FIAT DUCATO BASE CAMPER 2018 Owner handbook (in English)

Versions3.0 140 Natural Power
Light / Maxi
Running on petrol(*)–90
Running on methaneLOW roof H1 159
MEDIUM roof H2 155
HIGH roof H3 153
(*) N2-category vehicles are limited to 90 km/h by type-approval requirements. M2-category vehicles are limited to 100 km/h by type-approval requirements.
239

WEIGHTS AND
LOADS
To identify the weights and loads for
your vehicle, refer to the plate shown in
fig. 228 and described in the
“Identification data plate” chapter or
refer to the vehicle registration
certificate showing the type-approved
weights (for markets, where provided)
EMaximum permitted weight of fully
laden vehicle (GVW).
FMaximum permitted weight of the
vehicle (GVW) fully laden plus trailer. If
there is no value in the field or if
there is a dash, it means that the
vehicle cannot tow
GMaximum permitted weight on first
axle (front).
HMaximum permitted weight on
second axle (rear).To calculate the towable weight with a
braked trailer, take the difference
between values F and E shown on the
plate.
E.g.: F=6000 kg - E=3500 kg
Braked trailer=2500 kg
IMPORTANTDo not exceed the given
trailer and towable weights.
IMPORTANTComply with the vehicle
towing capacities.
The tables show the towable weight for
engine version.
228F1A0245
240
TECHNICAL DATA

TOWABLE WEIGHTS (kg)
Key:
A= TOWABLE WEIGHT
B= UNBRAKED TRAILER
C= LOAD ON TOW HOOK
VERSION (GVW) ENGINE A B C
LIGHT2800 2.0 115 Multijet 2 2000 750 100
3000 (3150 / 3300 /
3500 / 3650)2.0 115 Multijet 2 2000 750 100
2.3 130 - 150 Multijet 2 / 180 Multijet 2
Power
2.3 130 Multijet 2 with AdBlue
2.3 150 ECOJET
3.0 140 Natural Power (excluding
Panorama)2500 750 100
MAXI (HEAVY)35002.3 130 - 150 Multijet 2 / 180 Multijet 2
Power
2.3 130 Multijet 2 with AdBlue
2.3 150 ECOJET
3.0 140 Natural Power3000
(*)750
120(*)
40052.3 130 - 150 Multijet 2 / 180 Multijet 2
Power
3.0 140 Natural Power2500 750 100
42502.3 130 - 150 Multijet 2 / 180 Multijet 2
Power
3.0 140 Natural Power2250 750 100
44002.3 150 Multijet 2 / 180 Multijet 2
Power2100 750 100
(*) For Special T.L. 2500 Kg (towable weight = 100 Kg)
241

NOTE The following vehicles are excluded from the table:
Key:
A= TOWABLE WEIGHT
C= LOAD ON TOW HOOK
ENGINE BODY VERSION GVW A C
ALLMINIBUS / BASE
MINIBUSALL 4005 / 4250 / 4300 - -
NOTE For vehicles with tow hook: the vertical static load on the tow hook must be within the maximum permitted weight
declared for the vehicle.
MAX (Maximum permitted weight + TOWABLE WEIGHT) = 6500 kg
242
TECHNICAL DATA

REFUELLING
2.0 115 Multijet 22.3 130 - 150
Multijet2-150
ECOJET2.3 130 Multijet
with AdBlue2.3 180 Multijet 2
PowerPrescribed fuels
and original
lubricants
Fuel tank (litres):
90(*)90(*)90(*)90(*)Diesel for motor
vehicles (EN590
Specification) Including a reserve of
(litres):10/12 10/12 10/12 10/12
UREA tank (litres)
(for versions
markets, where
provided)-
15
(**)15 -AdBlue (water-urea
solution) standard
DIN 70 070 and ISO
22241-1
207) 208)
(*) A 120 litre tank is available on request for all versions (with reserve of 12 litres). With the "Tempo Libero" option a 60 litre tank is available on request (with reserve
of 10 litres).
(**) Only for 150 ECOJET versions
243

2.0 115 Multijet 22.3 130 - 150
Multijet2-150
ECOJET2.3 130 Multijet
with AdBlue2.3 180 Multijet 2
PowerPrescribed fuels
and original
lubricants
Engine cooling
system (litres):8(***)9.6(***)9.6(***)9.6(***)
Mixture of distilled
water and PARAFLU
UPliquid at 50%(****)
Engine sump (litres): 4.5 5.7 5.7 5.7
SELENIA WR
FORWARD Engine sump and
filter (litres):5.3 6.3 6.3 6.3
Gearbox/differential
casing (litres):- 2.7 (MLGU gearbox) - -TUTELA
TRANSMISSION
EXPERYA
(***) With Webasto: + 1/4 litre - Underseat heating 600cc: + 1 litre - Underseat heating 900cc: + 1.5 litres - Underseat heating + Webasto: + 1.25 litres - Underseat
heating + Webasto: +1.75 litres
(****) When the vehicle is used in particularly harsh weather conditions, we recommend using a 60-40 mixture of PARAFLU
UPand demineralised water.
244
TECHNICAL DATA

2.0 115 Multijet 22.3 130 - 150
Multijet2-150
ECOJET2.3 130 Multijet
with AdBlue2.3 180 Multijet 2
PowerPrescribed fuels
and original
lubricants
Gearbox/differential
casing (litres):2.9 2.9 (M38 gearbox) 2.9 2.9TUTELA
TRANSMISSION
GEARTECH
COMFORT-MATIC
transmission
hydraulic actuation
system (litres):0.7 0.7 0.7 0.7TUTELA CAR CS
SPEED
Hydraulic braking
circuit with ABS (kg):0.6 0.6 0.6 0.6
TUTELA TOP 4
TUTELA TOP4/S Hydraulic braking
circuit with ASR/ESC
(kg)0.62 0.62 0.62 0.62
Hydraulic power
steering:1.5 1.5 1.5 1.5TUTELA
TRANSMISSION
GI/E (red)
TUTELA
TRANSMISSION
GI/R (green)
(*)
Windscreen/
headlight washer
reservoir:5.5 5.5 5.5 5.5Mixture of water and
liquid PETRONAS
DURANCE SC 35
(*) On SCR ECOJET versions for cold countries
245

3.0 140 Natural Power Prescribed fuels and original lubricants
Fuel tank (litres):Petrol: 14.5
Methane (kg): 36(§) (°°)Petrol with an octane number (RON) no lower
than 95 (EN228 specification)
Automotive methane and bio-methane
(EN16723 specification) Including a reserve of (litres): Petrol: 8
Engine cooling system:
10
(***)Mixture of distilled water and PARAFLUUP
liquid at 50%(****)
Engine sump (litres): 8
SELENIA MULTIPOWER GAS 5W-40
Engine sump and filter (litres): 9
Gearbox/differential casing (litres): 2.9 TUTELA TRANSMISSION GEARTECH
COMFORT-MATIC transmission hydraulic
actuation system (litres):0.7 TUTELA CAR CS SPEED
Clutch hydraulic activation system (litres): 0,050 TUTELA TOP4
Hydraulic braking circuit with ASR/ESC (kg) 0.62TUTELA TOP 4
TUTELA TOP4/S
Hydraulic power steering: 1.5 TUTELA TRANSMISSION GI/E (red)
(§) Range on Methane: 400 km
(°°) The amount of methane depends on the outside temperature, the supply pressure, the quality of the gas and the type of refuelling system. The total volume of
the cylinders is about 220 litres (218.5 nominal) for all versions.
(***) With Webasto: + 1/4 litre - Underseat heating 600cc: + 1 litre - Underseat heating 900cc: + 1.5 litres - Underseat heating + Webasto: + 1.25 litres - Underseat
heating + Webasto: +1.75 litres
(****) When the vehicle is used in particularly harsh weather conditions, we recommend using a 60-40 mixture of PARAFLU
UPand demineralised water.
IMPORTANT Note that when using a fuel like methane, the range is extremely variable because in addition to the vehicle
maintenance and driving conditions it also depends on the temperature of the gas in the cylinder. The methane actually heats
up during the refuelling and cools down whilst driving, undergoing variations in pressure that reduce the quantity that can
be used.
246
TECHNICAL DATA

WARNING
207)Use AdBlue only according to DIN 70 070 and ISO 22241-1. Other fluids may cause damage to the system: also exhaust emissions
would no longer comply with the law.
208)The distribution companies are responsible for the compliance of their product. Observe the precautions of storage and maintenance, in
order to preserve the initial qualities. The manufacturer of the vehicle does not recognize any guarantee in case of malfunctions and damage
caused to the vehicle due to the use of urea (AdBlue) not in accordance with regulations.
247

FLUIDS AND LUBRICANTS
Your vehicle is equipped with an engine oil that has been thoroughly developed and tested in order to meet the
requirements of the Service Schedule. Constant use of the prescribed lubricants guarantees the fuel consumption
and emission specifications. Lubricant quality is crucial for engine operation and duration.
61)
PRODUCT SPECIFICATIONS
Use Features SpecificationOriginal fluids and
lubricantsReplacement interval
Diesel engine lubricantsSAE 0W-30ACEA C29.55535-DS1SELENIA WR
FORWARD
Contractual Technical
Reference N° F842.F13According to Service
Schedule
Lubricants for petrol/
methane enginesSAE 5W-40ACEA C39.55535-T2SELENIA MULTIPOWER
GAS 5W-40
Contractual Technical
Reference N° F922.E09According to Service
Schedule
If lubricants conforming to the required specification are not available, products that meet the indicated specifications can be
used to top up; in this case optimal performance of the engine is not guaranteed.
WARNING
61)The use of products with different specifications than those indicated above could cause damage to the engine not covered by the
warranty.
248
