FIAT FULLBACK 2017 Owner handbook (in English)

TYRES AND WHEELS
Tyre size
Tyres205R16C 8PR 110/108R 245/70R16 111S RF 245/65R17 111S
WheelSize16x6J, 16x6JJ 16x7J, 16x7JJ 17x7 1/2J
Offset38 mm
NOTE Contact a Fiat Dealership for details on the combination used on your vehicle.
289

REFILL CAPACITIES
A— RHD vehicles
No. Quantity Lubricants
1Engine coolant
(Includes 0.65 litre in the reserve tank)7.7 litresPARAFLU UPContractual Technical Reference
N° F101.M01 (1)
2 Brake fluid As requiredDOT4
TUTELA TOP 4/SContractual Technical Reference
N° F005.F15
478VANODIESEL3231EM
290
TECHNICAL SPECIFICATIONS

No. Quantity Lubricants
3 Clutch fluid As requiredDOT4
TUTELA TOP 4/SContractual Technical Reference
N° F005.F15
4 Engine oilOil pan 8.0 litres
SELENIA MULTIPOWER C3Contractual Technical
Reference N° F129.F11 Oil filter 0.3 litres
Oil cooler 0.1 litres
5 Power Steering As requiredTUTELA GI/ZContractual Technical Reference
N°F001.A16
6 Washer fluid 4.2 litresPETRONAS DURANCE SC 35Contractual Technical
Reference N° F001.D16
Automatic Transmission fluid 10.9 litresTUTELA TRANSMISSION GI/PAContractual Technical
Reference N°F001.A16
Manual transmission oil 5M/T
(1)2.2 litresTUTELA TRANSMISSION GEARSYNTH Z3
Contractual Technical Reference N°F001.A16
Manual transmission oil 6M/T
(1)TUTELA TRANSMISSION GEARSYNTH Z4
Contractual Technical Reference N°F002.A16
Transfer oilSuper select 4WD II 1.34 litresfor 5M/T:TUTELA TRANSMISSION GEARSYNTH Z3
Contractual Technical Reference N°F001.A16
for 6M/T, A/T:TUTELA TRANSMISSION GEARSYNTH
Z4Contractual Technical Reference N°F002.A16 Easy select 4WD 1.15 litres
Differential oil2WD 2.3 litresTUTELA TRANSMISSION AXLE ZContractual
Technical Reference N°F002.A16
4WDFront 1.2 litres
TUTELA TRANSMISSION AXLE Z-LSContractual
Technical Reference N°F003.A16
Rear 2.3 litres
(1) If so equipped
291

No. Quantity Lubricants
Refrigerant (Air
conditioning)Amount 0.52 kg
HFC-134a(2)Co2equivalent0.743 t
GWP 1,430
(2) Contains fluorinated greenhouse gases
NOTE For the Automatic transmission fluid, use only the Fiat Genuine products. Use of a different fluid could damage the
transmission.
No. Quantity Lubricants
Manual transmission oil 2.2 litresTUTELA TRANSMISSION GEARSYNTH Z3
Contractual Technical Reference N°F001.A16
Transfer oilSuper select 4WD II 1.34 litresfor 5M/T:TUTELA TRANSMISSION GEARSYNTH Z3
Contractual Technical Reference N°F001.A16
for 6M/T, A/T:TUTELA TRANSMISSION GEARSYNTH
Z4Contractual Technical Reference N°F002.A16 Easy select 4WD 1.15 litres
Differential oil2WD 2.3 litresTUTELA TRANSMISSION AXLE ZContractual
Technical Reference N°F002.A16
4WDFront 1.2 litres
TUTELA TRANSMISSION AXLE Z-LSContractual
Technical Reference N°F003.A16
Rear 2.3 litres
Refrigerant (Air
conditioning)Amount 0.52 kg
HFC-134a
(2)Co2equivalent0.743 t
GWP 1,430
(2) Contains fluorinated greenhouse gases
292
TECHNICAL SPECIFICATIONS

FLUIDS AND LUBRICANTS
Product specifications
Your vehicle is equipped with an engine oil that has been thoroughly developed and tested in order to meet the requirements of
the Scheduled Servicing Plan.
Constant use of the prescribed lubricants guarantees the fuel consumption and emission specifications. Lubricant quality is
crucial for engine operation and duration.
Lubricant Characteristics SpecificationOriginal Fluids and
LubricantsReplacement interval
Engine oil
With DPF
Without DPFSAE 5W-30
ACEA C39.55535-S3
or MS-11106SELENIA MULTIPOWER
C3
Contractual Technical
Reference N° F129.F11According to Scheduled
Servicing Plan
If lubricants compliant with the required specifications are not available, products that comply with the minimum required
characteristics can be used for topping up; in this case optimal performance of the engine is not guaranteed.
229)
293

Lubricant Characteristics SpecificationOriginal Fluids and
LubricantsApplication
Lubricants and greases
fordrive transmissionSynthetic lubricant ATF 9.55550-AV 6TUTELA TRANSMISSION
GI/PA
Contractual Technical
Reference N°F001.A16Automatic transmission
fluid
Synthetic lubricant SAE
75W-80 API GL-39.55550-MZ 9TUTELA TRANSMISSION
GEARSYNTH Z3
Contractual Technical
Reference N°F001.A16Manual transmission and
transfer oil for 5M/T
Synthetic lubricant SAE
75W-80 API GL-49.55550-MZ 10TUTELA TRANSMISSION
GEARSYNTH Z4
Contractual Technical
Reference N°F002.A16Manual transmission and
transfer oil for 6M/T
Synthetic lubricant SAE
75W-80 API GL-49.55550-MZ 10TUTELA TRANSMISSION
GEARSYNTH Z4
Contractual Technical
Reference N°F002.A16Transfer oil for A/T
Synthetic lubricant SAE
80 API GL-59.55550-DA 12TUTELA TRANSMISSION
AXLE Z
Contractual Technical
Reference N°F002.A16Differential oil for 2WD
and 4WD without multi
plate type LSD
Synthetic lubricant SAE
80 API GL-59.55550-DA 13TUTELA TRANSMISSION
AXLE Z-LS
Contractual Technical
Reference N°F003.A16Differential oil for 4WD
with multi plate type LSD
Brake fluid
Clutch fluidDOT 49.55597
or MS.90039TUTELA TOP 4/S
Contractual Technical
Reference N° F005.F15Hydraulic brakes and
hydraulic clutch controls
Power Steering Synthetic lubricant ATF 9.55550-AG 4TUTELA GI/Z
Contractual Technical
Reference N°F001.A16
294
TECHNICAL SPECIFICATIONS

Lubricant Characteristics SpecificationOriginal Fluids and
LubricantsApplication
Protective agent for
radiatorsCUNANC 956-16
ASTM D 33069.55523
or MS.90032PARAFLU UPContractual
Technical Reference
N° F101.M01
(1)Engine Coolant
Washer fluidMixture of spirits and
surfactants. Exceeds
CUNA NC 956-11
specifications.9.55522
or MS-90043PETRONAS DURANCE SC
35
Contractual Technical
Reference N° F001.D16To be used diluted or
undiluted in screen
washer/wiper systems
(1) The product used for initial filling and PARAFLU UP can be fully mixed, even though the colours may differ. PARAFLU UP may be used for topping up amounts of
up to 1 litre. Over this amount we recommend completely changing the coolant in the percentages given.
IMPORTANT
229)The use of products with specifications different than those indicated above could cause damage to the engine that is not covered by
the warranty.
295

FUEL CONSUMPTION / CO2EMISSION
COMBINED USE
Euro 5 engine Transmission CO2 (g/km)Fuel consumption
(L/100km)
2WD Hi-RiderWith Start&Stop 6M/T 166 6.3
Without Start&Stop 5A/T 185 7.0
4WDWith Start&Stop 6M/T 169 6.4
Without Start&Stop6M/T173
188
(*)192(**)
6.6
7.1(*),7.3(**)
5A/T189
197(*),203(**)
7.2
7.5(*),7.7(**)
(*) Vehicles for Russia
(**)Vehicles for Ukraina
296
TECHNICAL SPECIFICATIONS

COMBINED USE
Euro 6 engine Transmission CO2 (g/km)Fuel consumption
(L/100km)
2WD Hi-RiderWith Start&Stop 6M/T177
166(*)6.7
6.3(*)
Without Start&Stop 5A/T192
185(*)7.3
7.0(*)
4WDWith Start&Stop 6M/T180
169
(*)6.9
6.4(*)
Without Start&Stop6M/T186
188
(**)191(***)173(*)
7.1
7.1(**)7.2(***)6.6(*)
5A/T196
197(**)201(***)189(*)
7.5
7.5(**)7.6(***)7.2(*)
(*) Vehicles for Turkey
(**) Vehicles for Russia
(***) Vehicles for Ukraine
NOTE: The results given do not express or imply any guarantee of the fuel consumption of the particular vehicle. The vehicle
itself has not been tested and there are inevitably differences between individual vehicles of the same model. In addition, this
vehicle may incorporate particular modifications.
