FLUIDS AND LUBRICANTS
RECOMMENDED PRODUCTS AND THEIR SPECIFICATIONS
250
SAFETY
DEVICES
CORRECT USE
OF THE CAR
WARNING
LIGHTS AND
MESSAGES
CAR
MAINTENANCE
INDEX
DASHBOARD
AND CONTROLS
IN AN
EMERGENCY
TECHNICAL
SPECIFICATIONS
Original fluids and
lubricants
SELENIA 20K Fluid and lubricant specifications
for correct car operation
Synthetic-based engine oils grade SAE 10W-40
that pass ACEA A3 and API SL specifications.
Lubricants
for diesel
engines
For regular operation of Multijet versions with DPF, use only original oil. In an emergency (lacking the original product) only top up with max. 0,5
l and then drive immediately to the nearest Fiat Dealership.
If using non original SAE 5W-40 products, oils with minimum ACEA A3 specifications for petrol engines and ACEA B4 specifications for Diesel
engines are admitted; in this event top engine performance is not guaranteed.
Use of products with low-quality properties than ACEA A3 and ACEA B4 could cause damages to the engine that are not covered by the war-
ranty.
For very cold climate conditions, ask Fiat Dealership for the appropriate Seleniaproduct to use. Synthetic-based engine oils grade SAE 5W-40
that pass ACEA B4, API CF and FIAT 9.55535-M2specifica-
tions.SELENIA WR Lubricants
for petrol
enginesChange
According to Service
Schedule
According to Service
Schedule Use
