WARNING
6)Detergents pollute the environment.
Only wash your vehicle in areas equipped
to collect and treat wastewater from this
type of activity.
INTERIOR
175) 176)
SEATS AND FABRIC
PARTS
Remove dust with a soft brush or a
vacuum cleaner.
Rub the seats with a sponge moistened
with a solution of water and neutral
detergent.
WARNING To avoid ruining the
upholstery, do not use acetone, acetic
alcohol, denatured ethyl alcohol or
any highly aggressive solvents or
detergents to clean the fabric parts.
Use spotting agents such as isopropyl
alcohol or dry stain removers.
WARNING
175)Never use flammable products, such
as petrol ether or rectified petrol to clean
the inside of the car. The electrostatic
charges which are generated by rubbing
during the cleaning operation may cause a
fire.
176)Do not keep aerosol cans in the
vehicle: they might explode. Aerosol cans
must not be exposed to a temperature
exceeding 50°C. When the vehicle is
exposed to sunlight, the internal
temperature can greatly exceed this value.
149

TECHNICAL DATA
Everything you may find useful for
understanding how your car is made
and works is contained in this chapter
and illustrated with data, tables and
graphics. For the enthusiasts and the
technician, but also just for those who
want to know every detail of their
car.IDENTIFICATION DATA....................151
ENGINE ..........................................152
WHEELS .........................................156
DIMENSIONS ..................................165
WEIGHTS........................................168
REFUELLING ..................................175
FLUIDS AND LUBRICANTS ............177
PERFORMANCE .............................180
FUEL CONSUMPTION ....................181
CO2 EMISSIONS ...........................183
PRESCRIPTIONS FOR HANDLING
THE VEHICLE AT THE END OF ITS
LIFE ................................................185
150
TECHNICAL DATA

IDENTIFICATION
DATA
VEHICLE IDENTIFICATION
NUMBER (VIN) PLATE
Depending on the version, the plate fig.
134 may be located to the right or at
the centre of the luggage compartment
(lift the carpet covering to access it),
or on the driver-side door compartment
(open the driver door to access it). It
bears the following data:
AName of Manufacturer
BType-approval number.
CVehicle type identification code.
DChassis serial number.
EMaximum permitted weight of vehicle
fully laden.
FMaximum permitted weight of vehicle
fully laden plus trailer.
GMaximum permitted weight on first
axle (front).
HMaximum permitted weight on
second axle (rear).
IEngine type.
LBodywork version code.
MSpare part number.
NCorrect value of smoke coefficient
(for diesel engines).
BODYWORK PAINT
IDENTIFICATION PLATE
This is applied inside the bonnet (left
side) and bears the following data
fig. 135:
APaint manufacturer.
BColour name.
CFiat colour code.
DRespray and touch up code.CHASSIS MARKING
This is located on the right side of the
boot rear floor and gives the following
identification data:
type of vehicle;
chassis serial number.
ENGINE MARKING
It is stamped on the cylinder block and
includes the type and the engine serial
number.
134F1D1007
135F1D0128
151

ENGINE
Versions 1.2 8V 69 HP 1.2 8V 69 HP LPG
Engine code 169A4000 169A4000
Cycle Otto Otto
Number and position of cylinders 4 in line 4 in line
Piston bore and stroke (mm) 70.8 × 78.86 70.8 × 78.86
Total displacement (cm³) 1242 1242
Compression ratio 11.1: 1 11.1: 1
LPG Petrol
Maximum power (EC) (kW) 51 51 51
Maximum power (EEC) (HP) 69 69 69
corresponding engine speed (rpm) 5500 5500 5500
Maximum torque (EC) (Nm) 102 102 102
Maximum torque (EC) (kgm) 10.4 10.4 10.4
corresponding engine speed (rpm) 3000 3000 3000
Spark plugsNGK ZKR7A-10 or
CHAMPION RA8MCX4NGK ZKR7AI-8
FuelUnleaded petrol 95 R.O.N.
(EN 228 specifications)LPG for motor vehicles
(EN589 Specification)Unleaded petrol 95 R.O.N.
(EN 228 specifications)
152
TECHNICAL DATA

Versions
0.9 TwinAir 60 HP(*)0.9 TwinAir 65 HP0.9 TwinAir Turbo 80 HP(*)
Engine code 312A6000 312A4000 312A5000
Cycle Otto Otto Otto
Number and position of cylinders 2 in line 2 in line 2 in line
Piston bore and stroke (mm) 83.5 × 88 83.5 × 88 80.5 × 86
Total displacement (cm³) 964 964 875
Compression ratio 11.1: 1 11.1: 1 10: 1
Maximum power (EC) (kW) 44 48 59
Maximum power (EEC) (HP) 60 65 80
corresponding engine speed (rpm) 6250 6250 5500
Maximum torque (EC) (Nm) 88 88 145
Maximum torque (EC) (kgm) 8.9 8.9 14.8
corresponding engine speed (rpm) 3500 3500 1900
Spark plugs NGK T20182U NGK LKR7DI-12 NGK PLKR9C8
FuelUnleaded petrol 95 R.O.N.
(EN 228 specifications)Unleaded petrol 95 R.O.N.
(EN 228 specifications)Unleaded petrol 95 R.O.N.
(EN 228 specifications)
(*) For versions/markets, where provided
153

Versions 0.9 TwinAir Turbo 85 HP 0.9 TwinAir Turbo Natural Power
Engine code 312A2000 312A2000
Cycle Otto Otto
Number and position of cylinders 2 in line 2 in line
Piston bore and stroke (mm) 80.5 × 86.0 80.5 × 86.0
Total displacement (cm³) 875 875
Compression ratio 10: 1 10: 1
Methane Petrol
Maximum power (EC) (kW)
62.5 / 57
(*)59 62.5
Maximum power (EEC) (HP)
85 / 77.5
(*)80 85
corresponding engine speed (rpm) 5500 5500 5500
Maximum torque (EC) (Nm)
145 / 100
(*)140 145
Maximum torque (EC) (kgm)
14.8 / 10.2
(*)14.3 14.8
corresponding engine speed (rpm)
1900 / 2000
(*)2500 1900
Spark plugs NGK ILKR9G8 NGK ILKR9G8
FuelUnleaded petrol 95 R.O.N.
(EN 228 specifications)Methane for motor vehiclesUnleaded petrol 95 R.O.N.
(EN 228 specifications)
(*) With ECO button pressed
154
TECHNICAL DATA

Versions0.9 TwinAir Turbo 90 HP(*)1.3 16V Multijet 95 HP 1.3 16V MultiJet 80 HP
Engine code 312A7000
312B1000 / 330A1000(°)312B2000 / 225A2000(°°)
Cycle Otto Diesel Diesel
Number and position of cylinders 2 in line 4 in line 4 in line
Piston bore and stroke (mm) 80.5 × 86.0 69.6 × 82 69.6 × 82
Total displacement (cm³) 875 1248 1248
Compression ratio 10: 1 16.8: 1 16.8: 1
Maximum power (EC) (kW)
66.2 / 57
(**)70 59
Maximum power (EEC) (HP)
90 / 77.5
(**)95 80
corresponding engine speed (rpm) 5500 3750 3750
Maximum torque (EC) (Nm)
145 / 100
(**)200 200
Maximum torque (EC) (kgm)
14.8 / 10.2
(**)20.4 20.4
corresponding engine speed (rpm)
1900 / 2000
(**)1500 1500
Spark plugs NGK ILKR9G8 - -
FuelUnleaded petrol 95 R.O.N.
(EN 228 specifications)Diesel for motor vehicles
(EN590 Specification)Diesel for motor vehicles
(EN590 Specification)
(*) For versions/markets, where provided
(°) 4x4 and Cross Versions
(°°) 4x4 versions (**) With ECO button pressed
155

WHEELS
177) 178) 179)
Alloy or pressed steel rims. Tubeless
radial carcass tyres.
All approved tyres are listed in the
Registration Document.
IMPORTANT If there are any
discrepancies between the Owner
Handbook and the Registration
Document, take the information from
the latter. For safe driving, the car must
be fitted with tyres of the same make
and type on all wheels.
IMPORTANT Do not use inner tubes
with Tubeless tyres.
The M+S tyres provided with the
vehicle (on versions where provided) are
characterised by the 3PMSF (3 Peak
Mountain Snow Flake) marking
.
This marking certifies that the tyre has
passed the specific approval test
required by European Community
Regulation ECE 117, which ensures
better performance on snow than
a "simple" M+S.SNOW CHAINS
180) 181) 182)70)
Important notes
The use of snow chains should be in
compliance with local regulations of
each country. In certain countries, tyres
marked with code M+S (Mud and
Snow) are considered as winter
equipment; therefore their use is
equivalent to that of the snow chains.
The snow chains may be applied only
to the front wheel tyres.
Check the tension of the snow chains
after the first few metres have been
driven.
Using snow chains with tyres with
non-original dimensions may damage
the vehicle.
Using different size or type (M+S, etc.)
tyres between front and rear axle may
adversely affect car driveability, with the
risk of losing control of the car and
resulting accidents.
Snow chains cannot be fitted to the
space-saver wheel (for versions/
markets, where provided). If a front tyre
is punctured, replace a rear wheel
with the space-saver wheel and move
the rear wheel to the front axle. In
this way, with two normal drive wheels
at the front, snow chains can be fitted.
156
TECHNICAL DATA

RIMS AND TYRES PROVIDED
Panda versions
Versions Wheels Tyres provided Winter tyresSpace saver spare
wheel(*)
0.9 TwinAir 60 HP(*)5.5J x 14H2 - ET35
175/65 R14 82T(**)175/65 R14 82Q (M+S) 135/80 R14 84M
0.9 TwinAir 65 HP5.5J x 14H2 - ET35
175/65 R14 82T
(**)175/65 R14 82Q (M+S) 135/80 R14 84M
5.5J x 14H2 - ET35175/65 R14 82T
Goodyear Duragrip
(**)
(***)175/65 R14 82Q (M+S) 135/80 R14 84M
6J x 15H2 - ET35
(****)185/55 R15 82T(°)185/55 R15 82Q (M+S) 135/80 R14 84M
0.9 TwinAir 80 HP
(*)5.5J x 14H2 - ET35
175/65 R14 82T(**)175/65 R14 82Q (M+S) 135/80 R14 84M
0.9 TwinAir Turbo 85
HP5.5J x 14H2 - ET35
175/65 R14 82T
(**)175/65 R14 82Q (M+S) 135/80 R14 84M
5.5J x 14H2 - ET35175/65 R14 82T
Goodyear Duragrip
(**)
(***)175/65 R14 82Q (M+S) 135/80 R14 84M
6J x 15H2 - ET35
(****)185/55 R15 82T(°)185/55 R15 82Q (M+S) 135/80 R14 84M
(*) For versions/markets, where provided.
(**) The tyre can be fitted with size 9 mm snow chains.
(***) For versions/markets, where provided. Tyres offering equivalent performance can be used as an alternative.
(****) Alloy wheel rim.
(°) Not suitable for chains.
157

Versions Wheels Tyres provided Winter tyresSpace saver spare
wheel(*)
0.9 TwinAir Turbo
Natural Power6Jx15H2-ET35(****)175/65 R15 84T(°°°)175/65 R15 84Q (M+S) -
1.2 8V 69 HP5.5J x 14H2 - ET35
175/65 R14 82T
(**)175/65 R14 82Q (M+S) 135/80 R14 84M
6J x 15H2 - ET35
(****)185/55 R15 82T(°)185/55 R15 82Q (M+S) 135/80 R14 84M
1.2 8V 69 HP S&S5.5J x 14H2 - ET35 175/65 R14 82T 175/65 R14 84Q (M+S)135/80 R14 84P
135/80 R14 80P
reinforced
135/80 R14 84M 6J x 15H2 - ET35 185/55 R15 82T 185/55 R15 82Q (M+S)
1.3 16V MultiJet5.5J x 14H2 - ET35
175/65 R14 82T
(**)175/65 R14 82Q (M+S) 135/80 R14 84M
6J x 15H2 - ET35 185/55 R15 82H 185/55 R15 82Q (M+S) 135/80 R14 84M
(*) For versions/markets, where provided.
(****) Alloy wheel rim.
(°°°) Tyre to which chains can be fitted, with reduced size chains: 7 mm. (**) The tyre can be fitted with size 9 mm snow chains.
(°) Not suitable for chains.
158
