FIAT DUCATO BASE CAMPER 2018 Owner handbook (in English)

Use Features SpecificationOriginal fluids and
lubricantsApplications
Lubricants and greases
for drive transmissionSAE 75W grade synthetic
lubricant9.55550 - MZ2TUTELA
TRANSMISSION
EXPERYA
Contractual Technical
Reference N° F002.F13Mechanical transmission
and differential (MLGU
transmission)
Synthetic base lubricant
SAE 75W-85 grade9.55550-MZ3 or
MS.90030-M2TUTELA
TRANSMISSION
GEARTECH
Contractual Technical
Reference N° F704.C08Manual gearbox and
differential
Special oil with "ATF
DEXRON III" type additive-TUTELA CAR CS
SPEEDCOMFORT-MATIC
transmission hydraulic
actuator system
Molybdenum disulphide
grease, for use at high
temperatures.
Consistency NLGI 1-29.55580 - GRAS IITUTELA ALL STAR
Contractual Technical
Reference N° F702.G07Wheel side constant
velocity joints
Grease for constant
velocity joints with low
friction coefficient.
Consistency NLGI 0-19.55580 - GRAS IITUTELA STAR 700
Contractual Technical
Reference N° F701.C07Differential side constant
velocity joints
Lubricant for power
steering. Exceeds "ATF
DEXRON III" specifications9.55550-AG2TUTELA
TRANSMISSION GI/E
Contractual Technical
Reference N° F001.C94Hydraulic power steering
Lubricant for power
steering. "ISO VG 2" – "2F
TE_ML 02K"9.55550-AG3TUTELA
TRANSMISSION GI/R
Contractual Technical
Reference N° F428.HD4Electro-Hydraulic Power
Steering
Brake fluidSynthetic fluid for brake
and clutch systems.
Exceeds specifications:
FMVSS n° 116 DOT 4,
ISO 4925, SAE J 1704.9.55597 or MS.90039TUTELA TOP 4
Contractual Technical
Reference N° F001.A93
or
TUTELA TOP4/S
Contractual Technical
Reference N° F005.F15Hydraulic brakes and
hydraulic clutch controls
249

Use Features SpecificationOriginal fluids and
lubricantsApplications
Protective agent for
radiatorsRed protective with
antifreeze action, based
on inhibited monoethyl
glycol with organic
formula. Exceeds CUNA
NC 956-16, ASTM D
3306 specifications.9.55523 or MS.90032PARAFLUUP
Contractual Technical
Reference N° F101.M01Cooling circuits. Use rate
50% up to -35°C. Mixture
with different formulation
products not allowed.
(*)
Diesel fuel additiveAdditive for diesel
antifreeze, protecting
diesel engines.-PETRONAS DURANCE
DIESEL ART
Contractual Technical
Reference N° F601.L06To be mixed with diesel
(25 cc per 10 litres)
Additive for diesel
emissions (UREA)Water-urea solutionDIN 70 070 and ISO
22241-1AdBlueTo be used for filling the
tank UREA on vehicles
equipped with system of
Selective Catalytic
Reduction (SCR).
Windscreen washer fluidMixture of spirits and
surfactants. Exceeds the
CUNA NC 956-II
specification9.55522 or MS.90043PETRONAS DURANCE
SC 35
Contractual Technical
Reference N° F001.D16To be used diluted or
undiluted in windscreen
washer/wiper systems
(*) When the vehicle is used in particularly harsh weather conditions, we recommend using a mixture of 60%PARAFLUUPand 40% demineralised water.
250
TECHNICAL DATA

FUEL CONSUMPTION
The fuel consumption figures given in the tables below are determined on the basis of the type-approval tests laid down by
specific European Directives.
These consumption values refer to basic vehicles without optionals.
The following procedures are used to measure the fuel consumption:
urban cycle: begins with cold starting, followed by driving simulating the use of the vehicle in town;
extra-urban cycle: driving that simulates using the vehicle out of town with frequent acceleration in all gears; the speed
varies from 0 to 120 km/h;
combined consumption: calculated with a weighting of approximately 37% of the urban cycle and 63% of the extra-urban
cycle.
IMPORTANT The type of route, traffic situations, weather conditions, driving style, general conditions of the vehicle, trim
level/equipment/accessories, climate control system, vehicle load, roof rack, other situations that affect aerodynamics or air
drag may lead to different fuel consumption levels than those measured.
IMPORTANT It should also be pointed out that whilst the vehicle is being run in (up to around 3000 km) the fuel consumption
may be higher than the figures given.
Fuel consumption (according to the current European Directive - litres/100 km)
2.0 115 Multijet 2
VersionF.C.(*)Consumption
Urban Extra-urban Combined
Light / Tempo Libero 1700 6.1 5.3 5.6
Light / Tempo Libero 1810 6.3 5.5 5.8
Light / Tempo Libero 1930 6.3 5.7 5.9
Light / Tempo Libero 2040 6.6 5.9 6.2
Light / Tempo Libero 2150 6.7 6.1 6.3
(*) Flywheel class
251

2.3 150 ECOJET
VersionF.C.(*)Consumption
Urban Extra-urban Combined
Light 1700 5.6 5.2 5.3
Maxi 1700 5.8 5.2 5.4
Tempo Libero 1700 5.8 5.2 5.4
Light 1810 5.9 5.3 5.5
Maxi 1810 6.1 5.3 5.6
Tempo Libero 1810 6.1 5.3 5.6
Light 1930 6.3 5.4 5.7
Maxi 1930 6.4 5.5 5.8
Tempo Libero 1930 6.4 5.5 5.8
Light 2040 6.5 5.6 5.9
Maxi 2040 6.7 5.6 6.0
Tempo Libero 2040 6.7 5.6 6.0
Light 2150 6.8 5.7 6.1
Maxi 2150 7.0 5.7 6.2
Tempo Libero 2150 7.0 5.7 6.2
Light
-
Maxi
-
Tempo Libero2270 (I) 7.2 5.8 6.3
2270 (II) 7.2 5.9 6.4
2270 (III) 7.2 5.9 6.4
Light M1 2040 6.0 5.2 5.5
Light M1 2150 6.2 5.2 5.6
(*) Flywheel class
252
TECHNICAL DATA

VersionF.C.(*)Consumption
Urban Extra-urban Combined
Maxi M1 2150 6.3 5.2 5.6
Light M1 2270 (I) 6.6 5.3 5.8
Maxi M1 2270 (I) 6.6 5.3 5.8
(*) Flywheel class
253

2.3 130 Multijet 2
VersionF.C.(*)Consumption
Urban Extra-urban Combined
Light 1700 5.6 5.2 5.3
Maxi 1700 5.8 5.2 5.4
Tempo Libero 1700 5.8 5.2 5.4
Light 1810 5.9 5.3 5.5
Maxi 1810 6.1 5.3 5.6
Tempo Libero 1810 6.1 5.3 5.6
Light 1930 6.3 5.4 5.7
Maxi 1930 6.4 5.5 5.8
Tempo Libero 1930 6.4 5.5 5.8
Light 2040 6.5 5.6 5.9
Maxi 2040 6.7 5.6 6.0
Tempo Libero 2040 6.7 5.6 6.0
Light 2150 6.8 5.7 6.1
Maxi 2150 7.0 5.7 6.2
Tempo Libero 2150 7.0 5.7 6.2
Light
-
Maxi
-
Tempo Libero2270 (I) 7.2 5.8 6.3
(*) Flywheel class
254
TECHNICAL DATA

2.3 130 Multijet 2 with Adblue
VersionF.C.(*)Consumption
Urban Extra-urban Combined
Light 2040 6.9 5.4 6.0
Light 2150 7.0 5.5 6.1
Maxi 2150 7.2 5.5 6.1
Light 2270 7.2 5.7 6.3
Maxi 2270 7.6 5.8 6.5
(*) Flywheel class
255

2.3 150 Multijet 2 / 180 Multijet 2 Power
VersionF.C.(*)Consumption
Urban Extra-urban Combined
Light 1700 6.3 5.4 5.7
Maxi 1700 6.4 5.4 5.8
Tempo Libero 1700 6.4 5.4 5.8
Light 1810 6.5 5.5 5.9
Maxi 1810 6.7 5.5 5.9
Tempo Libero 1810 6.7 5.5 5.9
Light 1930 6.9 5.6 6.1
Maxi 1930 7.0 5.7 6.2
Tempo Libero 1930 7.0 5.7 6.2
Light 2040 7.1 5.8 6.3
Maxi 2040 7.3 5.8 6.4
Tempo Libero 2040 7.3 5.8 6.4
Light 2150 7.4 5.9 6.5
Maxi 2150 7.7 5.9 6.6
Tempo Libero 2150 7.7 5.9 6.6
Light
-
Maxi
-
Tempo Libero2270 (I) 7.8 6.0 6.7
2270 (II) 7.9 6.0 6.7
2270 (III) 7.9 6.0 6.7
(*) Flywheel class
256
TECHNICAL DATA

3.0 140 Natural Power
Consumption according to the current European directive
VersionF.C.(*)Methane (m3x100 km)Methane (kg/100 km)(**)
Urban Extra-urban Combined Urban Extra-urban Combined
Light –
16.3 11.2 13.1 10.6 7.3 8.6 Maxi –
Tempo Libero –
(*) Flywheel class
(**) Consumption in kg x 100 km according to molecular weight calculation
257

CO2EMISSIONS
The CO2emission figures in the table below refer to combined fuel consumption.
These emission values refer to basic vehicles without optionals.
CO
2emissions (according to the European Directive in force g/100 km)
2.0 115 Multijet 2
Version
F.C.(*)CO2emissions
Combined
Light / Tempo libero 1700 147
Light / Tempo libero 1810 152
Light / Tempo libero 1930 152
Light / Tempo libero 2040 162
Light / Tempo libero 2150 167
(*) Flywheel class
258
