secure the door glass
to the window regulator (2) through the two sight
windows (3 and 4) and disengage the door glass
from the regulator.
6. Position the door glass to the full up position and
secure the glass using a wooden wedge or an
equivalent.
7. Lower the window regulator (4) and remove the
two nuts (3) that secure the regulator stabilizer (1)
to the door (2).
8. Remove the bolt (5) that secures the window reg-
ulator to the door and loosen the other two regula-
tor bolts (7).
9. Slide the window regulator upward and disengage
the two regulator bolts from the door.
10. Remove the window regulator through the open-
ing in the door and disconnect the door wire har-
ness (6).

INSTALLATION
1. Connect the door wire harness (6) to the window
regulator (4) and install the regulator through the
opening in the door (2).
2. Engage the two regulator bolts (7) to the door.
3. Install the bolt (5) that secure the window regulator
to the door and tighten all three regulator bolts to
10 Nꞏm (89 in. lbs.).
4. Position the regulator stabilizer (1) into the door
and install the two nuts (3). Tighten the nuts to 10
Nꞏm (89 in. lbs.).
5. Raise the window regulator (2) to the position
shown.
6. Support the window glass and remove the wooden
wedge or equivalent.
7. Position the window glass to the window regulator
and install the two nuts (1) thought the two sight
windows (3 and 4). Tighten the nuts to 10 Nꞏm (89
in. lbs.).
8. Disconnect the electric window switch from the
door wire harness and reinstall the switch onto the
door trim panel (Refer to 8 - ELECTRICAL/POWER
WINDOWS/POWER WINDOW SWITCH - INSTAL-
LATION).
9. Install the waterdam (Refer to 23 - BODY/DOOR -
FRONT/WATERDAM - INSTALLATION).
10. Install the inner belt molding (Refer to 23 - BODY/
WEATHERSTRIP/SEALS/FRONT DOOR INNER
BELT WEATHERSTRIP - INSTALLATION).

WINDOW REGULATOR - MANUAL
REMOVAL
1. Remove the inner belt molding (Refer to 23 -
BODY/WEATHERSTRIP/SEALS/FRONT DOOR
INNER BELT WEATHERSTRIP - REMOVAL).
2. Remove the waterdam (Refer to 23 - BODY/DOOR
- FRONT/WATERDAM - REMOVAL).
3. Reinstall the manual window crank and raise the
door glass to the position shown.
4. Remove the two nuts (1) that secure the door glass
to the window regulator (2) through the two sight
windows (3 and 4) and disengage the door glass
from the regulator.
5. Position the door glass to the full up position and
secure the glass using a wooden wedge or an
equivalent.
6. Lower the window regulator (4) and remove the
two nuts (3) that secure the regulator stabilizer (1)
to the door (2).
7. Remove the two bolts (5) that secure the window
regulator to the door and loosen the other two reg-
ulator bolts (6).
8. Slide the window regulator upward and disengage
the two regulator bolts from the door.
9. Remove the window regulator through the opening
in the door.
